Changing the Position or Appearance of the Print

The following features can be changed and applied to modify the
quality or position of the print image:
• Print position
• Print orientation
• Darkness of the print image
• Print delay (intermittent mode applications only)
• Print speed (intermittent mode applications only)
• Printhead print position (continuous mode applications only)
• Interleaved printing
The print settings can be viewed and changed through the printhead
setup page by touching the Tools, Setup and Printhead buttons.
Figure 4-12 shows the printhead setup page for printers that have been
installed to work on an intermittent motion packaging machine (prints
only when the target material is stationary).
Figure 4-12: Printhead Setup Page for Intermittent Motion Applications
Figure 4-13 on page 4-15 shows the printhead setup page for printers
that have been installed to work on a continuous motion packaging
machine (prints while the target material is moving).
