4. Connecting with a target device

Figure 4-1:
IDC10 JTAG
connector
For connection with a target device mikroProg
connector, as shown on Figure 4-1. In order to make proper
connection with the target board it is necessary to pay attention
uses IDC10 to IDC10 connector pinout. Every pin has a different purpose and
™
for easy orientation IDC10 connector is marked with a little knob
and incision between pins number 9 and 7, Figure 5-1.
