Table 1 — Specifications
Net
TYPE Weight
lb. (kg.)
QPNC 10 41.9 (19)
QPNC 15 44.1 (20)
QPNC 25 55.1 (25)
QPNC 35 59.5 (27)
QPNC 50 59.5 (27)
Reference Conditions:
Ambient temperature: + 100 °F (+ 38 °C)
Inlet air temperature: + 100 °F (+ 38 °C)
Working pressure: 102 psi (7 bar)
Dew point in pressure: + 39 °F (+ 4 °C)
4
1
2
Pub. No. 2200772355 — October 2006
Refrigerant
R134a
lb. (kg.)
V230/115- V230-
60Hz 60Hz
0.397 0.161
(0.180) (120)
0.463 0.205
(0.210) (153)
0.639 0.312
(0.290) (233)
0.970 0.390
(0.440) (291)
1.047 0.417
(0.475) (311)
6
9
7
3
8
FIGURE 9 — GENERAL LAYOUT
Nomin Nomin
al
Power Power
HP (W) HP (W)
V115- V230- V115-
60Hz 60Hz 60Hz
0.164 0.040 0.040
(122) (30)
0.212 0.040 0.040
(158) (30)
0.306 0.040 0.040
(228) (30)
0.386 0.040
(288) (30)
0.441 0.040 0.040
(329) (30)
Limit Conditions:
Max. ambient temperature: + 115 °F (+ 46 °C)
Min. ambient temperature: + 40 °F (+ 4.5 °C)
Max. inlet air temperature: + 131 °F (+ 55 °C)
Max. working pressure: 232 psi (16 bar)
1.
2.
3.
4.
5.
6.
7.
8.
9.
5
Nominal
al
Power
HP (W)
V230- V115-
60Hz 60Hz
0.201 0.204
(30) (150) (152)
0.245 0.252
(30) (183) (188)
0.353 0.346
(30) (263) (258)
0.040 0.430 0.426
(30) (321) (318)
0.457 0.481
(30) (341) (359)
Refrigerant compressor
Condenser
Motor fan
Evaporator
Condensate drain
Hot gas bypass valve
Refrigerant filter-dryer
Expansion capillary tube
Pressure switch (only QPNC25 - 50)
MAX
psi (bar)
232 (16)
232 (16)
232 (16)
232 (16)
232 (16)
7
