W
arranty & Information
W
arranty & Information
General Information
In time you will develop a knack
for spotting wonderful little roadside
locations by turning off the main
highway and exploring. There are
many modern recreational vehicle
parks (including state, county, and
federal parks) with good facilities
where you can obtain hook-ups for
electrical, water, and sewage connec-
tions. Directories are published which
describe these parks and the avail-
ability of services and hook-ups. On
overnight or weekend trips chances are you will not fill up the sewage holding tank,
deplete the water or LP gas supply, or run down the batteries which supply the living area
12 volt DC current. On longer trips when you have stayed where sewer connections and
utility hook-ups were not available it will be necessary for you to stop occasionally to
empty the holding tanks, and to replenish your water and LP gas supply. Many gas sta-
tions have installed sanitary dumping stations. Publications are available which list
these dumping stations. When you stop for the night your Holiday Rambler motor home
is built to be safely parked in any spot that is relatively level and where the ground is
firm. Try to pick as level a parking spot as possible. Your facilities are with you, you are
self-contained.
!
These safety alert symbols mean CAUTION or WARNING - "Personal Safety
Instructions". Read and understand instructions where these symbols are
displayed in this manual. Failure to comply with specific instruction may
result in personal injury or death. Many instructions are required by the
National Safety Associations.
Customer Relations
Only by insuring your confidence and satisfaction with our products and services
can we have continued success as a manufacturer of motor homes. We believe a good
relationship with our customers is just as important as improving the technical excel-
lence of our products. Your authorized dealer is pleased to help you with instructions
about your motor home and to offer service when you need it. Most problems arise from
misunderstandings about warranty or service needs. If problems remain after you have
consulted your dealer you are invited to contact our Consumer Affairs Department.
Please have all pertinent information (serial numbers, model number, etc.) when calling
We will work with the dealer and see that every attempt to resolve the matter is made.
H
OLIDAY
Admiral
R
AMBLER
2000
1-1
