- Page 1 CER MIC COOKING HOBS Instructions for the use - Installation advices KEEP IN A SAFE PLACE Before operating this hob, please read these instructions carefully...
- Page 3 Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations given below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
- Page 4 IMPORT NT PREC UTIONS ND RECOMMEND TIONS After having unpacked the appliance, check to ensure that it is not damaged. If you have any doubts, do not use it and consult your supplier or a professionally qualified technician. Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as these may cause serious injuries.
- Page 5 TIPS FOR THE USER During and immediately after use some parts of the hob can reach very high tempera- tures. Do not touch them. Keep children away when the hob is in use. After use, ensure that the knobs are in the off position. Before any cleaning or maintenance, switch off the electricity to the cooktop.
- Page 6 FE TURES (Fig. 1.1) This model features 2 halolight cooking zones and 2 radiant zones. The 4 heating plates are controlled by “infinite control” switches. The heat power can be adjusted without steps from “0” to its max “12”. Fig. 1.1 (Fig.
- Page 7 (Fig. 1.4) This model features 4 HiLight radiant cooking zones. The 4 heating plates are controlled by “infinite control” switches. The heat power can be adjusted without steps from “0” to its max “12”. Fig. 1.4 (Fig. 1.5) This model features 1 double radiant cooking zone and 3 “3 circuits”...
- Page 8 All models have the temperature control knobs located on the right hand side of the hob. These knobs are wired as follows (Fig. 1.6): Rear right plate Rear left plate Front left plate Front right plate The hob is provided with a signal lamp (5) which lights up when the hob is switched on. The hob also features 4 warning lamps (6) which are wired to the corresponding plate.
- Page 9 HOW TO USE THE HOB Never cook food directly on the ceramic zones! Always use a saucepan or special container. Before you switch the hob on make sure that it is clean. To switch a cooking plate on you must turn the relevant control knob as follows: Model in figure 1.1 - turn clockwise...
- Page 10 TYPE OF HOTPL TES "Halolight" zones - Ø 145 mm 1200 W (at 230 V) - Ø 180 mm 1800 W (at 230 V) Halolight zone (Fig. 2.4) Incorporating 1 halogen ring lamp and 1 heating element in the middle of the halogen ring.
- Page 11 “Hi-light” radiant zone (Fig. 2.7) "Hi-light" radiant zones The heating element is formed of a coil - Ø 145 mm 1200 W (at 230 V) of resistant material which reaches the - Ø 180 mm 1800 W (at 230 V) working temperature quickly.
-
Page 12: Cooking Hints
COOKING HINTS To reduce the cooking time, you can turn the control knob to the max when you switch the plate on. After a short time you will set the control knob to the required position for the cooking. You should use pots and pans with flat bases. The diameter of the pan should match that of the cooking plate (or be slightly bigger) to make the most of the energy. - Page 13 ELECTRIC HOTPL TE US GE T BLE Cooking plate Cooking plate controlled by a 6 controlled by a 12 position switch position switch Type of cooking osition Switched OFF For melting operations (butter, chocolate). To keep food hot and to heat small quantities of liq- uid (sauces, eggs).
- Page 14 S FETY HINTS Before you switch the hob on, make DISTORTED PANBASE sure you know which touch controls the required cooking zone. We advise WRONG you to set the pan over the cooking zone before switching it on. Do not use pots and pans with rough DISTORTED bases (pay attention to cookware PANBASE...
-
Page 15: Control Knobs
CLE NING ND M INTEN NCE GENER L DVICE Before you begin cleaning you must ensure that the hob is switched off. It is advisable to clean when the appliance is cold and especially when cleaning the enamelled parts. All enamelled surfaces have to be washed with soapy water or some other non-abra- sive product with a sponge and are to be dried preferably with a soft cloth. - Page 16 CLE NING THE CER MIC HOB ATTENTION: MOST IMPORTANT! If cleaning the glass ceramic hob Before you begin cleaning make sure using a special tool (i.e. scraper) that the hob is switched off. take extra care to avoid damage to Remove spillages and other types of the seal at the edges of the glass incrustations.
- Page 17 Installation advice IMPORT NT The appliance should be installed by a QUALIFIED INSTALLATION TECHNICIAN. Failure to comply with this condition will render the guarantee invalid. The appliance must be installed in compliance with regulations in force in your country and in observation of the manufacturer's instructions. Before any operation of cleaning and maintenance disconnect the appliance from the electrical network.
- Page 18 INST LL TION TECHNIC L INFORM TION FOR THE INST LLER The ceramic hob must be kept no less than 50 mm away from any side wall; the rear wall must be at least 50 mm from the ceramic hob; there must be a distance of at least 650 mm between the hob and any wall cupboard or extractor hood positioned immediately above (see fig.
- Page 19 2. Fit the seal, which is supplied with the hob, on the rim of the hob as shown in figure 4.3. Adhesive side Fig. 4.3 3. Lay the hob in to the hole and secure NOTE: Avoid to placing wooden or plas- it by means of the brackets as indi- tic partitions underneath the hob and in cated in fig.
- Page 20 ELECTRIC L SECTION IMPORTANT: The appliance must be installed by a qualified technician accord- ing with the current local regulations and in compliance with the manufacturer instructions. Incorrect installation might cause harm and damage to people, animals or objects, for which the manufacturer accepts no responsibility. Connection to a good earth wiring system is absolutely essential.
- Page 21 FOR THE UNITED KINGDOM ONLY CONNECTION TO FIXED WIRING A double pole switch must be provided no further than 2 metres from the appliance to the electrical supply. If you are using the hob for the first time, or after a period of disuse, you should set the controls to the minimum position for approximately 30 seconds, to dry out any humidity.
- Page 22 FOR LL THE COUNTRIES To connect the feeder cable to the hob it is necessary to carry out the following operations: Unscrew the shield “A” at the bottom of the hob. Position the U bolts “C” onto terminal board “B” (fig. 5.2) according to the diagrams in fig.
- Page 23 Feeder cable section H05RR-F type Connection with wall box connection (1)(2) 230 V or 220-240 V 3 x 2,50 mm 230 V 3 or 220-240 V 3 4 x 2,50 mm 400 V 3N or 380-415 V 3N 5 x 1,50 mm 400 V 2N or 380-415 V 2N 4 x 2,50 mm...
-
Page 24: Technical Data
TECHNICAL DATA Haloligh hotplate Ø 145 - 1200 W at 230 V Haloligh hotplate Ø 180 - 1800 W at 230 V Hi-Light hotplate Ø 145 - 1200 W at 230 V Hi-Light hotplate Ø 180 - 1800 W at 230 V Radiant hotplate Ø... - Page 25 Model Model Model Model Model in figure 1.1 in figure 1.2 in figure 1.3 in figure 1.4 in figure 1.5 – – – – – – – – – – – – – – – – – – – – –...
- Page 28 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs. Cod.
