P/N 127779-01 Rev. A 02/2014
P126779-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
WARNING: Do not store gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the installation, operating and maintenance instructions thoroughly before install-
ing or servicing this equipment.
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
PFS
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE WARNING
•
This appliance can produce
carbon monoxide which has
no odor.
•
Using it in an enclosed
space can kill you.
•
Never use this appliance in
an enclosed space such as
a camper, tent, car or home.
WHEN USED AS INDOOR VENTED APPLIANCE
Installation and Operation Instructions
Astria
Vented Gas Log and Burner Set
TM
Models
®
MagniFlameOD24NE
MagniFlameOD24PE
US
WARNING: For Outdoor Use Only.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appli-
ance and immediately call your gas supplier
or fire department.
MagniFlameOD30NE
MagniFlameOD30PE
Advertisement
Table of Contents
Related Manuals for Astria MagniFlameOD24NE
Summary of Contents for Astria MagniFlameOD24NE
- Page 1 Installation and Operation Instructions Astria Vented Gas Log and Burner Set P/N 127779-01 Rev. A 02/2014 Models ® MagniFlameOD24NE MagniFlameOD24PE MagniFlameOD30NE MagniFlameOD30PE P126779-01 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. WHEN USED AS AN OUTDOOR APPLIANCE CARBON MONOXIDE WARNING WARNING: For Outdoor Use Only.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..................2 Specifications ..............16 Product Identification ............3 Wiring Diagram ..............17 Local Codes.................4 Troubleshooting ..............18 Unpacking................4 Accessories ...............21 Product Features ..............4 Parts ..................22 Installation ................4 Replacement Parts ............25 Operation ................14 Service Hints ..............25 Inspecting Burners.............15 Technical Service...............25 Cleaning and Maintenance ..........16 Warranty ................26 SAFETY Natural and Propane/LP gases are odorless. -
Page 3: Product Identification
SAFETY Continued 1. This appliance is only for use with the type of gas indicated 15.This appliances must not be connected to any external on the rating plate. This appliance is not convertible for use electrical source. with other gases. 16.Operating appliance above elevations of 4,500 feet may 2. -
Page 4: Local Codes
Gas type is indicated on the rating plate. Field conversion is not permitted. INSTALLATION AND CLEARANCES WARNING: DO NOT INSTALL IN SLEEPING WARNING: Maintain the minimum clearances. ROOM OF MOBILE HOMES. If you can, provide greater clearances from floor, ceiling and adjoining wall. www.Astria.US.com 126779-01A... - Page 5 See Figure 3 and Figures 4 and 5, page 6, for minimum clearances. IMPORTANT: If you cannot meet these minimum clearances, you must operate appliance with chimney flue damper open. Go to Installing Damper Clamp Accessory for Vented Opera- tion, page 6. www.Astria.US.com 126779-01A...
- Page 6 Figure 7 - Minimum Fireplace Clearances Above Combustible Flooring INSTALLING DAMPER CLAMP ACCESSORY FOR VENTED OPERATION Note: When used as a vented indoor appliance, appliance must be installed only in a solid-fuel burning fireplace with a working flue and constructed of noncombustible material. www.Astria.US.com 126779-01A...
- Page 7 Do NOT Kink Valve 1/2" NPT Incoming Gas Line Outlet Pressure Tap Note: 1) Wire connections not shown for clarity Set Screw 2) * 1/8" NPT Plugged Tapping Figure 9 - Connecting Incoming Gas Line to Flex Gas Line www.Astria.US.com 126779-01A...
- Page 8 • approved flexible gas line with gas connector (if allowed by Figure 11 - External Regulator With Vent Pointing Down local codes) (not provided * An equipment shutoff valve with 1/8" NPT tap is an ac- ceptable alternative to test gauge connection. Purchase the www.Astria.US.com 126779-01A...
- Page 9 1. Disconnect appliance with its appliance main gas valve Control Valve (control valve) and equipment shutoff valve from gas supply Location piping system. Pressures in excess of 1/2 psig will damage appliance regulator. Figure 14- Checking Gas Joints (Propane/LP Only) www.Astria.US.com 126779-01A...
- Page 10 4. Place battery pack next control valve away from the burner. Installing Batteries in Handheld Remote Control 1. Remove battery cover on back of remote control. 2. Install supplied A23/12V battery following positive and negative directions. 3. Replace battery cover onto remote control. www.Astria.US.com 126779-01A...
- Page 11 Flat Part of Log Grate Finger Figure 16A - Installing Right Front Log, Top View Burner Tube Square Grate Log Notch Burner Tube Figure 17 - Installing Back Left Log Figure 16B - Installing Right Front Log, Top View www.Astria.US.com 126779-01A...
- Page 12 Charred Log Front Left Log (D-059, D-017 or D-025) Log Notch Right Front Log Grate Fingers Figure 18 - Installing Front Left Log Figure 19 - Installing Charred Log www.Astria.US.com 126779-01A...
- Page 13 Square Peg Right Split Front Top Log Crossover (D-024) Rectangular Log (D-022) Middle Split Log (D-063, D-021 or D-028) Middle Split Log Figure 20 - Installing Middle Split Log (D-021) Figure 22 - Installing Front Top Log www.Astria.US.com 126779-01A...
-
Page 14: Operation
Do not place lava TO TURN OFF GAS rock or any other material on the burner. TO APPLIANCE 1. Push remote control ''OFF'' button. 2. Turn equipment shutoff valve clockwise to OFF. Do not force. www.Astria.US.com 126779-01A... -
Page 15: Inspecting Burners
• turn appliance off (see To Turn Off Gas to Appliance, page • see Troubleshooting, page 18 Yellow Flames with Figure 25 - Gas Module Right Side Orange Streaks Figure 26 - Gas Module Left Side Figure 28 - Correct Burner Flame Pattern www.Astria.US.com 126779-01A... -
Page 16: Cleaning And Maintenance
• Inlet Gas Pressure (in. of water): into the burner repeat steps 3 and 4. Additional cleaning Max - 14" W.C., Min* - 11" W.C. may be needed for proper operation based on use/lack of *For purpose of input adjustment use. www.Astria.US.com 126779-01A... -
Page 17: Wiring Diagram
WIRING DIAGRAM www.Astria.US.com 126779-01A... -
Page 18: Troubleshooting
Maintenance, page 16) or replace 8. Wire disconnected from gas con- burner orifice(s) trol 8. See Wiring Diagram, page 17 9. Ground wire issue 9. Verify black ground wire from module is secured under screw adjacent to ignitor www.Astria.US.com 126779-01A... - Page 19 This is normal when the appliance is installed outdoors in windy con- ditions. 4. Wire connection loose or wire broken 4. Check wiring connections (see wiring diagram, page 17). Re- place wire harness if necessary. www.Astria.US.com 126779-01A...
- Page 20 18 1. Gas leak. See Warning state- ment at top of page Gas odor during combustion 1. Locate and correct all leaks (see Checking Gas Connections, page www.Astria.US.com 126779-01A...
-
Page 21: Accessories
MAGNIFLAME EMBER BURNER KIT - MFEB (optional) For wood burning fireplace FIREPLACE HOOD Black - GA6050 Antique Brass - GA6053 For all models. Helps deflect heat away from mantel or wall above fireplace. Fits openings 28" to 48" wide. www.Astria.US.com 126779-01A... -
Page 22: Parts
PARTS MODELS MODELS MAGNIFLAME 24" AND 30" www.Astria.US.com 126779-01A... - Page 23 This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replace- ment Parts on page 25 of this manual PARTS AVAILABLE, NOT SHOWN - ALL MODELS 100639-12 Caution Decal 101137-02 Hardware Kit GA6060 Lava Rock 120466-01 Flextube with Fitting 099998-01 Fan Switch 125643-04 Remote Control www.Astria.US.com 126779-01A...
- Page 24 PARTS LOG SETS FOR MODELS MAGNIFLAMEOD24NE, MAGNIFLAMEOD24PE, MAGNIFLAMEOD30NE AND MAGNIFLAMEOD30PE This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on page 25 of this manual. MagniFlameOD24NE MagniFlameOD24NE MagniFlameOD30NE MagniFlameOD24PE MagniFlameOD24PE...
-
Page 25: Replacement Parts
You may have further questions about installation, operation or troubleshooting. If so, contact INNOVATIVE HEARTH PRODUCTS at 1-800-655-2008. When calling please have your model and serial numbers of your appliance ready. You can also visit our web site at www.IHP.US.com. www.Astria.US.com 126779-01A... -
Page 26: Warranty
THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Astria™ brand Gas Log Set or Outdoor Gas Fire Pit ("Product") to be free from defects in materials and workmanship at the time of manufacture. The logs and grate carry the Limited Three Year Warranty. After installation, if covered components manufactured by IHP are found to be defective in materials or workmanship during the Limited Three Year Warranty period and while the Product remains at the site of the original instal- lation, IHP will, at its option, repair or replace the covered components. - Page 27 WARRANTY KEEP THIS WARRANTY Model (located on product or identification tag) �������������������������������������� Serial No. (located on product or identification tag) ����������������������������������� Date Purchased �������������������������������������������� Keep receipt for warranty verification. www.Astria.US.com 126779-01A...
- Page 28 1508 Elm Hill Pike, Suite 108 Nashville, TN 37210 127779-01 1-800-655-2008 Rev. A www.IHP.US.com 02/14 P126779-01...
