Summary of Contents for PCE Instruments PCE-HVAC 6
- Page 1 User Manual PCE-HVAC 6 Digital Multimeter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 18 September 2019 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
MIN/MAX ......................... 9 Hold peak value ......................9 Measurement range ....................... 9 LED backlight ......................... 9 Activate / deactivate lamp .....................10 Auto Power Off ......................10 Battery level indicator ....................10 Replace the fuse ......................10 Warranty ........................11 Disposal .........................11 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Introduction
It is the ideal clamp meter for lots of inspection and maintenance applications in these areas. The PCE-HVAC 6 is a combination of multiple gauges. With its clamp, it can measure currents up to 1000 A DC and AC. Also, voltages up to 600V AC / DC can be measured accurately. - Page 5 Dimensions (W x H x D) 230 x 76 x 40 mm / 9 x 3 x 1.6 in Weight 315 g / <1 lb Safety IEC 1010-1 (2001): EN 61010-1 (2001) CAT III 600V CAT II 1000V Degree of pollution 2 © PCE Instruments...
-
Page 6: System Description
(resistance) amperes (current) farads (capacitance) hertz (frequency) Duty cycle °C und °F Temperature unit T1, T2, T1-T2 Temperature connection 1 Temperature connection 2 Temperature connection 1-2 n, m, µ, M, k Unit prefixes Continuity test Diode test © PCE Instruments... -
Page 7: Input Shutter
(see picture) and close the clamp. If the displayed reading is below 50 A AC/DC, turn the rotary function switch to “50 A”. Zeroing To zero the meter, short-press the ZERO key. If you hear a beep tone, zeroing has been successful. © PCE Instruments... -
Page 8: Ac/Dc Voltage Measurement
“COM“ jack and the red test lead to the red jack. The black jack is for negative connection and the red jack is for positive connection The voltage value will be displayed directly after connecting the test leads. © PCE Instruments... -
Page 9: Resistance / Continuity / Diode / Capacitance Measurement
Note that the capacitors are charged during this measurement. To avoid electric shocks, these should be discharged after the measurement where needed. Resistance measurement The resistance reading will be displayed immediately when the test leads have been connected. © PCE Instruments... -
Page 10: Frequency Measurement
“COM“ input jack and the red test lead to the red input jack. Now measure your test object. The black jack is for negative connection and the red jack is for positive connection. Make sure the meter is connected in series to the test object. © PCE Instruments... -
Page 11: Type Temperature Measurement
RANGE key, you can select a measurement range. To re-activate automatic mode, press the RANGE key for two seconds. LED backlight To activate the backlight, press the HOLD key for two seconds. The backlight is now activated. It will automatically be deactivated after 30 seconds. © PCE Instruments... -
Page 12: Activate / Deactivate Lamp
You can now see the fuse below the battery. You can now remove the fuse and replace it by a new one. The following type of fuse should be used: 500 mA, 660 V F [SIBA 70- 180-40]. © PCE Instruments... -
Page 13: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 14 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
