Rheem RPVS Series Installation, Operation & Maintenance Instructions Manual page 33

Figure 27: Typical Two-Stage Thermostat: Heat Pump
with Electric Heat
Figure 29: Typical Two-Stage Thermostat: Heat Pump
with Electric Heat Using A Two-Stage Thermostat with
Dehumidifi cation
Electrical - Low Voltage Wiring
Figure 28: Typical Two-Stage Thermostat: Heat
Pump with Electric Heat Using A Humidistat for
Dehumidifi cation
Figure 30: (-)PRL Heat Pump with Electric Heat Using
A Two-Stage Thermostat with Dehumidifi cation and A
Malfunction Light
R e s i d e n t i a l S p l i t
R e v. : 1 3 M a r c h , 2 0 1 5
33
