JS Automation DC2010 User Manual page 13

If the input method is touch click, refer the followings:
Touch click input method:
1. There are 2 cursors on the screen; the top lane cursor is the input cursor, the lower lane cursor is
the candidate cursor.
2. The cursor highlighted input digit is the digit available to input.
3. Touch the wheel left half ring; the cursor candidate digit will jump left.
4. Touch the wheel right half ring; the cursor candidate digit will jump left.
←
5. Left shift: shift left the input space cursor.
→
6. Right shift: shift right the input space cursor.
↵
7. Confirm: confirm the input data
↑
8. Return to upper level
Try an example of input; if the LCD message is on password input page, the device now is waiting
for your input.
P W D : _ _ _ _ _ _
0 1 2 3 4 5 6 7 8 9
Say the password is 123456 (note that: the factory default is 000000), the process you will go:
A. Press the wheel ring left or right to jump the candidate cursor to digit '1' then press the
confirmation button to enter the first digit while input cursor on first digit.
B. Press the wheel ring left or right to jump the candidate cursor to digit '2' then press the
confirmation button to enter the second digit while input cursor on second digit.
C. Repeat the process until all the digits are input.
D. Move the candidate cursor to confirm, press confirmation button to input data to the device.
E. If you want to change any digit already input, click the touch wheel to move candidate
cursor to left shit or right shift and press confirmation button to shift the input cursor to the
digit you want to change. Input the new digit as process described above.
We will use the touch wheel as default configuration, any terms mentioned as rotate wheel
right or left is equivalent to click right or left.
↵
← →
12
↵ ↑
