Maintenance - Black & Decker VP510 Instruction Manual

7.2 volt cordless detail sander
Hide thumbs

Advertisement

380850/VP510
5/1/02
11:00 AM
materials extra care should be taken to avoid inhalation and
minimize skin contact.
SAVE THESE INSTRUCTIONS
ASSEMBLY/ADJUSTMENT SET-UP
WARNING:
Always remove batteries from tool before any of the following
operations.
• PAPER ATTACHMENT
To apply a new piece of sandpaper, center the cloth side of the paper over the
platen, (Fig. 3). Press firmly.
NOTE: Use only VersaPak Detail Sandpaper with your detail sander.
OPERATING INSTRUCTIONS
• REMOVING AND INSTALLING THE BATTERIES
NOTE: VERSAPAK™ BATTERIES ARE NOT FULLY CHARGED AT THE
FACTORY.
To install the batteries into the tool, slide them into the handle until they click into
place.
To remove the VersaPak™ batteries from the tool, press the release buttons,
(Fig. 4), and pull the batteries out of the tool handle.
NOTE: Battery caps are provided for use when carrying batteries or while battery
is stored in a pocket, tool box, etc. Remove cap before placing battery in charger or
tool.
Install the battery cap, (Fig. 2), by snapping it in place. To remove the cap, simply
pull it off.
NOTE: Only operate tool with both VersaPak™ batteries installed.
• SWITCH
To turn the tool on, hold it (Fig. 5) and depress the front end of the rocker switch
labeled "I". To turn off, depress the rear end of the rocker switch labeled "O".
• SANDING
Do not push down on the tool. Pushing down while sanding slows the removal
rate.
Page 5
The tips of the sandpaper may wear unevenly, depending on use. When tip of
sandpaper is worn, remove the sandpaper, rotate it, and press it back on the
platen. NOTE: The platen is not designed to rotate. NOTE: Large work surfaces
should be sanded with a 1/4 sheet sander or a 1/2 sheet sander. Use this tool to
sand small or tight areas (Fig. 5).

MAINTENANCE

Use only mild soap and damp cloth to clean the tool. Never let any liquid get
inside the tool; never immerse any part of the tool into a liquid.
IMPORTANT: To assure product SAFETY and RELIABILITY, repairs, maintenance
and adjustment should be performed by authorized service centers or other
qualified service organizations, always using identical replacement parts.
• THE RBRC™ SEAL
The RBRC™ (Rechargeable Battery Recycling Corpora
the nickel-cadmium battery (or battery pack) indicates
that the costs to recycle the battery (or battery pack) at
the end of its useful life have already been paid by
Black & Decker. In some areas, it is illegal to place
spent nickel-cadmium batteries in the trash or municipal solid waste stream and
the RBRC program provides an environmentally conscious alternative.
RBRC in cooperation with Black & Decker and other battery users, has
established programs in the United States to facilitate the collection of spent
nickel-cadmium batteries. Help protect our environment and conserve natural
resources by returning the spent nickel-cadmium battery to an authorized
Black & Decker service center or to your local retailer for recycling. You may also
contact your local recycling center for information on where to drop off the spent
battery.
Accessories
Recommended accessories for use with your tool are available from your local
dealer or authorized service center. If you need assistance regarding accessories,
please call: 1-800-762-6672.
WARNING:
The use of any accessory not recommended for use with this
tool could be hazardous.
5
tion) Seal on
Ni-Cd
If you have any questions, call 1-800-54-HOW-TO
