Summary of Contents for HumanTechnik Swing

  • Page 1 Connevans.info Solutions to improve the quality of life This product may be purchased from Connevans Limited DeafEquipment.co.uk secure online store at www.DeafEquipment.co.uk...
  • Page 2 Seite 4 Bedienungsanleitung Page 24 Operating instruction Page 44 Manuel de service Pagina 64 Gebruiksaanwijzing Página 84 Instrucciones de servicio Pagina 104 Istruzioni per l‘uso...
  • Page 4 23 24 25 26 27...

  • Page 5: Table Of Contents

    Connect sender to the USB connector Connect sender to the mains supply Install sender Use Swing IR Use SWING IR standard version Use SWING IR LR Safety lock in the tele-loop Listening with the 3.5 mm stereo output Set balance...

  • Page 6: Safety Information

    3. If you use other medical devices, please use the SWING only by adhering to the safety information/safety directives of your physician or the manu- facturer.

  • Page 7: Scope Of Delivery

    Safety information for the lithium polymer battery The battery used in SWING is a lithium polymer battery, which was produced in accordance with the most current provisions and safety regulations. The battery can be damaged when misused or if not used according to the speci- fications, in this case Humantechnik accepts no liability.

  • Page 8: Quick Overview

    Quick overview These operating instructions let you fold the first 2 pages out. These pages show images of the SWING with identification by numbers. Overview headphone: 1 controller for volume 2 loud speaker ear adapters 3 battery compartment 4 status LED...

  • Page 9: Connect Sender To A Sound Source

    Plug the provided audio connection cable 28 into the green “Audio” female connector 26 of the sender. Several options exist to connect the SWING IR to a sound source (e.g. TV, computer, etc.). Please check the connection options of your sound source.

  • Page 10: Connect Sender To A Cinch Female Connector

    Connect sender to a Cinch female connector AUDIO AUDIO OUT AUDIO Connect the adapter cable with the Cinch plugs 29 to the audio connection cable 28. Plug the Cinch plug into the Cinch connection of your sound source. Please ensure that the white connection is connected to the white connection of your sound source.

  • Page 11: Connect Sender Headphone Connector

    Connect sender headphone connector AUDIO AUDIO PHONE Plug the audio connection cable 28 into the headphone connection of your sound source. You may need the 6.5 mm headphone plug adapter for the connection of the headphone to your sound source. Set the volume of your sound source to an average volume.

  • Page 12: Connect Sender To The Usb Connector

    Connect sender to the USB connector AUDIO AUDIO The USB cable 33 is not included in the scope of supply. It can be purchased from your specialty retailer. The sender has a mini USB connection. Plug the USB cable into the “USB” connection 24 of the sender and connect it to your computer.

  • Page 13: Install Sender

    Install sender Install the sender in a suitable position near the sound source. The view bet- ween the sender and the receiver must not be impeded. The infrared recepti- on diodes at the receiver must always be directed at the infrared transmission diodes of the sender.

  • Page 14: Use Swing Ir

    Use Swing IR Use SWING IR standard version Please follow the instruction to use your SWING IR: 1. Switch your sound source on (e.g. TV). 2. Adjust the volume level controller 1 initially to a low volume to protect your ears.

  • Page 15: Safety Lock In The Tele-Loop

    Safety lock in the tele-loop (only for LR version) Please ensure that the safety lock is completely closed in the tele-loop to guarantee a flawless functioning. Please ensure the receiver is worn correctly. Listening with the 3.5 mm stereo output (only for LR version) The following accessories can be connected to the 3.5 mm stereo jack plug: • Earphones discreet design...

  • Page 16: Set Balance

    The audio control is used to adapt the audio to your ear independently on the left and right. Caution: The sound controller for right (R) can be used in the SWING digital LR to adjust the sound in the ring loop.

  • Page 17: Set Volume

    Set volume Set the volume to a level agreeable to you by adjusting the volume control. Transparent cover The transparent cover protects the volume control against unintended adjust- ment of the volume control and against contamination by dust or fluids. Remove both rubber covers and click the transparent cover into the openings.

  • Page 18: Charge Battery

    Charge battery Once the battery is fully charged, it can be used for up to 6 hours. The red LED 4/13 starts flashing once the battery is almost empty. The battery should now be charged or exchanged. The operating time is dependent from the set volume and from what you hear.

  • Page 19: Cleaning And Care

    Cleaning and care Clean transmitter and receiver If the devices are dusty or dirty, please clean them now and then with a soft, clean and slightly moist cloth. Please disconnect the sender from the mains supply before you start with the cleaning activity.

  • Page 20: Important Information

    Open fire sources such as burning candles, must also not be put on the device. Warranty The Swing has a high operating safety. Please contact your specialty retailer or contact the manufacturer directly in case that failures occur despite proper assembly and operation. The warranty service includes the free repair as well as the free return shipment.

  • Page 21: Environmental Information/Disposal

    – 2004/108/EG EMV directive – 2006/95/EG low voltage directive The conformity of the a.m. directives is confirmed by the CE mark on the device. CE conformity declarations are available on the Internet under www.humantechnik.com. Subject to technical changes English 40...

  • Page 22: Failure Cause And Resolution

    Failure cause and resolution Symptoms Cause Resolution Charge control lamps Sender has no electric- Check whether the do not illuminate – de- ity from power supply. power supply is con- spite inserted battery nected to the electrical into the charge station outlet of the house and of the sender.
  • Page 23 The device is operated Use our SWING digital. together with a plasma TV set. Plasma TV sets interfere with the infrared transmission. The energy of the bat-...

  • Page 24: Technical Data

    Technical Data Modulation process Stereo Carrier frequency: 2.3MHz / 2.8 MHz Tone frequency transmission range: 50 – 16,000 Hz Distortion factor: < 1 % Signal/interference ratio: > 100 dB Working range: 10° C – 40° C Chin band receiver: Operating hours: app.
  • Page 25 Im Wörth 25 Fax: +49 (0) 76 21/ 9 56 89-70 Germany D-79576 Weil am Rhein E-mail: info@humantechnik.com Humantechnik GHL AG Tel.: +41 (0) 61/ 6 93 22 60 Rastatterstrasse 9 Fax: +41 (0) 61/ 6 93 22 61 Switzerland CH-4057 Basel E-mail: info@humantechnik.com...
