10-3 VOLTAGE DIAGRAM
J1
J2
10-4 BOARD LAYOUT
C1
13.80 V
R1 24
W1
R2 24
C1
0.1
Q2
RN2404
DS1 TLG124A
R4 10 k
Q3
R11
RN1409
1 k
0 V
13.77 V
D3
MA8056 M
C4
C3
R1
R3
R2
R11
R4
W1
12.49 V
12.47 V
R5 10 k
Q1
2SB1201 S
R3
11.82 V
27
11.80 V
R6
13.63 V
27
12.46 V
R8
R7
2 k
C2
2 k
0.1
D1
0.23 V
1SS355
0.22 V
R9
Q4
56 k
2SC2712 GR
R10
0.74 V
10 k
0.73 V
5.62 V
0 V
R9
C2
R10
R7
R8
D1
R6
R5
Q1
10 - 2
8.01 V
7.98 V
7.20 V
D2 1SS184
CHARGE+
C4
C3
0.1
0.1
TEMP
GND
