HOBS
BUILT-IN
MODELS
SERIES PI-EL : PI-NC30 / PI-63 / PI-93 / PI-NC60 / PI-NC63 / PI-NC93 / PI-SD45
SERIES PC
: PC-SY60 / PC-SY75 / PC-SY90 / PC-BB60 / PC-BB75 / PC-BB90
SERIES PI-PD : PI-PD60 / PI-PD70 / PI-PD75 / PI-PD90
SERIES PI-PFT: PI-PFT35 / PI-PFT45 / PI-PFT95
PRODUCT LABEL
INSTRUCTIONS FOR USE
INSTALLATION
AND MAINTENANCE
IMPORTANT: KEEP THIS MANUAL CAREFULLY
.
- 1 -
9880103502-EN-201115.doc
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Smalvic PI-EL SERIES
Summary of Contents for Smalvic PI-EL SERIES
- Page 1 HOBS BUILT-IN MODELS SERIES PI-EL : PI-NC30 / PI-63 / PI-93 / PI-NC60 / PI-NC63 / PI-NC93 / PI-SD45 SERIES PC : PC-SY60 / PC-SY75 / PC-SY90 / PC-BB60 / PC-BB75 / PC-BB90 SERIES PI-PD : PI-PD60 / PI-PD70 / PI-PD75 / PI-PD90 SERIES PI-PFT: PI-PFT35 / PI-PFT45 / PI-PFT95 PRODUCT LABEL INSTRUCTIONS FOR USE...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read and follow all the instructions before using this item to prevent the potential risk of fire, electric shock, personal injury or damage to the item itself as a result of improper use. This household appliance is compliant with the provisions of the European Community Directives - LOW VOLTAGE DIRECTIVE –... - Page 3 7) Make sure that all the knobs are in the zero position before connecting the appliance to the gas mains. 8) Before installing, verify that the local distribution conditions (gas type and pressure) and the adjustment state of the appliance are compatible. 9) The adjustment conditions of this appliance are specified on the label (or on the data plate).
- Page 4 For the burners, please see Fig. 03/A Notes on the use of gas burners: - A properly calibrated burner with clean holes will ignite in a few seconds. Using natural gas, the flame will be bluish with a more intense central cone. - With LPG, the presence of slight yellow tips are acceptable.
- Page 5 Use a damp cloth with a non-abrasive cleaning product, and then dry the surface with a soft dry cloth. In case of tough deposits, use a plastic sponge or similar with hot water and vinegar. Due to an increasing presence of new cleaning products on the market every year, it is not possible to establish a list of items suitable to clean this cooker.
- Page 6 The purchaser is responsible for installation. Assistance provided by the manufacturing company due to an incorrect installation will not be included in the warranty. ATTENTION: Do not use the hob to heat the premises or the room where it is located.
- Page 7 HOB POSITIONING It is important that all the operations relating to installation of the appliance must be carried out by qualified personnel INSTALLATION CLASS - 3 Do not position the hob in areas subject to air flows, such as near a window. Strong air currents can obstruct or disturb the flow of combustion and ventilation gases.
- Page 8 ELECTRIC HOB CONNECTION ELECTRICAL SAFETY IMPORTANT: The hob must be installed by qualified and skilled personnel. Attention, this appliance must be earthed in compliance with the standards in force. In addition it can also be installed and run in permanently ventilated rooms according to the relevant local regulations in force.
- Page 9 Ensure the electric cable does not pass near or come into contact with the surfaces reaching a temperature above 75° C. EARTH CONNECTION Installation, connection and earthing of the electric system must comply with the European standard requisites and meet the provisions of the local Standards in force.
- Page 10 THE PRODUCT THAT MAY CAUSE SERIOUS DAMAGE TO PEOPLE AND PROPERTY. CONNECTION TO THE GAS MAINS This electrical appliance must only be installed and used in permanently ventilated areas according to the local regulations in force. Gas compatibility Gas compatibility Before installation, verify that the local distribution conditions (gas type and pressure) and the adjustment state of the appliance are compatible (see appliance technical plate).
- Page 11 To replace the injectors and to adjust the minimum flow rate, read the paragraph "replacing the injectors" REPLACING THE INJECTORS To replace the injectors, simply unscrew the injector on the burner using a 7 mm hex key. (fig. 04) Screw in the new injector. Read the technical table "hob data"...
- Page 12 optimise the flame height by closing or opening the adjustment screw while keeping the shaft blocked. Perform some on and off tests moving from maximum to minimum. Should the flame go out slightly increase the minimum. NOTE: All adjustments must only be performed by qualified and authorised personnel.
- Page 13 Energy Efficiency Table Gas Burners / Electric Plates Front Rear Front Rear MODEL BURNERS/ELECTRIC Centr. Left Rear Right Front Average left left right right PLATES PI-NC 30 2G 59.2% 59.2% PI-NC30 BDC PI-63 4G 58.4% 59.2% PI-93 4G1BDC PI-NC63 4G 58.4% 59.2% PI-NC93 4G1BDC...
- Page 14 FIGURES Fig. 01 Fig. 02 Fig. 03/A Fig. 03 BURNER BODY SPARK PLUG INJECTOR THERMOCOUPLE INJECTOR CUP Fig. 04 Fig. 05 - 14 - 9880103502-EN-201115.doc...
- Page 15 Fig.6A PI-NC30 2G / 2ERS / GRILL PLATE Fig.6B PI-NC30 BDC Fig.6C PI-NC30 BARBECUE Fig.6D PI-NC30 FRYER Fig.6E PI-63 / NC60 / NC63 Fig.6F PD60 - 15 - 9880103502-EN-201115.doc...
- Page 16 Fig.6G PC-SY60 Fig.6H PC-BB60 Fig.6I PD-70 Fig.6L PD-75 Fig.6M PC-SY75 Fig.6N PC-BB75 Fig.6O PI-93 Fig.6P PD-90 - 16 - 9880103502-EN-201115.doc...
- Page 17 Fig.6Q PC-SY90 Fig.6R PC-BB90 Fig.6S PFT-35 Fig.6T PFT-45 Fig.6U PFT-95 Fig.6V PI-SD45 - 17 - 9880103502-EN-201115.doc...
- Page 18 Fig. n° 07 Fig. n° 08B Fig. n° 10 Fig. n° 10A - 18 - 9880103502-EN-201115.doc...
- Page 19 Fig. n° 09 ADJUSTMENT SCREW ADJUSTMENT SCREW Fig. n° 11 Fig. n° 11A - 19 - 9880103502-EN-201115.doc...
