BLACK KNIGHT 2 - Classic Collection
(GC No. 32 170 16)
Installation & Servicing Instructions
IMPORTANT - THIS FIRE DOES NOT NORMALLY REQUIRE ADDITIONAL
VENTILATION INTO THE ROOM IN WHICH IT IS INSTALLED
GENERAL INSTALLATION REQUIREMENTS
In your own interest and that of safety, it is the law that all gas appliances are installed by competent persons in accordance
with the current Gas Safety (Installation & Use) Regulations.
Failure to install appliances correctly could lead to prosecution.
The installation MUST be in accordance with these installation instructions, all the relevant parts of the Local and National
Building Regulations or Building Standards (Scotland) (Consolidation) Regulations and the relevant recommendations of the
current editions of the following British Standards:-
B.S. 5871 : Part 2.
B.S. 5440 : Parts 1 & 2.
B.S. 6891
B.S. 6461 : Parts 1 & 2.
B.S. 715
B.S. 1251.
Any other relevant British Standard Code of Practice
and/or Local Building Regulations.
This appliance must be installed in accordance with
the rules in force. For G.B. and I.E. only.
FOR USE WITH NATURAL GAS ONLY
(G20 at 20mbar supply pressure)
The Data Badge and Serial Number are located on the left hand side of the base plate.
Remove the Controls Fender to Gain Access.
PLEASE LEAVE THESE INSTRUCTIONS WITH THE USER
1
SERVICE & INSTALLATION
Advertisement
Table of Contents
Related Manuals for Robinson Willey BLACK KNIGHT 2
Summary of Contents for Robinson Willey BLACK KNIGHT 2
- Page 1 BLACK KNIGHT 2 - Classic Collection (GC No. 32 170 16) Installation & Servicing Instructions IMPORTANT - THIS FIRE DOES NOT NORMALLY REQUIRE ADDITIONAL VENTILATION INTO THE ROOM IN WHICH IT IS INSTALLED GENERAL INSTALLATION REQUIREMENTS In your own interest and that of safety, it is the law that all gas appliances are installed by competent persons in accordance with the current Gas Safety (Installation &...
-
Page 2: Technical Data
No component is manufactured from asbestos or asbestos related products. The Black Knight 2 is an open fronted, inset live coal effect gas fire. The control and burner systems are designed to give varying decorative flames at different settings. Ignition is by integral piezo spark operated by turning the control knob. The fire is fitted with combined flame supervision and oxygen depletion monitoring device (See Section 6.6). - Page 3 If the opening is larger than shown in Fig. 1 then it must be bricked up until the opening is a maximum of 580mm high x 457mm wide, alternatively a non-combustible infill panel may be used to achieve the required dimension. DO NOT USE THE BACK OF A FIRE SURROUND TO ACHIEVE THESE DIMENSIONS.
- Page 4 3.0 UNPACKING The fire is supplied in two packs, when unpacking refer to the check list to ensure that all the components are present. PACK 2 contains: [a] A pack located in the firebox which houses:- Front Coal Bed. (ii) A pair of side cheeks.
-
Page 5: Installation Of Fire
4.0 INSTALLATION OF FIRE There are two methods for securing the fire to the wall which are:- Fixing by tension cable. Screwing the fire directly to the wall. METHOD 1 is recommended where drilling holes in the front surface of the fireplace surround is unacceptable or otherwise risky, for example, marble surround. - Page 6 BS 715 by using Selkirk adaptor 175mm/125mm Product Code 0409605. When installing Black Knight to the Selkirk Box use the fixing kit supplied by Robinson Willey as an optional extra Part No. 992512 (G.C. No. 159 576) and install the fire as detailed in the Instructions with the kit.
-
Page 7: Gas Connection
4.4 GAS CONNECTION NOTE: The appliance must be connected to gas with rigid or semi-rigid tubing. A means of isolating the gas supply must be fitted upstream of the appliance inlet to facilitate connection and subsequent servicing. The supply pipe to the fire should be installed so that it is easy to remove prior to removal of the fire from the opening during servicing. - Page 8 4.5 INSTALL FUEL EFFECT COMPONENTS The fuel effect components comprise (Fig. 5A):- Rear Coal Bed. Centre Coal. Side Cheek LH Side Cheek RH Front Coal Bed. 10 Coals. Fig. 5A Correct arrangement of the coals is essential to ensure safe operation of the fire. DO NOT INSTALL THE FIRE WITH BROKEN OR MISSING COALS.
-
Page 9: Check Gas Pressure
Locate 4 coals on the front recesses of the front coal bed as shown in Fig. 6B. Wherever possible place the coals with the decorative faces forward. Ensure that the coals are stable and are not likely to fall off. In a similar manner place the remaining 6 coals above and behind the raised portions of the rear of the front coal bed as shown in Fig. -
Page 10: Instruct User
4.9 TEST FSD Light the fire and leave on full rate for a few minutes. Turn off the gas supply at the service cock or any other convenient isolating valve. Wait 3 minutes and re-establish the gas supply. Check that there is no gas to the burners. If so the safety valve has functioned correctly. -
Page 11: Fuel Effect Components
4. GAS TAP ASSEMBLY (INCLUDING IGNITER) Remove burner tray (Section 6.1). Pull off the control knob. Remove the two screws and washers securing the name plate. Undo the gas connections to the gas tap. Undo the thermocouple nut and ease out the probe. Disconnect the spark lead. - Page 12 Available in the following finishes:- Black (stoved paint) With brass effect trim Bronze Gunmetal Vitreous enammel With silver effect trim Pewter 991630 Issue 3 ROBINSON WILLEY LIMITED Mill Lane, Old Swan, Liverpool L13 4AJ Telephone: 0151-228 9111 Fax: 0151-228 6661 Website: www.robinson-willey.com...
