Summary of Contents for PhaseOne 645DF+

  • Page 1 User Guide Phase One 645DF+ Camera and IQ-series Digital Back User Guide: Phase One 645DF+ Camera and IQ2 Series Digital Back...
  • Page 2 Trademarks and Acknowledgements Capture One and Phase One are either registered trademarks or trademarks of Phase One A/S in the European Union and/or other countries. All other trademarks are the property of their respective owners.

  • Page 4: Table Of Contents

    Contents Drive Dial Exposure Modes 3.10 Flash Photography Introduction 3.11 Flash Compensation Settings Warranty Installation and Activation of Software Introduction to the IQ2 Series Digital Back Activation and Deactivation of Capture One Quick Start (shooting untethered) Screen Calibration General Hardware Setup Indicator Lights The 645DF+ Camera and IQ2 Digital Back System Indicators...
  • Page 5 7.1.2 Exposure Program File Format 7.1.3 AF Area Camera Mode 7.1.4 Light Metering Shutter Latency 7.1.5 Custom Function Set 7.10 Image Orientation 7.1.6 Setup Custom A, B or C 7.11 Auto Preview Mode 7.1.7 EV Step 7.12 Display 7.1.8 Lens Change Brightness 7.1.9 Sleep Timer...
  • Page 6 Double Exposure Protection 15.8 Cables shipped with IQ2 back for Hasselblad V 13.1 IQ2 Back and Phase One 645AF/DF/DF+ and Mamiya 645 AFD 13.2 Mounting IQ2 back on the Phase One 645 AF & 16.0 IQ2 Back for Hasselblad H Series Mamiya 645 AFD Series 16.1...
  • Page 7 Image Orientation 17.4 Flash Lead Connection 17.5 Cables Shipped with IQ back for the Contax 645 18.0 IQ Back for View Cameras Phase One Sleeping Architecture 18.1 Using the 2-shot Release 18.2 Using the 1-shot Release 18.3 Phase One FlexAdaptor 18.4...

  • Page 8: Introduction

    The Phase One IQ2 Series system gives you the absolute best solution when it comes to image quality and workflow. Capture One has been optimized for shooting with Phase One IQ digital backs, and is available for both Mac OS X and Windows operating systems.

  • Page 9: Warranty

    To install the software follow the procedure below: 1. Either load the Capture One DVD, or download the application from the Phase One website: www.phaseone.com. 2. Open the Capture One disk image. 3. Read and accept the license agreement presented.

  • Page 10: Activation And Deactivation Of Capture One

    3. Once you have entered the information press the ‘Activate’ button and your software will be validated by Phase One’s activation server. Your software is now activated and ready for use.

  • Page 11: Screen Calibration

    Screen Calibration Having a properly calibrated monitor is a critical factor when viewing im- ages. Ensure that digital viewing conditions are as accurate as possible. A quality monitor and calibration tool should help guarantee that displayed images on a screen are precisely rendered. Once a monitor has been calibrated, the color and brightness controls should be locked to prevent inadvertent changes.

  • Page 12: The 645Df+ Camera And Iq2 Digital Back System

    Classic and Value Added. Unpacking the 645DF+ and IQ2 Digital Back System The Phase One 645DF+ and IQ digital back system is delivered in a case created for the travelling photographer. The dimensions of this waterproof and impact resistant roller case are compatible with most airlines carry-on luggage requirements.

  • Page 13: Value Added

    • 2 lens wrappings • 2 digital back batteries • Dual DB battery charger • 2 Phase One 645DF+ rechargeable Li-Ion batteries • Phase One 645DF+ rechargeable Li-Ion battery charger • DB Multi connector cable • LCC calibration kit and 10x10cm plate •...

  • Page 14: Classic Vs. Value Added

    All the elements of the Value Added kit are available to buy as separate IQ2 Series digital back IQ2 Series digital back spare parts. Please consult your local dealer about the different Phase One Waterproof roller case (with room for or third party solutions if extra equipment is needed.

  • Page 15: Charging The Batteries For The Iq2 Digital Back

    After the first initial charge, the batteries can be charged one at a time. Purchasing Extra Batteries The Phase One IQ back comes with two batteries. Phase One recommends the Canon BP 915 (with more than 2500 mAh) if you need to purchase extra batteries.

  • Page 16: Batteries For Camera (Aa And Rechargeable Li-Ion Battery)

    1 battery + 1 charger. N.B. The rechargeable Li-Ion battery can be used instead of AA batteries with the Phase One 645DF. The uptime of one fully charged Li-ion battery is up to 3 times longer than using standard Alkaline batteries.

  • Page 17: Sleep Mode

    Sleep Mode The camera’s power is switched on when the shutter release mode selector is set to S, C or M.UP. In order to prevent the camera’s batteries from discharging, sleep mode is automatically entered if no operations are performed for a specific period of time while the power is ON (with exposure metering status maintained).

  • Page 18: Attach And Remove Lens

    Attach and Remove a Lens 1. Remove the front body cap in the same way that you would remove a lens; push the lens release button [A] backward and then turn the front body cap or the lens itself counter clockwise and lift out. 2.

  • Page 19: Adjusting The Strap

    Attach a Leaf Shutter Lens Leaf shutter lenses are equipped with an internal shutter. Leaf shutter lenses are capable of high shutter speeds 1/800 sec. or 1/1600 on IQ Series backs with flash synchronization, which is particularly useful for fill-in flash photography in bright ambient shooting conditions.

  • Page 20: Attaching The Iq2 Back

    The IQ back is fully integrated with the camera body and functions as a part of the whole camera system. Ensure that the Phase One 645DF+ camera mirror is up and the shutter is open when no digital back is attached.

  • Page 21: Names Of Parts And Functions (Nomenclature)

    2.10 Names of Parts and Functions (Nomenclature) Hot Shoe Self Timer Button Interval Button Rubber Eye Piece Exposure Mode Dial Main LCD Backlight Button Exposure Metering Mode Button Eyepiece Shutter Lever Focus Point Selector Button Main LCD Mirror* *Do not touch the mirror Rear Dial Set Button Exposure Compensation Button...

  • Page 22: The Displays

    2.11 The Displays Main LCD The display on the camera body will provide you with a lot of valuable infor- mation. This includes many features and settings including, but not limited to shutter speed, aperture value, exposure program, exposure compensations and metering modes.

  • Page 23: Displays, Abbreviations And Electronic Dial Operation

    Liquid Crystal Display 2.12 Displays, Abbreviations and Electronic Dial Operation Due to the limitations of the space and letters, words and letters on the LCD are abbreviated. Electronic Dial Operation Display examples of the main LCD Position Front dial Rear dial Exposure mode Shutter speed adjustment Aperture adjustment...

  • Page 24: The Buttons On The Back

    2.13 The Buttons on the Back The IQ is equipped with four external buttons. The buttons will change Play function to match the menu shown on the sceen. Find out more on the IQ menus from page 75. 2.14 LED Lights IQ Series digital backs feature two main LEDs located below the bottom left corner of the screen.

  • Page 25: Setting Date And Time

    2.15 Setting Date And Time Date and time parameters are set and controlled via the IQ back’s Menu system. If the IQ back has been without power for a long period of time, it will automatically ask you to set the time and date on the next occasion it is powered up.

  • Page 26: Replacing The Diopter Correction Lens

    Replacing the Diopter Correction Lens 1. Press the Eyepiece Lock, which is located in a gap between the Eyepiece Notice: If there is dirt or dust on the lens surface, and the Diopter Correction lens. (Turn the camera upside down to gain easy remove it with a blower or sweep it off access to it).
  • Page 27 27 27...

  • Page 28: Basic Functions

    Basic Functions ISO and White Balance The IQ back’s Home Screen enables quick access to the ISO and WB settings by either pressing the adjacent buttons or by tapping the screen directly. Scroll up and down, then select the setting by tapping the screen next to the desired rating so that a green check mark appears.

  • Page 29: Getting Started: Setting The Shutter Release, Focus, Exposure And Metering Modes

    Getting started: Setting the Shutter Release, Focus, Exposure and Metering modes 1. Set the Shutter Release mode selector lever to S (single-frame advance mode). There are two shutter release (drive) modes: S (single frame advance mode) and C (continuous advance mode). When set to L the power is turned off. 2.
  • Page 30 P: Program AE - The aperture and shutter speed are determined automatically for the optimum exposure, according to the ambient light conditions. This auto mode is best suited for general photography or for novice photographers, as it leaves the user free to concentrate on framing and capturing the subject. Av: Aperture priority AE - Set the desired aperture and the camera selects the correct shutter speed.

  • Page 31: Measuring Light - Exposure Metering

    Measuring Light – Exposure Metering 1. Press button [A] to adjust the exposure metering mode. There are three different exposure metering mode options that are displayed sequentially when either the front or rear dial is turned. Select an appropriate exposure mode.

  • Page 32: Focus Mode

    Focus Modes To use the Auto Focus function, both the camera body and the lens have to be set to their respective Auto Focus modes. Auto Focus does not function when either the camera body or the lens are set to manual focus. To activate Auto Focus (AF), first select AF on the focusing selector ring on the lens.
  • Page 33 Single Focus Mode (S) This mode uses the focus-priority mechanism. The shutter can be released when the focus mark • in the viewfinder is illuminated. This mode is suited for still subjects. Focus is locked when the focus mark • is illuminated in the viewfinder’s LCD.

  • Page 34: Focus Areas

    Focus Areas You can select the focus area that best suits the kind of pictures you intend to take. Push and hold the focus selection button [A] for at least one second; then turn the front or rear dial to select the appropriate focus area. The selected focus area can be seen on the main LCD panel.
  • Page 35 Manual Focusing using the Focus Mark (Focus confirmation method) Half-press the shutter release button and turn the lens focusing ring to focus on the subject. The focus mark is illuminated in the viewfinder’s LCD to signal that a picture is in focus. If ...

  • Page 36: Using Focus Lock And Infrared Focusing

    Using Focus Lock and Infrared Focusing Use the focus lock when the your intended focus point is not within the focus frame. In such cases where a subject is not located in the center of a frame, use the focus lock function to lock the focus before releasing the shutter. 1.

  • Page 37: Drive Dial

    Drive Dial Single-Frame Mode One photograph is taken each time the shutter release button is pressed. Set the shutter release mode selector to S. Continuous Mode Photographs are exposed as long as the shutter release button is pressed. Set the shutter release mode selector lever to C. Photographs are taken continuously at a rate depending on the buffer speed of the digital back mounted on the camera.

  • Page 38: Exposure Modes

    PH (high speed). For slower shutter speeds and wider depth of field, change to PL (low speed). This function allows these changes to be made quickly. Phase One 645 program shift chart (ISO100/AF80mm F2.8 D) 10 11 12 13...
  • Page 39 Aperture Priority AE (Av) Set the desired aperture, and the camera selects the optimum shutter speed NOTICE: The shutter speed value will blink when the accordingly. Use the Av mode to maintain specific control over depth of field, subject is too dark or too bright for a correct exposure.
  • Page 40 Manual Mode (M) NOTICE: This mode is used to set both the aperture and shutter speed for total When the exposure is compensated in the exposure control. Varying shutter speeds can be selected, including “bulb”, Manual mode, the difference between the “tIME”...
  • Page 41 One-push Shift Function When the difference between the set value and metered value is displayed on the viewfinder LCD in the Manual “M” mode, press the AEL button for approx. 1 second and the camera will automatically adjust the shutter speed to achieve the correct exposure based on the set aperture value.
  • Page 42 Exposure Mode Lens Mode Shutter speed X-Sync 1/4000-1/800 1/800-1S 1S - 30S+ 1/4000 - 1/800 1/800 - 1S 1s - 30S+ Program Leaf Shutter — — — — Focal Shutter — 1/90 - 1S — Leaf Shutter — — — —...

  • Page 43: Flash Photography

    1. A grip type flashgun or a strobe (with electric contacts other than X contact) can be operated with the Phase One 645DF+ by connecting a sync cord into the camera’s sync terminal. (See the note in the bottom left corner of the page about flash units designed exclusively for other camera makes.)
  • Page 44 Phase One 645DF+ features TTL (Through The Lens), OTF (Off The Film) and Metz 3952 functions electronic flash exposure metering. A flash sensor located inside the camera body reads the flash light reflected off the surface of the CCD at the moment...
  • Page 45 TTL flash Exposure mode Shutter speed Aperture With TTL flash photography, the reflection of the flash is metered and the Program AE Automatically set by Automatically set by intensity of the flash is adjusted automatically, which can mean TTL flash camera to 1/60 sec.

  • Page 46: Flash Compensation Settings

    3.11 Flash Compensation Settings   By combining a Metz flash and the SCA3952 adapter, the camera adjusts for flash. It can be adjusted within ±3EV in increments of 1/3 steps. 1. Turn on the Power Install the SCA3952 adapter on the Metz flash, and attach it to the camera. Lock the flash in place using the locking knob on the flash shoe.
  • Page 47 Flash Photography with Electronic Flash Models other than Metz units 1. To use a grip type flashgun or a strobe with other electric contacts than X contact, connect the sync cord to the camera’s sync terminal. (See note below about flashes designed exclusively for other makers’ cameras.) 2.

  • Page 49: Introduction To The Iq2 Series Digital Back

    Introduction to the IQ2 Series Digital Back System Overview The Phase One IQ2 Series Digital Back is designed to fit on the Phase One 645DF+ as well as several other brands or models of medium format cameras. The IQ2 Series include three different models; the IQ280, IQ260 and the IQ260 Achromatic.

  • Page 50: Quick Start (Shooting Untethered)

    Quick Start (shooting untethered) 1. Connect an IQ2 digital back to the camera and install the focusing screen if applicable. 2. Charge the batteries (See page 16) then insert them into the camera. 3. Insert a CompactFlash card into the IQ2 Back. 4.

  • Page 51: General Hardware Setup

    An ISO rating can be selected from the menu system (when untethered) or in the Capture Tool in Capture One Pro software (when tethered). Sensor+ technology, built into the Phase One IQ Series models, expands the ISO range from 140 to 3200 at 20 megapixels resolution for the IQ280. The IQ260 models have a Sensor+ ISO range from 200 to 3200 at 15 megapixels resolution.

  • Page 52: Indicator Lights

    Long exposure black reference: In order to capture noise free long expo- sures Phase One digital backs needs to capture a black reference after each capture. This black reference requires the same amount of time as the exposure itself.

  • Page 53: Tethered And Untethered Operations

    Capture One will automatically recognize the IQ2 back and settings shared. (Read more on shooting tethered in the Capture One software manual). N.B: IQ2 backs are compabile with FireWire 400. Please order a Phase One FireWire 800 to 400 cable 4.5M. Part No: 50300164...
  • Page 54 Tethered Operations Continued The display on an IQ2 Series back can be either be turned off while shooting tethered or set to display the images while they are shot, just as if shooting untethered. It is also possible to enlarge a section of an image on the IQ2 screen to help check focus of the current and upcoming captures.
  • Page 55 CompactFlash cards are manufactured by other suppliers and Phase One cannot guarantee that the cards are not defective. Inserting and Ejecting on the IQ2 Back The CompactFlash card is inserted in the hidden slot located under the cover on the left hand side of the IQ back.

  • Page 56: Secure Storage System (3S)

    Secure Storage System (3S) You can always be sure that your data is safe when working with memory cards in a Phase One IQ2 back. The Phase One Secure Storage System (3S) provides the industry’s safest memory card handling. The 3S technology automatically checks your card’s file structure every time it is inserted into...

  • Page 57: Formatting Your Memory Card

    Mac OS X will have the required drivers for the CF card reader. For information on how to import files to Phase One Capture One, please consult the Capture One online user guide available under Capture One Help in the Help Menu.

  • Page 58: Navigating The Iq2 User Interface And Menu System

    Navigating the IQ2 User Interface and Menu System Home Screen The IQ2 Home Screen is the first view users will see as soon as the back is switched on. This is the back’s default screen and the starting point in which to negotiate the menu system.

  • Page 59: Menu Buttons

    Menu Buttons The IQ2 back is equipped with four external buttons. The buttons will change Play function to match the menu shown on the display. The four external buttons are assigned to the Play, Menu, ISO and WB options when the IQ2 back is in its default Home Screen position. (See image left) The function of the four buttons changes once one of the Menu, ISO and WB Menu options has been selected.

  • Page 60: Touch Screen Operation

    Touch Screen Operation All three IQ2 models incorporate a 3.2 inch touch screen. The screen lets you zoom, pan and browse through images fast and it is easy to navigate between different menus and features. The IQ2 series backs are designed with invisible controls that are context sensitive and appear only when specific areas of the screen are touched.

  • Page 61: Iso

    3. Cover your entire camera with a Phase One lens wrap or similar light proof material to eliminate stray light. 4. Remember that when you make a long exposure, the digital back will make a black calibration after the capture of the same duration as the exposure.

  • Page 62: White Balance

    White Balance Push the lower right button or tap WB on the Home Screen. You will be presented with the back’s White Balance settings. Scroll up and down and tap the screen to select the desired setting. A green check mark will appear next to your chosen setting and you will automatically return to the Home Screen.

  • Page 63: Custom White Balance

    Custom White Balance To create a new Custom White Balance, first capture a reference White Balance image. (Try to use a gray card or neutral white surface). Next, select the Context menu and press the White Balance Picker icon. (Ensure that the image is in full screen view) Zoom in and pan to a desired part of the image and then tap on a white/ grey area to create a custom WB.

  • Page 64: Play Mode

    Play Mode Play mode is used to review captured images. Its touch screen interface makes it easy to delete, zoom, pan and browse through images quickly. Push the upper left (external) button or tap Play on the Home Screen to enter this mode.

  • Page 65: Play Mode Views

    Play Mode Views There are three Play mode views: Full Screen, Tool View and Thumbnail View. Full Screen displays an image in its entirety. A Zoom Slider, Context menu too and zoom level percentage will automatically disappear after a few sec- tions of inactivity.

  • Page 66: Play Mode: Context Menu

    Play Mode: Context Menu Press the Context Menu button in the corner of each Play mode. All Context Menus feature three navigation buttons. Select one of the three bottom items (from left to right) to switch to an alternative view. The Full Screen Context Menu features a Delete/Rating, Exposure Warning, Custom White Balance Picker and Grid options.

  • Page 67: Info Bar

    Info Bar The bottom of the screen features an Info Bar that displays a Power Indicator that shows the remaining battery capacity and a FireWire or USB3 icon if the IQ2 is being used to shoot tethered. The Power Indicator will start blinking when it runs low to warn users that the battery needs to be replaced before capturing any more images.

  • Page 68: Delete And Rating

    Delete and Rating Choose the top left button in the Context . A grey bar will appear at the bottom of the screen when reviewing in Full Screen or in the Tool View. Tap the dot in the grey bar to select a star rating from 1 to 5. Alternatively, swipe your finger along the bar to choose a star rating.

  • Page 69: Delete In Thumbnail View

    Delete in Thumbnail View Select the trash icon to Delete images in the Thumbnail View. A trash icon will appear in the Info Bar at the bottom of the screen. Tap each individual thumbnail that you want to delete. (A small red trash icon will appear in the top left corner of the thumbnail).

  • Page 70: Grid

    Grid Select the Context Menu and choose the (circled) icon to overlay a grid on captured images in Full Screen, Tool View and Play modes. Press the Grid icon in Context Menu again to deactivate the Grid. Long press the (circled) icon in Context Menu to configure the Grid. It is possible to select a different Grid Mode, Line Style and Color.
  • Page 71 The Grid Mode provides numerous style combinations. The Rectangular option can be configured to display up to 10 horizontal and vertical lines. In this example (left) the Color has be changed to yellow and the Line Style is Dotted. The Golden Ratio grid helps photographers compose images within some classic proportions.

  • Page 72: Tools

    Tools Play mode features five Tools to aid the capture and the review of images. The Tools include a Exposure warning, a Focus Mask, a Exposure Histogram, a Alignment tool and File Info. Tap the screen to scroll vertically through the tool selection.
  • Page 73 Alignment The Alignment tool helps keep the attached camera in a perfect horizontal or vertical position. Press the Alignment tool once to make it appear full screen. Tap the screen or press the upper left (external) button once to return to the Tool view.
  • Page 74 Exposure Warning Exposure Warning tool highlights areas of a captured image that are overexposed. Tap the Exposure Warning tool once to display any burned out areas of an image with a (default red) color overlay. Tap the Exposure Warning tool again to remove this overlay from view. Long press the Exposure Warning to access a dialog box to alter the Tool’s settings.

  • Page 75: Menu

    Menu The Menu can be accessed by either pressing the lower left exterior button or by tapping Menu directly on the Home Screen. The Menu can be navigated by using the touch screen functionality or by following the Enter, Exit, Up and Down arrows and pressing the corresponding buttons on the IQ2 back.

  • Page 76: Setup C1, C2 Or C3

    The IQ back enables users to set-up custom camera settings when it is used with a Phase One 645DF+ camera. Access the custom functionality via Menu > 645 DF. The 645 DF menu option is only present on Mamiya mount IQ backs.

  • Page 77: Custom Function Set

    7.1.5 Custom Function Set Assign the letter A, B or C to the chosen exposure mode settings in the Custom Function Set menu. N.B. It is possible to see the selected Exposure modes settings from the Setup C1, 2, 3 menu without having to go into the next menu option. 7.1.6 Setup Custom A, B or C The Setup Custom menu enable users to adjust and select 19 camera parameters to attain a precise custom camera set-up.

  • Page 78: Battery Type

    7.1.10 Battery Type The Phase One 645DF+ can be powered by three different battery types. Select the battery type that you want displayed on the external LCD panel to ensure the remaining battery charge is correctly displayed. 7.1.11 Bracketing Select 3, 5 or 7 Exposures as the bracketing width for the auto bracketing setting.

  • Page 79: Ael / Afl Button

    7.1.15 AEL / AFL button Interchange the operations of the front and rear AEL (Auto Exposure Lock) and AFL (Auto Focus Lock) buttons. Find out the location of these buttons on page 21. 7.1.16 Release Button Set the AE Lock and AF operations when the shutter release button is half- pressed.

  • Page 80: Afl

    7.1.18 AFL Set the function of the AF Lock button with one of the following options: While Pressed: Press the AFL to lock focus once. AF operation: This activates AF every time the AFL button is pressed. (It performs the same operation as half-pressing shutter button). Continuous: Locks AF until the AFL button is pressed again.

  • Page 81: Flash Sync

    Flash synchronization is only possible from 1/60th to 1/125 second. (Depending on the flash being used). N.B. The LCD screen on the Phase One 645DF+ will either display a LS (Leaf Shutter) or FS (Focal Shutter) icon to correspond to the shutter speed or...

  • Page 82: Shutter In M/X

    Flash synchronization is only possible from 1/60th to 1/125 second. (Depending on the flash being used). N.B. The LCD screen on the Phase One 645DF+ will either display a LS (Leaf Shutter) or FS (Focal Shutter) icon to correspond to the shutter speed or custom camera setting.

  • Page 83: Active Custom Set

    7.1.26 Active Custom Set Select the desired Custom Set for use. 7.1.27 Restore to Default Select Restore to Default to clear and reset all the current custom settings to the default. Warning! This cannot be undone once selected. 7.1.28 About System This menu screen displays the make and model of the camera and lens being used with the IQ2 back.

  • Page 84: Format Card

    Format Card Select Format Card to erase all data on a memory card. Memory card formatting is done in either FAT 16 or FAT 32 depending on card size. (IQ2 backs support CompactFlash cards formatted in both FAT 16 and FAT 32). WiFi All IQ2 digital backs can connect wirelessly with an iOS device like an iPad®...
  • Page 85 Setting up your IQ2 to connect via Router 1. Turn on WiFi: Menu>WiFi>Mode>On 2. Select network: Menu>WiFi>Select Network 3. Type user name and password as prompted from the network. Connecting Capture Pilot to your IQ2 when using router: 1. From General>WiFi: Select same network as selected on IQ2 2.

  • Page 86: Power Management

    Power Management The Power Management menu option has three criteria to help preserve battery life and help keep operating temperatures low when working in hot conditions. (See below and page 85 for more details). Display Off Time Switch off the IQ’s display screen after 5 seconds, 20 seconds, 1 minute, 5 minutes.

  • Page 87: Check Disk

    Phase One recommends leaving this feature turned on, to maximize data security on the memory cards. This feature can be deactivated in this menu. Read more about the Phase One Secure Storage System on page 56 of this User Guide.

  • Page 88: File Format

    Latency. The recommended setting is Normal Latency if the IQ is used with the Phase One 645DF+. Only change to Zero Latency if you work on technical, large format cameras or certain manual cameras in special situations.

  • Page 89: Auto Preview Mode

    7.11 Auto Preview Mode The Auto Preview option can be switched On or Off. Select On to revert to a Play mode when shooting. Select Off to remain on the same display. 7.12 Display The Display menu option has four options: Brightness, Display Off Time, Splash Screen and Background Image.

  • Page 90: Splash Screen

    Splash Screen Follow the proceeding steps to customize the splash screen on the IQ back. 1.Save the image file to a maximum 800 x 480 pixels resolution (landscape format). A smaller file will also be accepted and placed in the center of the screen with the surrounding space filled with black.

  • Page 91: Background Image

    Background Image Customize the background image on the IQ back Home Screen. 1.Save the image file to a maximum 800 x 480 pixels resolution (landscape format). A smaller file will also be accepted and placed in the center of the screen with the surrounding space filled with black.

  • Page 92: Ready Beep

    7.13 Ready Beep The IQ back will emit a small audio beep after every capture is taken. This Ready Beep signals that a capture has been completed, and that the IQ back is ready for next shot. The Ready Beep can set to either None, Single or Multi. The default setting is Single.

  • Page 93: Restore To Default

    7.16 Restore to Default Select Restore to Default to restore the IQ unit back to its default factory settings. Caution! All previous settings will be lost. 7.17 Firmware It is important to keep the IQ’s firmware up-to-date to ensure you get new features and remove any bugs or errors from previous firmware versions.

  • Page 94: Restore Firmware

    IQ back. This is especially useful if support is needed or if you want to check if Phase One is offering a newer firmware update. Please make a note of the About menu contents (see left) before contacting your dealer or Phase One Support.

  • Page 95: Iq2 Series Digital Back Overview

    IQ2 Digital Back Overview IQ280 IQ260 IQ260 Achromatic The IQ280 is the pinnacle of The IQ260 goes beyond the The IQ260 Achromatic offers pure image quality. The highest norm; it’s made for extraordinary black and white images; no filters resolution captures of any captures.

  • Page 96: Iq280 Digital Back Specifications

    IEEE 1394 interface, Windows XP®, Service Pack 3 or Windows Vista®, Service Pack 1 IQ280 FULL RESOLUTION CAPTURE MODE IQ BACK MOUNTS Resolution 80 megapixel Phase One 645DF + /AF Pixel size 5.2 x 5.2 micron Phase One/ Mamiya Mamiya 645DF + /AFDIII IIQ large: 80 MB...

  • Page 97: Iq260 Digital Back Specifications

    Windows Vista®, Service Pack 1 IQ260 FULL RESOLUTION CAPTURE MODE IQ BACK MOUNTS Resolution 60 megapixel Phase One 645DF + /AF Pixel size 6 x 6 micron Phase One/ Mamiya Mamiya 645DF + / AFDIII IIQ large: 60 MB...

  • Page 98: Iq260 Achromatic Digital Back Specifications

    53.7 mm x 40.3 mm or Windows Vista®, Service Pack 1 Pixel size 6 x 6 micron Image ratio IQ BACK MOUNTS Phase One 645DF + /AF Dynamic range 13 f-stops Phase One/ Mamiya Mamiya 645DF + / AFDIII Phase One H101...

  • Page 100: Advanced 645Df+ Camera Functions

    Advanced 645DF+ Camera Functions NOTICE: After taking pictures using the Exposure Compensation feature, be sure to return Exposure Compensation the exposure compensation dial to the 0 position. In situations providing extreme high contrast, the resulting photograph may be under or overexposed. When this occurs, use the Exposure Compensation The exposure compensation feature is function.

  • Page 101: Ae Lock

    AE Lock AE lock function is useful in a number of shooting scenarios but is particularly useful when capturing panoramic images where a consistent exposure is needed to seamlessly stick images together in post production. The AEL button will lock the Auto-exposure value as the photo is being recomposed.

  • Page 102: Metered-Value Difference Indicator

    Metered-Value Difference Indicator Keep pressing the AEL button [A] and the difference between the metered exposure value and the exposure of the new composition will be displayed on the viewfinder LCD. This function can be used to see if an object of very different brightness levels can be properly photographed.

  • Page 103: Auto Bracketing

    Auto Bracketing NOTICE: Auto Bracketing can be used when it is difficult to determine your exposure When you want to cancel the auto- compensation value. This function automatically captures different exposure bracketing mode, turn the rear dial to change “On” to “OF” variations in succession.
  • Page 104 Single-Frame Mode (S) AE Settings Under Auto-bracketing Mode Press the shutter release button for each shot. The camera meters adequate Exposure Mode Setting exposure value for each shot and performs Auto Bracketing. The camera Program AE Shutter speed varies stays in the Auto Bracketing mode until you cancel the Auto Bracketing mode manually.

  • Page 105: Taking Photos With The Mirror Up

    Taking Photos with the Mirror Up NOTICE: Auto bracketing exposures can be made This function prevents mirror-caused vibrations which may blur an image when the auto bracketing mode is set when shutter speed is slow. A electromagnetic Cable Release RE401 (optional) before taking photos with mirror up.

  • Page 106: Mirror Up Delay

    Mirror Up Delay To change from the Self-timer to the Mirror Up setting, press the shutter button so the mirror goes into the upright position. Once the set time has expired the shutter will release, and the mirror will return to the lower position.

  • Page 107: Bulb Mode & Long Exposure

    Bulb Mode & Long Exposure NOTICE: To make an exposure longer than 30 seconds, adjust the shutter speed As the camera is electronically controlled to “B” (bulb). In order to prevent camera shake, use the RE401 or RS402 even during exposures, it is recommended to replace batteries before bulb exposure.

  • Page 108: Front/Rear Dial Lock Mechanisms

    Front/Rear Dial Lock Mechanisms NOTICE: The setting will be stored after one second. When the Electronic Dial Lock is On, all currently set values in Av (Aperture Priority AE), Tv (Shutter Priority AE) and M (Manual mode) cannot be adjusted Dial lock can not be set when the exposure with the front or rear dials.

  • Page 109: Self-Timer Mode

    9.10 Self-Timer Mode The default setting for the Self-Timer mode to release the shutter is 10 seconds after the shutter release button is pressed. The self timer lamp flashes slowly for the first 7 seconds, and then flashes quickly for the last 3 seconds before the shutter is released.

  • Page 110: Interval Photography

    9.11 Interval Photography Interval photography can used for a variety of shooting scenarios such as such as to capture cloud movement or a flower coming into bloom. Notice: Repeat turning (according to the number of times) will lead to a countdown 1.

  • Page 111: Depth Of Field

    9.12 Depth of Field Depth of field (D.O.F.) is defined as the zone of sharpness before and behind the plane of focus. It depends on distance to subject, focal length of lens, aperture setting and distance the lens is focused at. In addition to visual observation via the depth of field preview button, the D.O.F.

  • Page 112: Infrared Photography

    DO NOT TRY THIS AT HOME! – All corrections in this area must be done by Phase One to ensure precision. If you remove the protective glass or make other physical adjustments on the back the warranty will immediately be void.

  • Page 113: Custom Function

    9.14 Custom Function The custom functions can store separate three different camera set-ups. When at C-00, chose 1 (A), 2 (B), or 3 (C) to store a specific set of user function selections for the group of custom settings from C-01 to C-19. The C-00 is set to 0 which is the settings used for the default set.

  • Page 114: Types Of Custom Functions

    9.15 Types of Custom Functions 0: Alkaline 1: NiCd, NiMH, Li–ion 2: Li-ION (Only for use with Li-Ion battery Kit or Vertical Grip) C-00 Custom functions profile [SEL] 0: None (default=0) C-05 Bracketing [Stno] 1: A Setting bracket’s width for auto bracketing setting 2: B 0: 3 Exposures 3: C...
  • Page 115 C-16 Beep [bu] When the SET button is pressed a beep sounds C-11 AEL function lock/unlock mode [AEL] This function is used to set the method of operating the AEL button to 0: ON (AF) (Default setting) 1: ON lock AE. At the default setting, when the AEL button is pressed, AE is locked;...
  • Page 116 C-97 Support for Mamiya ZD backs This function should ONLY be activated when shooting on a Mamiya ZD back. 0: Default setting NO Mamiya ZD back on the camera body 1: Mamiya ZD back on camera body C-98 Lens firmware version The current firmware version can be checked.
  • Page 117 Custom Functions overview Item Initial setting (0) C-00 Custom Function User Last used User A User B User C C-01 Steps of aperture, shutter speed, Exposure compensation 1/3 EV step 1/2EV step 1 EV step C-02 Aperture setting after lens change Previous aperture value Maximum aperture Minimum aperture setting...

  • Page 118: Custom Dial Modes C1, C2 Or C3

    9.16 Custom Dial Modes C1, C2 or C3 Mode dial options C1, C2 and C3 can be used to store preferred settings. These settings can be changed instantly to suit the photographer's needs. Users can change the settings on the camera body or via an IQ back. Programmable settings are exposure mode, P (program AE), Av (aperture priority AE), Tv (shutter speed priority AE), X (synchro mode), M (manual mode), focus area and spot metering.

  • Page 119: Lenses And Multi Mount

    9.18 Functions of the Phase One Lens The Phase One 80mm f/2.8 is a sharp and well tested digital lens. The lens is mounted by aligning the white dot on the lens with the white dot on the camera body. Carefully mount the lens by turning it clockwise, until a click is heard.

  • Page 120: List Of Alternative Lenses

    MC Arsat 600 f.8,0 Pentacon six Mirror Mamiya 75-150 f.4,5 Mamiya 645AFD Sekor Mamiya 35 f.3,5 Mamiya 645AFD Lenses usable in combination with Phase One Multi-Mount Mamiya 45 f.2,8 Mamiya 645AFD Carl Zeiss CFi 30 f.3,5 hasselblad V Mamiya 55 f.2,8 Mamiya 645AFD Carl Zeiss CFE 40 f.4,0...

  • Page 121: Maintenance

    If the Focusing Screen needs cleaning, send it to the nearest authorized Phase One official Phase One repair center. Do NOT try to repair any camera, lens or back service center. errors or malfunctions – Please consult your local dealer.

  • Page 122: Battery Socket

    10.2 Battery Socket Never leave batteries in the socket if the camera or back is not planned to be used for longer periods. Notice: Make sure to re-install the empty battery Keep contacts clean and dry at all times. case into the body. The empty battery cassette must be External Battery Socket inserted into the body.

  • Page 123: Camera Display Error-Notification

    10.4 Camera Display Error-Notification When Any of These Displays Appear When Any of These Displays Appear... LCD display Causes and remedies Problems Remedies The camera caution mark will blink if the camera body detects an abnormality.

  • Page 124: Lens Maintenance

    Back Maintenance Cleaning the CCD The Phase One IQ back must have the protection plate fitted when it is not attached to a camera. Dust may accumulate on the IR filter, which will degrade the image quality if not removed. Please follow the directions included in the CCD cleaning kit that came with the IQ back.

  • Page 125: 645Df+ Camera Body Specifications

    Shutter speed from 1/4000s to 60 minutes, extremely high flash synchronisation up to 1/1600 second to stop action with fast shutter speed or flash. The mirror and viewfinder of the Phase One 645DF+ camera are almost three times larger than those of 35mm cameras, providing much greater control of focus and composition.

  • Page 126: Phase One 645Df+ Housing Specification

    10.9 Phase One 645DF+ Housing Specification Camera type : 6x4.5cm format, electronically controlled focal-plane shutter, TTL multiple mode AE, AF single Flash control : TTL direct flash control, supports Metz SCA3002 system (SCA3952 Adapter) lens reflex Mirror up shot : Select by pressing the mirror up button.

  • Page 127: Software

    11.0 Software Capture One Pro is a professional RAW converter and image editing software. It contains all the essential tools and high-end performance in one package to enable you to capture, organize, edit, share and print images in a fast, flexible and efficient workflow.

  • Page 128: End User Support Policy

    Please check www.phaseone.com for the latest updated support policy. Worldwide Dealer Network At Phase One we think globally but act locally. Phase One’s products are sold through a worldwide network of dedicated and competent local partners to make after-sales support convenient for you.

  • Page 129: Web Resources

    Twitter, Facebook and Google+ There are plenty of ways to get in touch with Phase One across all the main social media platforms. Finds us on facebook follows us on Twitter and connect with us on Google+ for the latest product news, promotions and...

  • Page 131: Appendix: Open Platform

    Phase One’s Open Platform policy delivers maximum choice and compatibility with a wide range of different camera platforms. This section covers the IQ back’s compatibility with the Hasselblad V and H series, Mamiya RZ67, Phase One 645, Mamiya 645, Contax 645 and View Camera solutions. Double Exposure Protection...

  • Page 132: Iq2 Back And Phase One 645Af/Df/Df+ And Mamiya 645 Afd

    The IQ back communicates with the cameras through a fast internal electrical computer interface. Find out more about the Phase One DF+ camera and IQ back from page 12. 13.2 Mounting IQ back on the Phase One 645 AF &...

  • Page 133: More Details: Phase One And Mamiya 645 Series Cameras

    Studio Flash Sync on the Camera Body A flash sync lead should be connected to the camera body when using the IQ back on Phase One 645AF or 645DF/DF+, Mamiya AFD or AFDII models. Always use a flash cable and/or equipment that provides grounding for the flash.

  • Page 134: Mirror Up

    Drive Dial Shutter Release Button Viewfinder Masking The image area of the Phase One and Mamiya 645 cameras is approximately 56x42 mm. Viewfinder masking is not necessary for IQ280 and IQ260 models as their light sensitive CCD measures 53.9x40.4 mm.

  • Page 135: Iq2 Back For Mamiya Rz67

    The Hasselblad V version of an IQ back can be used on the older version Mamiya RZ PRO II with a Mamiya RZ Pro II adaptor. (Phase One Part# 70964) N.B. It is possible to use a Hasselblad V version of an IQ back on the new Mamiya RZ67 PRO IID by getting the back mount plate modified with the following Mamiya service part number: Y22995-RZ.

  • Page 136: Viewfinder Masking

    14.2 Viewfinder Masking The image area of Mamiya RZ67 at 56x69.5 mm is larger than the size of the three IQ model’s sensors so it is necessary to insert a viewfinder mask. There are two different masks available for the Mamiya RZ67 according to which IQ is being used.

  • Page 137: More Details: Mamiya Rz67

    14.3 More Details: Mamiya RZ67 Mode Selector The mode selector on the trigger button should be turned to the white dot when used with the IQ back. The selector should be set to the orange dot to avoid draining the small battery when the IQ back is attached to the body and not in use.

  • Page 138: Iq2 Back For Hasselblad V Series

    Warning! DO NOT MOUNT WHILE IN S OR RS MODE N.B. The Phase One IQ back should not be mounted while the camera is set to mirror up (S or RS modes). The camera should be set to AS, A or 0 mode.

  • Page 139: Mounting A Viewfinder Mask On A Hasselblad V Series Camera

    15.2 Mounting a Viewfinder Mask on a Hasselblad V Series Camera The image area of a Hasselblad V camera body at approx. 6x6cm is a different size to the three IQ model’s sensors so it is necessary to insert a viewfinder mask.

  • Page 140: More Details: Hasselblad V Series

    15.3 More Details: Hasselblad V Series Sync Cable A sync cable is always connected from the lens to the small connector in the front plate on either the left or right side of the IQ back regardless of which Hasselblad V type camera used. Flash Lead Connection A flash cable is always connected to the F-connector on the IQ back with all Hasselblad V series cameras.

  • Page 141: Hasselblad 555 Eld

    Ensure that the shutter release on the front of the Hasselblad 555 ELD is in the DIG position when using a Phase One IQ back. If for any reason you have to use the 555ELD in Film position (E.g. If the DIG is not working) then set the IQ to Zero Latency.

  • Page 142: Hasselblad 553 Elx

    DIN connector on the Hasselblad. Ensure that A or AS mode are not used. WARNING! Please note that the Phase One IQ back should not be mounted while the camera is set to mirror up (S or RS modes). Make sure that the lens is not jammed or locked open on the “B”...

  • Page 143: Hasselblad 501 Cm And 503 Cw Without Winder

    15.6 Hasselblad 501 CM and 503 CW without Winder The Phase One IQ back can also be used with mechanical Hasselblad cameras such as the 501 CM and 503 CW. These cameras are operated in single shot mode via the shutter release button or a standard cable release.

  • Page 144: Cables Shipped With Iq2 Back For Hasselblad

    15.8 Cables shipped with IQ back for Hasselblad V Classic and Value Added backs come with all the cables needed for the spe- cific camera platform. A Value Added back also comes with an additional 50300143 cable for use with large format and technical cameras. Part# 50300145 Motor cable for Hasselblad ELX.
  • Page 145 16.0 IQ Back for Hasselblad H Series The Phase One IQ (H-mount) digital back is designed specifically for Hasselblad H1 and H2 cameras. 16.1 Mounting the IQ back on the Hasselblad H1/H2 1. Ensure that the mirror is up and the shutter is open. (This is the default position when no cassette is attached to camera body).

  • Page 146: Viewfinder Masking

    16.2 Viewfinder Masking The image area of the Hasselblad H1/H2 cameras is 56x41.5 mm. A viewfinder mask is only needed for the smaller size of the IQ140 CCD that measures 44x33mm. Viewfinder masking is not necessary for IQ280 and IQ260 models as their light sensitive CCD measures 53.9x40.4 mm.

  • Page 147: More Details: Hasselblad H Series

    16.3 More Details: Hasselblad H Series Camera Display The Hasselblad H1/H2 incorporates a screen that displays information about the camera set-up. It shows the aperture value, AF mode, shutter speed etc. The Hasselblad H1/H2 will also display some IQ back information on this screen.

  • Page 148: Viewfinder Information

    Viewfinder Information The viewfinder information bar is located below the image area within the viewfinder display. It displays the camera’s exposure mode and values etc. It also includes a counter with the number of captures remaining on the storage media. (See top bar circled left). ‘99’ is the maximum number displayed.

  • Page 149: Flash Lead Connection

    The flash sync cable must not be connected to the camera back when used on a Hasselblad H1/H2. The flash sync connector on the IQ back is only intended for use with a Phase One FlexAdaptor or other large format adaptors. 16.4 Cables Shipped with IQ back for Hasselblad H No cables are required to use the IQ back with a Hasselblad H1/H2.

  • Page 150: Iq Back For Contax

    17.0 IQ Back for Contax 645 The Phase One IQ (Contax mount) digital back is designed specifically for the Contax 645 camera. The IQ back communicates with the Contax 645 through a fast internal electrical computer interface and utilizes TTL phase difference detection type auto focus system.

  • Page 151: Viewfinder Masking

    17.2 Viewfinder Masking The image area of the Contax 645 camera is 56x41.5 mm. A viewfinder mask is only needed for the smaller size of the IQ140 CCD that measures 44x33mm. Viewfinder masking is not necessary for IQ280 and IQ260 models as their light sensitive CCD measures 53.9x40.4 mm.

  • Page 152: More Details: Contax

    17.3 More Details: Contax 645 Exposure Modes The Contax 645 manual (M) and semi-auto exposure modes (Av, Tv) are fully supported by the IQ back. Please note that Bulb is only supported on Contax/ IQ back when used in conjunction with the Live View function. Go to Chapter 20 (from page 156) for more information about Live View.

  • Page 153: Ttl Flash

    The flash sync cable must not be connected to the camera back when used on a Contax 645. The flash sync connector on the IQ back is only intended for use with a Phase One FlexAdaptor or other large format adaptors.

  • Page 154: Cables Shipped With Iq Back For The Contax

    17.5 Cables Shipped with IQ back for the Contax 645 (Value added only) Part# 50300143 Multi-connector to Lens sync (for use with Large format - in two shot mode) Part# 50300144 This cable is available as a separate purchase only. From multi-connector to mini jack female (for use to adapt older Large format wake-up cables or older Kapture Group one shot adaptor cables to connect to the multiport).

  • Page 155: Iq Back For View Cameras

    18.0 IQ Back for View Cameras The Phase One IQ back is compatible with most technical view cameras and large format cameras via camera interface adaptors. The IQ back supports most mechanical shutters and some electronic shutters from Horseman, Schneider and other manufacturers.

  • Page 156: Using The 2-Shot Release

    18.1 Using the 2-shot Release The IQ back can be used with mechanical shutters that can be fired twice within four seconds. The first release of the shutter activates the digital back; the second release is for the exposure. If the time limit of four seconds is exceeded, the camera gives a warning ‘beep’...

  • Page 157: Phase One Flexadaptor

    18.3 Phase One FlexAdaptor The Phase One FlexAdaptor is available for use with most large format cameras. The Phase One FlexAdaptor can automatically stitch two or three images together using the Stitch function in Photoshop. Please see the reference manual that comes with the FlexAdaptor for more details.

  • Page 158: List Of Focusing Screens And Viewfinder Masks

    (Microprism for non AF lenses) 19.2 Viewfinder Masks Part # 40101906 Viewfinder Mask for Phase One IQ140 for Hasselblad H1/H2 40101903 Viewfinder Mask for Phase One IQ140 for Phase One/ Mamiya 645 AFD 40101905 Viewfinder Mask for Phase One IQ140 for Contax 645...

  • Page 159: Live View

    20.0 Live View The Live View function is intended for use when a camera is mounted on a tripod and the subject is stationary. Live View is ideal for use with technical view cameras in a studio environ- ment or for architectural photography, where photographers would ordi- narily have to rely on an external viewfinder or a separate focusing glass / sliding adaptor.

  • Page 160: Starting Live View

    20.1 Starting Live View 1. Live View is accessed from the Context Menu (circled left) in the lower right corner. The Context menu is always visible on the Home screen. Tap the lower right corner of the screen to reveal the icon if it is hidden in some of the Play mode displays.

  • Page 161: White Balance

    20.2 White Balance 1. After selecting the White Balance Picker, tap the screen to select a neutral area to calibrate the Live View. 2. If a precise white point is difficult to achieve in full screen view, slide a finger on the left side of the screen to zoom into to a part of the image that you want to use as white reference.

  • Page 162: Zoom

    20.4 Zoom Zoom into the live view by sliding a finger up in the left side of the screen. Double tap on the image to bring up a 100% view. If a zoom is already ap- plied, double tap the screen to return to a full image view. 20.5 Grid 1.

  • Page 163: Accessories

    20.7 Accessories Live View is easily overexposed in due to the high sensitivity of the IQ CCD sensor and its large size. It is sometimes necessary to take steps to prevent overexposure by either stopping down the aperture or by using a Neutral Density filters (ND filters ).

  • Page 164: Live View Camera Support

    20.8 Live View Camera Support The Phase One IQ back Live View function is supported on both medium and large format view cameras. Find out how to operate Live View from the following list of cameras: View Cameras 1. Open the lens and select the desired aperture value.

  • Page 165: Mamiya Rz67 Pro Ii/Pro Iid

    Hasselblad V 1. Activate Live View on the IQ back. 2. Select B (Bulb) mode. Mamiya RZ67 Pro II/Pro IID 1. Activate Live View on the IQ back. 2. Select B (Bulb) mode. N.B. It is only possible to change the aperture when the camera body is idle/not exposing.

This manual is also suitable for:

Iq series

Table of Contents
