Summary of Contents for Holiday Savoy LX 2006
- Page 1 Savoy SL & LX 5th Wheel & Travel Trailer Sections General Information ~ 1 Driving & Safety ~ 2 Exterior & Interior Care ~ 3 Appliances ~ 4 Equipment ~ 5 Water Systems ~ 6 LP-Gas Systems ~ 7 Electrical Systems ~ 8 Index ~ pp 149...
- Page 2 The information contained in this document is intended to reflect standard and optional equipment included in a typically equipped model at the time of delivery to the initial retail owner. Your actual unit may vary from this document as a result of optional equipment that is not generally offered on this model.
-
Page 3: Table Of Contents
Savoy SL & LX 2006 General Information — Section 1 Safety termS...............5 GloSSary of termS.............5 reportinG Safety defectS ..........8 Survey.................9 limited warranty application/ chanGe of owner information........11... -
Page 5: Safety Terms
Safety termS WARNING - Information pertaining to personal safety and/or potential extensive or permanent damage to the recreational vehicle. CAUTION - Information pertaining to potential damage to the recreational vehicle and/or its components. DANGER - Information pertaining to danger or caution of potential electrical shock to person(s) or component(s), and/or risk of electrical fire to recreational vehicle. - Page 6 Black Water - Term associated with the sewage holding tank. The toilet drains directly into this tank. British Thermal Unit (BTU) - Heat required to raise or lower temperature of one pound of water by 1° F. Circuit - Electric circuit:path of an electric current. Closed circuit: complete path. Open circuit: broken/disconnected path.
- Page 7 Full Hook-Up Site - A campground that has city water, shore power and sewer hook-ups or connections available. Grey Water - The waste water holding tank. Water from sink drains, shower and washer/dryer (if equipped) go in this tank. H,I,J,K House Battery - Powers 12 V lights and accessories inside recreational vehicle.
-
Page 8: Reporting Safety Defects
Wet Cell Battery - A type of battery that used liquid as an electrolyte and requires periodic maintenance. Manual addenduMs & Tech Tips www.monaco-online.com Click on the holiday Rambler logo, Place curser on seRVice link and choose either Manual addenduMs or Tech Tips from the drop down menu. -
Page 9: Survey
Owner’s Manual Survey 2006 Savoy SL & LX 5th Wheel & Travel Trailer Your suggestions are very important to us and we are continually striving to improve the quality of our manuals. After becoming familiar with your new recreational vehicle and the accompanying manual, please take the time to answer the following questions. -
Page 11: Limited Warranty Application/ Change Of Owner Information
Limited Warranty transfer appLication/change of oWner information submitted By: Mail to: Name: Monaco coach corporation p.O. Box 465 Address: Wakarusa, in 46573 attn. Warranty Registration City: State: Zip: Phone: ( Please read terms and representations below before signing. Limited Warranty Transfer Address Change a. - Page 13 Savoy SL & LX 2006 Driving & Safety — Section 2 Driving & Safety introDuction...... 1 5 BrakeS................37 tow vehicle............... 1 5 BrakesSynchronization...........37 tipS for Driving............15 Controllers............... 3 8 checkliSt - trip preparation.........17 Maintenance.............38 hitching the fifth wheel........18 Breakaway Switch........... 3 9 ConnectingtheHitch............
-
Page 15: Driving & Safety Introduction
Driving & Safety introDuction Towing the recreational vehicle may be an unfamiliar experience. Find out what gears are right for the vehicle. For sharp turns, reduce speed and swing wide after considering other traffic and obstacles in the intersection; do not be afraid to pull well into the intersection before making a turn. - Page 16 When traveling, make sure bridges can support the combined weight of the tow vehicle and recreational vehicle. Tonnage limits for bridges should be posted at entrances. Check the posted height of overhead clearances. Keep in mind road surfaces may have been repaved or become packed with snow. Therefore, the actual posted clearance height would not apply.
-
Page 17: Checklist - Trip Preparation
Night Driving: • Be well rested and alert when driving. If necessary, find a safe stopping place to rest until ready to continue. • Avoid using any interior lights while driving. They can create a glare on the windshield, decreasing visibility. -
Page 18: Hitching The Fifth Wheel
• Polarity tester: to check 120 AC outlets. Driving Preparations: GARDNER BENDER, INC • Check operation of all exterior lights, headlamp, taillight, brake and clearance lights. • Check tire pressure. OPEN GROUND OPEN NUETRAL • Check house battery condition. OPEN HOT HOT/GRD REVERSE HOT/NEU... -
Page 19: ConnectingTheHitch
Connecting the Hitch Begin by backing the tow vehicle close to the fifth wheel. Some tow vehicles have a tail gate cutout for the kingpin to pass through, while other tow vehicles require the tailgate be lowered. • Align the tow vehicle hitch with the fifth wheel hitch pin. Back up the tow vehicle so the hitches are about two feet apart. -
Page 20: Hitching The Travel Trailer
When using lubrication pads make it a matter of routine maintenance to inspect for pad wear. Before and after each trip, all nuts, bolts, safety pins and other hitch related hardware should be inspected. 1. Inspect the kingpin box mounting bolts at least every 2,000 miles. Using a torque wrench, tighten kingpin box bolts to 60 to 70 ft. -
Page 21: TypesOfHitches
Types of Hitches Weight-Carrying Hitch: The tow vehicle rear axles and tires, with a weight carrying hitch, must carry all trailer tongue weight. With heavier trailers this causes the vehicle to lower itself over the rear axle, causing a weight shift from the front wheels. -
Page 22: RideHeightAngle
• Attach breakaway cable to the tow vehicle, allowing enough slack for making tight turns. The breakaway switch cable should be attached to a place on the tow vehicle separate from the hitch assembly. Periodically pull out the breakaway switch pin and attempt to drive forward. If the breakaway system is operating correctly the trailer wheels will not turn. -
Page 23: Backing Up The Recreational Vehicle
Backing up the recreational vehicle When backing up the driver should be comfortable using the mirrors and/or the co-pilot’s directions for assistance. Practice using the co-pilot’s guidance in a large, unobstructed parking lot. Select a solid, level site, located on the roadside with a direct field of vision from the roadside mirror. If the site is on the curbside the driver will have to use the curbside mirror for backing up, which has a blind spot. -
Page 24: Parking&Leveling
Parking & Leveling The selected site must be as level as possible. This will ease the leveling process. After backing in or pulling the recreational vehicle into the selected site, set the parking brake, turn the ignition switch OFF and proceed as follows: Fifth Wheel Operation: •... -
Page 25: Landing Legs (Fifth Wheel)
• Connect the 120 Volt AC shore power. • Open the LP-Gas valves at the LP tanks. • Connect the fresh water supply and the water systems if necessary. • If applicable, start the refrigerator, water heater and furnace. NOTE: In extreme cases the use of leveling ramps under the tires may be necessary to level the recreational vehicle. -
Page 26: HitchJack(TravelTrailer)
NOTE: Landing legs may work with handle if the electric drive motor is inoperative or if electricity is unavailable. WARNING: The handle could cause injury. Remove the handle before using the electric motor. The handle may jerk, causing injury. Before towing, check for maximum clearance between the ground and the bottom of the landing gear. -
Page 27: PowerJack(TravelTrailer-NotOnAllUnits)
WARNING: The handle could cause injury. The handle may jerk, causing injury. Before towing, check for maximum clearance between the ground and the bottom of the landing gear. Power Jack (Travel Trailer - Not on All Units) The power jack makes trailer positioning hassle free. A rugged 12 Volt DC gear motor provides quick and easy hitching and unhitching of the trailer. -
Page 28: Checklist - Set-Up Procedures
WARNING: The stabilizer jack(s) must not be used for leveling on uneven ground or to change tires. Never use jack(s) to elevate any wheel off the ground. Damage to the stabilizer jack(s) and recreational vehicle main frame can occur. checkliSt - Set-up proceDureS The hook-up list is to only be used as a guide. -
Page 29: Breaking Camp
Setting Up for Dry Camping: • Switch refrigerator operation to LP-Gas. • Operate the water heater on LP-Gas. Turn it on about an hour before hot water is needed. • If the furnace is needed at night, set the thermostat temperature lower to prevent the furnace from cycling through the night. -
Page 30: Emergency Roadside Procedures
• Close all cabinet doors and drawers. • Turn off water heater, water pump and furnace. • Walk through the interior and check for any unsecured items. • Turn the interior lighting off. Departure Checklist: • Check items in storage bays to make sure shifting or damage of items will not occur. •... -
Page 31: ImportanceOfAirPressure
Modern tire technology blends a unique mix of chemistry, physics and engineering to provide a high degree of performance, efficiency, reliability and safety. To obtain the maximum wear and best service of the tires it is helpful to understand the components and function of the tires. NOTE: Tires can degrade over time. -
Page 32: TirePressureInflationGuideline
Tire Pressure Inflation Guideline Federal law requires specifications for the tire maximum load rating be molded on the sidewall of the tire. Air pressure amounts depend on the weight of the recreational vehicle when fully loaded. “Tire Inflation Chart” in this section shows weights supported by various air pressures. -
Page 33: AirPressureChecklist
Lower than Recommended Pressure can Cause: • Tire squeal on turns. • Reduced handling. • Rapid and uneven wear on the edges of the tread. • Separations. • Tire rim bruises and rupture. • Circumferential Breaks. • Tire cord breakage. •... -
Page 34: TireRotation
After a tire rotation, the inflation pressures should be checked and adjusted accordingly for the actual loads of the wheel position. Tires are under warranty by the tire manufacturer. Holiday Rambler is not responsible for tire wear. It is recommended that the tires be rotated every 5,000 miles. -
Page 35: SupportingTiresWhenLeveling
Supporting Tires When Leveling Extreme caution must be taken to ensure that the tires are fully supported when placing blocks under the tires. The load on the tire should be evenly distributed on the support block. In the case of dual tires, distribute the load evenly on blocks for both tires. -
Page 36: Wheel Mounting
∙ Remove the wheel and tire. ∙ Follow the procedures under “WHEEL MOUNTING” to mount the replacement tire. ∙ Lower jack and stow the jack, wood plank and wrenches. WARNING: Never allow anyone to go under the axle and trailer while it is being lifted by the jack. Sever injury or death can occur. -
Page 37: Brakes
06 savoy torque chart 130154 BrakeS The electric brakes on the recreational vehicle are similar to the drum brakes on the automobile. The difference is that automotive brakes are actuated by hydraulic pressure while electric recreational vehicle brakes are actuated by an electromagnet. With all of the brake components connected to the system, the brake will operate as follows: When electrical current is fed into the system by the controller it flows through the electromagnets in the brakes. -
Page 38: Controllers
or amount of deceleration of the tow vehicle. It is important that the brake control provide about 2 Volts to the braking system when the brake pedal is first depressed and gradually increases the voltage to 12 Volts as brake pedal pressure is increased. -
Page 39: Breakaway Switch
1. Jack up recreational vehicle and secure on adequate capacity jack stands. Follow recommendations for lifting and supporting the unit. Ensure wheel and drum rotate freely. 2. Remove the adjusting hole cover from the adjusting slot on the bottom of the brake backing plate. 3. -
Page 40: Weight Terms
weight termS The Gross Axle Weight Rating (GAWR) of the axles listed on the federal certification label attached to the recreational vehicle is the maximum allowable loaded weight on an axle. When the actual loaded weight of the recreational vehicle and the weight on each axle is unknown, follow the recommended tire inflation pressure(s) listed on the federal certification label. -
Page 41: Weighing The Fifth Wheel/Travel Trailer
weighing the fifth wheel/travel trailer Tire Pressure: A recreational vehicle may weigh slightly heavier on one side than on the other. Tire inflation pressure of the heavier side tires determine the inflation pressure for all tire(s) on that axle due to the weight transfer that occurs when cornering. -
Page 42: WeightLabel
Weight Label 100179f 42 • Section 2 — 2006 Driving & Safety Savoy SL & LX 5th Wheel & Travel Trailer... -
Page 43: Fifth Wheel/Travel Trailer And Tow Vehicle Weighing
Fifth Wheel/Travel Trailer and Tow Vehicle Weighing READING 1 - Tow Vehicle and Hitch Weight: Level and loaded for a recreational vehicle. Reading 2 - Tow Vehicle Only: Loaded for recreational vehicle. Reading 3 - GAW Gross Axle Weight Entire unit on scale level and loaded for recreational vehicle. - Page 44 The following procedure is used to determine tire pressures and ensure that gross axle weight ratings are not exceeded. The recreational vehicle must be weighed fully loaded with water, LP-Gas and cargo. All slide-out rooms must be in retracted position. •...
- Page 45 Load and Inflation Tables: The load and inflation table helps to determine the correct inflation for the recreational vehicle tires, after properly weighing the recreational vehicle. All pressures are rated at a cold psi. Cold conditions are defined as early in the morning before the day’s ambient temperature, sun’s radiant heat or the heat generated while moving have caused the tire pressure to temporarily increase.
- Page 46 NOTE: Following weights are fictitious, actual weights will vary with models and options. • Record GVWR and UVW weights from the GVWR =CCC recreational vehicle weight label. FORMULA 10,100 7,540 2,560 Subtract • Record the gallons of water and LP-Gas that FRESH WATER 50 x 8.3 = 415 2,145...
-
Page 47: FourTireWeighing
Four Tire Weighing Savoy SL & LX 5th Wheel & Travel Trailer 2006 Driving & Safety — Section 2 • 47... -
Page 48: Smoke Detector
Smoke Detector Statistics show that most fire casualties are not caused by direct flame, but by less visible smoke (products of combustion). The smoke detector responds to both visible and invisible products of combustion. The smoke detector automatically returns from alarm to normal state when the reason for activation, the presence of smoke, is completely removed. -
Page 49: Troubleshooting
Troubleshooting If the alarm does not sound when the test button is pushed, or with a smoke test, try the following: • Inspect alarm for obvious damage. • Check for the recommended battery type. • Check the battery for proper connection or replace the battery if needed. •... -
Page 50: Egress Exit Window
There are three classes of fire to be concerned with in a recreational vehicle. Any fire can fall into more than one class; a fire that involves both burning paper and kitchen grease would be a Class AB fire. Classes of Fire: A - Fires that are fueled by materials that leave a residue when they burn: paper, wood, cloth, rubber, and certain plastics. - Page 51 Savoy SL & LX 2006 Exterior & Interior Care — Section 3 ExtErior CarE..................53 Undercarriage..................53 Washing....................53 Waxing....................53 Bright.Metal....................54 Roof.Care....................54 Seal.Inspection..................55 intErior CarE..................55 Fabrics....................55 Vinyl.......................55 Floors.-.Carpet.Cleaning................56 Floors.-.Vinyl...................57 Wall.Coverings..................58 Wood.Care....................58 Countertops.-.Laminate................58 Windows....................58 Condensation..
-
Page 53: Exterior Care
ExtErior CarE Undercarriage The most common cause of corrosion to the recreational vehicle is the accumulation of road salt, grime and dirt. These elements, combined with moisture, may possibly cause early component failure. Salt air and fog from coastal trips can greatly accelerate the corrosion process. Corrosive materials collected from roadways accumulate on the undercarriage and around wheel openings. -
Page 54: Bright.metal
Waxes: Waxes come in many chemical make-ups. The popular Carnauba wax is a naturally occurring wax from the leaves of the Carnauba palm tree. Mineral waxes have a paraffin base. Other topical application products also contain silicone. Polishes: Polishes usually contain a combination of wax based substances with an abrasive, getting the two for one idea. -
Page 55: Seal.inspection
Seal Inspection Periodic resealing of the joints and seams is necessary to prevent the entrance of moisture into the recreational vehicle. Extreme damage from a water leak can occur rapidly. Never leave the recreational vehicle unattended with the slide room extended. If the recreational vehicle is stored outside in winter months, a full interior inspection for water leaks should be made bi-monthly. -
Page 56: Floors.-.Carpet.cleaning
Detergents should never be used on a regular or repeated basis for normal cleaning. CAUTION: Powdered cleaners containing abrasive, steel wool and industrial strength cleaners are not recommended for Morbern vinyl. CAUTION: Lacquer solvent will cause immediate irreparable damage to vinyl. Do not use wax on vinyl upholstery, as it will cause premature embrittlement and cracking. -
Page 57: Floors.-.Vinyl
A. Dry Cleaning Fluid: A nonflammable spot removal liquid, available in grocery and hardware stores. B. Nail Polish Remover: Any acetate, which often has a banana fragrance. Do not use if it contains acetone. C. Detergent Solution: Mix two cups of cold water and 1/8 teaspoon mild liquid detergent (no lanolin, non-bleach). -
Page 58: Wall.coverings
Wall Coverings Time is very important when removing substance that are solvent based or contain color from wall coverings. Do not use abrasive cleaners containing chlorine bleach or solvent (Fidelity and Jolie brands are recommended). Always begin with a mild detergent or soap and warm water. To remove normal dirt clean with a soft sponge. Rinse and wipe it dry. -
Page 59: Mold.&.Mildew
Controlling Moisture Condensation: Reduce or eliminate interior moisture condensation during cold weather by using the following steps. • Partially open the roof vents and windows so that outside air can circulate into the interior. Increase the ventilation when large numbers of people are in the recreational vehicle. Even in raining or snowing conditions the air outside will be far drier than the interior air. -
Page 60: Mini-Blinds
Mini-Blinds To maintain the mini-blinds, on a frequent basis vacuum with the brush attachment or use a dusting tool designed specifically for mini-blinds. Wash the mini-blinds with mild soap and water in a tub or hang the blinds on a fence or wall and gently rinse them with a hose. Night Shades The night shades are made of a polyester blended material. - Page 61 If the Recreational Vehicle is Stored in a Location Where AC Power is NOT Available: • Turn off all appliances. • If possible, situate the recreational vehicle so the batteries remain accessible. This allows a battery to be charged or replaced without moving the recreational vehicle. •...
-
Page 62: Winter.storage.-.Checklist
If the Recreational Vehicle is Stored Outdoors: • The interior should be heated to help prevent mold and mildew growth. Moisture removing desiccate filter systems are available from hardware and RV supply stores. Place the filter system inside the recreational vehicle to reduce inside moisture condensation or humidity. -
Page 63: Storage.-.Removal
Holding Tank - Drain and rinse. Close valves. Add a small amount of antifreeze to keep valves and gaskets lubricated. Drain Traps - Pour RV antifreeze down all drains. Refrigerator - Clean and leave the door propped open. Cover the exterior panels and roof vents. Batteries - Check, add distilled water and recharge if needed. -
Page 64: Lubrication & Maintenance
• Have a qualified technician inspect the LP-Gas system and perform a gas leak test. The leak test should also include a regulator adjustment (if needed). The test can also verify if the regulator is faulty and should be replaced. Have the LP-Gas tank inspected. •... - Page 65 Savoy SL & LX 2006 Appliances — Section 4 AppliAnces - introduction ...............67 Refrigerator....................67 Operation.Specifics................67 Refrigerator.Controls................68 Control.Panel..................68 Control.Panel.(Optional).................69 Doors....................70 Service....................70 Storage....................70 Microwave.-.General.Information............70 Operation.-.Microwave.Cooking..............72 cooktop rAnge/oven ................73 Range.Cover.(Optional.on.LX.Models)............73 Operation....................73 Lighting.Top.Burners................73 Burner.Grate..................74 Lighting.Oven.Pilot.................74 Cleaning.&.Maintenance.................74 rAnge Hood ..................75 Air conditioner - roof ..............75 Maintenance..................76...
-
Page 67: Appliances - Introduction
AppliAnces - introduction This section covers operation and care of various appliances found in the recreational vehicle. The recreational vehicle is equipped with a refrigerator, cooktop range, microwave, furnace, water heater, roof air conditioner and several optional appliances. Many of these appliances operate on AC or DC current, LP-Gas or a combination of all three. -
Page 68: Refrigerator.controls
NOTE: Keep interior box temperature at or below 54º F to reduce food spoilage. The Refrigerator will consume more energy to maintain temperature, especially in hot climates. Lower temperature may lead to quicker frost build-up. Refrigerator Controls In Order for the Refrigerator to Operate: •... -
Page 69: Control.panel.(Optional)
Control Panel (Optional) 030864b • ON/OFF Button - Turns the refrigerator on or off. - Push the ON/OFF button to start the refrigerator in Auto mode. - Push and hold the ON/OFF button for two seconds to shut it off. •... -
Page 70: Doors
Doors The refrigerator doors use a positive latch that secures the door with a “click” to prevent the door from opening while traveling. The doors use a heating element located in the flapper on the left door (four-door model) or in the door (two-door model). The heating element activates when operating the refrigerator in any mode to help prevent moisture accumulation in high humidity conditions. - Page 71 Microwave Tips: • Turn the oven off before cleaning. • Keep the inside of the oven clean. When food spatters or spilled liquids adhere to oven walls, wipe with a damp cloth. Mild detergent may be used if the oven gets dirty. The use of a harsh detergent or abrasive cleaner is not recommended.
-
Page 72: Operation.-.Microwave.cooking
The oven has safety interlocks to prevent use with the door open, and screens to prevent microwave leakage. These safety features should be kept in good condition - never attempt to bypass the safety interlocks or allow debris or residue to accumulate on the door or oven face. If the oven is damaged, do not attempt to use it. The oven should be adjusted or repaired by qualified service personnel. -
Page 73: Cooktop Range/Oven
cooktop rAnge/oven The cooktop uses LP-Gas as a fuel source. The burners use a piezo igniter. The cooktop should be used for cooking purposes only and not as a heating source. The flame should have a blue appearance with a lighter blue defined flame at the burner head. -
Page 74: Burner.grate
Burner Grate The burner grate can separate from the cooktop cover for cleaning purposes. Place a towel down onto the countertop next to the cooktop. Lift the cooktop cover straight up to remove it. After cleaning, place the grate into the cooktop grommets on each corner. -
Page 75: Range Hood
Porcelain Enamel: Porcelain enamel is a type of glass fused on steel at a very high temperature. It is not extremely delicate but must be treated as glass. Sharp blows, radical surface temperature changes, etc., will cause enamel to chip or crack. Some foods such as vinegar, lemon juice, tomatoes and milk contain acids which can dull the finish of the enamel. -
Page 76: Maintenance
4. COOL EMERGENCY BUTTON: Used when the remote control is lost or inoperative. Press the button to turn the air conditioner ON. The unit operates automatically according to the room temperature. The setting conditions of cool emergency operation are Operation Mode (COOL), Fan Speed (Auto), Preset Temperature (75ºF), and Timer Mode (Disabled). -
Page 77: Furnace
furnAce The furnace and its related components are 12 Volt DC operated, using LP-Gas as the fuel source. Electronic circuitry (automatic ignition) is used to ignite the burner. The furnace uses outside air for the burner combustion and exhaust is expelled through the outside vent. Inside air is drawn into the furnace and blown across the internal heat exchanger. -
Page 78: If.the.furnace.fails.to.light
If the Furnace Fails to Light • Make sure the LP-Gas supply valve is open. • The furnace will not light if the blower motor is not spinning to specified speed. due to a low house battery charge condition. Hook-up to shore power to charge the batteries. WARNING: If a gas smell exists and the blower motor is spinning, do not attempt additional furnace operation. -
Page 79: Fireplace Electric (Optional On Fifth Whell Sl Only)
5. OFF TIMER BUTTON: When the unit is turned on, press the OFF TIMER button to select the desired time, in hours, for the unit to turn off. 6. TEMPERATURE SELECTOR BUTTONS: Set the desired room temperature, then the unit will maintain the room temperature. -
Page 80: Operation
Operation The following will explain the function of each convenient control. To access the controls, open the upper grill by pulling near the top, forward and down. To conceal the controls during operation, return the grill to its original upright position. 030998 MAIN ON/OFF SWITCH: The ON/OFF switch supplies power to all fireplace functions (Heater/Flame). -
Page 81: Maintenance
Maintenance Light bulbs need to be replaced when you notice a dark section of the flame or when the clarity and detail of the log exterior disappears. There are two bulbs at the top of the opening which illuminate the log set exterior, and four bulbs under the log set which generate the flames and embers. -
Page 82: Before.using.the.water.heater
Before Using the Water Heater Prior to using the water heater, purge all trapped air from the water system. To purge the air and pressurize the system, fill the fresh water tank using the on board water pump or hooking up to city water. Check the tank for water leaks. -
Page 83: Operation
CAUTION: Ensure the water heater tank is cool prior to checking the valve. Re-establishing the Air Pocket: 1. Turn OFF the water heater. 2. Shut OFF the incoming water supply. 3. OPEN the hot water faucet closest to the water heater. 4. -
Page 84: Draining.&.Storage
120 Volt AC Operations: • Shore power is supplying AC voltage. • The water heater is plugged into the receptacle outlet. • The circuit beaker in the Distribution Panel is set ON. • Turn the electric water heater switch to On. The heating process occurs more quickly with both LP-Gas and 120 Volt AC operations activated. -
Page 85: Troubleshooting
Troubleshooting • If water heater fails to light, check the outside burner tube for obstructions. Spiders or insects may make nests in the burner tube. • If the indicator light on the monitor panel does not light, and the water heater does not light, verify the battery disconnect switch (Fifth Wheel) is on or check for a blown fuse in the house distribution panel or batteries are fully charged (Travel Trailer). -
Page 86: Operation
Operation 030992b 1. Measure detergent and pour it into the washer. If desired, add powdered or liquid color-safe bleach. 2. Drop a sorted load of clothes loosely into the washer. • Load evenly to maintain washer balance. • Mix large and small items. 3. -
Page 87: Winterizing.the.clothes.washer
• The cycle Status lights indicate operation being performed within the cycle. • When the cycle is complete, all Cycle Status lights will be OFF. NOTE: To change a cycle selection after the cycle has started, turn the Cycle Control knob to OFF. Select a new cycle. -
Page 88: Clothes Dryer (Optional On Travel Trailer Lx Only)
clotHes dryer (optionAl on trAvel trAiler lx only) The dryer operates on 120 Volt AC power from shore power and features three cycles: air, timed and automatic permanent press/regular. Clean the Lint Screen Before Each Use • Open door and pull screen straight out. •... - Page 89 Stopping and Restarting the Dryer: The dryer can be stopped any time during a program. To Stop the Dryer: • Open the dryer door or turn the Cycle and Temperature Control knob to OFF. NOTE: The Cycle and Temperature Control knob should point to an OFF area when the dryer is not in use.
- Page 90 ~notes~ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ___________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ 90 • Section 4 — Appliances Savoy SL & LX 5th Wheel & Travel Trailer...
- Page 91 Savoy SL & LX 2006 Equipment — Section 5 EquipmEnt - introduction ..........93 Entry StEp ................93 Operation................93 Entry door .................94 Adjustments................94 Grab HandlE (optional) ...........95 SlidE-out ................95 Slide-out.Extending...............96 Slide-out.Retracting...............96 Manual.Override..............96 Preventive.Maintenance............97 SlidE lock ................97 awninGS ................97 Main.(Not.On.All.Units).
-
Page 93: Equipment - Introduction
EquipmEnt - introduction This section covers the basic operation and care of various types of equipment found in the recreational vehicle, most of which are provided for comfort and entertainment. More detailed information about specific equipment may be found in each product manufacturer’s manual. Optional equipment will also be discussed in this section which may not apply to all recreational vehicles. -
Page 94: Entry Door
Entry door The door uses two separate locks for personal safety and security. The door handle incorporates a primary and secondary latching system. One locking system is the door handle and the other is a dead bolt. However, keeping the entry door in good operating condition requires some routine maintenance on a regular basis. -
Page 95: Grab Handle (Optional)
Grab HandlE (optional) The grab handle is used to aid in entering and exiting the recreational vehicle. 031067 • To use handle, lift up on handle and swing outward into use detent. • To store handle, lift up on handle and swing inward into stored detent. SlidE-out Before Operating the Slide-out System: •... -
Page 96: Slide-Out.extending
Slide-out Extending 1. Locate the two locking bar mechanisms on top of the slide-out room inside the recreational vehicle. Locking bars vary from model to model. Remove the bars from between the wall and the top of the slide-out room. Store the bars for future use when the recreational vehicle is to be moved. -
Page 97: Preventive.maintenance
Preventive Maintenance The slide-out system has been designed to require very little maintenance. To ensure the long life of the slide-out system, read and follow these procedures. • When the room is out visually inspect the inner slide rail assemblies. Check for excess build-up of dirt or other foreign material;... - Page 98 To Extend the Main Awning: 1. Hook the loop of the center pull strap with the pull wand and draw the awning away from the recreational vehicle to the desired extension. Slide the center pull strap to one end of the awning and store.
-
Page 99: Care.&.Maintenance
Securing the Awning For Travel: (Before traveling check the following) 1. The awning is fully retracted against the side of the recreational vehicle. 2. The black locking knobs are tightened. 3. The storage locks are down and in the locked position. 4. -
Page 100: Front.window.awning.(Not.on.all.units)
Front Window Awning (Not on All Units) To raise awning pull, out locking pins on each side of awning. Raise awning evenly into desired position and lock in place by tightening each side rail wing nut. To lower awning loosen each side rail wing nut and lower awning. Secure in place by pulling out each side locking pin and inserting pin into the end slots of the awning. -
Page 101: Fans
FanS Manual The recreational vehicle is equipped with manually operated roof air vents. The vent is opened or closed by turning the crank handle in the desired direction. The fan is for ventilation only, not to cool the recreational vehicle. The power fan is operated by pushing the small power button. The vent must be opened before using the power fan. -
Page 102: Sofa Hide-A-Bed Conversion (Optional)
SoFa HidE-a-bEd convErSion (optional) The sofa hide-a-bed will convert easily into a bed. Clear the area of obstructions and debris. Sofa to Sleeper: • Remove the seat cushions to access the hide-a-bed. The seat cushions should be stored safely until the bed is converted back to a sofa. •... -
Page 103: Storage - Under Bed
• Connect tie straps to anchor eyelet. • Pull the strap over the seat base and across the chair toward the other side. • The smaller strap has the securing catch assembly. • Lift the locking lever to insert the strap through the assembly. •... -
Page 104: Dvd Home Theater With Surround Sound
STOP BUTTON: When this button is pressed, compact disc play will stop. SKIP DOWN BUTTON: To skip to the next lower track on the compact disc. SKIP UP BUTTON: To skip to the next higher track on the compact disc, press this button. PROGRAM BUTTON: Use to arrange the tracks on the disc to play in desired order. -
Page 105: Television Antenna
STOP BUTTON – Stop playing a disc. FUNCTION BUTTON – Select a source. VOLUME CONTROLS – Change the loudness of the sound from the speakers connected to the unit. STANDBY/ON BUTTON – Turn the power ON or OFF. REMOTE SENSOR – Receives the remote control unit signals. tElEviSion antEnna The television antenna is a manual crank up antenna with built in electronics that use 12 Volts DC to boost signal strength. -
Page 106: Hook-Ups - Cable Tv
Hook-upS - cablE tv The recreational vehicle is equipped with a cable TV and telephone hook-up, located on the roadside of the recreational vehicle. The hook-up is used for connecting to cable service at campgrounds where cable is available. 060298 106 •... - Page 107 Savoy SL & LX 2006 Water Systems — Section 6 Water SyStemS ..............109 General Information ............109 monitor Panel ..............109 Measurement ..............109 Water tank - FreSh Water Fill ........109 Water - City hook-UP .............110 Water PUmP ..............110 FaUCet SCreenS ..............111 ShoWer - exterior ............111 DiSinFeCting FreSh Water ..........111 WaSte Water SyStemS ...........112 Proper Waste Disposal ............112...
-
Page 109: Water Systems
Water SyStemS General Information This section contains information and knowledge for the operation and care of the various water system equipment found in the recreational vehicle. The recreational vehicle is equipped with two separate water systems. More detailed information with CAUTION or WARNING instructions for the various equipment, other than what is found in this section, can be found in the manufacturer’s manual in the owner information box. -
Page 110: Water - City Hook-Up
6. Locate the monitor panel inside the recreational vehicle. Press the button marked “Fresh” for testing the level in the fresh water tank. Read the scale as the fresh water tank is filling. When the 2/3 tank light illuminates, filling of the tank should be nearly complete. Do not leave the recreational vehicle unattended while filling the fresh water tank. -
Page 111: Faucet Screens
To start pump after unhooking city water supply, or for first time use: • Fill the fresh water tank. • Open all faucets. This includes hot and cold water faucets and shower. • Turn water pump on and wait for water lines and hot water heater to fill. •... -
Page 112: Waste Water Systems
NOTE: An independently operated water pump with garden hose connections and a container to hold a prepared solution may be desired to perform this task. Use the Following Procedure to Disinfect the Water System: • Prepare a household chlorine bleach solution using 1 gallon water and ¼ cup of chlorine WATER TANK FILL bleach. -
Page 113: What To Put In The Holding Tanks
CAUTION: Do not use any products that contain petroleum distillate or ammonia in place of RV odor controlling chemicals. Petroleum distillate or ammonia will damage the ABS plastic holding tanks and seals. NOTE: Never dispose of sanitary supplies or other non-dissolving items into the system. Facial tissue, wet strength tissue, paper towels or an excessive amount of toilet tissue can create clogging in the holding tank system. -
Page 114: Connecting The Waste Drain Hose
Connecting the Waste Drain Hose A flexible 3” sewer hose attaches between the termination drain and the shore facility. Sewer hoses usually come in 10’ or 20’ lengths. The shore fitting for the sewer hose may be 3” or 4” inch pipe, which could be male or female thread. -
Page 115: Toilet
4. Open the black water valve located on the frame next to the drain terminal. Allow the black tank to drain. 5. If applicable, use the optional tank flush system. • Connect a non-potable water hose, with pressure regulator, to the flush system fitting. -
Page 116: Cleaning
• Poor flush: A good flush is obtained within two or three seconds. If problems persist remove the water supply line and check flow rate. The flow rate should be at least 10 quarts (9.5 liters) per minute. • To find leaks, check behind or under toilet. Take four or five sheets of toilet tissue and wipe all the seams and water line connections. -
Page 117: Cold Weather Use
ColD Weather USe A recreational vehicle is not designed for extended use in below freezing (32° F/0° C) weather; however, problems may not occur as long as the temperature does not drop too low. Interior water lines, fixtures, water storage tanks and pumps are normally protected from moderate freezing temperatures as long as the furnace is operating. -
Page 118: Using Nontoxic Antifreeze
10. Use one gallon of RV antifreeze to protect various water lines in the recreational vehicle. Pour 1 pint in both kitchen and bath shower drains, 2 pints go in bath sink drain with some of antifreeze going into gray tank to protect drain valve. While holding toilet flush handle open pour another 3½ pints into toilet, letting antifreeze run into black tank to protect valve located there. - Page 119 WARNING: Only use non-toxic RV antifreeze that is specifically made for potable water systems. Automotive antifreeze, if ingested, can cause blindness, deafness or death. WARNING: It is recommended that this procedure be done by a qualified RV service technician familiar with recreational vehicles, such as the authorized selling dealer.
- Page 120 ~noteS~ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ___________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ 120 • Section 6 — Water Systems Savoy SL & LX 5th Wheel & Travel Trailer...
- Page 121 Savoy SL & LX 2006 LP-Gas Systems — Section 7 LP-Gas system ..............123 LP-Gas Detector ..............123 Operation................124 LED.&.Alarm.Signals............124 Testing................124 Alarm..................124 Care.of.the.Detector............125 LP-Gas emerGency ProceDures - checkList ....125 LP-Gas tank ...............126 Capacity................126 Filling..................126 LP-Gas VaLVes ..............127 Operating.&.Monitoring............127 LP-Gas FunDamentaLs .............127...
-
Page 123: Lp-Gas System
LP-Gas system This section contains information and knowledge for the operation and care of the various Liquefied Petroleum (LP-Gas) system equipment found in the recreational vehicle. The recreational vehicle is equipped with several appliances and various equipment which are capable to operate on LP-Gas. Some items discussed may not be applicable to all units. -
Page 124: Operation
Operation Upon first application of power the detector cannot detect LP-Gas or sound the alarm for two minutes after it has been turned on. At the end of the start cycle the LED will turn green, indicating full operation. If an unsafe level of gas is detected, an alarm will immediately sound. -
Page 125: Care.of.the.detector
WARNING: If the alarm sounds and no danger is evident, open all doors and windows to air out the recreational vehicle. Exit the recreational vehicle and turn off the gas at the LP tank. Do not enter the recreational vehicle until the alarm stops. If the alarm sounds again after the gas is turned back on, turn the gas off. -
Page 126: Lp-Gas Tank
LP-Gas tank Capacity The recreational vehicle LP-Gas system is designed to accommodate two 30 pound (7.08 gallons) storage tanks. This is the only approved size for use. Filling Woodall’s Campground and Trailer Guide and other publications list refueling stations. Many travel parks sell LP-Gas. -
Page 127: Lp-Gas Valves
LP-Gas VaLVes Operating & Monitoring Open both LP-Gas primary shut-off valves. The tank to which the “lever” on the changeover valves point is the service tank. As long as there is fuel in the service tank the full-empty indicator on top of the valve will show green. -
Page 128: Lp-Gas Regulator
LP-Gas reGuLator The regulator is the heart of an LP-Gas system. The LP-Gas in the tank is under high pressure. The regulator reduces the pressure of gas so it is safe to use with various appliances. The regulator on the recreational vehicle is a two-stage regulator. -
Page 129: Lp-Gas Distribution Lines
This formula can be useful when trying to determine the approximate length of time a tank of LP-Gas will last. Generally, LP-Gas appliances do not operate continuously. An example would be the typical cycling of the furnace or water heater. Determining How Long a Tank of LP-Gas Will Last: •... - Page 130 LP-Gas Tanks and Cylinders: An alloy steel two-piece welded and brazed tank is used on all towable products. The marking on the collar, DOT 4BA240, identifies the DOT specifications and service pressure. Other pertinent information included on the collar is the water capacity (WC) and the tare weight (TW), both of which are measured in pounds, and the Manufacture date (one of the most important items).
- Page 131 Savoy SL & LX 2006 Electrical Systems — Section 8 ElEctrical introduction ..........133 AC System - 120/240 Volt ..........133 Shore Power ..............133 DC Systems - 12 Volt ............134 ShorE PowEr hook-uP ............134 BattEry diSconnEct (For FiFth whEEl) .......135 GFci BrEakErS & outlEtS ..........136 convErtEr - 50 aMP SErvicE (oPtional on travEl trailEr lX only) ......136 convErtEr/diStriBution PanEl -...
-
Page 133: Electrical Introduction
ElEctrical introduction The recreational vehicle is equipped with 120 Volt AC and 12 Volt DC electrical systems that supply the power to operate electrical appliances and equipment in the recreational vehicle. To hook up to 120 Volt power, find grounded supply cord (shore line) and plug it into an outside 120 Volt power source. Switch the main breaker ON. -
Page 134: Dc Systems - 12 Volt
DC Systems - 12 Volt A majority of lighting and appliances are designed to operate from 12 Volt DC (direct current) power, which is why the battery plays an important role in the function of the recreational vehicle. Keep the 12 Volt system in working order. -
Page 135: Battery Disconnect (For Fifth Wheel)
Electrical Adapters: There are many different electrical adapters available to suit a variety of needs. Only UL approved adapters should be used. The most common adapter is a 50-30 Amp adapter. This type of connector adapts the 50 Amp shore cord to a 30 Amp shore power outlet. Always install the adapter to the cord prior to making the connection to the outlet. -
Page 136: Gfci Breakers & Outlets
GFci BrEakErS & outlEtS A ground fault circuit interrupter (GFCI) can be found in two different applications. One is incorporated in a breaker used in 120 Volt AC breaker panels, the other is incorporated in an outlet. The GFCI, as a breaker or an outlet, offers two types of protection. One type of protection is from over-current or shorts. -
Page 137: Converter/Distribution Panel - 30 Amp 120 Volt Ac/12 Volt Dc
If the converter output is correct, but the battery is not charging, there may be a problem with an open wire between the converter and battery. If the fuses are blown the battery was connected in reverse. It only takes one second of reverse connection to blow the fuse. -
Page 138: Distribution Panel - 120 Volt Ac 50 Amp (Optional On Travel Trailer Lx Only)
diStriBution PanEl - 120 volt ac 50 aMP (oPtional on travEl trailEr lX only) The Load Center is a compact, electrical distribution panel designed to handle the 120/240 Volt AC distribution. The Load Center will accommodate a two-pole main and up to twenty branch circuits. Circuit Assignments are as Follows: 1. -
Page 139: (Optional On Travel Trailer Lx Only)
Fuse Assignments are as Follows: 1. Furnace - 15 Amp Fuse 2. Refrigerator - 5 Amp Fuse 3. Monitor Panel - 15 Amp Fuse 4. Living Room Slide-out - 15 Amp Fuse 5. TV Booster - 5 Amp Fuse 6. Service Lights - 15 Amp Fuse 7. -
Page 140: Battery
BattEry Deep Cycle Battery Deep cycle batteries, best suited for use with 12 Volt operated lights, appliances and inverters, are designed to have the majority of capacity used before being recharged. These batteries are available in many sizes and types. The most common is a non-sealed, liquid electrolyte battery. -
Page 141: Testing The Battery
Testing the Battery There are several ways to test and monitor a battery. The recreational vehicle uses a monitor panel that shows the status of the house batteries at a quick glance. By pressing and holding the test button the power level will display on the battery scale. -
Page 142: Solar Panel Preparation (Optional)
WARNING: Sulfuric acid in the batteries can cause severe injury or death. Sulfuric acid can cause permanent damage to eyes, burn skin and eat holes in clothing. Always wear splash-proof safety goggles when working around the battery. If battery electrolyte is splashed in eyes or on skin, immediately flush the affected area for 15 minutes with large quantities of clean water. - Page 143 NOTE: This chart reflects product specification available at the time of printing. Therefore any floor plans thereafter may not be reflected in the chart. All other information contained throughout the manual will still apply. NOTE: All tank capacities are estimated based upon calculations provided by the tank manufacturers and represent approximate capacities.
-
Page 144: Metric/U.s. Conversion Chart
MEtric/u.S. convErSion chart 144 • Section 8 — Electrical Systems Savoy SL & LX 5th Wheel & Travel Trailer... -
Page 145: Maintenance Record
MaintEnancE rEcord After scheduled services are performed, record the date and who performed the service in the boxes provided after the maintenance interval. Any additional information from “Owner Checks and Services” or “Periodic Maintenance” can be added on the following record pages. In addition, retain all maintenance receipts. The owner information portfolio is a convenient place to store them. - Page 146 Date Odometer Reading Serviced By Maintenance Performed 146 • Section 8 — Electrical Systems Savoy SL & LX 5th Wheel & Travel Trailer...
- Page 147 Savoy SL & LX 5th Wheel & Travel Trailer 2006 Electrical Systems — Section 8 • 147...
- Page 148 Savoy SL & LX 5th Wheel & Travel Trailer 2006 Layout Julie Slagle Savoy SL & LX 5th Wheel & Travel Trailer 2006 Cover Design Julie Slagle PRINTING Holiday Graphics - IN ONLINE CORPORATE SITE www.monaco-online.com ONLINE TOURS www.monaco-online.com/tours/ 148 • Section 8 — Electrical Systems...
- Page 149 Savoy SL & LX 2006 Index...
-
Page 151: Checklist - Set-Up Procedures 2
Cooktop Range/Oven ..........73 Range.Cover.(Optional.on.LX.Models)....73 Operation..............73 Air Conditioner - Roof ..........75 Lighting.Top.Burners..........73 Maintenance............76 Burner.Grate............74 Troubleshooting.............76 Lighting.Oven.Pilot..........74 Appliances - Introduction .........67 Cleaning.&.Maintenance........74 Awnings ..............97 Main.(Not.On.All.Units)........97 Care.&.Maintenance..........99 Front.Window.Awning.(Not.on.All.Units)...100 Checklist - Set-up Procedures ........28 Dinette Bed Conversion .........102 Disinfecting Fresh Water ........ - Page 152 I,J,K Fans ................101 Interior Care .............55 Manual..............101 Fabrics..............55 Faucet Screens ............111 Vinyl...............55 Fireplace Electric (Optional on Fifth Floors.-.Carpet.Cleaning........56 Wheel SL only) ............79 Floors.-.Vinyl............57 Operation..............80 Wall.Coverings............58 Maintenance............81 Wood.Care.............58 Fire Extinguisher ............49 Countertops.-.Laminate.
- Page 153 M,N,O,P,Q Storage ..............60 Short.Term..............60 Long.Term..............60 Maintenance Record ..........145 Winter.Storage.-.Checklist........62 Metric/U.S. Conversion Chart .......144 Storage.-.Removal..........63 Monitor Panel ............109 Storage - Under Bed ..........103 Measurement............109 T,U,V Television Antenna ..........105 Range Hood ...............75 Tips For Driving ............15 Rear Ladder (Not on All Units) ......100 Tires ................30...
-
Page 154: Wheel Mounting 3
Water Heater .............81 Before.Using.the.Water.Heater......82 Water.Heater.Compartment........82 Water.Heater.Bypass.System.........82 Pressure.-.Temperature.Relief.Valve......82 Operation..............83 Draining.&.Storage..........84 Tips.................84 Troubleshooting.............85 Water Pump ............. 110 Water Systems ............109 General.Information..........109 Water Tank - Fresh Water Fill .......109 Weighing the Fifth Wheel/Travel Trailer ....41 Weight.Label............42 Fifth.Wheel/Travel.Trailer.and.Tow.
Need help?
Do you have a question about the Savoy LX 2006 and is the answer not in the manual?
Questions and answers
