    1.0 General 1.1 Equipment Description The 1582-22L RF Protection Switch provides Auto, Manual or Remote latched relay switching between CH1 and CH2 RF signals from .95 to 2.15 GHz including 10 MHz and DC power for attached LNB or SSPB devices.
  • Page 4 1.2 Technical Characteristics TABLE 1.1 1582-22L RF Switch Specifications* Switch Characteristics Impedance Type / Configuration Latching Relay / DPDT Insertion Loss 2 dB (10 to 25 MHz) Not Specified (26 MHz to 0.8 GHz) 1.5 dB, 1.0 dB typ. (0.95 to 1.5 GHz) 2.5 dB, 2.0 dB typ.

  • Page 5: Installation

    It is housed in a 1 RU (1 3/4 inch high) by 12 inch deep chassis. Redundant switching power supplies provide power for the assembly. The 1582-22L can be secured to a rack using the 4 holes on the front panel.
  • Page 6 A&B. See Table 2.2. for switches A&B. See Table 2.2. 100-240 ±10% VAC, 47-60 Hz. FIGURE 2.2 1582-22L RF Switch Rear Panel Inputs/Outputs Table 2.1 J7 Pinouts (Monitors and Controls) Table 2.1 J7 P P inouts Pinouts (Monitors and...
  • Page 7 CH2 is manually remote control is active. alarm input is a closure or and stay red until HISTORY selected (using S3). open (selectable). RESET is pressed. FIGURE 2.3 1582-22L Front Panel Controls and Indicators 1582-22L Manual, Rev. C Page 7 06/13/11...
  • Page 8 RESET pin on J7, and then it switches to channel 1. (If channel 1 alarms are cleared ). If in the ICS mode and originally set to CH2 the 1582-22L will not switch if CH2 alarms.

  • Page 9: Operation

    2.4 Operation 1. Set the on board controls as desired (see Sections 2.3.1 and 2.5, and Figure 2.1). 2. Install the 1582-22L in the equipment rack. 3. Connect signals to the BNC connectors (J1-J6 and J8-J13). 4. Connect to signals on the MONITORS AND CONTROLS connector, J7, as desired (see Figure 2.2, Table 2.1).

  • Page 10: Switch Mode Setup

    Auto switching occurs only if current channel alarms and the other channel is clear. Non-dot - JP4; Dot - JP1, JP2, JP3; S4 - ALL TO ON. Factory set mode is generally 1) CH1 Prime Mode. 1582-22L Manual, Rev. C Page 10 06/13/11...
  • Page 11 G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed. If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS emission problems. 1582-22L Manual, Rev. C Page 11 06/13/11...
