Summary of Contents for movistar AW4062
- Page 1 Router ADSL Freedom in a box Installation guide...
-
Page 3: Package Contents
This guide details about the start up process for your Internet connection. You will be able to enjoy your connection in an easy, simple and quick way. Please follow the guide instructions step by step. Package contents (3) Three ADSL microfilters (1) Wireless router (2) Power adapter (6) Ethernet cable (category 5... -
Page 4: Power Adapter Connection
Start using your ADSL... 1. Microfilters installation 2. Telephone line connection Connect the grey telephony line cable (5) Connect a microfilter between each tele- to the free outlet (without microfilter) of phony device (telephones, faxes…) and the the multiple adapter (4) and to the ADSL telephone socket. - Page 5 Status of internet connection. (green) The routers provided by Movistar are optimised so that they can establish the connec- tion with Internet without any need for installations or configurations. For further information please refer to sections 3.4 of the user’s manual on the advanced settings CD...
- Page 6 Start using your ADSL... 5. Connecting the computer to the router. Two options are available You may either connect your computer to the router using an Ethernet cable if they are sufficiently close to each other or by means of a wireless network. Furthermore, you can simultaneously have certain items of equipment connected to the router using the Ether- net cable and others as portable through the wireless network.
- Page 7 If you are equipped with an external wireless device (PCMCIA or USB adap- ETHERNET WLAN CONEXIÓN INTERNET ter), install it with the aid of the CD that is provided with it. If you have a wireless device that is already integrated into your equipment, make sure that it is enabled with the aid of your operating system.
- Page 8 Connection using Windows wireless Search the available wireless networks. client You can update this list with the button When configuring your wireless device in “Refresh network list” or by clicking the Windows XP SP2, Vista or Windows 7 you button can use the wireless client management application.
- Page 9 Enter the security key that appears on the Check to make sure that the wireless net- router label. work connection icon for the system tray indicates that the connection has been correctly established. IMPORTANT. The wireless security key for the router is of the WPA/PSK type and its format is alphanumerical.
- Page 10 B. Connection using Ethernet cable Connect the yellow Ethernet cable (6) to the Ethernet card on the PC and to one of the router’s connectors labelled as ETHERNET 1 to 4 ETHERNET ADSL DC 15V-800mA RESET ETHERNET ADSL DC 15V-800mA RESET Switch the PC on.
- Page 11 Activate your free e-mail accounts and your website with the Internet access service contracted. Once you have accessed www.movistar.es, you can activate your mail account. After ty- ping in the initial identificador (user) and contraseña (password) provided in the letter with...
- Page 12 Advanced settings CD The CD is not required to set up your ADSL connection. On the CD you will be able to find further help in response to any needs that might arise regarding your ADSL Internet con- nection. Ayuda Conexión: Graphic help which will guide you along the whole start up procedure to connect to the Internet and the advanced configu-...
- Page 13 Solution to frequent problems Problema Causa Solución Verify that a microfilter has been installed between each tele- The connection drops if No microfilter has been installed phony device (telephones, faxes…) and services which use the I pick up the phone. between the phone device and phone line (alarms, etc.) and the phone socket (see step 1 in the the phone socket.
- Page 14 Solution to frequent problems Problema Causa Solución Your wireless client is not Make sure that your wireless client is correctly installed and I do not have an icon for correctly installed, set up or enabled. More information is contained in the manual for the the wireless client.
-
Page 15: Customer Care
The customer care service is available via telephone as well as via Internet. For further information, please refer to chapter 6 in the user’s manual. All the information about ADSL can be found in the “Internet” section at movistar.es: www.movistar.es/adsl... -
Page 16: Additional Information
• Business care center (900 12 09 00) All offenders will be penalised or otherwise Where you will be attended by our consul- punished by Law. tants or, if you prefere, visit Movistar web page: Cardboard boxes, the plastic part of the www.movistar.es... - Page 17 ...
- Page 18 An application that detects and removes Fixed / Dynamic IP addressing: any computer virus and other malicious programs. It indicates how Movistar assigns the IP address to your line. If every time that DHCP (Dynamic Host Configuration your router starts a session it can be...
- Page 19 Glosario Socket: Wireless client: A plug that is usually installed on the wall that enables the telephone cable to be A hardware or software element that is connected. used to connect to a network of compu- ters without any kind of cable being used SSID (Service Set Identifier): for the purpose.
- Page 20 For getting further information: 1004 +34 699 991 004 Your Movistar shop www.movistar.es Equipment supplied by: C.I.F.: B-83488676 REI-RAEE Code: 000334 Version 1.0...
