CONGRATULATIONS! Your purchase of this state-of-the-art security system expresses a
deep concern for the security of your vehicle, its contents, and passengers. To fully appreciate
the many functions and safeguards incorporated in this system, please spend a few minutes
reading this manual. You may find unexpected features that could mean the difference
between "protected" and "fully protected"
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such
situations. In addition, the chart on the last page of this manual has a section for the
particular features and options installed in your vehicle as well as the override method
selected. Valet Switch manual override is pre-selected from the factory, however, the
system can be configured for "Custom Code" operation. Confirm the override mode selected
on the last page of this manual, and familiarize yourself with the section on it's operation.
FEATURES :
2 Four Button Programmable RF Transmitters (capable of accepting 4 transmitters)
Separate Lock/Unlock Transmitter Buttons
Four Channel Receiver
Code Hopping Technology
Selectable Manual Override Mode
User Programmable Manual Override Code
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock, Drivers, All, None
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds / 1 Sec, Dbl. 1 Sec
Programmable Active or Passive Door Locks
RF Inhibit with ignition on
Interior Light Flasher (Arm/Disarm/Programming)
Remote Trunk Release (must have electronic trunk release)
LED Status Indicator Displays Arming, Armed, Disarmed & Valet
OPTIONS :
Parking Light Flasher (Relay Required) (Arm/Disarm/Programming)
Starter Disable (Relay Required)
Horn Output (Relay Required)
Multiple Vehicle Capable
Remote Vehicle Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Note: The "Arming" and "Disarming" references in this manual apply only to those vehicles
which have the optional starter inhibit relay installed, and take place when the vehicle
is locked and unlocked respectively.
Model CSI-100
Active/Passive Operation
Remote Keyless Entry
Owner's Manual
128-
1 of 8
Advertisement
Table of Contents
Related Manuals for Code Alarm CSI-100
Summary of Contents for Code Alarm CSI-100
- Page 1 Model CSI-100 Owner's Manual Active/Passive Operation Remote Keyless Entry CONGRATULATIONS! Your purchase of this state-of-the-art security system expresses a deep concern for the security of your vehicle, its contents, and passengers. To fully appreciate the many functions and safeguards incorporated in this system, please spend a few minutes reading this manual.
- Page 2 NOTE: Because this system has an optional horn annunciation circuit, where light flash is mentioned, the horn may also beep a tone pattern synonymous with the flash pattern of the lights. Locking / Arming (Active) 1. Turn off the engine, exit the vehicle, and close all doors. 2.
- Page 3 NOTE: If the optional two step unlock feature was installed, then only the driver's door will unlock during step 1 above. To unlock all doors, press the unlock button of the transmitter a second time. 3. Never attempt to disarm the system from a distance that prevents you from opening a door within 30 seconds, when the system is programmed for passive arming as the system will begin to rearm until a door is opened.
- Page 4 Programming Your Custom Override Code: Unlike override switches easily found, and defeated, this security system allows the consumer to program a personal override code, offering a higher level of security. To take advantage of this option, programmable feature # 6 must be selected for the Custom Code Option.
- Page 5 7. Within 10 seconds, begin to press and release the push button switch to set the units digit. (As per the example, press and release 2 times to set the units digit to 2). 8. Turn the ignition switch to the off position. Immediately observe the LED flash pattern. You will note the LED flashing five times, pause, and then flash two times, pause.
- Page 6 ALTERNATE OUTPUT: This system is designed with an additional output that responds when the asterisk transmit- ter button is presed two times in succession. The intent of this priority output is for use with an upgrade "Remote Start Module", however it can be used to operate any other option that may have been added to your vehicle.
- Page 7 THIS PAGE LEFT BLANK INTENTIONALLY 128- 7 of 8...
- Page 8 © 2003 Code Systems Inc. 525 Minnesota Drive. Troy, MI 48083 128- 128- 8 of 8...
