- Page 1 User Manual 深圳开源通信有限公司 OpenVox-Best Cost Effective Asterisk Cards OpenVox DE210P/DE410P User Manual Written by: James.zhu Email:james.zhu@openvox.cn,zhulizhong@gmail.com Date:29/04/2008 Version: 0.01 OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
- Page 2 Address: F/2,Building No.14,Shangsha Science & Technology Park, No.9283,Binhe Road, Futian District,ShenZhen ,Guangdong 518048,China Tel:+86-755-82535095,82535461,Fax:+86-755-82535174 E-Mail：sales@openvox.com.cn support@openvox.com.cn IM for Sales: betty_yljiang@hotmail.com rubyzhang1217@hotmail.com IM for Technical Support: support@openvox.com.cn,zhulizhong@gmail.com,james.zhu@openvox.cn Business Hours: 9:30AM-18:00PM from Monday-Friday URL：www.openvox.com.cn Thank You for Choosing OpenVox’s Products! OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
- Page 3 R e f e r e n c e … … … … … … … … … … … … … … … … … … … … … Chapter 4 Hardware Setting……………………………………………………… OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
-
Page 4: Chapter 1 Overview
Chapter 1 Overview 1. What is DE410P/DE210P The DE410P/DE210P is a bundling of our leading D410P/D210P product and our new EC100 Octasic DSP-based echo cancellation module. The EC100 provides a certified carrier-grade algorithm that has been labeled a benchmark for echo cancellation for OpenVox. - Page 5 Asterisk provides Voicemail services with Directory, Call Conferencing, Interactive Voice Response, Call Queuing. It has support for three-way calling, caller ID services, ADSI, IAX, SIP, H.323 (as both client and gateway), MGCP (call manager only) and SCCP/Skinny(voip-info.org). OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
-
Page 6: Chapter 2 Card Installation And Configuration
DIP Switch S5 controls the function of each span at E1 or T1 mode. for more detail, please check the switch on the board. CardID: if customers only have one DE410P/DE210P/DE210E/DE410E card in pc PCI express slot, customers should set SW1 to 0, otherwise set to SW1 of each card to different values, and it must start from 0 to card number -1. - Page 7 User Manual 2. Software Installation and Setup DE410P/DE210P supports original zaptel wct4xxp driver. Customers can download zaptel driver from asterisk.org. There are few steps to install wct4xxp drivers. In this manual, we will use DE410P as an example. 1) Checking the DE410P hardware by command: lspci -v...
- Page 8 # Span 2: TE4/0/2 "T4XXP (PCI) Card 0 Span 2" span=2,2,1,ccs,hdb3 # termtype: te bchan=32-46,48-62 dchan=47 # Span 3: TE4/0/3 "T4XXP (PCI) Card 0 Span 3" span=3,3,1,ccs,hdb3 # termtype: te bchan=63-77,79-93 dchan=78 span=4,4,1,ccs,hdb3 OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
- Page 9 => 1-15,17-31 group=2 signalling=pri_cpe channel => 32-46,48-62 group=3 signalling=pri_cpe channel => 63-77,79-93 group=4 signalling=pri_cpe channel => 94-108,110-124 OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
- Page 10 User Manual 5) Loading wct4xxp driver for DE410P/DE210P: modprobe zaptel modprobe wct4xxp ztcfg –vvvvvvvv dmesg command shows the card information and drivers. OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
- Page 11 User Manual 6) Starting asterisk by asterisk –vvvvvvvgc and run: zap show channels: Notes: Test environments: OS: Centos 5 Hardware: OpenVox DE410P Drivers: asterisk-1.4.8 and zaptel-1.4.8 This manual is workable for DE210P OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
-
Page 12: Chapter 3 References
Chapter 3 References www.openvox.com.cn www.digium.com www.asterisk.org www.voip-info.org www.asteriskguru.com Trademarks and Copyrights in this user manual: Asterisk® and Digium® are registered trademarks of Digium, Inc. OpenVox® is a registered trademark of OpenVox Communication Co., LTD. OpenVox Communication Co. Limited. URL: www.openvox.com.cn... -
Page 13: Chapter 4 Hardware Setting
User Manual Chapter 4 Hardware Setting Figure 3 DE410P/DE210P Hardware Configuration OpenVox Communication Co. Limited. URL: www.openvox.com.cn... - Page 14 User Manual Figure 4 EC100 Power Supply Setting OpenVox Communication Co. Limited. URL: www.openvox.com.cn...
