- Page 1 D I G I T A L S T U D C A M E R A S Y S T E M Digital Camera Back for 4" x 5" Large Format Cameras User’s Guide Edition 3.0 85350002...
-
Page 3: Table Of Contents
Studiokit Digital Camera Back for Large Format Cameras – User's Guide Table of Contents For Your Safety ........................2 Section 1: Introduction......................3 Section 1.1: How it Works...................3 Section 2: Back Panel Description ..................5 Section 3: Mounting and Unmounting the Camera Back ..........7 Section 3.1: Mounting the Camera Back ..............7... -
Page 4: For Your Safety
• Follow all instructions and warnings dealing with your system. • Never try to open any of your Studiokit units; electrical shock may result. If your units require service, contact your licensed Studiokit dealer. Warning: Electrical equipment may be hazardous if misused. Always super-... -
Page 5: Section 1: Introduction
Studiokit Digital Camera Back for Large Format Cameras – User's Guide Section 1 Introducing: The Studiokit Digital Camera Back for 4"x 5" Large Format Cameras The Studiokit digital camera back for large format cameras will enable you to use your usual 4" x 5" large format cameras and lenses to take digital photographs in color. - Page 6 Studiokit Digital Camera Back for Large Format Cameras – User's Guide Protection Legs Dust Cover Handle (in open position) SCSI Connector Scan CCD Sensor Direction Scan Area Fig.1 Back Panel of the Studiokit...
-
Page 7: Section 2: Back Panel Description
Studiokit Digital Camera Back for Large Format Cameras – User's Guide the TIFF file format, which is readable by nearly every other image pro- cessing and desk top publishing program. Section 2 Back Panel Description Referring to Fig.1, the following back panel features can be seen: •... - Page 8 Studiokit Digital Camera Back for Large Format Cameras – User's Guide Fig.2 Studiokit camera back mounted on a Sinar camera...
-
Page 9: Section 3: Mounting And Unmounting The Camera Back
Studiokit Digital Camera Back for Large Format Cameras – User's Guide Section 3 Mounting and Unmounting the Camera Back The camera back fits to your camera just like a normal film cassette. Use the following procedures to mount and unmount the camera back: Section 3.1... -
Page 10: Section 4: Care And Cleaning
Studiokit Digital Camera Back for Large Format Cameras – User's Guide Section 4 Care and Cleaning Your Studiokit camera back is a sensitive and high precision instrument. To keep it working properly, treat it carefully as you would any of your other high quality photography equipment, and take special note of the advice given here. -
Page 11: Section 4.3: Cleaning The Ccd Sensor
After the alcohol evaporates, inspect the CCD for dust. Repeat if necessary. 5. Use one pump of Studiokit anti-static spray (included with your cam- era back) to lightly moisten a new, clean piece of lens paper. Never spray the fluid directly into your camera back. -
Page 12: Section 5: Camera Back Specifications
Studiokit Digital Camera Back for Large Format Cameras – User's Guide Section 5 Camera Back Specifications Fits Standard for 4"x5" large format cameras Exposed Frame 7 x 10 cm (2.76" x 4") 2500 x 3600 pixels per color Maximum Print Size at 150 lpi 21 x 30 cm (8,3"...
