HOLIDAY RAMBLER
MOTORHOME LIMITED WARRANTY – 2011
WHAT THE PERIOD OF COVERAGE IS:
This Limited Warranty provided by Monaco RV, LLC ("Warrantor") for your Holiday
®
Rambler
covers those components, assemblies and systems of your new motorhome not
excluded under the section "What is Not Covered" and when sold by an authorized
dealer, for twelve (12) months from the original retail purchase date or the first 24,000
miles of use, whichever occurs first. However, this Limited Warranty covers the internal
steel or aluminum structural support frames inside the walls and roof (excluding slide-
outs) for sixty (60) months from the original retail purchase date or the first 50,000 miles
of use, whichever occurs first. If you use your motorhome for any rental, commercial or
business purposes whatsoever, the Limited Warranty provided by Warrantor covers your
new motorhome when sold by an authorized dealer for ninety (90) days from the original
retail purchase date or the first 24,000 miles of use, whichever occurs first, and it covers
the internal steel or aluminum structural support frames inside the walls and roof
(excluding slide-outs) for twelve (12) months from the original retail purchase date or the
first 24,000 miles of use, whichever occurs first. A conclusive presumption that your
motorhome has been used for commercial and/or business purposes arises if you have
filed a federal or state tax form claiming any business tax benefit related to your
ownership of the motorhome. The above Limited Warranty coverage applies to all
owners, including subsequent owners, of the motorhome. However, a subsequent owner
must submit a warranty transfer form by filing the form and paying the transfer fee. A
subsequent owner's warranty coverage period is the remaining balance of the warranty
coverage period the prior owner was entitled to under this Limited Warranty. Warranty
transfer forms can be obtained by contacting the Customer Relations Department. There
is a one time, $500 processing fee for the transfer.
LIMITATION AND DISCLAIMER OF IMPLIED WARRANTIES:
IMPLIED WARRANTIES, IF ANY, ARISING BY WAY OF STATE LAW,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND ANY
IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE TERM OF THIS LIMITED WARRANTY AND
ARE LIMITED IN SCOPE OF COVERAGE TO THOSE PORTIONS OF THE
MOTORHOME COVERED BY THIS LIMITED WARRANTY. WARRANTOR
DISCLAIMS ALL IMPLIED AND EXPRESS WARRANTIES, INCLUDING THE
IMPLIED WARRANTY OF MERCHANTABILITY AND THE IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, ON
COMPONENTS AND APPLIANCES EXCLUDED FROM COVERAGE AS SET
FORTH BELOW. There is no warranty of any nature made by Warrantor beyond that
contained in this Limited Warranty. No person has authority to enlarge, amend or modify
this Limited Warranty. The dealer is not the Warrantor's agent but is an independent
entity. Warrantor is not responsible for any undertaking, representation or warranty made
by any dealer or other person beyond those expressly set forth in this Limited Warranty.
Some states do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you.
Holiday RambleR limited WaRRanty
WHAT THE WARRANTY COVERS:
Warrantor's Limited Warranty covers defects in the manufacture of your motorhome
and defects in materials used to manufacture your motorhome. "Defect" means the failure
of the motorhome and/or the materials used to assemble the motorhome to conform to
Warrantor's design and manufacturing specification and tolerances. Also see the section
"What the Warranty Does Not Cover" set out below.
WHAT WE WILL DO TO CORRECT PROBLEMS:
Warrantor's sole and exclusive obligation is to repair and/or replace, at its option, any
covered defect if: (1) you notify Warrantor or one of its authorized servicing dealers of
the defect within the warranty coverage period and within five (5) days of discovering the
defect; and (2) you deliver your Motorhome to Warrantor or Warrantor's authorized
servicing dealer at your cost and expense. It is reasonable to expect some service items to
occur during the warranty period. The performance of warranty repairs shall not extend
the original warranty coverage period. Further, any performance of repairs after the
warranty coverage period has expired or any performance of repairs to component parts
and appliances that are excluded from coverage shall be considered "good will" repairs,
which shall not alter the express terms of this Limited Warranty. If the repair or
replacement remedy fails to successfully cure a defect after Warrantor received a
reasonable opportunity to cure the defect(s), your sole and exclusive remedy shall be
limited to Warrantor paying you the cost of having an independent third party perform
repair(s) to the defect(s). Warrantor may use new and/or remanufactured parts and/or
components of substantially equal quality to complete any repair.
Imperfections and/or damage to interior and exterior surfaces, trim, upholstery and
other appearance items may occur at the factory during manufacture, during delivery of
the motorhome to the selling dealer or on the selling dealer's lot. Normally, any such
imperfections are detected and corrected at the factory or by the selling dealer during the
inspection process performed by the Warrantor and the selling dealer. If, however, you
discover any such imperfection or damage when you take delivery of the motorhome, you
must notify your dealer or Warrantor within thirty (30) days of the date of purchase to
have repairs performed at no cost to you in accordance with this Limited Warranty. If not
reported within this time, such imperfections are conclusively presumed to be the result
of normal wear and tear.
If a servicing dealer is unable or unwilling to solve a problem you are convinced is
covered by the Limited Warranty, or that concerns the safety of your motorhome, or that
may involve local consumer protection or "lemon" laws, then you must, to the extent
permitted by law, notify Warrantor directly in writing of the failure to successfully
repair the defect(s) so that Warrantor can become directly involved in performing a
successful repair.
HOW TO GET SERVICE:
The "Acknowledgement of Receipt of Warranty/Production Information" form must be
returned to Warrantor promptly upon purchase to assure proper part replacement and repair
of your motorhome. Failure to return the "Acknowledgement of Receipt of
Warranty/Production Information" form will not affect your rights under the Limited
Warranty so long as you can furnish proof of purchase. For warranty service simply contact


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2011 MOTORHOME and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Holiday 2011 MOTORHOME

  • Page 1 Holiday RambleR limited WaRRanty ® HOLIDAY RAMBLER MOTORHOME LIMITED WARRANTY – 2011 WHAT THE WARRANTY COVERS: Warrantor’s Limited Warranty covers defects in the manufacture of your motorhome WHAT THE PERIOD OF COVERAGE IS: and defects in materials used to manufacture your motorhome. “Defect” means the failure of the motorhome and/or the materials used to assemble the motorhome to conform to This Limited Warranty provided by Monaco RV, LLC (“Warrantor”) for your Holiday...
  • Page 2 Holiday RambleR limited WaRRanty one of Warrantor’s authorized service centers for an appointment, then deliver your DISCLAIMER OF CONSEQUENTIAL AND INCIDENTAL DAMAGES: motorhome (at your expense) to the service center. If you need assistance in locating an THE ORIGINAL PURCHASER OF THE MOTORHOME AND ANY PERSON TO authorized warranty service facility, contact Warrantor’s Warranty Department...
  • Page 3 Sections Section 1 ~ General Information ........2 Section 2 ~ Driving & Safety ........9 Section 3 ~ Exterior & Interior Care ......43 Section 4 ~ Appliances ..........67 Section 5 ~ Equipment ..........81 Section 6 ~ Water Systems ........97 Section 7 ~ Propane Systems ........109 Section 8 ~ Electrical Systems - House ....
  • Page 4: Limited Warranty Transfer

    General Information Section 1 Warranty InformatIon fIle ..........3 reportIng Safety DefectS ............3 Safety termS ................3 gloSSary of termS ..............4 lImIteD Warranty tranSfer ..........7 The information contained in this document is intended to reflect standard and optional equipment included in a typically equipped model at the time of delivery to the initial retail owner.
  • Page 5: Warranty Information File

    Warranty InformatIon fIle In addition to this Owner’s Manual you will find a Warranty Information File in your unit. This file contains valuable documents about your motorhome’s systems and equipment. Many of the component manufacturer’s warranty registration cards can be found in the box. They will need to be filled out and mailed. Be sure you read and understand all the information in this file to help you safely operate, maintain and troubleshoot those items.
  • Page 6: Glossary Of Terms

    ASSEMBLE or REPAIR: Assembly, disassembly or installation of a component or part, and/or repair to the motorhome may be required. Assistance of Technical Support or Technician may be necessary. INFORMATION: References to additional information regarding operation of the motorhome and/or its components found in additional sources, other than the Owner’s Manual.
  • Page 7 Direct Current (DC) - Power that is stored in a battery bank or supplied by photovoltaics, alternator, chargers and DC generators. Direct current is also known as battery power. Current only flows one way. Drain Trap - This is a curve that is in all drains. Water is trapped in the curve and this creates a barrier so tank odors cannot escape through the drain.
  • Page 8 Shore Line - This is the electrical cord which runs from the motorhome to the campground 120 Volt AC electrical supply (30 AMP) or the 120/240 Volt AC electrical supply (50 AMP). Stinger - An arm attachment on a tow truck that is used to lift the motorhome slightly so that it can be towed. Volt - The unit of measure for electric potential.
  • Page 9 lImIteD Warranty tranSfer applIcatIon/change of oWner InformatIon Submitted By: Mail to: Name: Monaco RV LLC Warranty Transfer Address: 91320 Coburg Industrial Way Coburg, OR 97408 City: State: Zip: Phone: ( Please read terms and representations below before signing. Limited Warranty Transfer Address Change A.
  • Page 10 ~noteS~ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ___________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________...
  • Page 11: Table Of Contents

    Driving & Safety Section 2 DrIvIng & Safety � ����������������������������������������������������� 10 WeIghIng the motorhome � ������������������������������������� 32 Inspections������������������������������������������������������������� 10 TirePressure � ���������������������������������������������������������� 35 FamiliarizeYourself � ������������������������������������������������� 10 Scales�������������������������������������������������������������������� 35 SafetySeatBelts � ���������������������������������������������������� 10 Four-PointWeighing������������������������������������������������ 36 TipsforDriving������������������������������������������������������� 12 WeightRecordSheet � ���������������������������������������������� 37 trIp preparatIon�����������������������������������������������������...
  • Page 12: Driving & Safety � ����������������������������������������������������� 10 Weighing The Motorhome

    DrIvIng & Safety This section contains information on driving tips, emergency situations, towing, safety devices, weighing the motorhome and tires.  NOTE: The motorhome has electronic data recording devices that may record information about direction, road speed, engine speed, brake application, steering attitude or other vehicle operating data. Data recording devices can be present in engines, transmissions, ABS (Antilock Brake Systems) or other systems affiliated with operation of the vehicle.
  • Page 13 Child Passenger Safety: Child restraint requirements are determined by age and  weight. According to NHTSA (National Highway Traffic Safety Administration), there are four stages to child restraint safety. CAUTION: Always refer to the child seat manufacturer’s instructions for proper use and installation instructions. 020355 Step 1: For the best possible protection keep infants in the back seat, in rear-facing child safety seats, as...
  • Page 14: TipsForDriving������������������������������������������������������� 12 WeightRecordSheet

    CAUTION: Individual states and Canadian provinces may have laws that can exceed the requirements as described in this section. It is the owner’s responsibility to know and comply with the laws in the state or province in which the motorhome will travel. CAUTION: Use of a safety or booster seat in the front seat may be prohibited in some states and Canadian provinces.
  • Page 15 Driving Cautions: Avoid getting too close to the edge of the road. A soft shoulder may not support the weight of the  motorhome. Side spacing is best maintained by keeping the motorhome centered in the driving lane.  Driving lanes in work zones can be uneven, congested and narrower than usual. ...
  • Page 16: Trip Preparation

    Wipers should be in good condition and the washer reservoir should have sufficient window wash fluid  that has antifreeze included within it. Remove any ice build-up from the entry step to avoid accidental slipping.  Wet Conditions: The risk of hydroplaning is increased if tires are worn or improperly inflated. ...
  • Page 17: Hitch

    CAUTION: Open the cargo door slowly as cargo may shift forward during travel. WARNING: To avoid injury, never place hands near the edges of the bay door when opening or closing. Always use the latch handle. Apply pressure with the other hand just above the latch handle. hItch Using the Rear Receiver When using the rear hitch receiver, remember that the...
  • Page 18 Weight Distributing Hitches: A weight distributing hitch uses spring bars of spring steel to compensate for lack of adequate rear suspension of the tow vehicle. This type of hitch is generally used for towing heavier loads as tongue weight and gross tow weight increases. The spring bars attach to the hitch head assembly and the trailer frame. ...
  • Page 19 WARNING: Be sure the weight ratings of the ball mount, tow ball and safety chains are equal to or greater than the load. Use of an extension to the receiver or extended ball mount will significantly reduce hitch receiver weight ratings. Modifications to the hitch receiver, or use of the hitch receiver other than intended, can void the warranty of the hitch receiver, chassis or both.
  • Page 20: TowPlugConnection � ���������������������������������������������� 18 Maintenance

    DO NOT attempt to wire a tow plug connector if unfamiliar with these systems. A trained technician will install the proper converter so the taillights and turn signals work correctly on the motorhome and towed vehicle or trailer when the tow plug connection is made. Tow Plug Connection The motorhome is pre-wired from the factory with an electrical connection for towing.
  • Page 21: Brake-Parking

    The Five Directional Signals Are: 1. Co-pilot uses left hand and arm held horizontal with forefinger pointing right to direct rear of motorhome to the right.  2. Co-pilot uses right hand and arm held horizontal with forefinger pointing left to direct rear of motorhome to the left. 3. Co-pilot uses both arms and hands parallel with thumbs pointing up and to rear in a waving vertical motion.
  • Page 22: Setup Procedures � �������������������������������������������������� 20 PowerRequirements

    SetUp proceDUreS If the site for the motorhome has full hook-ups, use this quick reference hook-up checklist. This hook-up list is only a guide. Not all instructions will apply due to options and floorplans. This checklist has information on hooking up utilities and preparing appliances for use. Specific information on slide room and awning operations is discussed in detail in other sections.
  • Page 23: Dry Camping������������������������������������������������������������� 21 LowBatteryCondition

    Dry campIng For extended dry camping, resource management is essential. The motorhome has large batteries, plenty of water and ample holding tank capacities. With a little care and forethought, it is possible to go a long way with only the amenities you bring along. Conserve water! The motorhome holds a lot but it goes down the drain fast.
  • Page 24: Breaking Camp��������������������������������������������������������� 22 Operation

    Conserve propane by cooking dinner over the campfire. However, if cooking over the campfire is not  desired, use the cook top. If possible, use the generator (optional) to operate the microwave. Allow the generator (optional) to power up for a couple of minutes before applying a load. ...
  • Page 25: Emergency Roadside Procedures

    Interior Checklist: If applicable, clear slide-out room path, clean floor and make sure bay doors are shut.  NOTE: To operate the slideout, the ignition must be Off, the park brake must be set and the bay doors under the slide room must be closed. Secure and fasten bi-fold and pocket doors.
  • Page 26: JumpStarting��������������������������������������������������������� 24 Cleaning

    Jump Starting Alternative Starting Procedure: A weak or discharged battery will not supply the amount of CCA (Cold Cranking Amps) necessary to initiate and maintain cranking the engine while supplying the required voltage to start the engine. If the engine fails to crank, or cranks slowly due to a weak chassis battery, there are electrical back-up systems that will increase chassis battery voltage.
  • Page 27: Towing Procedures

    Jump Starting Using an External Source: The jumper cables must be connected in a parallel configuration.  That is, positive (+) to positive and negative battery (-) to negative chassis (-). Always connect the positive (+) before connecting the negative (-). To prevent arcing when disconnecting the cables; disconnect the negative (-) before disconnecting the positive (+).
  • Page 28: Tires��������������������������������������������������������������������������� 26 Maintenance

    The drive shaft must be removed to prevent damage to the transmission. Secure the end caps to prevent  losing or contaminating the needle bearings. 020183 020182 020228b WARNING: In case the motorhome requires towing, ensure all precautions are followed. The drive shaft must be disconnected.
  • Page 29: TirePressureInflationGuideline

    An under-inflated tire will also cause poor motorhome handling, rapid and/or irregular tire wear and an increase in rolling resistance that results in a decreased fuel economy. An over-inflated tire will reduce the tire’s footprint/ contact patch with the road, thus reducing traction, braking capacity and handling of the motorhome. Over- inflation of a tire for the load will result in a harsh ride, uneven tire wear and is susceptible to impact damage.
  • Page 30: AirPressureChecklist

    The pressure should be within a couple of pounds of each other on the same axle. Never let air out of a hot tire. When checking the inflation pressure, use a high-quality truck tire air gauge with an angle dual head. This type of pressure gauge can check the pressure of the inner dual wheel that has the valve stem pointing outward and the outer wheel has the valve stem pointing inward.
  • Page 31: LoadInflationTables

    5. If the tire is over-filled, release air by pushing on the metal stem in the center of the valve. Recheck the pressure with the tire gauge. 6. Replace the valve cap. 7. Repeat with each tire. 8. Visually inspect the tires to ensure there are no nails, or other objects, embedded that could poke a hole in the tire and cause an air leak.
  • Page 32: SupportingWhenLeveling

    Supporting When Leveling Extreme caution must be taken to ensure that the tires are fully supported when placing blocks. The load on the tire should be evenly distributed on the support block. In the case of dual tires, distribute the load evenly on blocks for both tires.
  • Page 33: WheelMounting

    WARNING: DO NOT mix tires of different sizes, load ranges or manufacturer brand types or models. Any and all replacement tires must have a rated load carrying capacity equal to or greater than the gross axle weight/load ratings as identified by the federal placard. WARNING: In many instances tire life is not determined by mileage or wear but by age.
  • Page 34: StorageOfTires-LongTerm

    If air wrenches are used they must be periodically calibrated for the proper torque output. Use a torque  wrench to check the air wrench output and adjust the line pressure for the correct torque. Storage of Tires - Long Term A cool, dry garage with a sealed cement floor is the preferred method of storage.
  • Page 35 Incomplete Vehicle Manufactured By – This certification label lists the name of the chassis manufacturer,  date of completion and location of construction. The gross vehicle weight rating and gross axle weight ratings. The tire size, load Incomplete Vehicle Certificate 100230e range and appropriate tire inflation pressure based on gross axle weight Incomplete Vehicle Certificate 100230f...
  • Page 36 CAUTION: Most States limit the amount of weight carried by any single axle position. It is the responsibility of the operator to know the legal weight limit of the State in which they travel. Side roads, surface streets and bridges may further impose weight restrictions. Weight Terms: The following are definitions of terms used when weighing.
  • Page 37: TirePressure

    Tire Pressure The motorhome may weigh slightly heavier on one side. The heaviest wheel position (if applicable) on a single axle will determine the inflation pressure for all tires on that axle due to weight transfer that occurs when cornering. Improperly inflated tires can result in sudden tire failure (blowout). Cargo not properly balanced on the suspension, can result in poor handling, over-stressed chassis components, overloaded wheel positions and/or tires.
  • Page 38 Each wheel position requires weighing to accurately determine the correct tire inflation pressure. When weighing, the scales and the motorhome must be level to obtain accurate scale readings. A definite lean in the motorhome will produce inaccurate scale readings. INFORMATION: The most accurate weighing method is to weigh each wheel position independently.
  • Page 39 Example: The curbside tire is the heavier  wheel position on the front axle weighing Gross Axle 6,200 lbs. Tire pressure for a 295/80r 22.5 Total Axle Weight Roadside Curbside Weight DIfference @ 6200 lbs. according to the Load Inflation Rating (GAWR) Table with load range H will be 95 PSI.
  • Page 40: Smoke Detector

    Smoke Detector Statistics show that most fire casualties are not caused by direct flame, but by less visible smoke (products of combustion). The smoke detector automatically returns from alarm to normal state when the reason for activation, the presence of smoke, is completely removed. Fires are commonly caused by smoking in bed, leaving children unattended or using flammable cleaning fluids.
  • Page 41: Carbon Monoxide Detector

    If these procedures do not correct the problem, do not attempt repairs. If the smoke alarm is within the warranty period and the terms indicate the nature of the problem, return the unit to your dealer. Smoke detectors beyond the warranty period cannot be economically repaired. carBon monoxIDe Detector Carbon monoxide (CO) is a colorless, odorless and tasteless gas that binds with hemoglobin reducing the body’s ability to absorb and carry...
  • Page 42: Alarm

    Operation The detector is not fitted with an on/off switch, it is automatically switched on when the 3 batteries are inserted. This is to ensure that the alarm cannot be inadvertently switched off and therefore fail to detect a build-up of carbon monoxide.
  • Page 43: Fire Extinguisher

    Cleaning Do not wash. Wipe the detector with a damp cloth to remove dust and dry with a soft cloth. Ensure that the holes on the front of the alarm are not blocked with dirt and dust. Do not open the detector for cleaning. Do not paint the detector.
  • Page 44: Escape (Egress) Window

    eScape (egreSS) WInDoW The Egress window, designated for use as an emergency exit, is identified inside of the motorhome by a red locking handle and Exit label. Style #1 Hinges along the outside window top identify the Egress window on the 080427m motorhome exterior.
  • Page 45: Exterior Care

    Interior & Exterior Care Section 3 exterIor care ............44 ceIlIng................ 53 Corrosion � ��������������������������������������������������������������� 44 Wall coverIngS ............54 WinterDriveProtection � ������������������������������������������� 44 WooD care ..............54 Washing����������������������������������������������������������������� 45 coUntertop ............... 56 Drying � �������������������������������������������������������������������� 45 Laminate � ���������������������������������������������������������������� 56 Waxing�������������������������������������������������������������������...
  • Page 46: Exterior Care

    INFORMATION This section is on general cleaning. Some of the articles within “Exterior & Interior Care - Section 3” may not apply to all models. Improper or inadequate maintenance may affect your warranty coverage. Please review this section carefully. For more information, see the terms and conditions of the Limited Warranty in the front of this Manual.
  • Page 47: Washing

    NOTE: No two motorhomes operate under identical conditions. Therefore, maintenance and maintenance intervals will vary. Washing The life of the exterior paint finish can be extended if properly cared for. Periodic cleaning will help preserve the paint finish. The motorhome is painted with a “base coat, clear coat system.” The clear coat is a polyurethane based material which brings out the shine or luster to the base coat paint.
  • Page 48: TireCare

    When selecting a product the container should be marked, “safe for clear coats” or “clear coat safe.” Carefully follow all manufacturer’s application instructions when using a product. Upon first use of a product, try it on a small test spot in an inconspicuous area in case an undesired reaction occurs. Observe the test area from different angles checking for hazing or swirl marks.
  • Page 49: WheelCovers

    Wheel Covers Clean the wheel covers frequently with high pressure water from a hose using a mild detergent. Do not use harsh alkalis, alcohol or acidic cleansers. A secondary hand washing with a soft cloth may be required to remove stubborn road grime. To remove the wheel covers from the wheel for a thorough cleaning use the special tool that was included with the motorhome.
  • Page 50: Interior Care

    WARNING: Some products may contain hazardous materials which require special handling. Read labels carefully. Follow all of the product manufacturer’s safety requirements. InterIor care Cockpit The cockpit area dashboard is a molded fiberglass vinyl wrapped pod. The instrument panel is comprised of various gauges and switches.
  • Page 51: Vinyl

    Many household cleaning solvents are harmful to the color and life of a fabric. Cleaning only by a professional furniture cleaning service is recommended. To prevent overall soil, frequent vacuuming or light brushing to remove dust and grime is recommended. “S”...
  • Page 52 NOTE: Detergents should never be used on a regular or repeated basis for normal cleaning. CAUTION: Powdered cleansers containing abrasives, steel wool and industrial strength cleaners are not recommended for Morbern vinyl. Bird Excreta & Vomit Stains: Sponge the area with soapy water containing a diluted bleach until the stain is removed.
  • Page 53: Ultra-Leather

     TIP: Vinyl requires periodic cleaning to maintain its appearance and to prevent the buildup of dirt and contaminants that may permanently stain or reduce the life of the vinyl if left untreated. Frequency of cleaning and procedures used depend upon the amount of use and the environmental conditions in which the vinyl is subjected.
  • Page 54: VinylFloors

    Pretest the spot removal agent in an inconspicuous area to make  A B C D E F G H I certain it will not damage the carpet dyes. Apply a small amount of the cleaning solution recommended for Use the solution ...
  • Page 55: LaminateFloors

    CAUTION: Flooring may become extremely slippery when wet. Avoid personal injury by wiping up spills and keeping flooring dry. Laminate Floors Laminate flooring used in the motorhome provides style, durability and ease of maintenance. This high-pressure laminated flooring is designed to be incorporated as a floating floor. Laminate flooring is constructed of three main material components.
  • Page 56: Wall Coverings

    WARNING: When using an alcohol solution avoid open flames or hot lighting. Hardwood Vinyl and Decorated Paneling: Hardwood vinyl and decorated paneling are sensitive and demanding materials. Certain cleaning agents will affect the surface on both printed and unprinted vinyl. Use only a mild, non-abrasive detergent and warm water with a soft cloth or sponge for cleaning to protect the material.
  • Page 57 Numerous waxes, polishes and finishing products are available for use. Always follow the manufacture label and instructions. The solid wood surfaces should be cleaned weekly. Dust regularly with a soft, lint-free cloth. Dampen the cloth slightly with water. Wipe one small area at a time and dry immediately. For stubborn stains, use a clean cloth dampened with a solution of mild, non-alkaline soap (like dish washing liquid) and water.
  • Page 58: Countertop

    Re-staining the wood: If bare wood is visible at the bottom of the scratch, the wood will need to be re-stained. To remove damaged varnish, lightly roughen a small area around the scratch with sandpaper, steel wool or synthetic steel wool. Find a stain that is a shade lighter than the wood finish. Stain the bare wood with a very small amount of stain on a rag, brush or cotton swab.
  • Page 59: Condensation

    Condensation Condensation is a natural phenomenon. The amount of condensation will vary with climate conditions, particularly in relative humidity. Condensation occurs from water vapor present in the air. Each of us add more vapors by breathing, bathing, cooking, etc. Water vapor collects wherever there is available air space. When the temperature reaches the dew point the water vapor in the air condenses and changes to liquid form.
  • Page 60: Day/NightShades

    Day/Night Shades The day/night shades are made of polyester blended material. Use the following guidelines to care and maintain the day/night shades: Leave Day-Night shades in the UP position when not in use to help shades hold their shape.  String tension for the shades should be equal.
  • Page 61: Pest Control

    Currently, there are no EPA regulations or standards for airborne mold contaminants. There is simply no practical way to eliminate all mold and mold spores in the indoor environment. For example, studies have shown that ozone cleaners are not effective at killing airborne mold or surface mold contamination. Controlling Mold Growth: ...
  • Page 62 To control pest infestation, eliminate those factors that attract pests, and take immediate steps to remove a pest as soon as the presence is detected. There are a number of steps that can be taken to help in controlling pests: Reduce clutter inside the motorhome and storage bays.
  • Page 63: Storage

    Fleas can be removed by properly treating pets with a veterinarian-approved treatment and a thorough cleaning of the motorhome. Vacuum vinyl areas and tile floors to remove dust, flea larva and flea eggs. Follow by thoroughly washing those areas with soap and water. Carpets must be vacuumed and treated with a residual flea control product labeled safe for indoor carpet and furniture use.
  • Page 64: LongTerm

    Checklist Short Term Storage: If applicable, retract the slide room(s). Do not store the motorhome with slide room(s) extended.  Shut off all appliances. Close the primary Propane shut off valve.  Remove all articles from refrigerator/freezer and clean thoroughly. Prop doors open to prevent mildew. ...
  • Page 65 CAUTION: A 20 Amp service using light duty extension cords and the required adapters create serious voltage losses. Line voltage loss and the resistance at each electrical connection is a hazardous combination and should be avoided. Damage to sensitive electronic equipment may result! Type of surface to park and store the motorhome on: The type of surface the motorhome is parked upon will affect how much moisture accumulation occurs on ...
  • Page 66: Winter Storage

    Electric Motors: Electric motors in the motorhome should be operated occasionally to help lubricate and keep surfaces rotating freely. These items include the roof air conditioners, dash blower motor, furnace motors and powered roof vents. WInter Storage Checklist Plumbing Lines - Drain and protect by filling with approved RV antifreeze. ...
  • Page 67 Shut the engine down. Adjust or add fluids as necessary. Inspect the engine for fluid leaks. Look under the  motorhome for any other type of fluid leaks. Drain, sanitize and flush the fresh water system as outlined in the “Water Systems - Section 6”. Inspect the ...
  • Page 68 ~noteS~ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ___________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ...
  • Page 69 Appliances Section 4 applIanceS - IntroDUctIon ........68 aIr conDItIoner ............74 refrIgerator ............68 Operation���������������������������������������������������������������� 74 OperationSpecifics������������������������������������������������� 68 Maintenance����������������������������������������������������������� 75 ControlPanel���������������������������������������������������������� 69 fUrnace ..............75 ControlPanel-TwoDoor � ���������������������������������������� 69 Operation���������������������������������������������������������������� 75 Doors��������������������������������������������������������������������� 70 WallThermostat � ����������������������������������������������������� 75 StorageProcedures � ������������������������������������������������ 70 IftheFurnaceFailstoLight �...
  • Page 70: Appliances - Introduction

    applIanceS - IntroDUctIon This section covers operation and care of various appliances found in the motorhome. The motorhome is equipped with a refrigerator, cooktop range, microwave, furnace, water heater, roof air conditioner and other optional appliances. Many of these appliances operate on AC or DC current, Propane or a combination of all three.
  • Page 71: ControlPanel

    Important: Operate refrigerator only when level. Level the refrigerator with two torpedo levels. Place the levels in a perpendicular orientation on the bottom shelf of the refrigerator. The bubbles should be at least half-way inside the circles. CAUTION: Leveling the refrigerator. Operating the refrigerator off-level separates chemicals, causing them to crystallize and block the circulation action 020295...
  • Page 72: Doors

    If the propance does not ignite within 30 seconds, the control changes to a different energy source or the gas safety valve closes and F displays. Turn the refrigerator off then back on. If the gas does not ignite after several attempts, consult your dealer or authorized Norcold service center.
  • Page 73: Service

    Service The propane function of the refrigerator, and propane system pressure check require annual service. Over time, the BTU rating of the flame can change, affecting the refrigerator’s performance. Ambient temperature, high humidity and altitude above 5,500 ft. can affect performance and function. If possible, switch mode operation to AC while at a higher altitude.
  • Page 74: Cooktop

    Cleaning Tips for the Microwave: Turn the oven off before cleaning.  Cover food while cooking to keep food spattering to a minimum.  Clean up all spills or spatters before they dry. Wipe up food spatters or spilled liquids with a damp cloth. ...
  • Page 75: Care&Cleaning

    Tips: When cooking at an altitude above 5,000 feet, the flame may change appearance and the flame BTU  output will be lowered. Allow extra cooking time. Do not allow the tips of the flame to extend beyond pan or pot edge. ...
  • Page 76: Air Conditioner

    aIr conDItIoner The roof air conditioner operates from 120 Volts AC shore power. The thermostat controls roof A/C functions and the furnace. INFORMATION: Refer to air conditioner OEM manual for detailed information and operating instructions. Operation System Switch Off – Turns the thermostat off. ...
  • Page 77: Maintenance

    Maintenance Periodically remove and clean return air filter. Filter is located above removable panel in air box .Wash  filters with soap and warm water and to air dry. Never run without filter. Remove and clean air box housing with mild detergent. Never use ...
  • Page 78: IfTheFurnaceFailsToLight

    CAUTION: DO NOT store any items or materials in the furnace area. Restricted air flow may hamper furnace operation leading to failure and/or fire hazard. NOTE: The automatic ignition circuit board will attempt to light the burner three times before the ignition board will go into “lock-out.”...
  • Page 79: BeforeUsingTheWaterHeater

    Two thermostats control water temperature: One for 120 Volt and the other for propane. The water heater manufacturer presets the temperature of both thermostats. Water is pumped into the bottom of the water heater tank and is heated using propane, 120 Volt AC or a combination of both.
  • Page 80: Pressure-TemperatureReliefValve

    Pressure - Temperature Relief Valve The water heater is equipped with a Pressure-Temperature Relief Valve that may discharge during the heating cycle due to thermal expansion of water. The Pressure- Temperature Relief Valve is designed to open when the water temperature within the heater reaches 210°...
  • Page 81: Draining&Storage

    120 Volt AC Operations: Shore power or optional generator is supplying AC voltage.  The water heater is plugged into the receptacle outlet.  The circuit beaker in the Load Center (circuit breaker panel) is On.  Turn the electric water heater switch to On. ...
  • Page 82 ~noteS~ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ___________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ 0...
  • Page 83 Equipment Section 5 eqUIpment - IntroDUctIon ........82 DInette ............... 92 entry Step..............82 DinetteBoothConversion���������������������������������������� 92 entry Door ............... 82 Sofa ................92 Adjustments � ����������������������������������������������������������� 82 Hide-A-BedConversion������������������������������������������ 92 SlIDeoUt operatIon ..........83 commanD central control center ..... 93 Extending&RetractingSlideoutRooms������������������� 84 entertaInment SyStemS .........
  • Page 84: Equipment - Introduction

    eqUIpment - IntroDUctIon This section covers the basic operation and care of various types of equipment found in the motorhome, most of which are provided for entertainment and comfort. More detailed information about specific equipment may be found in that particular manufacturer’s manual. Optional equipment will also be discussed in this section which may not apply to all motorhomes.
  • Page 85: Slideout Operation

    Hinges: The hinges for the door requires slight lubrication annually, or as needed, with any high-quality, dry spray lubricant. Screen Door - Adjusting: The screen door can be adjusted to sit flush in the door jam. This requires two separate adjustments be performed. The first adjustment made is at the screen door latch/catch itself. Loosen the two Phillips screws holding the latch to the door.
  • Page 86: Extending&RetractingSlideoutRooms

    CAUTION: Firmly latch all cabinet doors adjacent to the slide before extending or retracting the rooms. Damage to doors or the fascia may occur. CAUTION: Dirt and grit trapped under the slide room can scratch and damage the floor. Clean the floor before retracting the slide room.
  • Page 87: Troubleshooting

    WARNING: The exterior area must be clear of obstructions that can restrict slide room operation. Ensure there are five or more feet of clear space outside the slideout room prior to extending the room or damage to the slideout, the motorhome or property can occur. When retracting the slideout room, ensure there is sufficient clearance inside the motorhome.
  • Page 88: Roof Vents/Fans

    Cable System: Turn off both the battery and house disconnect switches.  Locate the bedroom slideout motor. The motor is located near  the ceiling of the slideout. Remove fascia trim. Trim may be held in place with Velcro ®   ...
  • Page 89: Power

    Power The power roof vent is operated by pushing the small power switch. The vent must be opened before using the power roof vent. The battery disconnect must be on to operate power roof vent. To close the power roof vent, push in the power switch to stop the fan and close the vent.
  • Page 90: Awnings

    aWnIngS Manual Patio Awning CAUTION: Always use the pull strap to extend or retract the awning. Do not extend or retract the awning by using rafter arms. Serious injury could occur if hands or fingers become pinched in awning hardware. INFORMATION: Refer to the awning OEM manual for more detailed information and operating instructions.
  • Page 91 Adjusting Pitch: 1. Open the arm latch. 2. Adjust outer arm to desired pitch of awning. 3. Close the arm lever. It may be necessary to move outer rafter up and down slightly for the lock pin to engage with hole. 4.
  • Page 92: ElectricPatioAwning(Optional)

    Electric Patio Awning (Optional) The awning operates from 12 Volt DC supplied by the battery. Ensure the battery is charged or hook to shore power. To Extend the Awning: Press and hold the awning switch to Extend.  Allow awning to extend fully then retract slightly until fabric fascia hangs vertical. ...
  • Page 93: Slide-OutCover

    Slide-out Cover The slide-out cover is automatic. When the slide-out moves in or out, the cover reacts to the slide-out direction. A fixed edge of the slide-out cover is installed into an awning rail, mounted just above the slide-out. A spring-loaded roller with special brackets mounts to the slide-out. In a hard rain, the cover helps prevent water from penetrating the seal of the slide-out.
  • Page 94: Dinette

    See “Storm Precautions” for information on the awning settings for proper water drainage. Sometimes soap or chemical residue, such as from active agents in insect fog or sprays, can “wet” the fabric so that it appears unable to repel water. Rinse the fabric thoroughly and test to see if it is water repellent after it dries. If leakage continues after repeating the washing and thoroughly rinsing, please contact Carefree Awning Magic concerning further maintenance.
  • Page 95: Command Central Control Center

    commanD central control center The Command Central Control Center is a central location for many operations of the motorhome. 1. Systems Monitor Panel: Pressing the individual buttons displays the status of the black and grey holding tanks, fresh water tank and Propane tank. Also displays status of battery.
  • Page 96: AntennaSelect

    To Raise the Antenna: Rotate the crank handle clockwise to raise the antenna  (about 14½ turns). Pull down on the outside directional wheel and rotate the antenna until the best picture is obtained. The directional wheel is spring loaded. To Lower the Antenna: Pull down on the directional wheel and align arrows.
  • Page 97: DvdPlayer

    NOTE: For functions regarding the main television make selections (Ant, Cable, etc.) in the area marked FRONT TV VIEWING. For the (optional) bedroom television use the area marked REAR TV VIEWING. To Watch TV from the Antenna: Press the ANT button located in the area marked FRONT TV VIEWING on the video selector box. ...
  • Page 98 ~noteS~ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ___________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ 9...
  • Page 99 Water Systems Section 6 Water SyStemS - IntroDUctIon ......98 toIlet ............... 104 SyStemS monItor ............ 99 LeverFlush����������������������������������������������������������� 104 freSh Water SyStem ..........99 PedalFlush����������������������������������������������������������� 104 CityWaterHookup�������������������������������������������������� 99 Cleaning��������������������������������������������������������������� 105 GravityFill � �������������������������������������������������������������� 99 Maintenance��������������������������������������������������������� 105 Water pUmp ............100 DrainTraps&AutoVents �...
  • Page 100: Water Systems - Introduction

    Water SyStemS - IntroDUctIon This section contains information about the operation and care of various water system equipment found in the motorhome. Optional water equipment will also be discussed, so not all information may be applicable to each motorhome. More detailed information with CAUTION or WARNING instructions for various equipment, other than what is found in this section, can be found in the OEM manuals in the owner information box.
  • Page 101: Systems Monitor

    Indicator Levels SyStemS monItor The systems monitor displays fresh water, grey water, black water, propane levels and battery state of charge. freSh Water SyStem Hookups to external services are located on the roadside. These connections are for city water and the waste water system tank valves. City Water Hookup When connecting the motorhome to city water, use a hose specifically manufactured and labeled for “potable”...
  • Page 102: Water Pump

    Water pUmp The water pump is designed to pressurize the fresh water system when not connected to city water. The water pump must be manually turned on, and is self- priming, operating on demand as water is used. WARNING: Before leaving the motorhome for extended periods of time (i.e. overnight or longer) be sure that the city water and all water pumps have been turned off.
  • Page 103: Water System

    The Water Pump is Noisy or Rough in Operation: Check for plumbing which may have vibrated loose.  Does the mounting surface multiply noise (flexible)?  Check for mounting feet that are loose or compressed too tight.  Look for loose pump head to motor screws (three long screws). ...
  • Page 104: Waste Water Systems

    Turn the water pump OFF.  Drain the fresh water tank. Close the drain and pour the solution into the fresh water tank using the gravity  fill and a funnel. Turn the water pump ON. Open each faucet in turn and run the water until you smell a distinct chlorine ...
  • Page 105: WhatToPutInHoldingTanks

    What to Put in Holding Tanks Black Tank: Before using the toilet, treat the sewage holding tank with water mixed with an odor-controlling chemical. These chemicals are readily available at most RV supply stores. Pour the chemicals into the holding tank through the toilet.
  • Page 106: DrainingTheHoldingTanks

    Draining the Holding Tanks Dumping the Tanks: 1. Connect sewer hose to drain terminal. 2. When preparing to dump the solid waste (Black) tank, first close the liquid waste (Grey) tank valve. 3. Fill the liquid waste (Grey) tank to at least 50% by running water in the shower or sinks.
  • Page 107: Cleaning

    Flushing the Toilet: To add water to the toilet before using, press and hold the pedal halfway until the  desired water level is reached. Generally, more water is required only when flushing solids. To flush the toilet, push the lever all the way down until the sewage leaves the toilet. ...
  • Page 108: DrainTraps&AutoVents

    Drain Traps & Auto Vents Sink and shower drains incorporate a water trap or “P-trap” and auto vents to prevent waste water holding tank odor from entering the motorhome. These P-traps are usually within 54” of a vent tee. These traps must have water in them to block odors.
  • Page 109: UsingAirPressure

    It is recommended to winterize whenever the recreational vehicle is placed in storage or below freezing weather is expected. When the plumbing system is purged with compressed air, antifreeze is not necessary except a small amount to protect P traps and termination valves from freezing. If using FDA approved antifreeze to winterize the plumbing system, several gallons may be required to fill the water lines.
  • Page 110: UsingNon-ToxicAntifreeze

    Using Non-Toxic Antifreeze If you choose to fill the water lines with antifreeze, you will need 5 gallons of FDA RV non toxic antifreeze. 1. Drain the fresh water tank by opening the fresh water tank drain valve. 2. Drain the low point drain valves. 3.
  • Page 111 Propane Systems Section 7 propane SyStemS ..........110 propane hoSe InSpectIon........116 propane Detector ..........111 propane DIStrIBUtIon lIneS ........ 117 Testing � ����������������������������������������������������������������� 112 propane conSUmptIon .......... 117 Alarm � ������������������������������������������������������������������� 112 propane Safety tIpS ..........118 Maintenance��������������������������������������������������������� 113 propane emergency proceDUreS.......
  • Page 112: Propane Systems

    propane SyStemS This section contains safety information and operating instructions for the propane system and related equipment in the motorhome. Some items discussed may not be applicable to all motorhomes. More detailed information with CAUTION or WARNING instructions for various equipment, other than items within this section, can be found in the equipment manufacturer’s manual in the owner’s information box.
  • Page 113: Propane Detector

    Leaks (identified by the odor of rotten eggs or sulfur) can be found by applying a leak detector solution on all connections. Never light a match, have an open flame or use any spark producing equipment or appliance to test for leaks.
  • Page 114: Testing

    Propane Detector Operation: Upon first application of power the LED will flash yellow for three minutes as the detector is stabilizing. At the end of the start cycle the LED will turn green, indicating full operation. If the detector senses unsafe levels of propane it will immediately sound an alarm.
  • Page 115: Maintenance

    Fault Alarm: Should the microprocessor sense a fault in the gas detector, a fault alarm will sound twice every 15 seconds. The LED will alternately flash red to green and the MUTE switch will not respond to any command. The detector must be repaired or replaced.
  • Page 116: TankOperation

    WARNING: Small amounts of propane can escape and evaporate during the fueling process. Protect bare skin. Instant freezing will occur if exposed to liquid propane. Propane exists in both liquid and vapor form within the tank. A full tank is approximately 80% liquid. The pressure inside the tank varies with the temperature of the liquid.
  • Page 117: Propane Regulator

    Basic Facts About Propane Propane detectors are a federal requirement on all propane  equipped recreation vehicles. Propane is a by-product produced by refining oil.  Odor is added to propane after the refining process.  Each liquid gallon of propane produces 1,502 BTU ...
  • Page 118: Propane Hose Inspection

    Damage to the regulator can occur when the tank is overfilled. The regulator is designed to work with vapor only. This is why the tank is filled to only 80% of its liquid capacity. The other 20% allows for vaporization of the liquid. The primary vapor valve is located in the vapor section of the tank.
  • Page 119: Propane Distribution Lines

    Additional suggested maintenance: After performing extensive testing the manufacturer of the flexible propane supply hoses has determined that the hoses be Propane Gauge replaced every ten (10) years as the failure rate may increase after Two-Stage Pro- pane Regulator this period of time. The motorhome manufacturer recommends following this guideline to assure continued safety and dependable use.
  • Page 120: Propane Safety Tips

    propane Safety tIpS Propane is one of the safest and most reliable fuels available on the market when handled properly. Propane, however, does have a great explosive potential if handled improperly. Danger is minimized by becoming familiar with and following a few safety precautions, and by learning how to properly operate propane appliances. Use of propane requires the responsibility of enforcing extra safety measures.
  • Page 121 Electrical Systems - House Section 8 hoUSe electrIcal - IntroDUctIon ...... 120 Battery ..............130 Battery SWItch ............121 HowItWorks�������������������������������������������������������� 130 Style1������������������������������������������������������������������ 121 BatteryTypes�������������������������������������������������������� 131 Style2������������������������������������������������������������������ 121 TestingtheBatteries���������������������������������������������� 131 Shore poWer hookUp ........... 121 ChargeTime&ConsumptionRate � ������������������������ 132 generator prep ............. 123 BatteryRatings�����������������������������������������������������...
  • Page 122: House Electrical - Introduction

    hoUSe electrIcal - IntroDUctIon This section contains guidelines, procedures and information that assist in understanding the electrical system and the operation of various components. Refer to the OEM manuals included in the Owner’s Information File box for their respective, in-depth, individual component operating instructions. Due to variations in options and floor plans, some items and materials discussed in this section will not apply to all motorhomes.
  • Page 123: Battery Switch

    NOTE: When 50 Amp shore service is not available, care will have to be used when operating the appliances and using the outlets to avoid overloading the shore power service. Generator (Optional): The generator can be selected for use when shore power is unavailable. The maximum amount of generator output power, measured in watts, is calculated at an elevation of 500 ft.
  • Page 124 NOTE: If shore power is less than what is rated for the motorhome (30 amp or 50 amp), electrical adapters will be required and power consumption must be reduced to avoid tripping the shore power breaker. CAUTION: Avoid flash damage to the electrical system contacts. Before plugging the motorhome into shore power, starting the generator or using the optional inverter all appliances must be off.
  • Page 125: Generator Prep

    Power Supply: Different amperage supplies vary greatly in the amount of available current. The continuous amount of current through a breaker or fuse is only 80% of its rated capacity.  50 Amp 240 Volt AC shore power service consists of two power supply conductors (120 Volts AC each), ...
  • Page 126: TransferSwitch

    Transfer Switch The transfer switch will automatically transfer AC power from the shore power cord or generator through the transfer switch to the 30 Amp 120 Volt AC breaker panel or the 50 Amp 120/240 Volt AC breaker panel (depending on floor plan and options). In the event both shore and generator power are available, generator power will override 060337 shore power after a 30 second delay.
  • Page 127: StartingTheGenerator

    Starting the Generator Push and hold the control switch in START position until the generator starts. Release switch. The control switch may flash up to 15 seconds indicating engine preheat. WARNING: Excessive cranking can overheat and damage the starter motor. DO NOT crank the engine for more than 30 seconds at a time, in two minute intervals.
  • Page 128: GeneratorFuel

    Generator Fuel There is always a possibility fuel may be contaminated. Any contamination of fuel will greatly reduce the total output of the generator and may cause erratic AC output. Average fuel 4,000 Watts 5,500 Watts NOTE: Consumption (gal./hrs.) (gal./hrs.) The motorhome manufacturer does not cover damage No Load to the generator caused by fuel contamination or to...
  • Page 129: Load Center

    loaD center The motorhome is equipped with a 30 Amp 120 Volt AC load center or a 50 Amp 120/240 Volt AC load center. The load center (circuit breaker panel) contains both AC circuit breakers and DC fuses as well as a power converter.
  • Page 130: Converter

    Converter Fuses Converter The power converter provides filtered 12 Volt DC power to the lighting and appliance circuits. The converter charges and maintains the battery. The power converter is built into the load center. There are some tests that can be performed to ensure the power converter is functioning properly.
  • Page 131: Fuses & Circuit Breakers - 12 Volt Dc

    The electronics monitor the normal current of power flowing to the hot (black) wire through the load (eg. a light bulb or appliance) and coming back on the neutral (white) wire. If a small amount of current comes back on the safety ground wire, the electronics will trip the breaker or outlet, stopping the flow of electricity.
  • Page 132: Battery

    Fuses: BLADe fUSe gUIDe Blade fuses come in three sizes: Mini, Mini Standard Maxi Standard and Maxi. Fuse color determines Black amperage ratings. A blown fuse indicates Gray an over-current condition has occurred. Violet Typically the conductor strip in the center of the fuse is broken, but not always, and Pink ATC Fuse...
  • Page 133: BatteryTypes

    Battery Types Starting Batteries: Starting batteries are designed for high output cranking power, but not for deep cycling like the house batteries are designed to do. Starting batteries will not last long in deep cycle application. The way they are rated should give a good indication of their intended use.
  • Page 134: ChargeTime&ConsumptionRate

    If one cell in a particular battery bank being tested is at a 50% state of charge while the others are indicating a full charge, charge only that battery to see if the low cell will come up. At the same time, do not over charge the healthy cells. If the low cell does not come up after charging, this battery can damage the rest of the battery bank and should be replaced.
  • Page 135: BatteryRatings

    When the inverter is used to operate an AC load, it uses approximately ten times the DC current needed from the battery when inverting 12 Volts to operate the 120 Volt item. Also, a small inverter loses approximately 10% of its efficiency when inverting. For example: When using the inverter to operate an AC electrical item, which has a current draw rating of 2 amps, the inverter will use over 20 amps DC power from the batteries.
  • Page 136 After checking the battery’s electrolyte levels it is also a good idea to check the battery connections for tightness and corrosion. If any corrosion is found disconnect the cables (make sure to mark their locations) and carefully clean them with a mild solution of baking soda and water. There are also aerosol products available that will work.
  • Page 137: Maintenance Records

    maIntenance recorDS BATTERY RECORD SERVICE MAkE TYPE DATE INSTALLED DATE REPLACED MONTHS MILES TIRE RECORD LOAD DATE MAkE SIZE REPAIRS MILES RANGE INSTALLED 1...
