commtech wireless Mercury Wall Pager User Manual

Mercury 8-line wall pager
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Asia Pacific
PO Box 1037
OPDC 6916
PERTH, Western Australia
Phone:
+61 8 6240 0000
Fax:
+61 8 6240 0001
Mercury Wall Pager

User Manual

(Manual Revision 4.30)
Email
sales@commtechwireless.com
Web
www.commtechwireless.com
Americas
8301 Cypress Plaza Drive, Suite 105
JACKSONVILLE, FL 32256-4416
Phone: +1 904 281 0073
Fax:
+1 904 281 0074
EMEA
Vindingaard Rinvej 1
DK-7100 Vejle
DENMARK
Phone:
+45 8226 7280
Fax:
+45 8226 7289

Advertisement

Table of Contents
loading

Related Manuals for commtech wireless Mercury Wall Pager

Summary of Contents for commtech wireless Mercury Wall Pager

  • Page 1: User Manual

    Mercury Wall Pager User Manual (Manual Revision 4.30) Email sales@commtechwireless.com www.commtechwireless.com Asia Pacific Americas EMEA PO Box 1037 8301 Cypress Plaza Drive, Suite 105 Vindingaard Rinvej 1 OPDC 6916 JACKSONVILLE, FL 32256-4416 DK-7100 Vejle PERTH, Western Australia Phone: +1 904 281 0073...
  • Page 2 In the event of notification within the warranty period of defects in material or workmanship, Commtech Wireless will replace the defective diskettes, documentation and electronic circuitry.

  • Page 3: Table Of Contents

    Manual Mercury 8-line Wall Pager Table of Contents ABOUT THE 8-LINE MERCURY ......................4 Features ............................4 About This Handbook ........................4 THE MERCURY 8-LINE PAGER ......................5 Getting Started ..........................5 2.1.1 Case Layout ......................... 5 2.1.2 LCD Screen ......................... 5 2.1.3 LED’s ..........................

  • Page 4: About The 8-Line Mercury

    Mercury 8-Line Wall Pager Manual ABOUT THE 8-LINE MERCURY Features The Mercury 8-line wall pager is a useful device for a multitude of applications. It can be used as a mass warning device for natural disasters, critical warnings and other important information.

  • Page 5: The Mercury 8-Line

    Manual Mercury 8-line Wall Pager THE MERCURY 8-LINE PAGER Getting Started 2.1.1 Case Layout The Mercury 8-Line pager has four buttons on its case. --- Up Key --- Down Key --- Menu Key --- Read Key 2.1.2 LCD Screen The Mercury 8-Line Wall Pager contains a backlit, 8-Line, alphanumeric LCD screen. Each line is 21 characters long.

  • Page 6: Power Socket

    Mercury 8-Line Wall Pager Manual 2.1.5 Power Socket The unit contains in internal rechargeable battery. This internal battery is charged via a mains plug-pack. (Output is 5volts DC unregulated.) The plug-pack connects into the socket shown below. The pinouts for this connector are as follows: Socket on unit ©...

  • Page 7: Mercury 8-Line Pager Installation

    Manual Mercury 8-line Wall Pager MERCURY 8-LINE PAGER INSTALLATION Follow these instructions to install and setup your Mercury Wall Pager. 1. Ensure the unit has been programmed correctly to suit the installation. (see the programming manual) 2. Screw on the hi-gain antenna onto the side of the unit and ensure it points upwards.

  • Page 8: Mercury 8-Line Pager Operation

    Mercury 8-Line Wall Pager Manual MERCURY 8-LINE PAGER OPERATION To turn the unit on, press and hold the Read Key , until the unit beeps and the screen displays the Start-up message. To save power, the LCD screen turns off a few seconds of inactivity. When a message is received, the pager will alert and the message will be displayed on the unit.

  • Page 9: Appendix

    Further Help and Support Contact your Place of Purchase A Commtech Wireless Authorized Distributor or Dealer sets up most systems. Contact your place of purchase with inquiries beyond the scope of this manual. This Product is Not Field Serviceable Should a fault develop with the hardware or software, contact your place of purchase for the most appropriate form of action.

  • Page 10: Specifications

    Mercury 8-Line Wall Pager Manual Specifications Note: Specifications subject to change to any notice Electrical Specification Rx Frequency ................135-175, 276-284, 406-478, 925-932 Technical Specification Code Format ..........................POCSAG Bit Rate ........................512/1200/2400bps Number of Cap codes ..........................6 Channel Space Receiver: ..................... 12.5/25KHz Modulation Method ........................
