- Page 1 Tursdale Technical Services Ltd Unit N12B Tursdale Business Park Co. Durham DH6 5PG United Kingdom Phone: +44 ( 0 ) 191 377 3398 Fax: +44 ( 0 ) 191 377 3357 info@tursdaletechnicalservices.co.uk http://www.industrial-needs.com/ Manual TRMS Multimeter PCE-UT 61E...
-
Page 2: Table Of Contents
info@tursdaletechnicalservices.co.uk Table of Contents Title Page Overview Unpacking Inspection Safety Information Rules For Safe Operation International Electrical Symbols The Meter Structure Rotary Switch Functional Buttons Display Symbols Measurement Operation A.DC/AC Voltage Measurement B.DC/AC Current Measurement C.Measuring Resistance D.Testing for Continuity E.Testing Diodes F.Capacitance Measurement G.Frequency Measurement... -
Page 3: Unpacking Inspection
info@tursdaletechnicalservices.co.uk This Operating Manual covers information on safety and cautions. Please read the relevant information carefully and observe all the Warnings and Notes strictly. Warning Except where noted, the descriptions and instructions in this Operating Manual apply to all Model UT61A/UT61B/UT61C/UT61D/UT61E. Unpacking Inspection Open the package case and take out the Meter. -
Page 4: Rules For Safe Operation
info@tursdaletechnicalservices.co.uk Rules For Safe Operation Warning To avoid possible electric shock or personal injury, and to avoid possible damage to the Meter or to the equipment under test, adhere to the following rules: l Before using the Meter inspect the case. Do not use the Meter if it is damaged or the case (or part of the case) is removed. -
Page 5: The Meter Structure
info@tursdaletechnicalservices.co.uk The Meter Structure (see figure 1) LCD Display Functional Buttons Blue button Rotary Switch Input Terminal: Rotary Switch Below table indicated for information about the rotary switch positions. AC and DC Voltage Measurement AC Voltage Measurement (UT61D only) DC Voltage Measurement (UT61D only) Resistance Measurement Diode Test Continuity Test... -
Page 6: Display Symbols
info@tursdaletechnicalservices.co.uk Display Symbols Symbol Meaning Data hold is active. Sleep Mode indicator Indicates negative reading. Indicator for AC measurement Indicator for DC measurement The Meter is in the auto range mode in which the Meter automatically selects the range with the best resolution. Indicator for manual ranging mode. -
Page 7: A.dc/Ac Voltage Measurement
info@tursdaletechnicalservices.co.uk A. DC/AC Voltage Measurement (See figure 2) figure 2 Warning To avoid harms to you or damages to the Meter from electric shock, please do not attempt to measure voltages higher than 1000V although readings may be obtained. When measuring high voltage, take extra care to avoid electric shock. 1. -
Page 8: B.dc/Ac Current Measurement
info@tursdaletechnicalservices.co.uk B. DC/AC Current Measurement (See figure 3) figure 3 Warning Before connecting the Meter to the return circuit to be tested, cut off the current of the return circuit. If the fuse burns out during measurement, the Meter may be damaged or the operator himself may be hurt. -
Page 9: C.measuring Resistance
info@tursdaletechnicalservices.co.uk C. Measuring Resistance (See figure 4) figure 4 Warning To avoid damages to the Meter or to the devices under test, disconnect circuit power and discharge all the high-voltage capacitors before measuring resistance. To avoid harm to yourself, do not input higher than DC 60V or AC 30V voltages. To measure resistance, connect the Meter as follows: 1. -
Page 10: D.testing For Continuity
info@tursdaletechnicalservices.co.uk D. Testing for Continuity (See figure 5) Warning To avoid damages to the Meter or to the devices under test, disconnect circuit power and discharge all the high-voltage capacitors before testing for continuity. To avoid harm to yourself, do not input higher than DC 60V or AC 30V voltages. To test for continuity, connect the Meter as below: 1. -
Page 11: F.capacitance Measurement
info@tursdaletechnicalservices.co.uk l Connect the test leads to the proper terminals as said above to avoid error display. The LCD will display OL indicating diode being tested is open or polarity is reversed. The unit of diode is Volt (V), displaying the forward voltage drop readings. - Page 12 info@tursdaletechnicalservices.co.uk To measure capacitance, connect the Meter as follows: 1. Insert the red test lead into the terminal and the black test lead into the COM terminal. 2. Set the rotary switch to and press BLUE button to select nF measurement mode. l At that time, the Meter will display a fixed value as below which is the Meter internal fixed distributed capacitance value.
-
Page 13: H.temperature Measurement
info@tursdaletechnicalservices.co.uk l When frequency measurement has been completed, disconnect the connection between the testing leads and the circuit under test, and remove the testing leads away from the input terminals of the Meter. H. Temperature Measurement (UT61B and UT61C only) (See figure 9) Warning To avoid harm to yourself, do not input higher than DC 60V or AC 30V voltages. -
Page 14: J.ef Function
info@tursdaletechnicalservices.co.uk 1. Set the rotary switch to hFE. 2. Insert the multi-purpose socket into the input terminal as shown on figure 10. 3. Insert the transistor to be tested into the corresponding multi-purpose socket jacks. 4. The LCD display hFE nearest value Note l When transistor measurement has been completed, disconnect all the connection between multi-purpose socket, transistor and the Meter. -
Page 15: Max Min Button
info@tursdaletechnicalservices.co.uk MAX MIN button (UT61A, UT61B, UT61C and UT61D only) l Press MAX MIN to start recording of maximum and minimum values. Steps the display through high (MAX) and low (MIN) readings. The Meter enters manual ranging mode after pressing MAX MIN button. l Press and hold MAX MIN for over 2 seconds to exit MAX MIN mode and return to the present measurement range. -
Page 16: General Specifications
info@tursdaletechnicalservices.co.uk General Specifications l Maximum Voltage between any Terminals and Grounding: Refer to the different ranges input protection voltage.. Fused Protection for AmA Input Terminal:1A H 240V 6x25mm. Fused Protection for 10A Input Terminal:10A H 240V 6x25mm. l Display UT61A and UT61B:Maximum reading 4000 (frequency 9999), analogue bar graph 41 segments UT61C and UT61D:Maximum reading 6000 (frequency 9999), analogue bar graph 61 segments. - Page 17 info@tursdaletechnicalservices.co.uk (0.8%+3)
- Page 18 info@tursdaletechnicalservices.co.uk...
- Page 19 info@tursdaletechnicalservices.co.uk...
- Page 20 info@tursdaletechnicalservices.co.uk...
- Page 21 info@tursdaletechnicalservices.co.uk 0.01Hz 0.001Hz 0.001V 0.0001V...
-
Page 22: Maintenance
info@tursdaletechnicalservices.co.uk Maintenance This section provides basic maintenance information including battery and fuse replacement instruction. Warning Do not attempt to repair or service your Meter unless you are qualified to do so and have the relevant calibration, performance test, and service information. To avoid electrical shock or damage to the Meter, do not get water inside the case. -
Page 23: B.replacing The Battery
info@tursdaletechnicalservices.co.uk l Do not use or store the Meter in a place of humidity, high temperature, explosive, inflammable and strong magnetic field. B. Replacing the Battery Warning To avoid false readings, which could lead to possible electric shock or personal injury, replace the battery as soon as the battery indicator ìcî... - Page 24 info@tursdaletechnicalservices.co.uk Warning To avoid electrical shock or arc blast, or personal injury or damage to the Meter, use specified fuses ONLY in accordance with the following procedure. To test the fuse: (See figure 13) The Meter does not response when measuring current and transistor hFE, go to inspect the Meter built-in fuses if they are broken.
