- Page 1 Tursdale Technical Services Ltd Unit N12B Tursdale Business Park Co. Durham DH6 5PG United Kingdom Phone: +44 ( 0 ) 191 377 3398 Fax: +44 ( 0 ) 191 377 3357 info@tursdaletechnicalservices.co.uk http://www.industrial-needs.com/ MANUAL PCE-123...
- Page 2 info@tursdaletechnicalservices.co.uk Features: 1. 4-20mA (1K Ω load, 24V Loop Supply) 2. 0-100.00mV,0-1.000V, 0-12.000V 3. K, J, E, T Thermocouple ( C and 4. Frequency 1-62500 Hz 5. 0.025% Basic Accuracy 6. Easy Key-pad Operation 7. Easy Step and Auto Ramp Functions 8.
-
Page 3: Table Of Contents
info@tursdaletechnicalservices.co.uk Table of Contents I. PANEL DESCRIPTION ........................4 II. OPERATING INSTRUCTION ......................9 1. mA OUTPUT............................ 9 1a. General Operation 4 - 20mA..................... 9 1b. Select 0 - 20mA or 0 - 24mA....................10 1c. Enter a value less than 1 ......................11 2. -
Page 4: Panel Description
info@tursdaletechnicalservices.co.uk I. Panel Description 1. LCD DISPLAY 6. NUMERICAL & FUNCTION KEYPAD 2. THERMOCOUPLE SOCKET 7. STAND 3. ON/OFF BUTTON 8. AC ADAPTOR INPUT SOCKET 4. SHIFT BUTTON 9. OUTPUT LEADS 5.FUNCTION SELECT SWITCH... - Page 5 info@tursdaletechnicalservices.co.uk...
- Page 6 info@tursdaletechnicalservices.co.uk Press SHIFT button, and then press one of these three buttons to select desired mA Range. Press SHIFT button, then press this button to select desired mV or V range...
- Page 7 info@tursdaletechnicalservices.co.uk °C °F Press SHIFT button, then press this button to select º C or º F K J E T Press SHIFT button, then press this button to select desired type of thermocouple. Press SHIFT button, then press this button to perform auto-ramp function. To stop the auto-ramp function, press this button again Press this button to enter negative temperature.
- Page 8 info@tursdaletechnicalservices.co.uk While the calibrator is in the SHIFT mode, and the percentage is entered, press this button to increment %. ENTER Always press this button to complete the entry of numbers.
-
Page 9: Operating Instruction
info@tursdaletechnicalservices.co.uk II. Operating Instruction 1. mA Output 1a. General Operation 4 - 20mA 1 Turn the power on, and wait until the STBY symbol disappears (about 1 min.) 2 Plug the test leads into the output connectors of calibrator accordingly (Black to black, red to red). -
Page 10: 1B. Select 0 - 20Ma Or 0 - 24Ma
info@tursdaletechnicalservices.co.uk 1b. Select 0 - 20mA or 0 - 24mA The default setting for mA function is 4 - 20mA. But users can select 0 - 20mA or 0-24 mA by pressing the SHIFT button to enter the SHIFT mode. Then press the NUMBER 2 or NUMBER 3 button to select desired DC current range. -
Page 11: 1C. Enter A Value Less Than 1
info@tursdaletechnicalservices.co.uk 1c. Enter a value less than 1 In the mA functions, the standard way to enter a value less than 1 is to press leading 0 before pressing the decimal point. Though the decimal point can be entered, the decimal point will not be shown in the LCD. -
Page 12: Mv, V Output
info@tursdaletechnicalservices.co.uk 2. mV, V Output 2a. General Operation 0 - 100mV 1. Turn the power on, and wait until the STBY symbol disappears (about 2 min.). 2. Plug the test leads into the output connectors of calibrator accordingly (Black to black, red to red). Attach alligator clip if necessary. 3. -
Page 13: 2B. Select 0 - 1V Or 0 - 12V
info@tursdaletechnicalservices.co.uk 2b. Select 0 - 1V or 0 - 12V The default setting for mV, V function is 0 - 100.00mV. Users can select 0 -... -
Page 14: 2C. Enter A Value Less Than 1
info@tursdaletechnicalservices.co.uk 2c. Enter a value less than 1 In the mV/V functions, the standard way to enter a value less than 1 is to press the leading 0 before pressing the decimal point. Though the decimal point can be entered first, the decimal point will not be shown in the LCD. -
Page 15: Thermocouple Calibration Of º C, º F
info@tursdaletechnicalservices.co.uk 4. Thermocouple Calibration of º C, º F. 4a. General Operation 1.Turn the power on, and wait until the STBY symbol disappears (about 1 min.). 2.Plug the corresponding connector (K-type connector for K-type thermocouple, J- type connector for J-type thermocouple, ...) into TC terminals of calibrator and thermometer to be calibrated. - Page 16 info@tursdaletechnicalservices.co.uk Note: Users can plug the connector into the TC terminals of calibrator even before the power is turned on for better thermal equilibrium between the TC terminal and thermocouple connector. Note: Only in the º C and º F functions, the negative values are allowed to be entered. To enter negative temperature, press the minus"-"...
-
Page 17: 4B. Select ºc, Or ºf
info@tursdaletechnicalservices.co.uk 4b. Select ºC, or ºF Users can select º C or º F by pressing the shift button to enter SHIFT mode. Then press the NUMBER 5 button repeatedly to select desired temperature unit. After desired unit is selected, press the SHIFT button again to exit the SHIFT mode. Corresponding voltage º... -
Page 18: 4C. Select K, J, E, Or T Type Thermocouple
info@tursdaletechnicalservices.co.uk 4c. Select K, J, E, or T type Thermocouple Users can select K, J, E, or T type Thermocouple by pressing the shift button to enter SHIFT mode. Then press the number 6 button repeatedly to select desired type of thermocouple. -
Page 19: 4D. Enter A Negative Temperature
info@tursdaletechnicalservices.co.uk 4d. Enter a Negative Temperatura The resolution of temperature is 1 degree, so the decimal point is used a minus "-" sign. To enter a negative temperature, press the "-" button first. 5. % input in the mA, mV, V functions In the mA, mV, or V function, users can enter percentage. - Page 20 info@tursdaletechnicalservices.co.uk...
-
Page 21: Easy Step In The Ma, Mv, And V Functions
info@tursdaletechnicalservices.co.uk 6. Easy Step in the mA, mV, and V Functions While the percentage is entered and calibrator is still in the SHIFT mode, users can step up or down by the percentage entered. The maximum percentage is 100% while the minimum percentage is 0%. -
Page 22: Auto Ramp In The Ma, Mv, And V Function
info@tursdaletechnicalservices.co.uk 7. Auto Ramp in the mA, mV, and V functions In the mA, mV, and V function, auto ramp function is available to the users. To start the ramp function: 1. Press the SHIFT button to enter the SHIFT mode. 2. - Page 23 info@tursdaletechnicalservices.co.uk Note: Do not press any button while the calibrator is performing the ramp function (except NUMBER 7 button to stop the ramp function).
-
Page 24: How To Get Negative Output
info@tursdaletechnicalservices.co.uk 8. How to Get Negative Output If negative output (mA, mV, or V) is needed, users can achieve it by interchange the connection of test leads. -
Page 25: Electrical Specification
info@tursdaletechnicalservices.co.uk III. Electrical Specification (23 º C ± 5 º C, 3 minutes after power is on) mA DC Current (1K Ω Max. Load, 24V Loop Supply) Beeper warning when output is open and specified current output > 1mA mV, V DC Voltage (1mA Supply Current) Beeper warning when output is short and specified voltage output >... - Page 26 info@tursdaletechnicalservices.co.uk Frequency (1 - 125Hz, 1K Ω Load Min.) Range Resolution Accuracy 1 - 125 Hz 1 Hz ± 0.04Hz Available Frequencies (126 - 62500Hz, Accuracy ± 0.01% ± 0.04Hz, 1K Ω Load Min): 126.00 127.03 128.07 129.13 130.20 131.30 132.41 133.54 134.12...
- Page 27 info@tursdaletechnicalservices.co.uk 1470.58 1488.09 1506.02 1524.39 1543.20 1562.50 1582.27 1602.56 1623.37 1644.73 1666.66 1689.18 1712.32 1736.11 1760.56 1785.71 1811.59 1838.23 1865.67 1893.93 1923.07 1953.12 1960.78 1968.50 1976.28 1984.12 1992.03 2000.00 2008.03 2016.12 2024.29 2032.52 2040.81 2049.18 2057.61 2066.11 2074.68 2083.33 2092.05 2100.84 2109.70 2118.64 2127.65 2136.75 2145.92 2155.17 2164.50 2173.91 2183.40 2192.98 2202.64 2212.38 2222.22 2232.14 2242.15 2252.25 2262.44 2272.72 2283.10 2293.57 2304.14 2314.81 2325.58 2336.44...
- Page 28 info@tursdaletechnicalservices.co.uk 1470.58 1488.09 1506.02 1524.39 1543.20 1562.50 1582.27 1602.56 1623.37 1644.73 1666.66 1689.18 1712.32 1736.11 1760.56 1785.71 1811.59 1838.23 1865.67 1893.93 1923.07 1953.12 1960.78 1968.50 1976.28 1984.12 1992.03 2000.00 2008.03 2016.12 2024.29 2032.52 2040.81 2049.18 2057.61 2066.11 2074.68 2083.33 2092.05 2100.84 2109.70 2118.64 2127.65 2136.75 2145.92 2155.17 2164.50 2173.91 2183.40 2192.98 2202.64 2212.38 2222.22 2232.14 2242.15 2252.25 2262.44 2272.72 2283.10 2293.57 2304.14 2314.81 2325.58 2336.44...
-
Page 29: Use The Ac Adapter
info@tursdaletechnicalservices.co.uk General Specification: Battery Type: 9V Alkaline Battery Power Consumption: 60mA - 180mA (depends on output) Low battery: 5.5V at 150mA Load Display: 4 and 5 Digits Operating Temperature: 0 to 50 º C ( 32 to 122 º F) Operating Humidity: Less than 85% relative Storage Temperature:... -
Page 30: Battery Replacement
info@tursdaletechnicalservices.co.uk V. Use External Battery Pack An external battery pack is included for a longer period usage. The external battery pack needs to be packed with 6 pieces of 1.5 volts AA batteries. To use the external battery pack, plug into the AC terminals located in the back of the calibrator. - Page 31 info@tursdaletechnicalservices.co.uk In this direction will find a vision of the measurement technique: http://www.industrial-needs.com/measuring-instruments.htm NOTE: "This instrument doesn’t have ATEX protection, so it should not be used in potentially explosive atmospheres (powder, flammable gases)."...
