OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Baja Bullet ESC Features:
Forward, Brake & Reverse
Micro Processor Control
Input Voltage: 6V - 12V
Frequency: 3Khz
Continuous Current: 20Amps
BEC Cutoff: 5V/2Amps
Temperature Cutoff: 80º Celsius
Weight: 2.4 Ounces
Thank you for purchasing the XTM Racing Baja Bullet RTR 2WD electric truck. These Operating Instructions are provided
to help you enjoy your new Baja Bullet without any of the hassles you might expect. Please read through all of the literature
that is provided with your truck. Doing so will help you become familiar with how your truck and radio system operate.
IMPORTANT
Before running your new truck, please read and understand the warnings listed on the next page. Failure to do so could lead to bodily
harm and/or injury. The XTM Racing Baja Bullet RTR 2WD electric truck is not intended for those under 12 years of age, unless
closely supervised by an adult.
XTM Racing products are distributed exclusively by Global Hobby Distributors 18480 Bandilier Circle, Fountain Valley, CA 92728
For more cool and exciting XTM Racing products, visit our website at http://xtm.globalhobby.com
All contents copyright © 2002, Global Hobby Distributors Version V2.0 March 2002
Baja Bullet Truck Features:
Built and Ready-to-Run
Electronic Speed Control
Full Ball Bearing Set
Painted Body with Decals
Powerful 21 Turn Motor
2 Channel Radio System Preinstalled
1
Advertisement
Table of Contents
Related Manuals for XTM Racing Baja Bullet
Summary of Contents for XTM Racing Baja Bullet
- Page 1 Thank you for purchasing the XTM Racing Baja Bullet RTR 2WD electric truck. These Operating Instructions are provided to help you enjoy your new Baja Bullet without any of the hassles you might expect. Please read through all of the literature that is provided with your truck.
-
Page 2: For Your Information
# 13. The troubleshooting guide is provided to help you find a quick and immediate resolution to any number of problems that might occur. If you cannot solve a problem using the troubleshooter, or if you have any other questions or concerns, please contact us below: XTM Racing Customer Service 18480 Bandilier Circle Fountain Valley CA 92728... -
Page 3: Section 1: Our Recommendations
Section 1: Our Recommendations This section lists the items you will need to run and maintain your new XTM Baja Bullet RTR electric truck. As you can see, there's not much to it! Trinity Amp Max II 1500Mah Battery Pack - Part # 842006 Promax Black Widow AC/DC Peak Charger - Part # 350360 Trinity "8 Pack"... - Page 4 Receiver: The receiver picks up the signals from the transmitter and sends those signals to the ESC and the steering servo. Shock: The shocks used on the Baja Bullet are oil-filled and use a spring that is well-suited for most off-road conditions. The shocks can be easily tuned for different driving conditions.
-
Page 5: Section 3: Preparing To Run Your Baja Bullet Electric Truck
Note: If you find it hard to slide the antenna through the tube, apply a light coat of Windex to the antenna to make it slide easier. ® For more cool and exciting XTM Racing products, visit our website at http://xtm.globalhobby.com... - Page 6 Push the end of the plastic tube firmly into the molded hole in the chassis. Note: Leave the excess antenna hanging from the top of the tube. Under no circumstances should you cut or shorten the antenna. Charge the motor battery using your AC/DC peak charger. Note: When you buy new battery packs, they do not come fully charged.
-
Page 7: Section 4: Checking The Controls
Never attempt to operate your model if the radio control system is not functioning properly. Doing so could be harmful to others around you and/or to your model. For more cool and exciting XTM Racing products, visit our website at http://xtm.globalhobby.com... - Page 8 Checking the Steering Controls With the both the transmitter and the truck turned on, rotate the transmitter's steering wheel forward (to the right). The front wheels on the truck should turn right. If they don't, flip the steering servo reversing switch on the top of the transmitter to change the direction.
-
Page 9: Section 5: Electronic Speed Control
Section 5: Electronic Speed Control The ESC included in your Baja Bullet truck does not require any programming or setup. This is done for you automatically when you turn on the transmitter and the truck. Listed below is some information you may find useful about the ESC: The ESC includes a brake and reverse function. -
Page 10: Section 7: Making Chassis Adjustments
Section 7: Making Chassis Adjustments Chassis alignment and geometry are important if you want your truck to perform well. A good performing truck means a truck that is easier to drive, too. Follow our guidelines in this section to get the most out of your truck. It's very important when making changes to the settings of your truck that you make the settings the same for each side. -
Page 11: Adjusting The Spring Tension
If you are running on rough surfaces, use a lighter weight oil. We recommend using only 100% Silicon Shock Oil. Do not use motor oil. The shock oil in the Baja Bullet's shocks is good for most off-road applications. -
Page 12: Section 8: Checking And Adjusting The Gear Mesh
Section 8: Checking and Adjusting the Gear Mesh It's important to periodically check the mesh between the motor pinion gear and the spur gear. Sometimes the motor can work itself out of alignment during very rough running conditions. To adjust the gear mesh, first remove the plastic gear cover. Loosen the two screws that hold the motor in place and pivot the motor so there is a gap between the pinion gear and the spur gear. -
Page 13: Section 10: Troubleshooting Guide
C) Charge motor battery completely 7) Spur gear strips easily A) Slipper clutch too tight A) Loosen slipper clutch B) Pinion/spur gear mesh out of alignment B) Reset the gear mesh For more cool and exciting XTM Racing products, visit our website at http://xtm.globalhobby.com... -
Page 14: Section 11: Replacement Parts
Section 11: Replacement Parts Listed below and on the next few pages are the replacement parts that are available for your XTM Baja Bullet electric truck. The part numbers for each part are provided for ordering convenience. Replacement parts are available through your local authorized XTM Racing dealer or directly from us. - Page 15 149241 (CHB041) 149242 (CHB042) 149239 (CHB039) Front Wheels (1 Pair) Rear Wheels (1 Pair) Front Tires - Ribbed (1 Pair) Front Shock Tower Continued on Back Page For more cool and exciting XTM Racing products, visit our website at http://xtm.globalhobby.com...
- Page 16 If your Baja Bullet is out of the warranty period you may request an estimate of services at the time you return your truck for service. An omission of this request implies permission for XTM Racing to service your truck at our discretion.
