The range will not tip during normal use. However, the range can tip if you apply too much force or weight to the open door without the anti-tip bracket fastened down properly.
Do not store items of interest to children in cabinets above a range or on the back- guard of a range – children climbing on the range to reach items could be seriously injured. Proper Installation – Be sure the range is properly installed and grounded by a qualified technician.
Page 5
IMPORTANT SAFETY INSTRUCTIONS Keep Oven Vent Ducts Unobstructed. Placement of Oven Racks – Always place oven racks in desired location while oven is cool. If rack must be moved while oven is hot, do not let potholder contact hot heating element in oven. DO NOT TOUCH HEATING ELEMENTS OR INTERIOR SURFACES OF OVEN –...
PARTS AND FEATURES This manual covers several different models. The range you have purchased may have some or all of the items listed. The locations and appearances of the features shown here may not match those of your model. Control Panel 1.
Large diameter cookware. (on some ceramic glass models) Large quantities of food. REMEMBER: When range is in use or (on some models) during the Self-Cleaning cycle, the entire cooktop area may become hot. POWER ON Lights Each control knob has a POWER ON light. The light will glow when its control knob is on.
Ceramic Glass The surface cooking area will glow red when an element is on. It will cycle on and off, at all settings, to maintain the selected heat level. It is normal for the surface of white ceramic glass to appear to change color when surface cooking areas are hot.
Cookware IMPORTANT: Never leave empty cookware on a hot surface cooking area, element or surface burner. Ideal cookware should have a flat bottom, straight sides, a well- fitting lid and the material should be of medium-to-heavy thickness. Rough finishes may scratch the cooktop. Aluminum and copper may be used as a core or base in cookware.
1. Oven Display Symbol 2. Heat Settings 3. Oven Display 4. Start/Stop Time 5. Number Pads Electronic Control Pads When pressing any control pad function on the Electronic Oven Control, use the pad of your index finger to press the desired function.
Fahrenheit and Celsius To Set Oven to Cook in Celsius: 1. Open the oven door. 2. Press CANCEL OFF. 3. Press number pads 1, 2 and 3, in that order. 4. Press BROIL. 5. Press START. Press BAKE to confirm that Celsius is being used.
Aluminum Foil IMPORTANT: Do not line the oven bottom with any type of foil, liners or cookware because permanent damage will occur to the oven bottom finish. Do not cover entire rack with foil because air must be able to move freely for best cooking results.
Bakeware The bakeware material affects cooking results. Follow manufacturer’s recommendations and use the bakeware size recommended in the recipe. Use the following chart as a guide. BAKEWARE/ RECOMMENDATIONS RESULTS Light colored Use temperature and time aluminum recommended in recipe. Light golden crusts Even browning Dark aluminum...
(Maxi/Econo on some models) 1. Broil Maxi Use only the broiler pan and grid provided with the range. It is designed to drain juices and help prevent spatter and smoke. For proper draining, do not cover the grid with foil. The bottom of the pan may be lined with aluminum foil for easier cleaning.
5. 1. Press CONVECTION BAKE. Press the number pads to enter a temperature other than 325°F (163°C). The convection bake range can be set between 170°F and 500°F (77°C and 260°C). 2. Press START. “Lo°” will appear on the oven display if the actual oven temperature is under 170°F (77°C).
3. Broil pan 1. Press CONVECTION ROAST. Press the number pads to enter a temperature other than 300°F (149°C). The convection roast range can be set between 170°F and 500°F (77°C and 260°C). 2. Press START. “Lo°” will appear on the oven display if the actual oven temperature is under 170°F (77°C).
Close the door. 1. Press CONVECTION BROIL. Press the number pads to enter a temperature other than 450°F (232°C). The convection broil range can be set between 170°F and 500°F (77°C and 260°C). 2. Press START. The set oven temperature will appear on the oven display until oven is turned off.
When disabled, the Sabbath Mode cannot be regularly set until reactivated. To Set Range for Sabbath Mode: To set range to meet “no work” requirements for the Sabbath, first activate the Sabbath mode using the five activation steps, then follow the next 8 steps.
2. Open the oven door. 3. Press BAKE. 4. Press the number pads to enter a temperature other than 350°F (177°C). The bake range can be set between 170°F and 500°F (77°C and 260°C). 5. Press START. 6. Press and hold number pad 6 for 5 seconds. “START?” will appear on the display.
1. Temperature probe jack 2. Temperature probe 1. Press the number pads to enter a probe temperature other than 160°F (71°C). The probe range can be set between 130°F and 190°F (54°C and 88°C). 2. Press BAKE, CONVECTION BAKE or CONVECTION ROAST.
If on, end-of-cycle tones will sound, then reminder tones will sound every minute. 7. Press CANCEL OFF or open the oven door to clear the display and/or stop reminder tones. RANGE CARE Self-Cleaning Cycle (on some models) WARNING Burn Hazard Do not touch the oven during the Self-Cleaning cycle.
Prepare Cooktop and Storage Drawer: Remove plastic items from the cooktop because they may melt. Remove all items from the storage drawer. How the Cycle Works IMPORTANT: The heating and cooling of porcelain on steel in the oven may result in discoloring, loss of gloss, hairline cracks and popping sounds.
Page 23
(on some models) CERAMIC GLASS Do not use steel wool, abrasive powder cleansers, chlorine bleach, rust remover or ammonia because damage may occur. Always wipe with a clean, wet cloth or sponge and dry thoroughly to prevent streaking and staining. Cooktop Polishing Creme is recommended for regular use to help prevent scratches, pitting and abrasions, and to condition the cooktop.
2 replaceable parts. The starter is a knob-shaped part located on the right side of the backguard, under the light bulb. Before replacing, make sure the range is off and cool. The cooktop light is located in the backguard. It is controlled by the SURFACE LIGHT command pad on the control panel.
5. Plug in range or reconnect power. Oven Door For normal range use, it is not suggested to remove the oven door. However, if removal is necessary, make sure the oven is off and cool. Then, follow these instructions. The oven door is heavy.
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call. Nothing will operate Is the power supply cord unplugged? Plug into a grounded 3-prong outlet. Has a household fuse been blown or has the circuit breaker been tripped? Replace the fuse or reset the circuit.
To locate the KitchenAid designated service company in your area, you can also look in your telephone directory Yellow Pages. For further assistance If you need further assistance, you can write to KitchenAid with any questions or concerns at: KitchenAid Brand Home Appliances Customer Interaction Center...
For one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, KitchenAid will pay for factory specified parts and repair labor costs to correct defects in materials or workmanship.
