Service Manual
Auto Washer
Model : DWF-700M
DAEWOO ELECTRONICS CO., LTD.
OVERSEAS SERVICE DEPT.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWF-700M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daewoo DWF-700M

  • Page 1 Service Manual Auto Washer Model : DWF-700M DAEWOO ELECTRONICS CO., LTD. OVERSEAS SERVICE DEPT.
  • Page 2: Specifications

    1. SPECIFICATIONS ITEM DWF-700M POWER SOURCE AVAILABLE IN ALL LOCAL AC VOLTAGE AND CYCLE 50Hz 430W POWER CONSUMPTION 60Hz 530W NON-PUMP 42Kg MACHINE WEIGHT PUMP 43Kg 598 X 956 X 643 DIMENSION (WXHXD) FULL AUTOMATIC 5 COURSE WASHING COURSE (NORMAL, BLANKET, ECONOMY, SUIT, SOAK)
  • Page 3: Structure Of The Washing Machine

    2. STRUCTURE OF THE WASHING MACHINE The parts and features of your washer are illustrated on this page. Be come familiar with all parts and features before using your washer. @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ e ?
  • Page 4: Directions For Installation And Use

    3. DIRECTIONS FOR INSTALLATION AND USE Installing Place Install the washer on a horizontal solid floor. If the washer is installed on an unsuitable floor, it could make considerable noise and vibration. N N e e v v e e r r i i n n s s t t a a l l l l i i n n t t h h e e s s e e p p l l a a c c e e s s The place where it would be exposed to direct sunlight.
  • Page 5: How To Connect The Inlet Hose

    How to Connect the Inlet Hose Be careful not to mistake in supplying between the hot(maximum : 50˚C) and cold water. In using only one water tap or in case of attached one water inlet valve, connect the inlet hose to the cold water inlet valve.
  • Page 6: How To Clean The Filter

    How To Clean The Filter CLEANING THE LINT FILTER Pull the Filter frame Turn the lint filter Return the filter as it was, and upward. inside out, wash to insert the filter frame into the the lint off with water. slot.
  • Page 7: Feature And Technical Explanation

    4. FEATURE AND TECHNICAL EXPLANATION Feature of the Washing Machine 1 The first air bubble washing system in the world. 2 Quiet washing through the innovational low-noise design. 3 The wash effectiveness is much more enhanced because of the air bubble washing system. 4 The laundry detergent dissolves well in water because of the air bubble washing system.
  • Page 8: Functional Principle Of Bubble Washing Machine

    Functional Principle of Bubble Washing Machine ACROSS SECTION Air bubble Outer tub Pulsator FUNCTIONAL PRINCIPLE Bubble Motor supplies the air from the bottom of outer tub to the inner space of pulsator, the air is dispersed by the rotation of pulsator. Air-bubble is created by the centrifugal force, and rises up. Automatic Drainning time Adjustment This system adjusts the draining time automatically according to the draining condition.
  • Page 9: Automatic Unbalance Adjustment

    Automatic Unbalance Adjustment This system is to prevent abnormal vibration during intermittent spin and spin process. FUNCTIONAL PRINCIPLE Contact of safety switch Lid closing 1 When the lid is closed, the safety switch contact is “ON” position. 2 In case that wash loads get uneven during spin, the outer tub hits the safety switch Lid opening due to the serious vibration, and the spin...
  • Page 10: Lint Filter

    Lint Filter Much lint may be obtained according to the kind of clothes to be washed and some of the lint may also sticks to the clothes. Filter Filter To minimize this possibility a lint filter is provided on the upper part of the tub to filter the wash water as it Bleach Bleach Inlet Inlet...
  • Page 11: Gear Mechanism Ass'y

    Gear Mechanism Ass’y The proper water currents is made by the rotation of pulsator at a low speed to prevent the damage to the small sized clothes. Sun gear Planetary gear Internal gear Motor Pulsator 1800 r.p.m (60Hz) 1500 r.p.m (50Hz) Gear unit as V.BELT 1 revolution...
  • Page 12: Presentation Of The P.c.b Ass'y

    8. PRESENTATION OF THE P.C.B ASS’Y Concerning Error Message MESSAGE CAUSE SOLUTION Install drain hose properly. Improper installation of drain hose. Remove foreign matter from drain hose. The drain hose is blocked up by foreign matter. Change drain motor. Drain motor is inferior. Open the water tap.
  • Page 13: Wiring Diagram [Non Pump]

    APPENDIX Wiring Diagram [non pump] WIRING DIAGRAM...
  • Page 14 [Non-Pump, Single Valve] WIRING DIAGRAM...
  • Page 15 [Pump] WIRING DIAGRAM...
  • Page 16: Parts Diagram

    Parts Diagram PARTS DIAGRAM...
  • Page 17 PARTS DIAGRAM...
  • Page 18 PARTS DIAGRAM...
  • Page 19: Parts List

    Parts List PARTCORD PART NAME SPEC Q’ TY UNIT NOTE 3610906800 PP(INLET) CAP VALVE 3610906800 PP(INLET) SINGLE VALVE 3612300110 PVC-S(INLET) GASKET VALVE 3612300110 PVC-S(INLET) SINGLE VALVE 7122402011 SCREW TAPPING T2S TRS 4X20 MFZN 3614231100 PANEL B 3614201300 SENSOR PRESSURE AS 0˚C CDN-D6N CUS-D6N 3619006380 DC 15V 040P...
  • Page 20 3612760400 HARNESS AS DWF-850M NON PUMP 3612760410 DWF-170MTC COLD ONLY 3612760420 DWF-170MNP PUMP *DWF-700M: DOOR A TYPE (A21) + PANEL A TYPE (A25) 3611201000 CLAMP HSW3, D2.6, MFZN D36 NON PUMP 3611202200 HSW3 PE-LD PUMP 3613220200 HOSE DRAIN O AS...
  • Page 21 THEMINAL PUMP AC 125V/3.15A #250CONN 110-130V/60Hz 3618703760 AC 250V/1A #250CONN 220-240V/50Hz 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN 3611408500 COVER TUB O DWF-700M 3610910600 CAP PULSATOR 4505E3203A SC. PULSATOR FIX AS 6X25 O-RING+SILOCK 36169705800 PULSATOR AS PP DWF-850M 3616006200 SPECIAL NUT...
  • Page 22 PARTCORD PART NAME SPEC Q’ TY UNIT NOTE 7341601611 SPECIAL BOLT 6B-1-6X16 MFZN 3612718200 INNER EARTH WIRE GREEN VSF(30/0.18) L=350 PHILIPPINES 3612713100 AWG18 16/0.26 GN/YW STANDARD AREA 3616006900 SPECIAL SCREW SCM24H 6.5X18 450ED45100 MOTOR SYNCHR. AC 110-120V/60Hz L=450 #250 110-130V(NON PUMP) 3966010200 AC 220-240V/50Hz L=450 #250 220-240V(NON PUMP)
  • Page 23 Circuit Diagram[Non Pump] CIRCUIT DIAGRAM...
  • Page 24 Circuit Diagram[Non Pump, Single Valve] CIRCUIT DIAGRAM...
  • Page 25 Circuit Diagram[Pump] CIRCUIT DIAGRAM...
