moon Andromeda Owner's Manual

Evolution series reference cd player
Hide thumbs Also See for Andromeda:
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
MOON Evolution Series
ANDROMEDA
Reference CD Player

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Andromeda and is the answer not in the manual?

Questions and answers

Related Manuals for moon Andromeda

Summary of Contents for moon Andromeda

  • Page 1 Owner’s Manual MOON Evolution Series ANDROMEDA Reference CD Player...

  • Page 2: Important Safety Instructions

    MOON Andromeda CD Player Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 3 To prevent shock hazard, all three connections must ALWAYS be used. Connect the MOON Andromeda only to an AC source of the proper voltage; Both the shipping box and rear panel serial number label will indicate the correct voltage. Use of any other voltage will likely damage the unit and void the warranty AC extension cords are NOT recommended for use with this product.

  • Page 4: Table Of Contents

    Congratulations ..........5 Unpacking ............5 Introduction ........... 6 Installation & Placement ........7 Connecting the Andromeda Power Supply .... 8 Loading a Compact Disc ........9 Top Panel Controls .......... 9 Front Panel Controls ........10 Rear Panel Connections ........12 SimLink™...

  • Page 5: Congratulations

    Your new CD Player is a true dual-mono design, whereby each channel operates completely independent of the other. The performance of your Andromeda will continue to improve during the first 400 hours of listening. This is the result of a “break-in”...

  • Page 6: Introduction

    MOON Andromeda CD Player Introduction Your MOON Andromeda CD Player incorporates many significant design features to achieve its “world class” level of performance. This is an abbreviated list of the more important features: 24-bit/705.6kHz internal upsampling using BurrBrown DF1704 Digital Filter with 16X oversampling.

  • Page 7: Installation & Placement

    These cones will easily scratch most surfaces, therefore it’s advisable to follow these instructions: Place your Andromeda on a soft surface (i.e. carpet) and carefully turn it so that it rests on its side. Screw one cone onto each of the four posts.

  • Page 8: Connecting The Andromeda Power Supply

    Ensure that the AC wall outlet you use has a functioning ground. For the best sonic performance, it is preferable that you plug your MOON Andromeda CD Player directly into a dedicated AC outlet and avoid using an extension cord.

  • Page 9: Loading A Compact Disc

    For the MOON Andromeda to operate reliably, it is important to ensure that the surface of the transport platter and the inside of the clamp are free of any dust, or other debris.

  • Page 10: Front Panel Controls

    The “Time” button allows you to scroll through the four (4) different display modes for time related information. Each time you press the “Time” button, the system scrolls to the next time information mode. By default, the Andromeda will display the elapsed time of the track currently playing.
  • Page 11 To turn the display back on, simply press and hold the “Display” button for 3 seconds. The sonic performance of the MOON Andromeda CD Player may improve slightly when the display is turned off. The “Program” button allows you to program a selection of tracks in the order that you wish to listen them. After loading a...

  • Page 12: Rear Panel Connections

    There is one S/PDIF digital input on a BNC connector labeled “Digital In”. This allows you to use external digital source with a digital output such as a music server in conjuction with the MOON Andromeda, with the latter functioning as a reference digital-to-analog converter.

  • Page 13: Simlink

    In the event that you plan to be away from your home for a few days, powering off the CD Player may not be a bad idea. Once fully “broken-in”, please keep in mind that your Andromeda will require several hours of playing time before it reaches its peak performance after you’ve powered it up again.

  • Page 14: Balanced Operation

    For example, when one conductor is carrying a signal of +4 Volts, the other will be carrying a signal of –4 Volts. When these two inverted signals on a balanced line are output from the MOON Andromeda, any noise picked up by the interconnect will be eliminated since a differential circuit amplifies only the difference between these two signals: Noise on a balanced interconnect will be equal on both conductors and therefore not be processed.

  • Page 15: Specifications

    Balanced Pin Assignment: Pin 1........ Ground Pin 2........ Positive Pin 3 ......Negative NOTE: In the event that you require the RS-232 codes for your MOON Andromeda, please contact Simaudio Ltd. directly by either email (service@simaudio.com) or by toll-free telephone (877-980-2400).
