S/M No.:DWM161011

Service Manual

Washing Machine

Model : DW -1050
DW-1051
• Caution:
In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
Sep. 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW-1050 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DW-1050

Summary of Contents for Daewoo DW-1050

  • Page 1: Service Manual

    S/M No.:DWM161011 Service Manual Washing Machine Model : DW -1050 DW-1051 • Caution: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    ASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASH TO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AU ASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASH TO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AU ASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASH TO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AU...

  • Page 3: Specifications

    1. SPECIFICATIONS ITEM SPECIFICATIONS 1 POWER VOLTAGE AC 110V AC 220V AC 127/220V AC 110/220V AC 220V AC 240V SOURCE FREQUENCY 60Hz 50Hz 2 POWER PUMP 580W 550W CONSUMPTION NON PUMP 530W 500W 3 DIMENSION NET : 884X542X1020, PACKED UP : 898X558X1035 (WXDXH) 4 MACHINE PUMP NET : 35kg, PACKED UP : 37kg...

  • Page 4: External View

    2. EXTERNAL VIEW Structure Of The Washing Machine Control Panel (Panel b Ass’y) 1 LEVER WATER SUPPLY SELECTOR 4 WASH ACTION Left : water supply in the WASH TUB. Use to select wash action. (“STRONG”, “NORMAL”) Right : water supply in the BASKET SPIN. 5 VALVE SELECTOR 2 INLET WATER Select “WASH, RINSE”...

  • Page 5: Principles Of Operation And Explanation Of Functions

    3. PRINCIPLES OF OPERATION AND EXPLANATION OF FUNCTIONS Wash Timer FUNCTION The main switch remains ON during the washing time set by turning the timer knob. At the same time, the internal switch T1 and T2 which provide power to WASH MOTOR alternately at assigned Intervals. Select switch knob sets the wash type by means of controlling the interval of internal switch contact.

  • Page 6: Door Switch

    Spin Timer FUNCTION The spin timer is the switch providing power to the SPIN MOTOR(DRAIN PUMP MOTOR) during the set spin dry time, and is a spring-type time switch comes on turning and those contact points comes off after the set time. STRUCTURE AND PRINCIPLE OF ACTIVATION 1) The main shaft turns due to the unwinding force when the spin timer is turned, the spring wound with that force being delivered through each gear and the spring slowly unwinding at a speed finally controlled by the angle...
  • Page 7 BRAKE SYSTEM When the DOOR SPIN is opened, LINK BRAKE which con- nect to DOOR SPIN loosens. And then the BRAKE BAND touches the DRUM COUPLING assembly and stops the BAS- KET SPIN as it is pulled by the SPRING in the BRAKE FIX PLATE assembly.
  • Page 8 GEAR HOUSING ASS’Y The GRAR HOUSING ASSEMBLY is a transmission device which turns the PULSATOR at 3.3:1 (DWM-160C) or 6:1 (DWM-170C) lowered speed through the gear unit assembly which receives power at the GEAR SHAFT UNIT. STRUCTURE (DWM-160C) DWM-170C STRUCTURE (DWM-170C) 1) The two sides of the GEAR SHAFT UNIT are supported by the OILLESS BEARING in the GEAR HOUSING ASSEMBLY.

  • Page 9: Direction For Disassembly And Assembly

    4. DIRECTION FOR DISASSEMBLY AND ASSEMBLY Ass’y Panel Back 1. Remove 3 screws on the PANEL B. 2. Remove KNOB, wash timer and spin timer on the PANEL B. 3. Remove 3 screws and CONTROL LEVER Basket Spin 4. Remove 4 screws on the COVER BACK. 5.
  • Page 10 6. Remove 1 bolt and nut on the upper side of the 7. Remove the PLATE T on the TUB. DRUM COUPLING AS. 8. Lift up the BASKET SPIN. Ass’y Base Under 9. Remove 1 screw on the CABINET. 10. Separate HARNESS AS connectors.
  • Page 11 11. Remove a V-BELT from PULLEY MOTOR. 12. Turn over the washing machine. 13. Remove 7 screws on the BASE UNDER ASSY. 14. Remove 3 screws on the BRACKET MOTOR, and remove the SPIN MOTOR. 15. Remove 3 bolts on the BASE UNDER, and 16.

  • Page 12: Troubleshooting Guide

    5. TROUBLESHOOTING GUIDE NOTES Pull out the power plug to repair and make sure that the Washing Machine has been properly grounded. Concerning Wash PROBLEM CHECK POINT CAUSE SOLUTION Is the Power properly connected? Reconnect the Power Cord. Is there a whirring sound from the Wash Motor when turned on? Reconnect the Condenser.
  • Page 13 PROBLEM CHECK POINT CAUSE SOLUTION Does the Gear Housing Shaft Worn out the Serration Replace Pulsator. Pulsator rotate properly when the Pulsator within the Pulsator. does not has been disassembled? rotate smoothly. Defective Gear Housing Replace Gear Housing As. Improper Connection Reconnect Is the wiring of Wash condenser properly connected?
  • Page 14 PROBLEM CHECK POINT CAUSE SOLUTION Brake wire is too long. The Brake Band is touching Assemble after loosening the Drum Coupling Assembly. LINK BRAKE and adjusting downward. BRAKE SPRING is broken. Replace Brake Spring. Is the Motor hot? (In case there is Power has been cut off by Power restored when motor Thermal Protector)
  • Page 15 PROBLEM CHECK POINT CAUSE SOLUTION Is the Bellows Assembly properly Waterproofing not working Re-assemble assembled? due to defective assembly. Bellows Assembly. There is leak- age during Replace Bellows The Waterseal or the spinning. Assembly. Oilless Metal in the Bellows Assembly is worn out. Brake wire is too short.
  • Page 16 PROBLEM CHECK POINT CAUSE SOLUTION Is the Drain Selector in the DRAIN Turn the Drain Selector to The position is fault. position DRAIN. Draining does not function dur- Defective wiring Reconnect wiring ing drain Is the pump Motor wiring properly selecting connected? Defective Pump motor...

  • Page 17: Exploded View And Parts List

    6. EXPLODE VIEW AND P ARTS LIST 6. EXPLODE VIEW AND P ARTS LIST 6. EXPLODE VIEW AND P ARTS LIST 6. EXPLODE VIEW AND P ARTS LIST 6. EXPLODE VIEW AND P ARTS LIST 6. EXPLODE VIEW AND P ARTS LIST 6.
  • Page 18  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PANNEL ASS'Y PART NAME PART CODE DESCRIPTION...
  • Page 19 Ass’y Tub...
  • Page 20  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) ass’y tub PART NAME PART CORD SPECIFICATION...
  • Page 21 Ass’y Main...
  • Page 22  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) ass’y main PART NAME PART CORD SPECIFICATION...
  • Page 23  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CORD SPECIFICATION Q’TY...

  • Page 24: Wiring Diagram

    7. WIRING DIAGRAM Single Voltage/Normal Single Voltage/Pump...
  • Page 25 Dual Voltage/Normal...
  • Page 26 DAEWOO ELECTRONICS CO., LTD. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” FAX: 82-2-360-7877 TEL: 82-2-360-7114 http://www.dwe.co.kr PRINTED DATE: SEP.2001 S/M NO. : DWM161C011...
