Oven Door Parts - KitchenAid KEMS308SBL04 Parts List

Illus. Part
No. No. DESCRIPTION
1 8303737BL Door Liner
2 W10174285 Hinge, Door (2)
3 3196183 Screw
4 8304581BL Vent, Door Top
5 Bracket, Door
8304377 Right
8304378 Left
6 Cover, Hinge
W10137044 Right
W10137043 Left

OVEN DOOR PARTS

For Models:KEMS308SBL04, KEMS308SWH04, KEMS308SSS04
(BLACK)
Illus. Part
No. No.
7 8303731 Glass, Inner
8 4449154 Screw
10 8304523 Seal
11 8304360BL Bracket, Handle
12
8303993 Black
8303995 White
W10237350 Stainless
(WHITE) (STAINLESS)
Illus.
DESCRIPTION No.
13
15
Door Glass,
16
Assembly
17
Lower Includes #17
18
4
Part
No. DESCRIPTION
Door Handle
8303774BL Black
8303774WH White
8303774SS Stainless
8303745BL Frame, Door Side
8303746 Door, Top Bracket
Badge
8304603BL Black
8304603WH White
8304603SS Stainless
8304522 Bumper, Glass
W10269268
