- Page 1 User Manual 深圳开源通信有限公司 OpenVox-Best Cost Effective Asterisk Cards OpenVox DE210E/DE410E User Manual Written by: James.zhu Email:james.zhu@openvox.cn,zhulizhong@gmail.com Date:29/04/2008 Version: 0.01 OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 2 OpenVox Communication Co. Ltd. Address: F/2,Building No.14,Shangsha Science & Technology Park, No.9283,Binhe Road, Futian District,ShenZhen ,Guangdong 518048,China Tel:+86-755-82535095,82535461,Fax:+86-755-82535174 E-Mail：sales@openvox.cn support@openvox.cn IM for Technical Support: support@openvox.cn,zhulizhong@gmail.com Business Hours: 9:00AM-18:00PM from Monday-Friday URL：www.openvox.cn Thank You for Choosing OpenVox’s Products! OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 3 R e f e r e n c e … … … … … … … … … … … … … … … … … … … … … 13 Chapter 4 Hardware Setting……………………………………………………… OpenVox Communication Co. Limited. URL: www.openvox.cn...
-
Page 4: Chapter 1 Overview
Chapter 1 Overview 1. What is DE410E/DE210E The DE410E/DE210E is a bundling of our leading D410E/D210E product and our new EC100 Octasic DSP-based echo cancellation module. The EC100 provides a certified carrier-grade algorithm that has been labeled a benchmark for echo cancellation for OpenVox. - Page 5 Asterisk provides Voicemail services with Directory, Call Conferencing, Interactive Voice Response, Call Queuing. It has support for three-way calling, caller ID services, ADSI, IAX, SIP, H.323 (as both client and gateway), MGCP (call manager only) and SCCP/Skinny(voip-info.org). OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 6 DIP Switch S5 controls the function of each span at E1 or T1 mode. for more detail, please check the switch on the board. CardID: if customers only have one DE410P/DE210P/DE210E/DE410E card in pc PCI express slot, customers should set SW1 to 0, otherwise set to SW1 of each card to different values, and it must start from 0 to card number -1.
- Page 7 User Manual 2. Software Installation and Setup DE410E/DE210E supports original zaptel wct4xxp driver. Customers can download zaptel driver from asterisk.org. There are few steps to install wct4xxp drivers. In this manual, we will use DE410E as an example. 1) Checking the DE410P hardware by command: lspci -v...
- Page 8 # Span 2: TE4/0/2 "T4XXP (PCI) Card 0 Span 2" span=2,2,1,ccs,hdb3 # termtype: te bchan=32-46,48-62 dchan=47 # Span 3: TE4/0/3 "T4XXP (PCI) Card 0 Span 3" span=3,3,1,ccs,hdb3 # termtype: te bchan=63-77,79-93 dchan=78 span=4,4,1,ccs,hdb3 OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 9 => 1-15,17-31 group=2 signalling=pri_cpe channel => 32-46,48-62 group=3 signalling=pri_cpe channel => 63-77,79-93 group=4 signalling=pri_cpe channel => 94-108,110-124 OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 10 User Manual 5) Loading wct4xxp driver for DE410E/DE210E: modprobe zaptel modprobe wct4xxp ztcfg –vvvvvvvv dmesg command shows the card information and drivers. OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 11 User Manual OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 12 6) Starting asterisk by asterisk –vvvvvvvgc and run: zap show channels: Notes: Test environments: OS: Centos 5 Hardware: OpenVox DE410E Drivers: asterisk-1.4.8 and zaptel-1.4.8 No need to adjust Power Supply (3.3 V and 5V) for DE210E/DE410E This manual is workable for DE210E OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 13 Chapter 3 References www.openvox.com.cn www.digium.com www.asterisk.org www.voip-info.org www.asteriskguru.com Trademarks and Copyrights in this user manual: Asterisk® and Digium® are registered trademarks of Digium, Inc. OpenVox® is a registered trademark of OpenVox Communication Co., LTD. OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 14 User Manual Chapter 4 Hardware Setting Figure 3 DE410E/DE210E Hardware Configurations OpenVox Communication Co. Limited. URL: www.openvox.cn...
- Page 15 User Manual Figure 4 EC100 Power Supply Setting (Only for DE210P/DE410P) OpenVox Communication Co. Limited. URL: www.openvox.cn...
