Important Notice before Using GV-Video Capture Card

1. Exclusions:
• Currently GV-Video Capture Cards are not compatible with VIA-series, ATI-series
chipset motherboards.
• Currently GV-600A, GV-650A and GV-800A Cards are not compatible with VIA-series,
ATI-series and Intel Sandy Bridge series chipset motherboards.
• Currently GV-3008 Card is not compatible with VIA-series, ATI-series, Intel Sandy
Bridge series and NVIDIA-series chipset motherboards.
If your GV-Video Capture Card or GV-System works in conjunction with the following GV
accessories, note the limitation that these accessories do not support 64-bit Windows
versions currently: GV-Multi Quad Card, GV-Keyboard V1 / V2.
2. Hard Disk Requirements:
• It is strongly recommended to use two separate hard disks. One is for installing Windows
operating system and GV-System software, and the other is for storing recorded files.
• The total of recording frame rates that you can assign to a single hard disk is listed as
below:
Frame rate limit in a single hard disk when connecting to analog cameras
Software Compression
Video resolution
CIF
VGA/D1
Turbo VGA
Turbo D1
Hardware Compression
Video resolution
D1
MPEG4
NTSC PAL
480 fps 400 fps
240 fps 200 fps
416 fps 400 fps
352 fps 320 fps
H.264
NTSC PAL
240 fps 200 fps
