KitchenAid KSRV22FVBL01 Parts List page 12

For Models: KSRV22FVWH01, KSRV22FVBT01, KSRV22FVBL01, KSRV22FVSS01, KSRV22FVMS01
(White)
FREEZER DOOR PARTS
(Biscuit)
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(Includes Item 8
And Dispenser
Front Parts)
W10214818 White
W10214815 Biscuit
W10214814 Black
W10214817 Stainless
W10214816 Monochromatic
2 Handle
(Includes #4)
2319727W White
2319727T Biscuit
2319727B Black
2319727S Stainless/Satina
3 2308091 Thimble−Top
4 488208 Screw
5 2219698 Stud, Handle
6 2156021 Trivet (3)
7 3400012 Screw
8 Door Gasket,
Magnetic
2309604 Mist Beige
2309654 Black
2327162 Grey
9 2212375 Trim, Door Shelf
10 2182178 Door Closer,
Upper Cam
11 489420 Screw
12 Bracket, Door Stop
2323534 Chrome
2323534B Black
13 Set Screw
W10010140 Chrome
W10010150 Black
12
(Black) (Stainless) (Monochromatic Stainless)
W10246564
