GPSmap 76CS
GPS Navigation

Display Setup

Backlight
Timeout
Options
Display Setup Page

Interface Setup

Interface Setup
Page
58
Display Setup
The Display Setup Page allows you to select a screen display color
scheme for day and night veiwing. You can set the backlight timeout and
the level of brightness which can significantly save on battery power.
To change a System Setup feature:
1. Use the ROCKER and ENTER keys to select the feature fi eld
and setup options menus.
Color Scheme
2. With an option for a feature fi eld highlighted, press ENTER
Options
to select. Use the ROCKER key to slide the brightness level
selector.
Level
Selector
Interface Setup
The Interface Setup Page allows you to control the input/output
format used when connecting your unit to a computer, external NMEA
devices, a DGPS beacon receiver, etc. using a USB or Serial Port Cable
The following settings are available:
GARMIN - The proprietary format used to exchange waypoint, route,
track log and MapSource data with a PC.
GARMIN DGPS - The proprietary format used with a Garmin dif-
ferential beacon receiver (e.g., GBR 21). Provides for tuning of
the beacon receiver directly from the GPSmap 76CS.
NMEA In/NMEA Out - Supports input and output of standard
NMEA 0183 version 3.01 data.
Data Format
Text Out - Allows ASCII text output of location and velocity informa-
Options
tion. No input.
