FIRECHARM R.S. Electronic
Room Sealed Live Fuel Effect Gas Fire
The FIRECHARM R.S. Electronic is a room sealed, live fuel effect gas fire with coals. The outer case is available in two colours,
antique bronze or black.
It has a balanced flue system which takes air for combustion from the outside and discharges products of combustion to the
outside. It must be mounted on an external wall and can stand on a non-combustible hearth or suitable fire surround. There are
four heat settings operated by turning the control knob which is located at the top right hand side of the fire. The burner system
is designed to give various flame effects at the respective heat settings.
Ignition is by battery spark generator operated by turning and pressing the knob to light the pilot. It has a thermo electric flame
supervision device for safety. Use only the coal bed supplied with this fire. Do not use any other material or burn any rubbish on
the fire. Do not use the fire with a broken or damaged fuel bed or with a broken or cracked glass.
1.
This fire is for use on Natural Gas only and cannot be used on any other gas (G20 at 20mbar).
2.
The fire must be installed and serviced regularly in accordance with the installation/servicing instructions, the rules in
force and Gas Safety (Installation and Use) Regulations, by a competent person, i.e. a Gas Safe registered Engineer.
3.
The glass door becomes very hot when the fire is in use and must not be touched. The glass door conforms with the
requirements of BS 1945 : 1991 and satisfies the Heating Appliances (Fireguards) (Safety) Regulations 1991. The door is to
prevent risk of fire or injury from burns and it shall not be permanently removed or the fire used without it fitted.
IT DOES NOT GIVE FULL PROTECTION FOR YOUNG CHILDREN, THE ELDERLY OR THE INFIRM .
A fireguard conforming to B.S. 8423 (Fireguards for heating appliances for domestic use) should be used for the protection
of children, the elderly or the infirm. Such a guard is also recommended for pet animals.
WARNING: The glass is of a special heat resisting type, and if damaged must be replaced with the proper spare.
4.
A minimum clearance of 500mm is required to a combustible adjacent wall.
5.
After the fire has been installed you may wish to fix a shelf of combustible material above. This is quite acceptable provided
the dimensions shown in the table below are used. For deeper shelves allow 15mm (
every 25mm (1in) additional shelf depth.
6.
On the outside wall, the flue terminal (and terminal guard if fitted) must be clear of
obstructions (as for wall heaters).
7.
The distance between the sides of the fire and any permanent fittings must be at
least 75mm (3in). This permits proper access to the case fixing screws, and to
change the battery.
FOR USE IN G.B. & I.E.
G.C. No. 32 689 43 (BLACK)
Users Operating Instructions

IMPORTANT NOTES

G.C. No. 32 689 44 (BRONZE)
1
987615 Issue 5
in) increase in shelf clearance for
5/8
Minimum Height to
Depth of Shelf
Underside of Shelf
mm
in
mm
125
5
130
150
6
145
175
7
160
in
5
1/8
5
3/4
6
3/8
USER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32 689 43 and is the answer not in the manual?

Questions and answers

Related Manuals for Robinson Willey 32 689 43

Summary of Contents for Robinson Willey 32 689 43

  • Page 1: Important Notes

    987615 Issue 5 FIRECHARM R.S. Electronic Room Sealed Live Fuel Effect Gas Fire G.C. No. 32 689 43 (BLACK) G.C. No. 32 689 44 (BRONZE) Users Operating Instructions The FIRECHARM R.S. Electronic is a room sealed, live fuel effect gas fire with coals. The outer case is available in two colours, antique bronze or black.
  • Page 2 Clothes etc. must not be draped over the fire. Curtains must be 150mm (6in) clear at the top of the heater and 50mm (2in) at the sides. If wall mounted do not obstruct the underside of the fire. "Soft furnishings" such as blown vinyl wallpaper are easily affected by heat and may become discoloured if fitted close to a heating appliance.
  • Page 3 HEAT SETTINGS There are four heat settings 1, HIGH, 2 and ECON (See Fig. 1A). Setting 1 provides gas to the full burner at a low level. Setting HIGH gives the full heat output. Setting 2 uses about the same amount of gas as 1 but limits this to the centre section of the burner.

  • Page 4: Spares And Service

    For spares and service apply to your local supplier or installer stating that the appliance is a FIRECHARM R.S. Electronic. The appliance G.C. Number is 32 689 43/44 and this together with the serial number of the fire is shown on the small label on the lower right side of the fire.
