LI 9TE
Luft/Wasser-
Wärmepumpe für
Innenaufstellung
Bestell-Nr. / Order no. / N
Air-to-Water
Heat Pump for
Indoor Installation
o
de commande : 452160.66.04
Montage- und
Gebrauchsanweisung
Installation and
Operating Instructions
Instructions d'installation
et d'utilisation
Pompe à chaleur
air-eau pour
installation
intérieure
FD 8905
Advertisement
Chapters
Related Manuals for Dimplex LI 9TE
Summary of Contents for Dimplex LI 9TE
- Page 1 LI 9TE Montage- und Gebrauchsanweisung Installation and Operating Instructions Instructions d’installation et d’utilisation Luft/Wasser- Air-to-Water Pompe à chaleur Wärmepumpe für Heat Pump for air-eau pour Innenaufstellung Indoor Installation installation intérieure Bestell-Nr. / Order no. / N de commande : 452160.66.04...
-
Page 2: Table Of Contents
8.1 Maintenance ............................EN-8 8.2 Cleaning the Heating System ......................EN-8 8.3 Cleaning the Air System ........................EN-8 Faults / Trouble-Shooting ......................EN-8 10 Decommissioning/Disposal ...................... EN-8 11 Device Information ........................EN-9 Anhang / Appendix / Annexes ......................A-I www.dimplex.de EN-1... -
Page 3: Please Read Immediately
Please Read 1.2 Intended Use Immediately This device is only intended for use as specified by the manufac- turer. Any other use beyond that intended by the manufacturer is prohibited. This requires the user to abide by the manufacturers 1.1 Important Information: product information. -
Page 4: Purpose Of The Heat Pump
The evap- Filter dryer orator is defrosted automatically by the heat pump as required. Steam may be emitted from the air outlet depending on the at- Liquifier mospheric conditions. www.dimplex.de EN-3... -
Page 5: Switch Box
Transport 3.2 Switch Box ATTENTION! ATTENTION! Before opening the device, ensure that all circuits are isolated from the When transporting the heat pump, ensure that it is not tilted more than power supply. 45° (in any direction). The switch box is located in the heat pump. It can be swung out Use a wooden pallet for transporting the heat pump to the final in- after removing the lower front cover and loosening the fastening stallation location. -
Page 6: Set-Up
If both air openings are connected directly to a wall opening, the ventilator terminals can be reversed from a delta to a star con- nection (see information in the ventilator terminal box). www.dimplex.de EN-5... -
Page 7: Heating System Connection
6.3 Heating System Connection The heating system connections on the heat pump have a 1" ex- ternal thread. Use a spanner to firmly grip the transitions when connecting the heat pump. Before connecting the heating water system to the heat pump, the heating system must be flushed to remove any impurities, residue from sealants, etc. -
Page 8: Electrical Connection
When all heat circuits are fully open and a return flow tem- perature of at least 18 °C is maintained, set a minimum vol- ume flow quantity on the overflow valve (where present) and on the heat circulating pump. www.dimplex.de EN-7... -
Page 9: Maintenance / Cleaning
Maintenance / Cleaning ATTENTION! Before opening the device, ensure that all circuits are isolated from the power supply. 8.1 Maintenance Remove and rehang the side panel assemblies as described in To protect the paintwork, avoid leaning or putting objects on the Chapter 4. -
Page 10: Device Information
11 Device Information Type and order code LI 9TE Design Degree of protection according to EN 60 529 for compact devices IP 21 and heating components Installation location Indoors Performance data Operating temperature limits: Heating water flow/return flow °C / °C Up to 58 / above 18 °C... -
Page 11: Anhang / Appendix / Annexes
4.2 Monoenergetische Anlage und Warmwasserbereitung / Mono energy system and domestic hot water preparation / Installation mono-énergétique et production d´eau chaude ..........A-X 4.3 Bivalente Anlage / Bivalent system / Installation bivalente ..............A-XI 4.4 Legende / Legend / Légende........................A-XII Konformitätserklärung / Declaration of Conformity / Déclaration de conformité ....A-XIII www.dimplex.de... -
Page 12: Maßbilder / Dimension Drawings / Schémas Cotés
1 Maßbilder / Dimension Drawings / Schémas cotés 1.1 Wärmepumpe / Heat pump / Pompe à chaleur A-II... -
Page 13: Einbaumaße / Installation Dimensions / Cotes De Montage
1.2 Einbaumaße / Installation Dimensions / Cotes de montage www.dimplex.de A-III... -
Page 14: Diagramme / Diagrams / Diagrammes
2 Diagramme / Diagrams / Diagrammes 2.1 Kennlinien / Characteristic Curves / Courbes caractéristiques A-IV... -
Page 15: Stromlaufpläne / Circuit Diagrams / Schémas Électriques
3 Stromlaufpläne / Circuit Diagrams / Schémas électriques 3.1 Steuerung / Control / Commande www.dimplex.de... -
Page 16: Last / Load / Charge
3.2 Last / Load / Charge A-VI... -
Page 17: Anschlussplan / Circuit Diagram / Schéma Électrique
3.3 Anschlussplan / Circuit Diagram / Schéma électrique www.dimplex.de A-VII... -
Page 18: Legende / Legend / Légende
3.4 Legende / Legend / Légende Drahtbrücke einlegen, wenn kein EVU-Sperr- Wire jumper must be inserted if no utility blocking Cavalier à fil à monter en absence de contacteur schütz benötigt wird (Eingang offen = EVU-Sperre contactor is required (contact open = utility block = de coupure du fournisseur d'énergie (pont ouvert = = Wärmepumpe „aus“) heat pump “off”). -
Page 19: Hydraulische Prinzipschemen / Hydraulic Plumbing Diagrams / Schémas Hydrauliques
4 Hydraulische Prinzipschemen / Hydraulic Plumbing Diagrams / Schémas hydrauliques 4.1 Monoenergetische Anlage / Mono energy system / Installation mono- énergétique www.dimplex.de A-IX... -
Page 20: Monoenergetische Anlage Und Warmwasserbereitung / Mono Energy System And Domestic Hot Water Preparation / Installation Mono-Énergétique Et Production D´eau Chaude
4.2 Monoenergetische Anlage und Warmwasserbereitung / Mono energy system and domestic hot water preparation / Installation mono- énergétique et production d´eau chaude... -
Page 21: Bivalente Anlage / Bivalent System / Installation Bivalente
4.3 Bivalente Anlage / Bivalent system / Installation bivalente www.dimplex.de A-XI... -
Page 22: Legende / Legend / Légende
4.4 Legende / Legend / Légende Absperrventil Shutoff valve Robinet d’arrêt Überstromventil Overflow valve Vanne de trop-plein Sicherheitsventilkombination Safety valve combination Groupe de valves de sécurité Umwälzpumpe Circulating pump Circulateur Ausdehnungsgefäß Expansion vessel Vase d´expansion Raumtemperaturgesteuertes Ventil Room temperature-controlled valve Valve commandée par température Absperrventil mit Rückschlagventil Shutoff valve with check valve... -
Page 23: Konformitätserklärung / Declaration Of Conformity / Déclaration De Conformité
5 Konformitätserklärung / Declaration of Conformity / Déclaration de conformité www.dimplex.de A-XIII... - Page 24 Glen Dimplex Deutschland GmbH Irrtümer und Änderungen vorbehalten. Geschäftsbereich Dimplex Subject to alterations and errors. Am Goldenen Feld 18 Sous réserve d’erreurs et modifications. D-95326 Kulmbach +49 (0) 9221 709 565 www.dimplex.de...
