Summary of Contents for PCE Instruments PCE-TT 4
Page 1
User Manual PCE-TT 4 Digital Multimeter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 16 July 2020 v1.0 © PCE Instruments...
Page 2: Table Of Contents
Current measurement ...................... 6 Resistance measurement, diode test, continuity test, capacitance measurement ..... 6 NCV measurement ......................8 Temperature measurement ....................8 Phase recognition ......................9 10 Battery replacement................9 11 Warranty ....................9 12 Disposal ....................9 © PCE Instruments...
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments...
Page 4: Delivery Contents
Delivery contents 1 x digital multimeter PCE-TT 4 1 x pair of test leads 1 x K-type thermocouple 1 x transport bag 2 x 1.5 V AAA battery 1 x user manual Technical specifications Measurement Measurement Resolution Accuracy function range...
Page 5: Device Description
Description NCV sensor Signal lamp lights up as soon as the NCV sensor detects a voltage Display Keyboard Rotary measuring switch Connections for test leads Test lead holder - first possibility Test lead holder - second possibility © PCE Instruments...
Page 6: Keyboard Description
Hold function - the measured value has been frozen "Not Connected Voltage" measuring function for checking an applied voltage Voltage units mV,V μA,mA,A Current units Ω,KΩ,MΩ Resistance units Frequency units Hz,kHz F, μF, nF Farat units °C, °F Temperature units © PCE Instruments...
Page 7: Switching On / Switching Off
Note: With the smaller measurement ranges, a measured value can be displayed even if the measuring cable is not connected. This is due to the sensitivity of the measuring instrument. As soon as the measuring instrument is connected to the test sample, the correct measured value is displayed. © PCE Instruments...
Page 8: Current Measurement
"SEL" key. Then connect the test lead to your test object to perform a measurement. The measured value is shown directly on the display. The following measurement ranges are available for the resistance measurement: 600 Ω, 6 Ω, 60 Ω, 600 kΩ, 6 Ω, 60 MΩ © PCE Instruments...
Page 9
Pay attention to the polarity when measuring. After a measurement, the measured capacitors are charged. There is a risk of electric shock. During the continuity test, an acoustic signal is triggered as soon as the measured resistance is <50 Ω. © PCE Instruments...
Page 10: Ncv Measurement
In order to carry out a temperature measurement, turn the rotary measuring switch to " ". Now connect a K-type thermocouple. The current measured value is displayed directly. To select one units degrees Fahrenheit degrees Celsius, press "SEL" key. © PCE Instruments...
Page 11: Phase Recognition
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments...
Page 12
