Table Of Contents; Safety Warnings - Please Read Before Proceeding - XTM Racing X-Crawler EP Super Class Crawler ARR Assembly Manual And Setup Manual

Safety Warnings - Please Read Before Proceeding ..................................2
Customer Service Information ...................................................................3
Introduction ................................................................................................3
Rock Crawling Information Sources ..........................................................3
Recommended Accessories ......................................................................4
Recommended Tools and Supplies ...........................................................5
Parts Identification .....................................................................................5
Becoming Familiar with Your X-Crawler EP Super Class Crawler ARR ....6
Assembly Tips From the Pros....................................................................6
Final Assembly ....................................................................................7~12
Chassis Setup Guide .........................................................................13~16
Replacement Parts and Assembly Drawings.....................................16~23
Applying The Decals ..........................................................................24~25
Important Warrany Service Information .................................... Back Cover
Warranty Information ................................................................ Back Cover

SaFety warninGS - PleaSe read beFore ProCeedinG

Under no circumstances should you operate your model in crowds of people. Serious injury could result.
l
Never operate your model on busy streets or if there are cars present.
l
Do not use your model to chase pets or other animals.
l
Periodically check all of the fasteners to ensure that they're tight. Use threadlock on all screws that thread into metal to help keep
l
the screws from loosening due to vibration and normal use.
Each time you use your model, first check the throttles and brakes to ensure that they're working properly.
l
Clean and double-check everything on your model after each day of use to ensure top performance and reliability.
l
Always follow the directions provided with your battery charger to charge your battery pack correctly.
l
Periodically check your battery pack for excessive heat build-up during the charging process. If the battery pack is hot to the touch,
l
remove it from the charger and let it cool. never leave your battery pack unattended during the charging process.
Always allow your battery pack to completely cool before recharging.
l
Never over-charge your battery pack or serious damage to the battery pack and/or injury to the user could result.
l
When turning on your model, always turn on the transmitter before turning on the receiver (or plug in the battery pack if your
l
Electronic Speed Controllers (ESCs) don't feature an ON/OFF switch).
When turning off your model, always turn off the receiver (or unplug the battery pack if your ESCs don't feature an ON/OFF switch)
l
before turning off the transmitter.
Always unplug the battery pack when you're not using your model.
l
Never cut the receiver antenna shorter or you could lose control of your model.
l
When operating your model, make sure the transmitter antenna is completely extended.
l
Because your model is operated by radio control, it is important to make sure you are always using fresh and/or fully charged
l
batteries (if using NiCDs or NiMHs). Never allow the batteries to run low or you could lose control of your model.
To ensure that your radio control system is operating properly and to prevent any chance of a runaway model, your radio control
l
system should be range checked before the first run of the day and/or after a crash.

table oF ContentS

General warninGS
battery PaCK warninGS
radio Control SySteM warninGS
Page
Visit us on the web at
www.teaMXtM.CoM
