- Page 1 User Manual PCE-AMM 5 Analogue Multimeter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 23 January 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
DC Voltage Measurement (DCV) ..................5 AC Voltage Measurement (ACV) ..................6 Current Measurement (DC mA) ..................7 Resistance measurement (Ω) ................... 7 LED Measurement ......................8 Continuity Test ......................... 8 Audio Measurement (dB)....................9 Warranty ....................10 Disposal ....................10 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
Maximum working height 2000 meters Safety IEC61010-1, CAT III 600 V Pollution degree Dimensions 168 x 95 x 46 mm Weight approx. 320 g (without batteries) Safety Symbols There are several icons on the meter which mean the following: © PCE Instruments... - Page 5 This icon can be found next to another symbol or a connection and is a reference to the user manual. This icon indicates that high voltage could be present. Shock hazard! Double insulation Earth (ground) DC (direct current) AC (alternating current) Diode Fuse Battery European Conformity © PCE Instruments...
-
Page 6: Device Layout
Device Layout Protective cover Resistance Zero-Point Test Display Cover Function Dial Pointer Panel Manual Pointer Adjust Input Jacks © PCE Instruments... -
Page 7: Display Layout
Switch the device to DCV range • Insert the test leads as shown in the figure below • Select the appropriate voltage in the function dial (6) • Measure the voltage and read the result on the DC scale (11) © PCE Instruments... -
Page 8: Ac Voltage Measurement (Acv)
Switch the device to ACV range • Insert the test leads as shown in the figure below • Select the appropriate voltage in the function dial (6) • Measure the voltage and read the result on the AC scale (12) © PCE Instruments... -
Page 9: Current Measurement (Dc Ma)
If the pointer cannot stay at zero even after adjustment, then the batteries are low and need replacement. • Measure the resistance and read the result on the resistance scale (Ω) (9) • Check the zero point after every reading and readjust if necessary © PCE Instruments... -
Page 10: Led Measurement
Adjust the pointer manually to zero (4) • Insert the test leads as shown in the figure below • Measure the resistance and read the result on the resistance scale (Ω) (9) • If the resistance is below 100Ω the buzzer will sound © PCE Instruments... -
Page 11: Audio Measurement (Db)
Measure the dB and read the result on the dB scale (14) The dB scale shows dB levels from -10bD to ~22dB. For ranges exceeding the scale, the actual dBV should be converted according to the table below. -10~22 4~36 18~50 24~56 © PCE Instruments... -
Page 12: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 13 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
