DC2010
Data Center
User's Manual (V1.0)
健昇科技股份有限公司
JS AUTOMATION CORP.
新北市汐止區中興路 100 號 6 樓
6F., No.100, Zhongxing Rd.,
Xizhi Dist., New Taipei City, Taiwan
TEL：+886-2-2647-6936
FAX：+886-2-2647-6940
http://www.automation.com.tw
http://www.automation-js.com/
E-mail：control.cards@automation.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC2010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JS Automation DC2010

  • Page 1 DC2010 Data Center User’s Manual (V1.0) 健昇科技股份有限公司 JS AUTOMATION CORP. 新北市汐止區中興路 100 號 6 樓 6F., No.100, Zhongxing Rd., Xizhi Dist., New Taipei City, Taiwan TEL：+886-2-2647-6936 FAX：+886-2-2647-6940 http://www.automation.com.tw http://www.automation-js.com/ E-mail：control.cards@automation.com.tw...
  • Page 2 Correction record Version Record...

  • Page 3: Table Of Contents

    Restore system setting from local panel ................24 4.15 System restart setting from local panel..................25 4.16 Shutdown DC2010 from local panel ..................25 4.17 AUTO shut down by UPS power lost..................26 Introduction to web storage manager....................27 System information from web storage manager ................29 Login the administration page ....................29...
  • Page 4 Access Right Management -> Group management ...............41 Access Right Management -> User management..............43 Access Right Management -> File Sharing ................47 System service ...........................51 System Service -> FTP Service .....................51 System Service -> iTunes Service ..................52 System Service -> Backup.....................54 System Service -> Log file ....................58 Application.............................60 10.1 BitTorrent..........................60...

  • Page 5: Introduction

    1 Introduction Thank you for purchasing the DC2010 data center. This device is network attached file server (NAS) with RAID1 auto backup. The operating system is a customized Linux based OS, which stored at on board flash. For the ultimate safety, the power of the hard disks is separately powered.

  • Page 6: Install Hard Disks

    2 Install hard disks Slide out the rack 1. Un-screw the screws as red circle shown. 2. Pull to slide out the rack from cover.
  • Page 7 Install hard disks 3. Install the hard disk power and control cables 4. Screw to fix the hard disks. 5. Install the cables to the hard disks...
  • Page 8 Re-cover the device 6. Slide in the rack to the cover 7. Screw the bottom screws 8. Screw the rear panel screws...

  • Page 9: Hardware Installation

    3. RJ45: Ethernet connector Connecting to a single PC DC2010 may work as an external safe storage of your PC, if you connect the DC2010 to your PC only. In this environment, you cannot share files through network with others.

  • Page 10: Connecting To Be Accessible From Internet

    DC2010 rear D type 9pin connector to the UPS 9 pin connector with standard RS232 cable. When the power is lost, the UPS will inform the DC2010 to safely shut down; then if power recovered, the UPS will inform the DC2010 to auto boot.

  • Page 11: Configuration Through Front Panel

    2. UPS: UPS active indicator, when the rear RS232 connector successfully connect to OPTI-UPS VS375C, the indicator will light. 3. ACT: ACT indicator flicks while power on but the DC2010 not active. While the device is activated, the ACT will light.

  • Page 12: How To Operate The Touch Wheel

    How to operate the touch wheel Before we use touch wheel and confirmation button to input or correct the digits, let us take a brief trip about the operation. There are two possible manual touch methods, rotate wheel or touch click. The default is rotate wheel input method.
  • Page 13 If the input method is touch click, refer the followings: Touch click input method: 1. There are 2 cursors on the screen; the top lane cursor is the input cursor, the lower lane cursor is the candidate cursor. 2. The cursor highlighted input digit is the digit available to input. 3.

  • Page 14: First Boot Up

    When power on, the front panel ACT indicator will be flicking to indicate power on but DC2010 not working. To start the DC2010 press the confirmation button more than 3 s. The LCD will display the welcome message as follows:...

  • Page 15: System Creation

    System creation System creation will erase the data already on the hard disk and copy the operating system to hard disk. At first boot up system requires creating system. If system failure or manually request to create system, you must make sure if you want to discard the data or you have data backed up somewhere. The default configuration of the system is RAID1, we strongly recommended to use 2 disks of the same model.

  • Page 16: Entering Parameter Editing Mode

    0 1 2 3 4 5 6 7 8 9 ↵ ↑ ← → Select confirm to input data to DC2010 P a s s w o r d E r r o r P l e a s e...
  • Page 17 ← → Go back to top layer of menu S y s t e m R e s t a r t ← → DC2010 restart A u t o D e m o ← → Demonstrate the setting procedures...

  • Page 18: System Information From Local Panel

    N a m e D C 2 0 1 0 Display device name, default is DC2010 but you can modify to your preferred through web API program. Touch confirmation button for next message. F i r m w a r e V 1 .

  • Page 19: Lcd Backlight Setting From Local Panel

    LCD backlight setting from local panel Right shift the touch wheel until ‘Screensaver time’ displayed. L C D B a c k l i g h t → ← Now you’re in LCD back light setting sub-function, touch confirmation button to choose it.

  • Page 20: Network Setting From Local Panel

    0 1 2 3 4 5 6 7 8 9 ↵ ↑ ← → Select the confirm icon and touch the confirmation button to set DC2010 D a t a C e n t e r 1 9 2 . 1 6 8 . 0 . 7 Now return the upper level and new IP displayed, rotate touch wheel to next item.
  • Page 21 (other DNS Server display) then rotate touch wheel to ‘Return’ display. R e t u r n Touch confirmation button to update the setting of DC2010. N e t w o r k R e s t a r t...

  • Page 22: Usb Backup Setting From Local Panel

    4.10 USB backup setting from local panel USB back up function can be used for copy files from USB to DC2010 directly. All the files on USB will copy to DC2010. Right shift the touch wheel until ‘Backup from USB’ displayed.

  • Page 23: Selection Of Input Method

    4.11 Selection of input method Selection method provide the possible input method: rotate wheel or touch click input method S e l e c t i o n M e t h o d ← → Now you’re in input method selection sub-function, touch confirmation button to choose it.

  • Page 24: Password Change Setting From Local Panel

    4.12 Password change setting from local panel Right shift the touch wheel until ‘Password Change’ displayed. P a s s w o r d C h a n g e ← → Now you’re in password change sub-function, touch confirmation button to choose N e w P W D : _ _ _ _ _ _ 0 1 2 3 4 5 6 7 8 9...

  • Page 25: Create System Setting From Local Panel

    4.13 Create system setting from local panel Create System will destroy all the data already on the device. Please make sure you have backup copy or you will discard the data else do not try this function. C r e a t e S y s t e m ←...

  • Page 26: System Restart Setting From Local Panel

    ■ Y e s Rotate the touch wheel to choose what you want then touch the confirmation button to take action. 4.16 Shutdown DC2010 from local panel From the default system display: D C - 2 0 1 0 1 9 2 . 1 6 8 . 0 . 1 2 0 Press the confirmation button to shutdown the device.

  • Page 27: Auto Shut Down By Ups Power Lost

    4.17 AUTO shut down by UPS power lost If the device has backup with a OPTI_UPS model VS375C UPS; the power input to the UPS is lost, the DC2010 will automatically shutdown then automatically wake up (auto re-boot) while power comes again.

  • Page 28: Introduction To Web Storage Manager

    C zone: the web tab area for fast page changing, if the tabs is more than 6, an alarm will request you close for further display. Please click the close icon on the tab to close the undesired display. D zone: logout icon, if you just close the browser without logout, the DC2010 will wait about 5 minutes to re-log in.

  • Page 30: System Information From Web Storage Manager

    Login the administration page Open the web browser and key in the IP address of DC2010. If you do not know the IP address the current DC2010 occupied, please take a look at the panel of DC2010. (If you access the DC2010 administration page from external, please confirm that the DC2010 has mapped to external IP by router or gateway and use the mapped IP to connect).

  • Page 31: System -> Overview

    If you have not change the administrator’s name and password, you should use the default username: admin and default password: 123456 to log in. On the same web page, you can choose the language to be displayed (currently only English, Chinese and Japanese can be choose).

  • Page 32: System -> Summary

    Workgroup Name: display workgroup name set at System Manager->Network. IP Address: the IP address set (set at System Manager->Network or by DC2010 touch panel) Firmware Version: version on current system (defined by manufacture) Hard Disk Capacity: capacity of the hard disk installed...

  • Page 33: System Management From The Web Storage Manager

    7 System management from the web storage manager System Manager -> Date and Time To setup and adjust the server time. Time Zone: select the time zone where your server is located...
  • Page 34 Time Setting: To choose the server time will synchronize with external standard time server (NTP server) or internal clock. Synchronize with a NTP server：choose the server you prefer.
  • Page 35 Manually: setup the internal real time clock and the server synchronizes with it. You should click the date icon to choose the date you will set. Either Synchronize with a NTP server or Manually mode, you must click the Apply button to save the settings to the server.

  • Page 36: System Manager -> Network

    System Manager -> Network To set up the network related parameters. Device Name：set the device name, the default name is DC2010. If you have multiple devices, it is better to give different names. LAN Setting: setup the IP manually or Automatically define by DHCP.
  • Page 37 After all parameters are setup, use Apply button to save the data. Special Notes: The server IP, Netmask, Gateway and DNS are very important parameters to the DC2010. Any error setting will cause mal-function. Please consult with your network administrator or the...

  • Page 38: System Manager -> Language

    System Manager -> Language You can choose the language you preferred used in the web storage management interface. Currently, we provide 3 languages: English, Japanese and Traditional Chinese. Choose then click apply to activate or cancel to keep the old setting.

  • Page 39: System Manager -> Administrator

    System Manager -> Administrator Old user：the previous administrator’s name Old Password：the previous name New users：new administrator’s name you want to use Password Strength：pass word security strength Password：your new password Confirm Password：password confirmation Click ‘Apply’ to store and change setting.

  • Page 40: System Manager -> Disk Manager

    System Manager -> Disk Manager There are two possible disks: internal disk and external disk. The internal disk is the disk installed in the DC2010 and external disk is the disk sees from the USB port. Internal Disk Manager Choose ‘Internal Disk Manager’, you will get the information of the internal RAID disks.

  • Page 41: System Manager -> Ddns

    System Manager -> DDNS The DDNS(dynamic direct name server, dynamic DNS) is used for the dynamic IP, which is not fixed at each time you hook on the internet, the DDNS will give the user as if the IP is fixed. You must register you web name on some DDNS server, each time the guests visit your web site the server will route to the IP now you are using.

  • Page 42: Access Right Management From The Web Storage Manager

    8 Access Right Management from the web storage manager Access Right Management -> Group management Group management is used to setup the authority of groups, which will simplify the user management. Users can be belonged to one or several groups to define their authentication. Add group：add new group.
  • Page 43 How to add a group: 1. Click Add group icon. 2. Key in the group name. 3. Click ‘Apply’ to enter the data. How to delete a group: 1. Click Delete group at the group you want to delete. 2. For example to delete NAS group. Click the delete icon of the NAS group then the pop up screen wants you to confirm.

  • Page 44: Access Right Management -> User Management

    Access Right Management -> User management There are 3 functions in user management: Add user: add new user. Modify user: modify user’s setting Delete user: delete user...
  • Page 45 How to add a user: 1. Click Add user to enter add user mode. 2. Select one of the name lists in the main group. For example ‘Nas’. (The list is setup at Group management)
  • Page 46 Select subgroup by click on the items in the list. (Multiple select can use the mouse click with control key pressed). For example choose RD,MD as subgroup, you must press the control key then click on RD and MD. The selected items will be highlighted. 4.
  • Page 47 Modify a user attribute 1. Click Modify user to enter modify user attribute mode. 2. The main group, subgroup and password are the attributes to be modified. 3. Click ‘Apply’ to confirm the modification or click ‘Cancel’ to discard modification. How to delete a user: 1.

  • Page 48: Access Right Management -> File Sharing

    Access Right Management -> File Sharing There are 2 file types of files sharing: CIFS(Common Internet File System, used for windows neighboring) and FTP (File Transfer Protocol, a standard network protocol used to copy a file from one host to another over a TCP-based network). You can enable or disable the file protocol for the designate file directory, which will decide the function you will provide.
  • Page 49 How to add a folder: 1. Click Add folder to enter add folder mode. In ‘Share’ column key in the folder name you want. say ‘TEST’ for example. 3. In ‘Services’ column, choose the file protocol you want to use. 4.
  • Page 50 6. Click ‘Apply’ to enter the data or click ‘Cancel’ to discard setting. 7. If you click “apply’ to enter data, you will be able to watch the new added folder in the file sharing list.
  • Page 51 How to modify folder: 1. Click Modify folder to modify attributes. 2. You can modify the authentication, as you need. 3. Click ‘Apply’ to confirm the modification or click ‘Cancel’ to discard modification. How to delete folder: 1. Click Delete folder in the folder list to delete the folder. For example, click the delete icon in the NAS column;...

  • Page 52: System Service

    9 System service System Service -> FTP Service 1. FTP service web page is used for FTP configuration. FTP Enable: check it will enable the FTP service else no FTP service. FTP Connection Setting Port no.: FTP service port, the default is 21 Client Connection Limitations: Check to configure the following settings else no limit.

  • Page 53: System Service -> Itunes Service

    2. Open the iTunes application program; it will automatically scan the iTunes server. 3. You will find the server on your DC2010 device name. (Say, your DC2010 is named as jsnas then the iTunes will display ‘jsnas’ as the iTunes server name)
  • Page 54 53 53...

  • Page 55: System Service -> Backup

    For safety reason we want to backup data automatically to a different place. Using remote backup you need 2 working DC2010’s on internet. Local DC2010 and remote DC2010. Then you can configure to backup data from local to remote automatically.
  • Page 56 Destination folder: the directory (in the remote server) which you want to backup to. Destination IP: the IP of remote DC2010. Destination Password: The password of remote DC2010 for remote backup purpose. Backup: There are 4 backup modes. Do not back up: setup configuration only and do not start backup function.
  • Page 57 The remote backup keeps your data in a safety place, if you need to restore to the original local DC2010, you must follow the instructions: 1. On the remote DC2010, please enter the web storage management page. 2. In the Access right management -> File Sharing, modify the attributes cifs and FTP of folder...
  • Page 58 USB will display on the Do not backup files list) 2. Click on the file and using -> or <- to configure the file selection. 3. Assign the destination path of the DC2010 that you want to backup the files from USB. 4. Click ‘Apply’ to start the operation.

  • Page 59: System Service -> Log File

    System Service -> Log file Log file will record the date, time, login user and login IP’s and the DC2010 echo messages. It provides information for you to debug or monitoring the operations. Delete the log file: delete the log file, all the logging information will be cleared.
  • Page 60 How to delete the log file 1. Click Delete the log file, if you want to clear all the log messages. 2. Click ‘Apply’ to confirm the operation or click ‘Cancel’ to discard the operation. How to delete a log message 1.

  • Page 61: Application

    Application Torrent files are part of a P2P (peer to peer) trading system that make transferring files from one person to another on the Internet very easy, quick and effective. It is important to note that torrent sharing is different from other types of P2P services, you need a .torrent files that contain the information required for a torrent client to find, manage and download the requested file.
  • Page 62 Start Torrent Service：Open BT service. Empty Start：Stop BT service Torrent Download Directory： directory to store T o rrent downloaded files Download Port：Torrent download port. Download Bandwidth：Download bandwidth (kbps) (0 means no limit) Upload Bandwidth：Upload bandwidth (kbps) (0 means no limit) Maximum Peers：Maximum shared users Setup all the required information and check “Start Torrent Service”...
  • Page 63 Add a new torrent download: File extension must be .toreent Use browse to select a torrent which is already download from other website. The name of the file to be download will display in the name column.
  • Page 64 After finish the progress of JAVA, etc., there will be a file management interface Multiple Torrent uploader. Add Files to add multiple files Remove Files to delete the unwanted files. Upload Filesa to load the .torrent to the DC2010 BT server.
  • Page 65 BT service Now you can choose the .torrent you want to start download, say the Fedora file as the above shown. Click to start BT service. If you want to stop, select the .torrent you want to stop then click to stop it.

  • Page 66: Downloader

    10.2 Downloader The downloader service is used for the file download automatically from some service provider and save the file under the directory” Public”. Click to add a new download URL. The add new URL screen will show as follows. Key in the URL with the file path and click Download Now to start download.
  • Page 67 The confirmation prompt ask you to confirm the deletion.

  • Page 68: System Update

    11 System update Online software updates, this file will be downloaded on the official website, then software updates from the webUI System update：Can download the update file from the update DC-2010 system or web page。 Click Choose File to select a file there will be a picture, the file extension tar, after being confirmed press Open.
