- Page 1 Attachable LCD Entertainment System U s e r m a n u a l...
- Page 2 Schiller Park, Illinois 60176 • U.S.A. 847.288.3300 • FAX: 847.288.3703 800.735.3867 (Toll-free within U.S.A., Canada) www.lifefitness.com NTERNATIONAL FFICES LIFE FITNESS ASIA PACIFIC LTD LIFE FITNESS EUROPE GMBH Room 2610, Miramar Tower Siemensstrasse 3 132 Nathan Road 85716 Unterschleissheim Tsimshatsui, Kowloon...
- Page 3 NSTALLATION NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference with radio communications.
-
Page 4: Table Of Contents
Service Contacts ...........21 © 2005 Life Fitness, a division of Brunswick Corporation. All rights reserved. -
Page 5: Important Safety Instructions
• Never operate a Life Fitness product if it has a damaged power cord or electrical plug, or if it has been dropped, damaged, or even partially immersed in water. If this occurs, contact Life Fitness Customer Support Services as outlined in Service Contacts at the end of this manu- •... - Page 6 Toujours suivre les instructions sur le produit pour s'assurer de son fonctionnement adéquat. • Ne jamais insérer aucun objet dans les ouvertures du produit Life Fitness. Si un objet tombe à l'intérieur du produit Life Fitness, le débrancher et extraire l'objet soigneusement pendant que l'appareil est débranché.
-
Page 7: Tv Cable Connections
MPORTANT AFETY NSTRUCTIONS Note to the CATV Installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical. -
Page 8: System Setup
YSTEM ETUP ASIC UNCTIONS Turn the power on by pressing the ON/OFF button (1) on the remote control. On EZ model Bike, Cross- Trainer and Stairclimber products, begin pedaling to power the console before using the ON/OFF button. The volume can be increased or decreased by pressing the up or down VOLUME ARROW KEYS (2). A volume indicator will appear on the TV while the volume is being adjusted. -
Page 9: How To Access Menus
YSTEM ETUP OW TO CCESS ENUS Turn the power on by pressing the ON/OFF button on the remote control. Wait at least five seconds before proceeding. To access the system setup menus, press and hold the ON/OFF button on the remote control for five seconds. The main system setup menu will appear. - Page 10 COUNTRY Selecting COUNTRY will display a menu from which available coun- TV Install TV Install tries can be selected. Selecting the proper country ensures the Country receiver is configured for the correct broadcast type. System Sound Use the VOLUME ARROW KEYS on the remote control to highlight Air/Cable either next or back in the COUNTRY menu.
- Page 11 YSTEM ETUP SYSTEM Selecting SYSTEM displays a selection of compatable PAL TV Install TV Install broadcast types. This input will override settings made when Country choosing a COUNTRY in the TV INSTALL menus. System Sound Selecting the wrong input will result in a distorted broadcast pic- Air/Cable ture.
- Page 12 SOUND Selecting SOUND will display a menu from which specific audio TV Install TV Install formats can be selected as the input preference. Country System Sound Air/Cable Channel Scan Frequency Scan Add Channel Add Channel Revove Channel Revove Channel Channel Swap Channel Swap Sleep Timer Sleep Timer...
- Page 13 YSTEM ETUP AIR/CABLE Selecting AIR/CABLE will display a menu from which either stan- TV Install TV Install dard air broadcast or cable television can be selected as the Country input preference. A color change occurs to verify selection System acceptance Sound Air/Cable Channel Scan...
- Page 14 ADD CHANNEL TV Install TV Install Selecting ADD CHANNEL will add an available channel that has Country been previously removed from the viewable listing. ADD CHAN- System NEL can also be used to add channels with weak signal strength Sound that the TV tuner cannot automatically find.
- Page 15 YSTEM ETUP CHANNEL SWAP Selecting CHANNEL SWAP will display a menu from which avail- TV Install TV Install able channel number assignments can be modified. Country System Use the VOLUME ARROW KEYS on the remote control to select- Sound the DESIRED channel to swap (A). Use the CHANNEL DOWN Air/Cable ARROW KEY to highlight the alternate channel selection.
-
Page 16: Language Menu
ANGUAGE Selecting LANGUAGE will display a menu from which available languages can be selected in which to display setup menus. Use the VOLUME ARROW KEYS on the remote control to high- light the DESIRED language. Select the NEXT option to view additional language choices. - Page 17 YSTEM ETUP HORIZONTAL POSITION Selecting HORIZONTAL POSITION will display a numeric indicator below the menu display. Using the VOLUME ARROW KEYS on the remote control, the horizontal position of where the setup menus appear can be modified. Use the VOLUME UP ARROW to move the menu to the right and the VOLUME DOWN ARROW to move the menu to the left on the screen.
-
Page 18: Picture Menu
ICTURE Selecting the PICTURE menu will display options to modify cur- rent display quality settings including CONTRAST, BRIGHT- NESS, SATURATION, HUE and SHARPNESS. The broadcast input type can be modified as well. CONTRAST Selecting CONTRAST will display a numeric indicator below the menu display. - Page 19 YSTEM ETUP Selecting HUE will display a numeric indicator below the menu display. Using the VOLUME ARROW KEYS on the remote con- trol, the picture color hue can be modified. Use the VOLUME UP ARROW to increase and the VOLUME DOWN ARROW to decrease the picture color hue.
-
Page 20: Caption/Text Menu
APTION Selecting CAPTION/TEXT will display a menu listing of possible closed caption text channels. ESET Selecting RESET ALL will return ALL settings to the original factory defaults. This includes all TV Install, Language, OSD, Picture, and Caption/Text settings. -
Page 21: Other Information
THER NFORMATION ROUBLESHOOTING If you are having a problem with your TV, try the suggestions below. If the problem persists, contact Life Fitness Customer Support Services as outlined in Service Contacts at the end of this manual. Problem Possible Solutions Reset the TV to factory settings Refer to the System Setup section for instruction on how to access the Reset All option. -
Page 22: Specifications
PECIFICATIONS Channel coverage VHF: 2-13/UHF: 14-69/CATV: 1-125 Antenna 75-ohm external antenna terminal for VHF/UHF (>43dBuV (@75ohm) or > 65.8dBm) Screen Size 12.1 in. Diagonal, 800 x 600 TFT LCD Power requirements 100V-240v, 50-60 Hz External Power Supply 12v. DC Headphone Jack 300 milliwatt, 3.5mm Stereo Power Consumption 12 v. - Page 23 M051-00K32-A065 Life Fitness World Headquarters 5100 North River Road Schiller Park, IL 60176...
