First Boot Up - JS Automation DC2010 User Manual

4.3

First boot up

When power on, the front panel ACT indicator will be flicking to indicate power on but DC2010
not working. To start the DC2010 press the confirmation button more than 3 s. The LCD will display the
welcome message as follows:
D a t a
J S A u t o m a t i o n
S y s t e m
> > >
Normally the system will be ready to serve within 2 minutes. After the system boot up, there are
two possible situations will be:
A. If first time boot up and hard disk have never formatted. The system will request to create
system.
C r e a t e
←
B. If the system has already created and no error occurs, the message will be the IP you set. (in this
example the IP is : 192.168.0.168)
D C - 2 0 1 0
1 9 2 . 1 6 8 . 0 . 1 6 8
C e n t e r
B o o t i n g
S y s t e m
(Welcome message)
(System booting...)
→
13
