  • Page 1 OPERATING GUIDE PLEASE READ THIS ENTIRE GUIDE BEFORE BEGINNING...
  • Page 2 IMPORTANT SAFETY INFORMATION EXPLANATION OF ATTENTION WORDS AND SYMBOLS USED IN THIS GUIDE This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 3 • If the condition persists beyond 48 hours, see your veterinarian. For additional information on bed sores and pressure necrosis, please visit the Support section for Remote Trainers at www.sportdog.com. These steps will help keep your dog safe and comfortable. Millions of dogs are comfortable while they wear stainless steel contacts.

  • Page 4: Table Of Contents

    To get the most protection out of your warranty, please register your product within 30 days at www.sportdog.com. By registering and keeping your receipt you will enjoy the product’s full warranty and, should you ever need to call the Customer Care Centre, we will be able to help you faster.

  • Page 5: Components

    HOW THE SYSTEM WORKS The SportDOG® Brand TEK Series 2.0 Systems have been proven safe, comfortable, and effective for all dogs over 3.6 kg. Consistent, correct use of this product allows you to track your dog, reinforce commands, and correct misbehaviour from up to 16 km line of sight.

  • Page 6: Key Definitions

    KEY DEFINITIONS HANDHELD DEVICE: Receives and displays location updates from the GPS Collar. It sends the radio signal to the E-Collar Module. It is waterproof and can be submerged in water to a depth of 1.5 m. ON/OFF BUTTON: Pressing and releasing this button will cause the unit to vibrate and the Start-up Screen will display.
  • Page 7 GPS COLLAR: Receives location from GPS and GLONASS constellations and transmits location updates to the Handheld Device. It is waterproof and can be submerged in water to a depth of 7.6 m. ON/OFF BUTTON: Pressing this button and releasing when the GPS Indicator Light comes on will turn the unit on.

  • Page 8: Icon Definitions

    ICON DEFINITIONS The following icons are used throughout the TEK Series 2.0 software interface. ICON FUNCTION GENERAL ICONS TIME INDICATOR: Displays the current local time. BATTERY GAUGE: Displays the battery charge status. UP / DOWN INDICATORS: Indicate menu choices available. Use the arrow pad keys to view additional menu items.
  • Page 9 Available only with the TEK-V2LT system. For the TEK-V2L system, purchase the TEK-2T TRAINING ICONS E-Collar Module accessory to add E-Collar functionality to a GPS Collar. CONTINUOUS STATIC STIMULATION: You control both when and how long static stimulation is delivered, up to a maximum of 10 seconds. After 10 seconds, the static stimulation will “time out”...

  • Page 10: Operate The Tek Series 2.0 Handheld Device

    OPERATE THE TEK SERIES 2.0 HANDHELD DEVICE The following terms are used throughout this Operating Guide: Select: Use the Up/Down/Left/Right Arrow Keys to scroll through and highlight menu items or areas of the screen. A selected item is highlighted in orange. Home: The main screen that displays the icons.

  • Page 11: Prepare The Gps Collar/E-Collar Module

    TO CHARGE THE GPS COLLAR/E-COLLAR MODULE 1. Attach the supplied Charge Cradle so that the SportDOG® Brand logo on the Charge Cradle covers the SportDOG® Brand logo on the GPS Collar. 2. Connect the appropriate charger connector to the charging jack.
  • Page 12 GPS COLLAR INDICATOR LIGHT OPERATIONAL MODE LIGHT COLOUR LIGHT FUNCTION BATTERY STATUS SPEAKER FUNCTION Unit is turned on via Green Light is solid in Good Beeps 1-5 times On/Off Button colour during depending on beep sequence GPS Code Unit is turned off via Light is solid in On/Off Button colour during...
  • Page 13 ABOUT RECHARGEABLE BATTERIES • The Handheld Device and GPS Collar contain Lithium-Ion (Li-Ion) batteries; never incinerate, puncture, deform, short-circuit, or charge with an inappropriate charger. Fire, explosion, property damage, or bodily harm may occur if this warning is not followed. •...

  • Page 14: Convert A Gps Collar To A Gps Collar With E-Collar Module

    CONVERT A GPS COLLAR TO A GPS COLLAR WITH E-COLLAR MODULE 1. Remove the outer screws from the Location-Only Module with a 3/32 Allen wrench (A). 2. Separate the Location-Only Module from the GPS Collar’s front housing (B). 3. Thoroughly clean inside the front housing with a soft towel, removing any debris.

  • Page 15: Fit The Gps Collar Or Gps Collar With E-Collar Module

    FIT THE GPS COLLAR OR GPS COLLAR WITH E-COLLAR MODULE To ensure the effectiveness of this product and the comfort and safety of your dog, check the fit of the collar frequently. If you notice that your dog is experiencing skin irritation, discontinue use of the collar for a few days. If the condition persists beyond 48 hours, see your veterinarian.

  • Page 16: Prepare The Tek Series 2.0 Handheld Device

    STEP :: 02 PREPARE THE TEK SERIES 2.0 HANDHELD DEVICE YOU MUST COMPLETE THESE STEPS PRIOR TO USING THIS DEVICE FOR THE FIRST TIME. TO CHARGE THE HANDHELD DEVICE 1. Lift the rubber cover protecting the charging jack. 2. Connect the appropriate charger connector to the charging jack.

  • Page 17: Tek 2.0 Setup Wizard

    STEP :: 03 TEK 2.0 SETUP WIZARD The first time you turn on your TEK 2.0 Handheld Device, the Setup Wizard will walk you through setting up your device. The Setup Wizard has four sections: 1. Initial Device Settings 2. Adding Dogs 3.
  • Page 18 TIME The Wizard will then ask you to choose: • Time Format – 12 Hour or 24 Hour • Auto Time Zone – Enabled or Disabled (If you choose Enabled, the Handheld Device will update the time zone automatically based on the GPS location and the internal time zone table). •...
  • Page 19 COLLAR COLOUR You will now add a collar to be assigned to the dog. Choose the collar colour for this dog. This colour will represent the dog on all screens. Press the Enter Button or the Right Arrow Key to bring up a selection of colours. There are 21 colours available to assign to collars and hunters.

  • Page 20: Home

    HANDHELD DEVICE NAME Now you will assign a name for your TEK 2.0 Handheld Device. This is the name you will use to share your Handheld Device information with other hunters. Press the Enter Button to bring up the keyboard. Use the arrow keys or the Wheel to enter the name.

  • Page 21: My Dogs

    MY DOGS The My Dogs Screen displays a list of your dogs. You can add and remove dogs, assign each dog to a colour-coded collar so it can be tracked, and manage settings for each dog from this screen. DOG LIST Active dog names (up to 21) appear next to their collar colours and inactive dog names appear in grey.
  • Page 22 Action The Handheld Device can alert you when your dog exhibits specific hunting actions: • On-Point – used for pointing dogs to detect when the dog is stationary, indicating it is on-point. • Treed – used for hunting with trailing dogs to indicate the dog is “on the tree” and holding an animal at bay. Select None, On-Point, or Treed and then select Next to move to the next screen.
  • Page 23 Bark Indicator The Bark Indicator reports each time a selected dog barks (barks per minute). Press the Enter Button or the Right Arrow Key to select Yes or No. NOTE: The Bark Indicator options are a placeholder for future functionality. This feature will not currently operate.

  • Page 24: My Collars

    MY COLLARS The My Collars Screen displays a list of your collars. You can add and remove collars and manage settings for all collars from this screen. COLLAR LIST Active collars appear next to their selected colour and inactive collars appear in grey. You can have up to 21 collars in the list.
  • Page 25 Pair Collar Follow the instructions on the screen to pair the collar with your TEK 2.0 Handheld Device. Press and hold the collar On/Off Button until the Indicator Light turns amber to put the collar in Pairing Mode. When the collar Indicator Light flashes green 5 times, pairing is complete.
  • Page 26 Shared Collar Press the Enter Button or the Right Arrow Key to select Yes or No. If you select Yes, you must enter the Owner ID and Collar ID*. Press the Enter Button or the Right Arrow Key to bring up a keypad. Use the arrow keys to enter an ID number.

  • Page 27: Hunters

    HUNTERS The Hunters Screen displays a list of hunters who have shared their Handheld Devices with you, so you can track each other on the map. You can add, remove, and manage settings for all hunters from this screen. HUNTER LIST Active hunter names appear next to their assigned colour and inactive hunter names appear in grey.
  • Page 28 HUNTER DETAILS To view a hunter’s details, highlight and select the hunter name in the list. To edit a specific detail, highlight the field and press the Enter Button or the Right Arrow Key. Press the Left Arrow Key at any time to return to the Hunters Screen.

  • Page 29: Training

    TRAINING NOTE: If you own the TEK Series 2.0 GPS Tracking System (TEK-V2L) you must purchase the TEK-2T E-Collar Module accessory to utilise the training functionality. The Training Screen displays the Stim Button settings for active dogs and lets you deliver stimulation from all 3 User-Defined Stim Buttons.
  • Page 30 INTENSITY LEVEL The number displayed in the center of the Training Screen is the Intensity Level setting for the current dog. Use the Up/Down Arrow Keys to adjust the level from 1-99.* * The default Intensity Level is 1. Each time you adjust the Intensity Level for a dog, that value is remembered between training sessions and recharge cycles.

  • Page 31: Tracking

    TRACKING The Tracking Screen lets you easily view dog locations and deliver stimulation* to control dog movement. A map shows all of the items your Handheld Device is currently tracking, including you, your dogs, and any shared hunters or shared dogs. Below the map, the Name List shows all of the tracked items along with status details.
  • Page 32 SCALE BAR The scale bar below the map displays the current map scale* and notifies you if the map is set to Auto Scale. By default, the Tracking Screen will automatically scale to best fit all tracked items on the screen. You can override Auto Scale by using the Wheel to zoom in or out.
  • Page 33 TRACKING MENU To display the Tracking Menu, press the Menu Button while viewing the Tracking Screen. You can exit the Tracking Menu at any time by pressing the Left Arrow Key. Home: Select Home to display the Home Screen. Stop Navigation: Select Stop Navigation to stop navigating to a route and clear the route content from the Tracking Screen (only visible when a route is active).

  • Page 34: Map

    The Map Screen offers a full-screen view of any map data that is loaded on the Handheld Device. A black arrow icon displays your current location and additional GPS information can be found at the bottom of the map. Menu options allow you to customise the map and visible GPS information (Info Fields).
  • Page 35 Information about a Location Press the Enter Button while hovering over an object to display information about the object. If there are multiple objects under the cursor when you press the Enter Button, a list of all the available objects will appear.
  • Page 36 Info Field Arrangement Options: • 1 Wide, 2 Narrow • 4 Narrow • 2 Wide • 2 Narrow • 1 Wide Change Info Fields: Select Change Info Fields to choose different tracking information to display. On the Map Screen, use the arrow keys to highlight the Info Field you want to change.

  • Page 37: Voice

    VOICE When activated, the Voice feature provides audible alerts on all active tracked items and reports audible status updates on selected tracked items. Updates are given in the order that your tracked items appear in the Name List on the Tracking Screen and include all the information displayed on the Tracking Screen.

  • Page 38: Compass

    COMPASS The Compass looks and acts like a traditional floating needle compass. The cardinal letters rotate as the Handheld Device rotates, maintaining orientation to North. Directional arrows to tracked items are shown. Use the Left/Right Arrow Keys to scroll through the list of tracked items. Up to three are displayed at a time. The Compass Screen is used in two modes: General Tracking (when a route is not active): •...
  • Page 39 INFO FIELDS The Info Fields at the bottom of the Compass Screen display information about the current track or route. You can choose the tracking information each field displays through the Compass Menu. COMPASS MENU To display the Compass Menu, press the Menu Button while viewing the Compass Screen.

  • Page 40: Settings

    SETTINGS Customise your Handheld Device on the Settings Screen. Each field in the Settings Screen list opens to display a menu of specific options. STANDARD SETTINGS OPTIONS Every Settings menu contains two standard options: Restore Defaults: Highlight Restore Defaults and press the Enter Button or the Right Arrow Key to restore that setting to the factory defaults.
  • Page 41 Stim Buttons...: Set the default Stim Button configuration for when a new dog is added. See “TRAINING” on page 29 for a detailed list of stimulation options for each field. Default: Button 1: (C) Continuous / Button 2: (M) Momentary / Button 3: (T) Tone Alert: Choose how you are notified of an alert.
  • Page 42 Datum: Choose preferred Datum. Select from: • Guam 1963 • Nahrwan Masirah • Adindan • Afgooye • GUX 1 Astro • Nahrwan UArabEm • Namibia • AIN EL ABD ‘70 • Hjorsey 1955 • Hong Kong 1963 • Naparima BWI •...
  • Page 43 TIME Highlight and press the Enter Button to select preferred time settings. Time Format: Choose either Local 12 Hour (Default) or Local 24 Hour. Auto Time Zone: Control the auto time zone settings. Select from: Enabled: Allows the Handheld Device to update the time zone automatically based on the GPS location and the internal time zone table (Default).
  • Page 44 Fence/Lost Dog Alert: Choose the sound made when a dog has exited a Geofence boundary or the Handheld Device has lost communication with a dog’s GPS Collar. • Off • Tone • Long Ring • Beep • Alarm • Long Tone •...
  • Page 45 RESET Highlight and press the Enter Button. An alert message Resetting to factory defaults will delete all saved information. Are you sure you want to reset to factory defaults? will appear. Select Reset to revert back to the original factory settings or Cancel to exit the menu.

  • Page 46: Trip Computer

    TRIP COMPUTER The Trip Computer Screen is designed to give you as much information as possible about the current GPS tracking session, including details about movement and GPS Collar settings. The first screen is the Trip Computer statistics for the owner. Press the Left/Right Arrow Keys to show the Trip Computer for a different tracked item.
  • Page 47 TRIP COMPUTER MENU To see the Trip Computer Menu, press the Menu Button while viewing the Trip Computer Screen. You can exit the Trip Computer Menu at any time by pressing the Left Arrow Key. Home: Select Home to display the Home Screen. Go To...: Displays an additional menu for creating a route to a tracked item or Waypoint.

  • Page 48: Journal

    JOURNAL Journals save and store the notes, Waypoints, and breadcrumbs that you create. You have access to all Journals in a single, easy to manage collection. ACTIVE JOURNAL The active Journal is automatically started when the Handheld Device is powered on. It is named the date and time it was started.
  • Page 49 SAVED JOURNALS MENU To display the Saved Journals Menu, press the Menu Button while viewing a saved Journal. Press the Left Arrow Key at any time to return to the saved Journal. Home: Select Home to display the Home Screen. Breadcrumbs…: Displays an additional menu for choosing breadcrumb options.

  • Page 50: Geofences

    Geofences and manage settings for all Geofences from this screen. Geofences can be synchronised with the TEK 2.0 Companion Application for easier management. Geofences are a boundary line drawn on the map. When active, you will be alerted if a dog crosses a Geofence line.
  • Page 51 • When complete, press the Menu Button and select Finish Geofence. If another Geofence is already active, a message will ask you if you want to activate the new Geofence instead. Highlight Yes or No and press the Enter Button. NOTE: Complex polygons are not supported.

  • Page 52: Waypoints

    WAYPOINTS The Waypoints Screen displays a list of existing Waypoints. You can view and edit details of each Waypoint, view each Waypoint on the map, and create a route to a Waypoint. You can have up to 1,000 saved Waypoints. WAYPOINT LIST The bearing and distance to a Waypoint (from the current GPS location) is available on the Waypoint List Screen.
  • Page 53 Elevation Waypoint elevation is determined by the GPS signal. To change the reported elevation, highlight the number and press the Enter Button to bring up a keypad. Use the arrow keys to enter a new number. When complete, select the checkbox. Time/Date Waypoint time and date are determined by the GPS signal when the Waypoint was created.

  • Page 54: Sun/Moon/Hunt

    SUN/MOON/HUNT The Sun/Moon/Hunt Screen displays valuable information about the rising and setting times for the sun and moon, as well as predictions for hunting conditions. You can change the date in order to view information about future solar and lunar cycles and hunting activity.

  • Page 55: Connect To A Computer

    REGISTER YOUR TEK SERIES 2.0 SYSTEM TO RECEIVE E-MAIL ALERTS FOR PRODUCT UPDATES. ACCESSORIES To purchase additional accessories for your SportDOG® Brand TEK Series 2.0 System, contact the Customer Care Centre or visit our website at www.sportdog.com. S P O R T D O G . C O M...

  • Page 56: Frequently Asked Questions

    Contact Points. Can I program my TEK Series 2.0 System No. The TEK Series 2.0 Systems are not compatible with other to work with my other SportDOG® Brand SportDOG Brand®products. Systems, including TEK Series 1.0? Can I organise the way my dogs are Yes.

  • Page 57: Troubleshooting

    TROUBLESHOOTING The answers to these questions should help you solve any problem you have with this system. If they do not, please contact the Customer Care Centre or visit our website at www.sportdog.com. PROBLEM SOLUTION My Handheld Device does not Check to make sure the unit was properly charged.
  • Page 58 • If you notice your operating time dropping to about half the original time, the GPS Collar with E-Collar Module battery needs to be replaced. Contact the Customer Care Centre or visit sportdog.com to order a replacement. S P O R T D O G . C O M...

  • Page 59: Terms Of Use And Limitation Of Liability

    Radio Systems Corporation are in violation of EU R&TTE regulations, could void the user’s authority to operate the equipment, and void the warranty. The Declaration of Conformity can be found at: www.sportdog.com/eu_docs.php IC - CANADA This device complies with Industry Canada licence-exempt RSS standard(s).

  • Page 60: Battery Disposal

    If this is not possible, please contact the Customer Care Center for further information. For a listing of Customer Care Center telephone numbers, visit our website at www.sportdog.com. This product is protected by the following patents: U.S.

  • Page 61: Warranty

    THREE YEAR NON-TRANSFERRABLE LIMITED WARRANTY This Product has the benefit of a limited manufacturer’s warranty. Complete details of the warranty applicable to this Product and its terms can be found at www.sportdog.com and/or are available by contacting your local Customer Care Centre.

  • Page 62: Tek Series 2.0 Add-A-Dog® Collars

    TEK :: 2AD :: E TEK :: 2AD :: C TEK :: 2AD :: AU TEK :: 2AD :: NZ NOT COMPATIBLE WITH TEK SERIES 1.0 OR OTHER SPORTDOG BRAND SYSTEMS. ® *PINK AND GREEN ID BANDS ALSO INCLUDED. ©2014 RADIO SYSTEMS CORPORATION Radio Systems Corporation •...
