Solectek SkyWay-Excel Series User Manual page 24

Frequency Allows selection of the center frequency of the RF link, based on the model
purchased, region of operation and operating bandwidth. The Frequency setting is available on
the Master unit only. The slave unit will follow that of the Master unit.
A sample frequency list for the US FCC version, is as follows:
Link Distance Should be set to the link distance, rounded up to the nearest mile or km. This
parameter is used to optimize the performance across long distance links, accounting for the
time of flight of packets from one side to the other.
RF Network Name The wireless network name assigned to this PTP kit only.
NOTE
each PTP link should use a unique RF Network Name.
NOTE
alphanumerics, plus the following symbols: @ (at sign) - (dash) . (period) ' (tick) _
(underscore). RF Network Name may not include spaces.
Transmit Power This parameter sets the RF output power of the radio. Increasing this value
will extend the range of the MULTIPOINT system. However, the maximum available power is
limited by the chosen RF modulation and the regulatory entities in each country.
For example, in the US, the maximum operating power is limited as follows:
Channel Bandwidth
20 MHz
20 MHz
20 MHz
20 MHz
20 MHz
20 MHz
40 MHz
40 MHz
40 MHz
- The RF Network Name should be changed from the default settings, and
- RF Network Name can be up to 32 characters long, and consist of all
Frequency Center
5735 MHz
5755 MHz
5775 MHz
5795 MHz
5815 MHz
5835 MHz
5745 MHz
5785 MHz
5825 MHz
24
