1/6 GAS-POWERED 2WD BUGGY
ASSEMBLY AND OPERATING INSTRUCTIONS
Incredible 1/6 Scale Size!
Includes 23cc Gasoline Engine with Pull-Starter
Steel Differential
Full Ball Bearings
Huge Front Bumper
Factory-Trimmed Body
Double Epoxy Brake Discs
Strong 7mm Thick Dogbones
Heavy-Duty Side Dust Guards
Factory-Glued Tires with Inserts
Thank you for purchasing the XTM Racing 1/6 Gas-Powered 2WD Buggy. These Assembly and Operating Instructions are provided to help you enjoy
your new 1/6 Gas-Powered 2WD Buggy without any of the hassles you might expect. Please read through all of the literature that is provided in the box.
IMPORTANT
Before operating your new 1/6 Gas-Powered 2WD Buggy, please read and understand the warnings listed on the next page. Failure
to do so could lead to bodily harm and/or injury. The XTM Racing 1/6 Gas-Powered 2WD Buggy is not intended for persons under 12 years of age,
unless closely supervised by an adult.
The XTM Racing 1/6 Gas-Powered 2WD Buggy is distributed exclusively in the U.S.A.by
Features of Your New XTM Racing 1/6 Gas-Powered 2WD Buggy:
Global Hobby Distributors
18480 Bandilier Circle
Fountain Valley, CA 92708
All contents copyright © 2004, Global Hobby Distributors Version V1.0 July 2004
Kit Product # 146300
Internal Roll Cage for Protection
Massive Servo Saver for Steering
Fully Threaded, Oil-Filled Aluminum Shocks
Dust Cover to Protect the Pinion and Spur Gears
Adjustable Camber, Castor and Toe-In Front and Rear
4mm Aluminum Chassis with Curved Edges for More Strength
Uses Regular Unleaded Gasoline with 2-Stroke Oil Added
Water-Resistant Receiver and Battery Boxes
Large Fuel Tank with Ventilation Lines
Large Pull-Starter for Easy Starting
1
Advertisement
Related Manuals for XTM Racing 146300
Summary of Contents for XTM Racing 146300
- Page 1 Before operating your new 1/6 Gas-Powered 2WD Buggy, please read and understand the warnings listed on the next page. Failure to do so could lead to bodily harm and/or injury. The XTM Racing 1/6 Gas-Powered 2WD Buggy is not intended for persons under 12 years of age, unless closely supervised by an adult.
-
Page 2: Customer Information
We urge you to come check out our website at http://globalservices.globalhobby.com. There you will find public message boards frequented by other XTM Racing product owners and the XTM Racing support staff. This is a great place to learn about new XTM Racing products, get help and suggestions for your current XTM Racing products or just simply hang out and chat with people that share your same interests. -
Page 3: Tools Needed For Assembly
TOOLS NEEDED FOR ASSEMBLY MODELING KNIFE PHILLIPS HEAD SCREWDRIVERS (# 1 AND # 2 SIZES) WIRE CUTTERS 1.5MM, 2MM AND 2.5MM HEX WRENCHES NEEDLE NOSE C/A GLUE PLIERS YOU WILL ALSO NEED HIGH-QUALITY 2-STROKE ENGINE OIL TO MIX WITH THE REGULAR UNLEADED GASOLINE USED IN THE ENGINE. - Page 4 Certain servos may require the use of the included spacers to mount properly. This will be dependent on brand and type, and may not be required for all servos. When installing the servos, both servos' output shafts should be toward the REAR of the chassis.
- Page 11 Spark plug gap should be set to 0.7mm - 0.8mm OEM replacement spark plug part # 32730 Your engine comes equipped with a standard air filter that includes a foam filter element. As a precaution, we recommend that you change or clean the air filter element on a regular basis.
- Page 12 Starting a Warm Engine: Set the carburetor throttle lever to the idle position, but leave the choke lever open. Press the primer pump until it is filled with fuel. Pull the pull-start cord firmly until the engine starts. To stop the engine, press and hold the ignition switch until the engine stops.
- Page 13 ENGINE TROUBLESHOOTING GUIDE This troubleshooting guide has been provided to help you diagnose and solve most problems that you may encounter with the engine in your 1/6 Gas-Powered 2WD Buggy. Most problems encountered can be solved by carefully following the problem-cause-solution sections.
-
Page 14: Spare Parts List
SPARE PARTS LIST XTM Racing stocks a complete line of replacement parts for your 1/6 Gas-Powered 2WD Buggy and 23cc Gasoline Engine. Listed on the next few pages are the replacement parts that are available along with their respective part numbers for easy ordering convenience. - Page 15 SPARE PARTS LIST, CONTINUED... 32601 Cylinder Head 32663 Lower Gasket 32602 Cylinder Head Gasket 32664 Diaphragm-Lower 32603 Cylinder Head Screw Set M5x22 32665 Upper Gasket 32604 Carburetor Mounting Insulator 32666 Diaphragm-Upper 32605 Carburetor Mounting Insulator Gasket 32667 Carburetor Body-Upper 32606 Carburetor Gasket 32668 Carburetor Upper Cover...
- Page 16 SPARE PARTS LIST, CONTINUED... 146310 (002159) 146311 (002160) 146312 (002161) 146313 (11310) 146314 (11311) Ball Bearing 12x28x7 Ball Bearing 8x22x7(2) Ball Bearing 10x22x6 Antenna Tubes (5) Antenna Caps (10) 146315 (11333) 146316 (11399) 146317 (11447) 146318 (11922) 146319 (11923) M3 Set Screws (10) Body Pins (10) M3 Lock Nuts (10) M5 Lock Nuts (5)
- Page 17 SPARE PARTS LIST, CONTINUED... 146350 (32431) 146351 (32432) 146352 (32433) 146353 (32434) 146354 (32435) M4x8 R.H. Screws (5) Differential - Complete M4x16 F.H. Screws (5) M5x25 F.H. Screws (5) M5x25 Set Screws (5) 146355 (32436) 146356 (32437) 146357 (32438) 146358 (32439) 146359 (32440) Lower Shock Mounts (2) M5x4 Set Screws (5)
- Page 18 SPARE PARTS LIST, CONTINUED... 146390 (32471) 146391 (32472) 146392 (32473) 146393 (32474) 146394 (32475) Brake Cam & Lever Fuel Line Brake Pads Engine Mount Washers (4) Rear Layshaft 146395 (32476) 146396 (32477) 146397 (32478) 146398 (32479) 146399 (32480) Spacers/Brakes Spring/Servo Saver M4 Collars (5) M2 Collars (5) Bearing Spacers (8)
- Page 19 SPARE PARTS LIST, CONTINUED... 146431 (32551) 146432 (32552) 146433 (32553) 146434 (32554) 146435 (32555) Shock Adjusting Rings (4) Shock Caps (4) Upper Shock Mounts (4) Shock Pistons (4) Shock Cap Seals (4) 146436 (32556) 146437 (32557) 146438 (32558) 146439 (32559) 146440 (32560) Shock Spring Retainers Shock Body-Rear (2)
- Page 20 In that XTM Racing has no control over the final assembly or material used for final assembly, no liability shall be assumed for any damage resulting from the use by the user of the final user-assembled product.
