Command
String
8-bit Graphic mode is selected.<n1> and <n2> is a 16 bit integer indicating the
Esc-'V'-n1-n2
number of graphic lines to be received. Valid Graphic character sets are from 0x00
to 0xFF Hex using bits 0-7.
Esc-'J'-n
Performs <n*0.125mm> feed.
Esc-V-0x01-
This code prints a single line of graphic.
0x00 104 bytes
of data
Dip Switch
1 & 2 & 6 & 7
3 & 4 & 5
Power LED Status Indication:
ALL Dip Switches OFF --- Blinking GREEN - Serial RS232 Mode
Dip Switch 2 ON --- Steady BLUE - Bluetooth Mode
Dip Switch 1 & 2 ON --- Steady ORANGE - 802.11b Mode
Printer Action
8-bit Dot addressable Graphic Commands
Dip Switch Summary Table
Function
Communication Interface
RS232
IrDA
Bluetooth
802.11b
Baud Rate
115200
57600
38400
19200
14400
9600
2400
1200
Switch #
Switch #
SW 1
SW 2
OFF
OFF
ON
OFF
OFF
ON
ON
ON
SW 3
SW 4
OFF
OFF
ON
OFF
OFF
ON
ON
ON
OFF
OFF
ON
OFF
OFF
ON
ON
ON
Switch #
Switch #
SW 5
OFF
OFF
OFF
OFF
ON
ON
ON
ON
