Summary of Contents for PhaseOne 645DF

  • Page 1 User Guide Phase One 645DF Camera and IQ-series Digital Back User Guide: Phase One 645DF Camera and IQ Series Digital Back...
  • Page 2 On Rights ©2011 Phase One A/S. All rights reserved. Made in Denmark. Ver. 1.0 Colorspace images created in CROMiX ColorThink. Photos by: Jens Honoré Stefan Kapfer Eugeni Pons Text By: The dedicated Phase One staff. On Liability The information in this User Guide is provided “as is”. Under no circumstances, including negligence, shall Phase One be liable for any incidental, special, direct, indirect or consequential damages arising out of or relating to use of the information provided in this guide with or without the software and/or hardware described in the guide.

  • Page 4: Table Of Contents

    Indicator Lights Activation and Deactivation of Capture One Indicators Screen Calibration Tethered and Untethered Operations The 645DF Camera and IQ Digital Back System CF Card Usage Unpacking the 645DF and IQ Digital Back System Secure Storage System (3S) Value Added Formatting your Memory Card Classic vs.
  • Page 5 Back Maintenance Ready Beep 10.7 IR Filter on the CCD Check Disk 10.8 645DF Camera Body Specifications Restore to Default 10.9 Phase One 645DF Housing Specification Firmware 11.0 Software About 11.1 To Import Images IQ Digital Back Overview 12.0 End User Support Policy IQ180 Digital Back Specifications 12.1...

  • Page 6: Introduction

    Introduction Thank you for choosing the Phase One 645DF camera and the IQ Series digital back solution. The Phase One 645DF and IQ Series digital is the most powerful digital camera solution whether you are working on location or tethered in a studio.

  • Page 7: Warranty

    To install the software follow the procedure below: 1. Either load the Capture One DVD, or download the application from the Phase One website: www.phaseone.com. 2. Open the Capture One disk image. 3. Read and accept the license agreement presented.

  • Page 8: Activation And Deactivation Of Capture One

    If you are experiencing problems activating the software, follow the instructions provided in the application, read the software manual enclosed or visit our website for inspiration and troubleshooting: http://www.phaseone.com/support Deactivation of Capture One An Internet connection is needed to deactivate Capture One.

  • Page 9: Screen Calibration

    Screen Calibration Having a properly calibrated monitor is a critical factor when viewing im- ages. Ensure that digital viewing conditions are as accurate as possible. A quality monitor and calibration tool should help guarantee that displayed images on a screen are precisely rendered. Once a monitor has been calibrated, the color and brightness controls should be locked to prevent inadvertent changes.

  • Page 10: The 645Df Camera And Iq Digital Back System

    Classic and Value Added. Unpacking the 645DF and IQ Digital Back System The Phase One 645DF and IQ digital back system is delivered in a case cre- ated for the travelling photographer. The dimensions of this waterproof and impact resistant roller case are compatible with most airlines carry-on luggage requirements.

  • Page 11: Value Added

    Value Added: The waterproof roller case will hold: • Phase One 645DF body • IQ Digital Back • Schneider Kreutznach 80mm LS f 2.8 Lens • Capture One Pro software • 5 year Value Added warranty on IQ digital backs Accessories •...

  • Page 12: Classic Vs. Value Added

    2 Battery Focusing screen or Viewfinder Focusing screen or Viewfinder Masks The 645DF camera and SK LS lenses have a warranty of 1 year or 100,000 Masks depending on camera model depending on camera model shutter actuations, whichever comes first. Phase One AF/MF lenses have a 4.5m FireWire 800 cable...

  • Page 13: Charging The Batteries For The Iq Digital Back

    Charging the Batteries for the IQ Digital Back Charge the batteries as soon as the camera system has been unpacked. The Value Added roller case is delivered with two 7.2 volt Lithium-Ion batteries and a duo-charger. Although only one battery can be used in the IQ back at a time, it is recommended to charge both batteries fully before you start.

  • Page 14: Batteries For Camera

    Batteries for Camera Set the shutter release mode selector lever to L (to turn the power off ). Use six AA alkaline or rechargeable batteries. NiCd or NiMH batteries should only be used in the camera body if CF04 is set on rechargeable.

  • Page 15: Sleep Mode

    Sleep Mode The camera’s power is switched on when the shutter release mode selector is set to S, C or M.UP. In order to prevent the camera’s batteries from discharging, sleep mode is automatically entered if no operations are performed for a specific period of time while the power is ON (with exposure metering status maintained).

  • Page 16: Attach And Remove Lens

    Attach and Remove Lens 1. Remove the front body cap in the same way that you would remove a lens; push the lens release button [A] backward and then turn the front body cap or the lens itself counter clockwise and lift out. 2.

  • Page 17: Adjusting The Strap

    Attach a Leaf Shutter Lens Leaf shutter lenses are equipped with an internal shutter. Leaf shutter lenses are capable of high shutter speeds 1/800 sec. or 1/1600 on IQ Series backs with flash synchronization, which is particularly useful when you are doing daytime fill-in flash photography.

  • Page 18: Attaching The Iq Back

    The IQ back is fully integrated with the camera body and functions as a part of the whole camera system. Ensure that the Phase One 645DF camera mirror is up and the shutter is open when no digital back is attached.

  • Page 19: The Parts Of The Camera System

    2.10 The Parts of the Camera System Self Timer Button Hot Shoe Interval Button Rubber Eye Piece Exposure Mode Dial Main LCD Backlight Button Exposure Metering Mode Button Eyepiece Shutter Lever Focus Point Selector Button Main LCD Mirror* *Do not touch the mirror Rear Dial Electronic Contacts Strap Lug...

  • Page 20: The Displays

    2.11 The Displays The display on the camera body will provide you with a lot of valuable information. This includes many features and settings including, but not limited to shutter speed, aperture value, exposure program, exposure compensations and metering modes. See the figure for full explanation. mode set During actual use, only the relevant icons and indicators are displayed.

  • Page 21: Display Abbreviations

    2.12 Display Abbreviations Display examples in the custom function mode Liquid Crystal Display Due to the limitations of the space and letters, words and letters on the LCD are abbreviated. Display examples of the main LCD...

  • Page 22: The Buttons On The Back

    2.13 The Buttons on the Back The IQ is equipped with four external buttons. The buttons will change Play function to match the menu shown on the display. Find out more on the IQ menus from page 73. 2.14 LED Lights IQ Series digital backs feature two main LEDs located below the bottom left corner of the screen.

  • Page 23: Setting Date And Time

    2.15 Setting Date and Time Date and time parameters are set and controlled via the IQ back’s Menu system. If the IQ back has been without power for a long period of time, it will automatically ask you to set the time and date on the next occasion it is powered up.

  • Page 24: Replacing The Diopter Correction Lens

    Replacing the Diopter Correction Lens Notice: 1. Press the Eyepiece Lock, which is located in a gap between the Eyepiece If there is dirt or dust on the lens surface, and the Diopter Correction lens. (Turn the camera upside down to gain easy remove it with a blower or sweep it off access to it).
  • Page 25 25 25...

  • Page 26: Basic Functions

    Basic Functions ISO and White Balance The IQ back’s Home Screen enables quick access to the ISO and WB settings by either pressing the adjacent buttons or by tapping the screen directly. Scroll up and down, then select the setting by tapping the screen next to the desired rating so that a green check mark appears.

  • Page 27: Getting Started: Setting The Shutter Release, Focus, Exposure And Metering Modes

    Getting started: Setting the Shutter Release, Focus, Exposure and Metering modes 1. Set the Shutter Release mode selector lever to S (single-frame advance mode). There are two shutter release (drive) modes: S (single frame advance mode) and C (continuous advance mode). When set to L the power is turned off.
  • Page 28 P: Program AE - The aperture and shutter speed are determined automatically for the optimum exposure, according to the ambient light conditions. This auto mode is best suited for general photography or for novice photographers, as it leaves the user free to concentrate on framing and capturing the subject. Av: Aperture priority AE - Set the desired aperture and the camera selects the correct shutter speed.

  • Page 29: Measuring Light - Exposure Metering

    Measuring Light – Exposure Metering 1. Press button [A] to adjust the exposure metering mode. There are three different exposure metering mode options that are displayed sequentially when either the front or rear dial is turned. Select an appropriate exposure mode.

  • Page 30: Focus Modes

    Focus Modes To use the Auto Focus function, both the camera body and the lens have to be set to their respective Auto Focus modes. Auto Focus does not function when either the camera body or the lens are set to manual focus. To activate Auto Focus (AF), first select AF on the focusing selector ring on the lens.
  • Page 31 Single Focus Mode (S) This mode uses the focus-priority mechanism. The shutter can be released when the focus mark • in the viewfinder is illuminated. This mode is suited for still subjects. Focus is locked when the focus mark • is illuminated in the viewfinder’s LCD.

  • Page 32: Focus Areas

    Focus Areas You can select the focus area that best suits the kind of pictures you intend to take. Push and hold the focus selection button [A] for at least one second; then turn the front or rear dial to select the appropriate focus area. The selected focus area can be seen on the main LCD panel.
  • Page 33 Manual Focusing using the Focus Mark (Focus confirmation method) Half-press the shutter release button and turn the lens focusing ring to focus on the subject. The focus mark is illuminated in the viewfinder’s LCD to signal that a picture is in focus. If ...

  • Page 34: Using Focus Lock And Infrared Focusing

    Using Focus Lock and Infrared Focusing Use the focus lock when the your intended focus point is not within the focus frame. In such cases where a subject is not located in the center of a frame, use the focus lock function to lock the focus before releasing the shutter. 1.

  • Page 35: Drive Dial

    Drive Dial Single-Frame Mode One photograph is taken each time the shutter release button is pressed. Set the shutter release mode selector to S. Continuous Mode Photographs are exposed as long as the shutter release button is pressed. Set the shutter release mode selector lever to C. Photographs are taken continuously at a rate depending on the buffer speed of the digital back mounted on the camera.

  • Page 36: Exposure Modes

    Exposure Modes NOTICE: If a correct exposure cannot be obtained, (P) Program AE the shutter speed and aperture value blink. In such cases, the pictures can be taken but The aperture and shutter speed are determined automatically for the they may out too bright or too dark. optimum exposure, according to the ambient light conditions.
  • Page 37 Aperture Priority AE (Av) Set the desired aperture, and the camera selects the optimum shutter speed NOTICE: The shutter speed value will blink when the accordingly. Use the Av mode to maintain specific control over depth of field, subject is too dark or too bright for a correct exposure.
  • Page 38 Manual Mode (M) NOTICE: This mode is used to set both the aperture and shutter speed for total When the exposure is compensated in the exposure control. Varying shutter speeds can be selected, including “bulb”, Manual mode, the difference between the “tIME”...
  • Page 39 One-push Shift Function When the difference between the set value and metered value is displayed on the viewfinder LCD in the Manual “M” mode, press the AEL button for approx. 1 second and the camera will automatically adjust the shutter speed to achieve the correct exposure based on the set aperture value.
  • Page 40 Exposure Mode Lens Mode Shutter speed X-Sync 1/4000-1/800 1/800-1S 1S - 30S+ 1/4000 - 1/800 1/800 - 1S 1s - 30S+ Program Leaf Shutter — — — — Focal Shutter — 1/90 - 1S — Leaf Shutter — — — —...

  • Page 41: Flash Photography

    1. A grip type flashgun or a strobe (with electric contacts other than X contact) can be operated with the Phase One 645DF by connecting a sync cord into the camera’s sync terminal. (See the note in the bottom left corner of the page about flash units designed exclusively for other camera makes.)
  • Page 42 Phase One 645DF features TTL (Through The Lens), OTF (Off The Film) and Metz 3952 functions electronic flash exposure metering. A flash sensor located inside the camera body reads the flash light reflected off the surface of the CCD at the moment...
  • Page 43 TTL flash Exposure mode Shutter speed Aperture With TTL flash photography, the reflection of the flash is metered and the Program AE Automatically set by Automatically set by intensity of the flash is adjusted automatically, which can mean TTL flash camera to 1/60 sec.

  • Page 44: Flash Compensation Settings

    3.11 Flash Compensation Settings   By combining a Metz flash and the SCA3952 adapter, the camera adjusts for flash. It can be adjusted within ±3EV in increments of 1/3 steps. 1. Turn on the Power Install the SCA3952 adapter on the Metz flash, and attach it to the camera. Lock the flash in place using the locking knob on the flash shoe.
  • Page 45 Flash Photography with Electronic Flash Models other than Metz units 1. To use a grip type flashgun or a strobe with other electric contacts than X contact, connect the sync cord to the camera’s sync terminal. (See note below about flashes designed exclusively for other makers’ cameras.) 2.

  • Page 47: Introduction To The Iq Series Digital Back

    The Phase One IQ Series Digital Back is designed to fit on the Phase One 645DF as well as several other brands or models of medium format cameras. The Phase One IQ Series include three different models; the IQ180, IQ160 and the IQ140 that feature maximum resolutions of 80, 60.5 and 40 high quality...

  • Page 48: Quick Start (Shooting Untethered)

    Quick Start (shooting untethered) 1. Connect IQ digital back to the camera and install the focusing screen if applicable. 2. Charge the batteries (See page 14). Insert batteries into the camera. 3. Insert a CompactFlash card into the IQ Back. 4.

  • Page 49: General Hardware Setup

    General Hardware Setup Powering up the IQ back After an IQ back is connected to a camera body, insert a battery or a FireWire 800 cable and it will automatically turn on. The back is switched on/off by pressing the power button located below the IQ back display. ISO Settings The IQ180 back has a default ISO spectrum from ISO 35-800.

  • Page 50: Indicator Lights

    Indicator Lights IQ Series digital backs feature two main red and green LEDs located below the bottom left corner of the screen. When the IQ back is activated, the green and red LEDs will flash shortly and a beep will sound to indicate that it is ready to capture.

  • Page 51: Tethered And Untethered Operations

    Tethered and Untethered Operations Untethered: An IQ Series back can be operated as a fully portable battery powered unit. Image files are shot and transferred to a CompactFlash card which is inserted in the CF-card slot on the left side of the camera back. Tethered: Remember to always keep a battery in the IQ back even when shooting tethered to a computer via a FireWire connection.
  • Page 52 (The IQ back can be forced to shoot to either CompactFlash or via a FireWire 800 cable to a computer. Find out more on page 74). For more information on capturing tethered with Capture One please consult the online User Guide available in the Capture One Help menu or go direct to http://help.phaseone.com/en/CO6/Capture/Tethered-Shooting.aspx...

  • Page 53: Compactflash Card Usage

    CompactFlash Card Usage It is important to follow a few simple guidelines to help avoid loss of data when working with CompactFlash cards, card readers and digital cameras. Phase One recommends that you test-drive all new CompactFlash cards including the one that comes with your IQ back. By performing an initial test to verify that the capture files are stored properly on the card and can be accessed on a computer you will avoid unpleasant surprises on location or when you return from a job.

  • Page 54: Secure Storage System (3S)

    Secure Storage System (3S) You can always be sure that your data is safe when working with memory cards in a Phase One IQ back. The Phase One Secure Storage System (3S) provides the industry’s safest memory card handling. The 3S technology automatically checks your card’s file structure every time it is inserted into the IQ back.

  • Page 55: Formatting Your Memory Card

    Formatting your Memory Card Most CompactFlash cards are preformatted and ready for use in the IQ backs. However, Phase One recommends that all cards should be formatted in the IQ back to ensure their optimum performance. Memory card formatting is done in either FAT 16 or FAT 32 depending on card size.

  • Page 56: Navigating The Iq User Interface And Menu System

    Navigating the IQ User Interface and Menu System Home Screen The IQ Home Screen is the first view users will see as soon as the back is switched on. This is the back’s default screen and the starting point in which to negotiate the menu system.

  • Page 57: Menu Buttons

    Menu Buttons The IQ back is equipped with four external buttons. The buttons will change Play function to match the menu shown on the display. The four external buttons are assigned to the Play, Menu, ISO and WB options when the IQ back is in its default Home Screen position. (See image left) The function of the four buttons changes once one of the Menu, ISO and WB Menu options has been selected.

  • Page 58: Touch Screen Operation

    Touch Screen Operation All three IQ models incorporate a newly-designed 3.2 inch touch screen. The screen lets you zoom, pan and browse through images fast and it is easy to navigate between different menus and features. The IQ series backs are designed with invisible controls that are context sensitive and appear only when specific areas of the screen are touched.

  • Page 59: Iso

    Push the top right button or tap ISO on the Home Screen. You will be presented with the back’s ISO spectrum. Scroll up and down and tap the screen to select the desired setting. A green check mark will appear next to your chosen setting and you will automatically return to the Home Screen.

  • Page 60: White Balance

    White Balance Push the lower right button or tap WB on the Home Screen. You will be presented with the back’s White Balance settings. Scroll up and down and tap the screen to select the desired setting. A green check mark will appear next to your chosen setting and you will automatically return to the Home Screen.

  • Page 61: Custom White Balance

    Custom White Balance To create a new Custom White Balance, first capture a reference White Balance image. (Try to use a gray card or neutral white surface). Next, select the Context menu and press the White Balance Picker icon. (Ensure that the image is in full screen view) Zoom in and pan to a desired part of the image and then tap on a white/ grey area to create a custom WB.

  • Page 62: Play Mode

    Play Mode Play mode is used to review captured images. Its touch screen interface makes it easy to delete, zoom, pan and browse through images quickly. Push the upper left (external) button or tap Play on the Home Screen to enter this mode.

  • Page 63: Play Mode Views

    Play Mode Views There are three Play mode views: Full Screen, Tool View and Thumbnail View. Full Screen displays an image in its entirety. A Zoom Slider, Context menu too and zoom level percentage will automatically disappear after a few sec- tions of inactivity.

  • Page 64: Play Mode: Context Menu

    Play Mode: Context Menu Press the Context Menu button in the corner of each Play mode. All Context Menus feature three navigation buttons. Select one of the three bottom items (from left to right) to switch to an alternative view. The Full Screen Context Menu features a Delete/Rating, Exposure Warning, Custom White Balance Picker and Grid options.

  • Page 65: Info Bar

    Info Bar The bottom of the screen features an Info Bar that displays a Power Indicator that shows the remaining battery capacity or a FireWire icon if the IQ is being used to shoot tethered via a FireWire 800 connection. The Power Indicator will start blinking when it runs low to warn users that the battery needs to be replaced before capturing any more images.

  • Page 66: Delete And Rating

    Delete and Rating Choose the top left button in the Context . A grey bar will appear at the bottom of the screen when reviewing in Full Screen or in the Tool View. Tap the dot in the grey bar to select a star rating from 1 to 5. Alternatively, swipe your finger along the bar to choose a star rating.

  • Page 67: Delete In Thumbnail View

    Delete in Thumbnail View Select the trash icon to Delete images in the Thumbnail View. A trash icon will appear in the Info Bar at the bottom of the page. Tap each individual thumbnail that you want to delete. (A small red trash icon will appear in the top left corner of the thumbnail).

  • Page 68: Grid

    Grid Select the Context Menu and choose the (circled) icon to overlay a grid on captured images in Full Screen, Tool View and Play modes. Press the Grid icon in Context Menu again to deactivate the Grid. Long press the (circled) icon in Context Menu to configure the Grid. It is possible to select a different Grid Mode, Line Style and Color.
  • Page 69 The Grid Mode provides numerous style combinations. The Rectangular option can be configured to display up to 10 horizontal and vertical lines. In this example (left) the Color has be changed to yellow and the Line Style is Dotted. The Golden Ratio grid helps photographers compose images within some classic proportions.

  • Page 70: Tools

    Tools Play mode features five Tools to aid the capture and the review of images. The Tools include a Exposure warning, a Focus Mask, a Exposure Histogram, a Alignment tool and File Info. Tap the screen to scroll vertically through the tool selection.
  • Page 71 Alignment The Alignment tool helps keep the attached camera in a perfect horizontal or vertical position. Press the Alignment tool once to make it appear full screen. Tap the screen or press the upper left (external) button once to return to the Tool view.
  • Page 72 Exposure Warning Exposure Warning tool highlights areas of a captured image that are overexposed. Tap the Exposure Warning tool once to display any burned out areas of an image with a (default red) color overlay. Tap the Exposure Warning tool again to remove this overlay from view. Long press the Exposure Warning to access a dialog box to alter the Tool’s settings.

  • Page 73: Menu

    Menu The Menu can be accessed by either pressing the lower left exterior button or by tapping Menu directly on the Home Screen. The Menu can be navigated by using the touch screen functionality or by following the Enter, Exit, Up and Down arrows and pressing the corresponding buttons on the IQ back.

  • Page 74: Brightness

    The IQ needs to wake up before shooting and the timing of this wake up signal is referred to as the Latency. The recommended setting is Normal Latency if the IQ is used with the Phase One 645DF format camera. Storage Storage allows users to configure how an IQ back should store the captures created.

  • Page 75: Image Orientation

    Image Orientation The Image Orientation function sets and stores the orientation of all subsequently captured images. Select 0, 80, 180 or 270 to force the back to mark images as captured with that orientation. The Auto setting uses the back’s built in orientation sensor to determine the orientation at the moment of capture.

  • Page 76: Date And Time

    Date And Time Set the Date and Time to your local time zone. The default Date and Time is GMT+1. Tap the screen and scroll through the numbers to attain the appropriate date and time. Tap the check mark icon, which will appear in the bottom right hand corner of the screen to confirm your entry.

  • Page 77: Auto Power Down

    Auto Power Down Auto Power Down determines the amount of time before the IQ back shuts down, when there is no activity. Choose 1 minute, 5 minutes, 30 minutes, 2 hours or deactivate this function by selecting Off. Press the Power button to switch on and restart the IQ back after it has shut down.

  • Page 78: Check Disk

    Firmware ver- sions. Firmware updates can be found in the download section at www.phaseone.com. Download the latest IQ Firmware from the website, transfer it to a memory card and insert it into the IQ’s card slot. Select Update Firmware and the IQ back will automatically detect and implement the update from the card.

  • Page 79: Iq Digital Back Overview

    IQ Digital Back Overview IQ180 IQ160 IQ140 Description World leading image quality The IQ160 digital back is The IQ140 digital back delivers the perfect combination of with 80 megapixel full-frame the optimal solution for the world leading image quality resolution. Switch to Sensor+ demanding photographer, and a fast workflow.

  • Page 80: Iq180 Digital Back Specifications

    ® , Service Pack 1 IQ180 full resolution capture mode IQ back mounts Resolution 80 megapixel Phase One/ Phase One 645DF/AF Pixel size 5.2 x 5.2 micron Mamiya Mamiya 645DF/ AFDIII RAW file IIQ large: 80 MB Phase One H101...

  • Page 81: Iq160 Digital Back Specifications

    , Service Pack 1 ® IQ160 full resolution capture mode IQ back mounts Resolution 60.5 mega pixels Phase One/ Phase One 645DF/AF Pixel size 6 x 6 micron Mamiya Mamiya 645DF/ AFDIII RAW file IIQ large: 60 MB Phase One H101...

  • Page 82: Iq140 Digital Back Specifications

    IQ140 full resolution capture mode ® Resolution 40 megapixel IQ back mounts Pixel size 6 x 6 micron Phase One/ Phase One 645DF/AF RAW file IIQ large: 40 MB Mamiya Mamiya 645DF/ AFDIII compression IIQ small: 26 MB Phase One H101...

  • Page 84: Advanced Functions

    Advanced Functions NOTICE: After taking pictures using the Exposure Compensation feature, be sure to return Exposure Compensation the exposure compensation dial to the 0 position. In situations providing extreme high contrast, the resulting photograph may be under or overexposed. When this occurs, use the Exposure Compensation The exposure compensation feature is available during AE locked operation.

  • Page 85: Ae Lock

    AE Lock AE lock function is useful in a number of shooting scenarios but is particularly useful when capturing panoramic images where a consistent exposure is needed to seamlessly stick images together in post production. The AEL button will lock the Auto-exposure value as the photo is being recomposed.

  • Page 86: Metered-Value Difference Indicator

    Metered-Value Difference Indicator Keep pressing the AEL button [A] and the difference between the metered exposure value and the exposure of the new composition will be displayed on the viewfinder LCD. This function can be used to see if an object of very different brightness levels can be properly photographed.

  • Page 87: Auto Bracketing

    Auto Bracketing NOTICE: Auto Bracketing can be used when it is difficult to determine your exposure When you want to cancel the auto- bracketing mode, turn the rear dial to compensation value. This function automatically captures different exposure change “On” to “OF” variations in succession.
  • Page 88 Single-Frame Mode (S) AE Settings Under Auto-bracketing Mode Press the shutter release button for each shot. The camera meters adequate Exposure Mode Setting exposure value for each shot and performs Auto Bracketing. The camera stays in the Auto Bracketing mode until you cancel the Auto Bracketing Program AE Shutter speed varies mode manually.

  • Page 89: Taking Photos With The Mirror Up

    Taking Photos with the Mirror Up NOTICE: Auto bracketing exposures can be made This function prevents mirror-caused vibrations which may blur an image when the auto bracketing mode is set when shutter speed is slow. A electromagnetic Cable Release RE401 (optional) before taking photos with mirror up.

  • Page 90: Mirror Up Delay

    Mirror Up Delay To change from the Self-timer to the Mirror Up setting, press the shutter button so the mirror goes into the upright position. Once the set time has expired the shutter will release, and the mirror will return to the lower position.

  • Page 91: Bulb Mode & Long Exposure

    Bulb Mode & Long Exposure NOTICE: To make an exposure longer than 30 seconds, adjust the shutter speed As the camera is electronically controlled even during exposures, it is recommended to “B” (bulb). In order to prevent camera shake, use the RE401 or RS402 to replace batteries before bulb exposure.

  • Page 92: Front/Rear Dial Lock Mechanisms

    Front/Rear Dial Lock Mechanisms NOTICE: The setting will be stored after one second. When the Electronic Dial Lock is On, all currently set values in Av (Aperture Dial lock can not be set when the exposure mode is P (program AE). Priority AE), Tv (Shutter Priority AE) and M (Manual mode) cannot be adjusted with the front or rear dials.

  • Page 93: Self-Timer Mode

    9.10 Self-Timer Mode The default setting for the Self-Timer mode to release the shutter is 10 seconds after the shutter release button is pressed. The self timer lamp flashes slowly for the first 7 seconds, and then flashes quickly for the last 3 Notice: seconds before the shutter is released.

  • Page 94: Interval Photography

    9.11 Interval Photography Interval photography can used for a variety of shooting scenarios such as such as to capture cloud movement or a flower coming into bloom. Notice: Repeat turning (according to the number of times) will lead to a countdown 1.

  • Page 95: Depth Of Field

    9.12 Depth of Field Depth of field (D.O.F.) is defined as the zone of sharpness before and behind the plane of focus. It depends on distance to subject, focal length of lens, aperture setting and distance the lens is focused at. In addition to visual observation via the depth of field preview button, the D.O.F.

  • Page 96: Infrared Photography

    9.13 Infrared Photography Infrared Photography is complicated when using digital backs, as the digital back is adjusted to match the viewable light perfectly. Use a dedicated digital back for infrared photography. The IQ back needs to be adjusted to work properly for infrared photography. DO NOT TRY THIS AT HOME! –...

  • Page 97: Custom Function

    9.14 Custom Function The custom functions can store separate three different camera set-ups. When at C-00, chose 1 (A), 2 (B), or 3 (C) to store a specific set of user function selections for the group of custom settings from C-01 to C-19. The C-00 is set to 0 which is the settings used for the default set.

  • Page 98: Types Of Custom Functions

    9.15 Types of Custom Functions remaining battery charge will be displayed correctly on the external LCD panel. 0: Alkaline C-00 Custom functions profile [SEL] 1: NiCd, NiMH, Li–ion 0: None (default=0) 2: Li-ION (ONLY FOR USE WITH VERTICAL GRIP) 1: A 2: B C-05 Bracketing [Stno] 3: C...
  • Page 99 release button is half-pressed. timing. This allows you to have the flash fire at the beginning of the exposure 0: AF operation (default setting) or at the end of the exposure. 1: AF & AE operation 0: First (default setting) 2: Only shutter release 1: Second C-11 AEL function lock/unlock mode [AEL]...
  • Page 100 C-97 Support for Mamiya ZD backs This function should ONLY be activated when shooting on a Mamiya ZD back. 0: Default setting NO Mamiya ZD back on the camera body 1: Mamiya ZD back on camera body C-98 Lens firmware version The current firmware version can be checked.
  • Page 101 Custom Functions overview Item Initial setting (0) C-00 Custom Function User Last used User A User B User C C-01 Steps of aperture, shutter speed, Exposure compensation 1/3 EV step 1/2EV step 1 EV step C-02 Aperture setting after lens change Previous aperture value Maximum aperture Minimum aperture setting...

  • Page 102: Custom Dial Modes C1, C2 Or C3

    9.16 Custom Dial Modes C1, C2 or C3 Mode dial options C1, C2 and C3 can be used to store preferred settings. These settings can be changed instantly to suit the photographer's needs. Users can change the settings on the camera body or via an IQ back. Programmable settings are exposure mode, P (program AE), Av (aperture priority AE), Tv (shutter speed priority AE), X (synchro mode), M (manual mode), focus area and spot metering.

  • Page 103: Lenses And Multi Mount

    9.17 Lenses and Multi Mount When it comes to lenses, Phase One provides the widest range of possibilities to ensure photographers get the most creative freedom from their Phase One camera. This chapter looks at some possible lens systems. However, it is worth noting that there are even more applicable lenses available than presented in the upcoming pages.

  • Page 104: List Of Alternative Lenses

    9.20 List of Alternative Lenses Producer Specs Limitations Adaptor/Mount Notice Recommended digital lenses Arsat MC Arsat 30 f.3,5 fisheye Pentacon six Arsat MC Arsat 45 f.3,5 Wide Angle Pentacon six Producer Specs Limitations Adaptor/Mount notice Arsat MC PCS Arsat 45 f.3,5 Pentacon six shift Mamiya 28 f.4,5 AFD...

  • Page 105: Maintenance

    10.0 Maintenance NOTICE Since the Focusing Screen’s surfaces are soft The Phase One 645DF generally needs very little maintenance. But this is a and easily damaged, handle them carefully. professional tool and should be treated with care and caution. Always do test shots before a photographic session if the camera for any reason has not Never touch the surface with bare fingers.

  • Page 106: Battery Socket

    10.2 Battery Socket Never leave batteries in the socket if the camera or back is not planned to be used for longer periods. Notice: Make sure to re-install the empty battery Keep contacts clean and dry at all times. case into the body. The empty battery cassette must be External Battery Socket inserted into the body.

  • Page 107: Camera Display Error-Notification

    10.4 Camera Display Error-Notification When Any of These Displays Appear LCD display Causes and remedies Problems Remedies The camera caution mark will blink if the camera body detects an abnormality.

  • Page 108: Lens Maintenance

    10.5 Lens Maintenance Never touch the inner optics of the lens with your fingers. Keep the inner optics perfectly clean with air, a lens brush or the dry cloth delivered with the lens. Do not touch the contacts. Keep the contacts clean with either a dry cloth or by using a fibreglass brush.

  • Page 109: 645Df Camera Body Specifications

    Shutter speed from 1/4000s to 60 minutes, extremely high flash synchronisation up to 1/1600 second to stop action with fast shutter speed or flash. The mirror and viewfinder of the Phase One 645DF camera are almost three times larger than those of 35mm cameras, providing much greater control of focus and composition.

  • Page 110: Phase One 645Df Housing Specification

    10.9 Phase One 645DF Housing Specification Flash control : TTL direct flash control, supports Metz SCA3002 system (SCA3952 Adapter) Camera type : 6x4.5cm format, electronically controlled focal-plane shutter, TTL multiple mode AE, AF single lens reflex Mirror up shot : Select by pressing the mirror up button.

  • Page 111: Software

    Please go to http://help.phaseone.com/en for further information regarding Capture One. (This online Users Guide can also be found under the Help menu on Windows and Mac). A PDF of the Capture One User Guide can also be found on the USB memory stick that came with you IQ back.

  • Page 112: End User Support Policy

    12.0 End User Support Policy Phase One guarantee World Class Support and Service with every purchased product. Please check www.phaseone.com for the latest updated support policy. Worldwide Dealer Network At Phase One we think globally but act locally. Phase One’s products are sold through a World wide network of dedicated and competent local partners to make after-sales support convenient for you.

  • Page 113: Web Resources

    Phase One offer users a host of online resources including inspire, enthuse and inform. Find detailed information including User Guides and manuals about Capture One or our Digital Backs from www.phaseone.com Knowledge Base Phase One’s searchable Knowledge Base at http://support.phaseone.com provides detailed answers to many users questions.
  • Page 115 It is not possible to accidentally double expose an image by capturing one shot quickly after another when an IQ back is used on cameras such as the Phase One 645AF, Phase One 645DF, Mamiya 645 AFD/AFD II/AFDIII, or Hasselblad 555 ELD (DIG mode). The electronic communication with the body ensures that the IQ back is ready before allowing release of the next shot.

  • Page 116: Iq Back And Phase One 645Af/Df And Mamiya 645 Afd

    13.1 IQ Back and Phase One 645AF/DF and Mamiya 645 AFD The IQ back is fully integrated with the Phase One and Mamiya 645 camera series and functions as a part of the whole camera system. The IQ back communicates with the cameras through a fast internal electrical computer interface.

  • Page 117: More Details: Phase One And Mamiya 645 Series Cameras

    13.3 More Details: Phase One and Mamiya 645 Series Cameras Power Management and Shutter Latency The IQ CCD is put to sleep to reduce power consumption when it is not in use. The IQ needs to wake up before shooting and the timing of this wake up signal is referred to as the Latency.
  • Page 118 IQ180 back is 2 minutes and the IQ160 and IQ140 is 1 minute. The Phase One 645AF, 645DF and the Mamiya AFDIII can use the Bulb function to work in the same way as the T Mode. Please consult the relevant manual for more infomation or see page 91 of this user guide to learn more about the Bulb function for the Phase One 645DF.

  • Page 119: Iq Back For Mamiya Rz67

    The IQ backs are compatible with the Mamiya RZ PRO II and PRO IID with the use of an adaptor plate. The 645DF version of an IQ back can be used on a Mamiya RZ PRO IID with a Mamiya RZ PRO IID adaptor plate. (Phase One Part # 70994) The Hasselblad V version of an IQ back can be used on the older version Mamiya RZ PRO II with a Mamiya RZ Pro II adaptor.
  • Page 120 14.2 Viewfinder Masking The image area of Mamiya RZ67 at 56x69.5 mm is larger than the size of the three IQ model’s sensors so it is necessary to insert a viewfinder mask. There are two different masks available for the Mamiya RZ67 according to which IQ is being used.

  • Page 121: More Details: Mamiya Rz67

    14.3 More Details: Mamiya RZ67 The mode selector on the trigger button should be turned to the white dot when used with the IQ back. The selector should be set to the orange dot to avoid draining the small battery when the IQ back is attached to the body and not in use.

  • Page 122: Iq Back For Hasselblad V Series

    15.0 IQ Back for Hasselblad V Series The Phase One IQ back can be mounted on a wide range of Hasselblad cameras including Hasselblad 555 ELD, 553 ELX, 501 CM and 503 CW. 15.1 Mounting the IQ Back on a Hasselblad V Series Camera 1.
  • Page 123 15.2 Mounting the Viewfinder Mask on a Hasselblad V Series Camera The image area of a Hasselblad V camera body at approx. 6x6cm is a different size to the three IQ model’s sensors so it is necessary to insert a viewfinder mask.

  • Page 124: More Details: Hasselblad V Series

    15.3 More Details: Hasselblad V Series A sync cable is always connected from the lens to the small connector in the front plate on either the left or right side of the IQ back regardless of which Hasselblad V type camera used. Flash Lead Connection A flash cable is always connected to the F-connector on the IQ back with all Hasselblad V series cameras.

  • Page 125: Hasselblad 555 Eld

    15.4 Hasselblad 555 ELD Ensure that the shutter release on the front of the Hasselblad 555 ELD is in the DIG position when using a Phase One IQ back. If for any reason you have to use the 555ELD in Film position (E.g. If the DIG is not working) then set the IQ to Zero Latencey.

  • Page 126: Hasselblad 553 Elx

    15.5 Hasselblad 553 ELX When using the IQ back on some Hasselblad motorized bodies (i.e. Hasselblad ELX or Hasselblad ELM series), a motor cable is supplied to enable users to fire the camera shutter from a computer using the Capture One Pro Capture button.

  • Page 127: Hasselblad 501 Cm And 503 Cw Without Winder

    15.6 Hasselblad 501 CM and 503 CW without Winder The Phase One IQ back can also be used with mechanical Hasselblad cameras such as the 501 CM and 503 CW. These cameras are operated in single shot mode via the shutter release button or a standard cable release. WARNING! Please note that the Phase One IQ back should not be mounted while the camera is set to mirror up.

  • Page 128: Cables Shipping With Iq Back For Hasselblad

    15.8 Cables shipping with IQ back for Hasselblad V Classic and Value Added backs come with all the cables needed for the spe- cific camera platform. A Value Added back also comes with an additional 50300143 cable for use with large format and technical cameras. Part# 50300145 Motor cable for Hasselblad ELX.

  • Page 129: Iq Back For Hasselblad H Series

    16.0 IQ Back for Hasselblad H Series The Phase One IQ (H-mount) digital back is designed specifically for Hasselblad H1 and H2 cameras. 16.1 Mounting the IQ back on the Hasselblad H1/H2 1. Ensure that the mirror is up and the shutter is open. (This is the default position when no cassette is attached to camera body).
  • Page 130 16.2 Viewfinder Masking The image area of the Hasselblad H1/H2 cameras is 56x41.5 mm. A viewfinder mask is only needed for the smaller size of the IQ140 CCD that measures 44x33mm. Viewfinder masking is not necessary for IQ180 and IQ60 models as their light sensitive CCD measures 53.9x40.4 mm.

  • Page 131: More Details: Hasselblad H Series

    16.3 More Details: Hasselblad H Series Camera Display The Hasselblad H1/H2 incorporates a screen that displays information about the camera set-up. It shows the aperture value, AF mode, shutter speed etc. The Hasselblad H1/H2 will also display some IQ back information on this screen.
  • Page 132 Viewfinder Information The viewfinder information bar is located below the image area within the viewfinder display. It displays the camera’s exposure mode and values etc. It also includes a counter with the number of captures remaining on the storage media. (See top bar circled left). ‘99’ is the maximum number displayed.
  • Page 133 Flash Lead Connection A flash cable is always connected to the Hasselblad H1/H2 camera body. The flash sync cable must not be connected to the camera back when used on a Hasselblad H1/H2. The flash sync connector on the IQ back is only intended for use with a Phase One FlexAdaptor or other large format adaptors.

  • Page 134: Iq Back For Contax

    17.0 IQ Back for Contax 645 The Phase One IQ (Contax mount) digital back is designed specifically for the Contax 645 camera. The IQ back communicates with the Contax 645 through a fast internal electrical computer interface and utilizes TTL phase difference detection type auto focus system.
  • Page 135 17.2 Viewfinder Masking The image area of the Contax 645 camera is 56x41.5 mm. A viewfinder mask is only needed for the smaller size of the IQ140 CCD that measures 44x33mm. Viewfinder masking is not necessary for IQ180 and IQ160 models as their light sensitive CCD measures 53.9x40.4 mm.

  • Page 136: More Details: Contax

    17.3 More Details: Contax 645 Exposure Modes The Contax 645 manual (M) and semi-auto exposure modes (Av, Tv) are fully supported by the IQ back. Please note that Bulb is only supported on Contax/ IQ back when used inconjunction with the Live View function. Go to Chapter 20 (from page 143) for more infomation about Live View.
  • Page 137 TTL flash Using TTL flash with the Contax 645 camera and IQ back will result in a 2 f-stop overexposure. When using TTL flash, the exposure compensation on the flash unit must therefore be set to –2 f stops. This overexposure happens because the CCD element reflects light differently than film and this cannot be communicated to the Contax.
  • Page 138 17.5 Cables Shipped with IQ back for the Contax 645 (Value added only) Part# 50300143 Multi connector to Lens sync (for use with Large format - in two shot mode) Part# 50300144 This cable is available as a seperate purchase only. From multi connector to mini jack female (for use to adapt older Large format wakeup cables or older Kapture Group one shot adaptor cables to connect to the multiport).

  • Page 139: Iq Back For View Cameras

    18.0 IQ Back for View Cameras The Phase One IQ back is compatible with most technical view cameras and large format cameras via camera interface adaptors. The IQ back supports most mechanical shutters and some electronic shutters from Horseman, Schneider and other manufacturers. Phase One Sleeping Architecture The Phase One Sleeping Architecture has been developed to help produce noise free exposures without the use of active cooling of the CCD.
  • Page 140 18.1 Using the 2-shot Release The IQ back can be used with mechanical shutters that can be fired twice within four seconds. The first release of the shutter activates the digital back; the second release is for the exposure. If the time limit of four seconds is exceeded, the camera gives a warning ‘beep’...
  • Page 141 18.3 Phase One FlexAdaptor The Phase One FlexAdaptor is available for use with most large format cameras. The Phase One FlexAdaptor can automatically stitch two or three images together using the Stitch function in Capture One. Please see the reference manual that comes with the FlexAdaptor for more details.

  • Page 142: List Of Focusing Screens And Viewfinder Masks

    19.0 List of Focusing Screens and Viewfinder Masks 19.1 Full Frame Focusing Screens or with Engraved Masking Part # 70756 Focusing Screen for Phase One 645 Camera (Standard Full Frame IQ180/IQ160) 70754 Focusing Screen IQ140 for Phase One 645 Camera 70757 Focusing Screen for Phase One 645 Camera SD402 (Checker Grid)

  • Page 143: Live View

    20.0 Live View The Live View funtion is intended for use when a camera is mounted on a tripod and the subject is stationary. Live View is ideal for use with technical view cameras in a studio environ- ment or for architectural photography, where photographers would ordi- narily have to rely on an external viewfinder or a separate focusing glass / sliding adaptor.

  • Page 144: Starting Live View

    20.1 Starting Live View 1. Live View is accessed from the Context Menu (circled left) in the lower right corner. The Context menu is always visible on the Home screen. Tap the lower right corner of the screen to reveal the icon if it is hidden in some of the Play mode displays.
  • Page 145 20.2 White Balance 1. After selecting the White Balance Picker, tap the screen to select a neutral area to calibrate the Live View. 2. If a precise white point is difficult to achieve in full screen view, slide a finger on the left side of the screen to zoom into to a part of the image that you want to use as white reference.
  • Page 146 20.4 Zoom Zoom into the live view by sliding a finger up in the left side of the screen. Double tap on the image to bring up a 100% view. If a zoom is already ap- plied, double tap the screen to return to a full image view. 20.5 Grid 1.
  • Page 147 20.7 Accessories Live View is easily overexposed in due to the high sensitivity of the IQ CCD sensor and its large size. It is sometimes necessary to take steps to prevent overexposure by either stopping down the aperture or by using a Neutral Density filters (ND filters ).

  • Page 148: Live View Camera Support

    1. Open the lens and select the desired aperture value. 2. Activate Live View on the IQ back. Phase One 645AF/645DF 1. Activate Live View on the IQ back. 2. Adjust the exposure time dial until the camera display states ‘time’ .
  • Page 149 Hasselblad V 1. Activate Live View on the IQ back. 2. Select B (Bulb) mode. Mamiya RZ67 Pro II/Pro IID 1. Activate Live View on the IQ back. 2. Select B (Bulb) mode. N.B. It is only possible to change the aperture when the camera body is idle/not exposing.

Table of Contents

Save PDF
