INSTALLATION INSTRUCTIONS

PACKAGE GAS ELECTRIC
FEATURING EARTH-FRIENDLY R-410A REFRIGERANT
RRNL-B/C 13 SEER (2-5 TONS)
RRPL-B 14 SEER (2-5 TONS)
RRRL-C UP TO 16 SEER (2-5 TONS)
Seasonal Energy Efficiency Ratio (SEER)
RRNL
RRPL
13.0
14.0
—
10.6
Uses least energy
Annual Fuel Utilization Efficiency -
THIS MODEL
80.0%
MID
78%
82%
88%
ISO 9001:2008
RRRL
16.0
©
16.05
AFUE
HIGH
97%
(14 SEER &
ABOVE)
U.L. recognized fuel gas and CO (carbon monoxide) detectors are recommended in all
applications, and their installation should be in accordance with the manufacturer's
recommendations and/or local laws, rules, regulations, or customs.
r e f r i g e r a n t
92-21916-30-09
SUPERSEDES 92-21916-30-08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RRPL-B and is the answer not in the manual?

Questions and answers

Related Manuals for Rheem RRPL-B

Summary of Contents for Rheem RRPL-B

  • Page 1: Installation Instructions

    PACKAGE GAS ELECTRIC FEATURING EARTH-FRIENDLY R-410A REFRIGERANT r e f r i g e r a n t RRNL-B/C 13 SEER (2-5 TONS) RRPL-B 14 SEER (2-5 TONS) RRRL-C UP TO 16 SEER (2-5 TONS) Seasonal Energy Efficiency Ratio (SEER) RRNL...

  • Page 2: Table Of Contents

    T BLE OF CONTENTS I. Safety Information ....................3 II. Introduction......................6 III. Checking Product Received ..................6 IV. Specifications ......................6 A. General ......................6 B. Major Components....................6 C. R-410A Refrigerant ...................6 D. Comfort Alert System ..................7 1. Comfort Alert ....................7 2. High Pressure Control...................8 3.

  • Page 3: Safety Information

    I. S FETY INFORM TION W RNING PROPOSITION 65: THIS FURNACE CONTAINS FIBERGLASS INSULATION. RESPIRABLE PARTICLES OF FIBERGLASS ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER. EXHAUST GAS FROM THIS FURNACE CONTAINS CHEMICALS, INCLUDING CARBON MONOXIDE, KNOWN TO THE STATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER REPRODUC- TIVE HARM.
  • Page 4 W RNING NEVER ALLOW PRODUCTS OF COMBUSTION OR THE FLUE PRODUCTS TO ENTER THE RETURN AIR DUCTWORK, OR THE CIRCULATING AIR SUPPLY. ALL RETURN DUCTWORK MUST BE ADEQUATELY SEALED AND SECURED TO THE FURNACE WITH SHEET METAL SCREWS, AND JOINTS TAPED. ALL OTHER DUCT JOINTS MUST BE SECURED WITH APPROVED CONNECTIONS AND SEALED AIRTIGHT.
  • Page 5 W RNING DO NOT JUMPER THIS DEVICE! DO NOT reset the overtemperature control without taking corrective action to assure that an adequate supply of combus- tion air is maintained under all conditions of operation. Failure to do so can result in carbon monoxide poisoning or death. Replace this control only with the identical replacement part.

  • Page 6: Introduction

    II. INTRODUCTION W RNING This booklet contains the installation and operating instructions for your combination gas IMPORTANT: ALL MANUFACTUR- heating/electric cooling unit. There are some precautions that should be taken to derive ER PRODUCTS MEET CURRENT maximum satisfaction from it. Improper installation can result in unsatisfactory operation FEDERAL OSHA GUIDELINES FOR or dangerous conditions.

  • Page 7: Comfort Alert System

    2. Quick Reference Guide For R-410 • R-410A refrigerant operates at approximately 60% higher pressure (1.6 times) than R- 22. Ensure that servicing equipment is designed to operate with R-410A. • R-410A refrigerant cylinders are pink. • R-410A, as with other HFC’s is only compatible with POE oils. •...

  • Page 8: High Pressure Control

    of times consecutively, pause and then repeat the process. To identify a Flash Code number, count the number of consecutive flashes. IMPORTANT: Every time the module powers up, the last ALERT Flash Code that occurred prior to shut down is displayed for one minute. The module will continue to display the flash code until the condition returns to normal or if 24VAC power is removed from the module.
  • Page 9 The Comfort Alert diagnostics module diagnoses system and electrical problems in the air conditioning system. Abnormal conditions are indicated by flashing ALERT codes on the yellow LED on the Comfort Alert module. The flash codes are transmitted to the thermostat when the L terminal on the Comfort Alert Module is connected to the L terminal on the thermostat.
  • Page 10 3) Flash Code 4 - Locked Rotor Condition: The compressor internal overload trips where the average run time is less than 15 seconds. Possible causes: Bad run capacitor Low line voltage Excessive liquid refrigerant in compressor Compressor bearings are seized Faulty hard start components Active Thermostat Reaction: The thermostat implements a hard lockout once this error is sensed.

  • Page 11: Unit Dimensions

    V. UNIT DIMENSIONS FOR CLE R NCES SEE FIGURE 4. FIGURE 4 30% ± 2% OUTDOOR FAN GRILLE OUTDOOR COIL AND COMPRESSOR ACCESS PROTECTIVE GRILLE FLUE EXHAUST 21% ± 2% 29% ± 2% SIDE 20% ± 2% RETURN DUCT OPENING FIELD POWER THREADED WIRE ENTRANCE...
  • Page 12 FIGURE 4 (CONTINUED) FRONT VIEW BACK VIEW SIDE ⁄ ” SUPPLY ⁄ ” DUCT OPENING ⁄ ” 15” ⁄ ” ⁄ ” ⁄ ” ⁄ ” ⁄ ” TYP. ⁄ ” ⁄ ” ⁄ ” ⁄ ” ⁄ ” ⁄ ”...

  • Page 13: Installation

    VI. INST LL TION . GENER L 1. PRE-INSTALLATION CHECK-POINTS — Before attempting any installation, care- fully consider the following points: Structural strength of supporting members (Rooftop Installation) Clearances and provision for servicing Power supply and wiring Gas supply and piping Air duct connections and sizing Drain facilities and connections Location for minimum noise and vibration...

  • Page 14: Attaching Exhaust And Combustion Air Inlet Hoods

    FIGURE 5 OUTSIDE SLAB INSTALLATION. CLOSET DISTRIBUTION SYSTEM. SLAB FLOOR CONSTRUCTION 2. Provide a slab sufficiently high enough above grade to prevent surface water from entering the unit. Where snowfall is anticipated, mount the unit above the anticipat- ed maximum snow depth for your area. Do not locate unit in an area where exces- sive snow drifting may block combustion air inlet.

  • Page 15: Cover Panel Installation/Conversion Procedure

    FIGURE 7 COMBUSTION AIR INLET HOOD & EXHAUST HOOD INSTALLATION FIGURE 6 PITCHING UNIT TO INSURE PROPER CONDENSATE DRAINAGE. EXHAUST COMBUSTION HOOD W/(4) AIR INLET SCREWS HOOD W/(4) SCREWS I655 D. COVER P NEL INST LL TION/CONVERSION PROCEDURE 1. HORIZONTAL TO DOWNFLOW a.
  • Page 16 FIGURE 8 FIGURE 5 COVER GASKET DETAIL FOR UNITS SHIPPED FOR DOWNFLOW COVER GASKET DETAIL FOR UNITS SHIPPED FOR DOWNFLOW APPLICATION BEING CONVERTED TO SIDE DISCHARGE APPLICATION BEING CONVERTED TO SIDE DISCHARGE SUPPLY/RETURN AIR COVER FIGURE 9 FIGURE 6 TAPE AROUND FLANGE COVER GASKET DETAIL FOR UNITS SHIPPED FOR SIDE DISCHARGE COVER GASKET DETAIL FOR UNITS SHIPPED FOR SIDE DISCHARGE...

  • Page 17: Clearances

    FIGURE 12 CLEARANCES left side of unit. (See Figure 12.) If no economizer is required, then a 12” clearance is required on left side of unit. 2. Provide 60” minimum clearance between top of unit and maximum 3 foot overhang. 3.
  • Page 18 FIGURE 13 FIGURE 10 EXCEPTION TO NON-COMBUSTIBLE FLOORING REQUIREMENT EXCEPTION TO NON-COMBUSTIBLE FLOORING REQUIREMENT BOTH ENDS MUST BE SIDEFLOW SIDEFLOW OPEN FOR SUPPLY RETURN PLENUM DOWNFLOW PLENUM CONNECTION OR SIDEFLOW CONNECTION DUCTWORK TO PROVIDE NOMINAL VENTILATION 4 x 4 TIMBER (SIDES ONLY) 3-1/2”...

  • Page 19: Return Air

    FIGURE 16 PITCHED ROOFTOP INSTALLATION, ON ROOFJACK, DOWNFLOW DUCTWORK, ATTIC OR DROP CEILING DISTRIBUTING SYSTEM. PITCH UNIT TOWARD DRAIN. Place the unit as close to the conditioned space as possible allowing clearances as indi- cated. Run ducts as directly as possible to supply and return outlets. Use of non-flam- mable weatherproof flexible connectors on both supply and return connections at unit to reduce noise transmission is recommended.

  • Page 20: Filters

    FIGURE 17 LIFTING DETAIL. . FILTERS The installer must install field supplied filters in the return air duct. A field installed filter grille is recommended for easy and convenient access to the filters for periodic inspec- tion and cleaning. Filters must have adequate face area for the rated air quantity of the unit.
  • Page 21 FIGURE 18 FIGURE 15 ROOFCURB ROOFCURB FIGURE 19 FIGURE 16 RETURN PLENUM ROOFCURB ROOFCURB MAX. ROOFTOP UNIT GASKET MAX. SUPPLY INSULATION PLENUM PANELS TIE DOWN SCREW MAX. ROOFCURB NAILING STRIP DUCT DUCT FLANGE (NOT TO EXCEED 1() ROOF FLASHING ROOFING INSULATION NAILING CANT STRIP...

  • Page 22: Gas Supply, Condensate Drain And Piping

    VII. G S SUPPLY, CONDENS TE DR IN ND VII. PIPING . G S CONNECTION IMPORTANT: Connect this unit only to gas supplied by a commercial utility. 1. Install gas piping in accordance with local codes and regulations of the local utility company.

  • Page 23: Lp Conversion Single Stage Gas Heat

    W RNING DO NOT USE AN OPEN FLAME TO CHECK FOR LEAKS. THE USE OF AN OPEN FLAME CAN RESULT IN FIRE, EXPLOSION, PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. TO CHECK FOR GAS LEAKS, USE A SOAP AND WATER SOLUTION OR OTHER APPROVED METHOD.

  • Page 24: Lp Conversion Two Stage Gas Heat

    C. LP CONVERSION TWO ST GE G S HE T W RNING THIS UNIT IS EQUIPPED AT THE FACTORY FOR USE ON NATURAL GAS ONLY. CONVERSION TO LP GAS REQUIRES A SPECIAL KIT SUPPLIED BY THE DIS- TRIBUTOR OR MANUFACTURER. MAILING ADDRESSES ARE LISTED ON THE FURNACE RATING PLATE, PARTS LIST AND WARRANTY.

  • Page 25: Condensate Drain

    TABLE 3 METER TIME IN MINUTES AND SECONDS FOR NORMAL INPUT RATING OF FURNACES EQUIPPED FOR NATURAL OR LP GAS METER HEATING VALUE OF GAS BTU PER CU. FT. INPUT SIZE 1000 1040 1100 2500 BTU/HR CU. FT. MIN. SEC. MIN. SEC. MIN. SEC. MIN. SEC. MIN. SEC. 40,000 30 15 0 15...
  • Page 26 1. All wiring should be made in accordance with the National Electrical Code. Consult the local power company to determine the availability of sufficient power to operate the unit. Check the voltage at power supply to make sure it corresponds to the unit’s RATED VOLTAGE REQUIREMENT.

  • Page 27: Hook Up

    B. HOOK-UP To wire unit, refer to the following hook-up diagram (see Figure 24). Refer to Figure 4 for location of wiring entrances. Wiring to be done in the field between the unit and devices not attached to the unit, or between separate devices which are field installed and located, shall conform with the temperature limitation for Type T wire [63°F rise (35°C)] when installed in accordance with the manufacturer’s instructions.

  • Page 28: Furnace Section Controls And Ignition System

    TABLE 6 TABLE 6 FIELD WIRE SIZE FOR 24 VOLT THERMOSTAT CIRCUITS SOLID COPPER WIRE - AWG. Length of Run – Feet (1) (1) The total wire length is the distance from the furnace to the thermostat and back to the furnace. NOTE: DO NOT USE CONTROL WIRING SMALLER THAN NO.
  • Page 29 NORMAL HEAT MODE A. Call For First Stage (low fire) Only: 1. Zone thermostat contacts close, a call for first stage (low fire) heat is initiated. 2. Control runs self check. 3. Control checks the high-limit switch for normally closed contacts, each pressure switch for normally open contacts, and all flame rollout switches for continuity.

  • Page 30: Operating Instructions

    C. OPER TING INSTRUCTIONS This appliance is equipped with a direct spark intermittent ignition device. This device lights the main burners each time the room thermostat (closes) calls for heat. See operat- ing instructions on the back of the furnace/controls access panel. W RNING DO NOT ATTEMPT TO MANUALLY LIGHT THIS FURNACE WITH A MATCH OR ANY OPEN FLAME.

  • Page 31: Burners

    W RNING SHOULD OVERHEATING OCCUR OR THE GAS SUPPLY FAIL TO SHUT OFF, SHUT OFF THE MANUAL GAS VALVE TO THE APPLIANCE BEFORE SHUT- TING OFF THE ELECTRICAL SUPPLY. FAILURE TO DO SO CAN RESULT IN AN EXPLOSION OR FIRE CAUSING PROPERTY DAMAGE, SEVERE PERSON- AL INJURY OR DEATH! D.

  • Page 32: Lubrication

    1. Turn off the electrical power to the unit and set the thermostat to the lowest tem- perature. 2. Shut off the gas supply to the unit either at the meter or at manual valve in the supply piping. W RNING LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CON- TROLS.

  • Page 33: Cooling Section Maintenance

    D. COOLING SECTION M INTEN NCE W RNING DISCONNECT MAIN ELECTRICAL POWER TO THE UNIT BEFORE ATTEMPT- ING MAINTENANCE. FAILURE TO DO SO MAY RESULT IN ELECTRICAL SHOCK OR SEVERE PERSONAL INJURY OR DEATH. It is recommended that at the beginning of each cooling season a qualified installer or service agency inspect and clean the cooling section of this unit.
  • Page 34 pull wires through the hole on the bottom of the control box on the left side and into the control box. Reconnect fan motor wires per the wiring diagram attached to the back of the control box cover. 4. Replace wire strain relief in bulkhead after the slack is pulled out of the wires on the fan side.
  • Page 35 FIGURE 25 FIGURE 21 INTEGRATED FURNACE CONTROL BOARD INTEGRATED FURNACE CONTROL BOARD FIGURE 26 208/230 Volt X-13 Motor 208/230 Volt PSC Motor 2, 2.5, 3, 3.5, 4 TON MODELS COOL HEAT COOLING SPEED MAY BE ADJUSTED TO LOW COOL BY MOVING BLUE WIRE TO TAP 2. HEAT SPEED IS DEDICATED AND SHOULD NOT BE ADJUSTED.

  • Page 36: Units With Ecm Blower Motors (Rrrl-B Models Only)

    FIGURE 27 FACTORY SET BLOWER SPEEDS PSC MOTOR X-13 MOTOR MODEL COOL HEAT COOL HEAT 2.0 TON W/40K HEAT HIGH HIGH (Tap 3) DEDICATED (Tap 1) 2.0 TON W/60K HEAT HIGH HEAT HIGH (Tap 3) DEDICATED (Tap 1) 2.0 TON W/80K HEAT HIGH HEAT HIGH (Tap 3)

  • Page 37: Transformer Protection

    FIGURE 28 DO NOT WIRE DIRECTLY TO THIS BOARD. THERMOSTAT SHOULD ECM INTERFACE BOARD BE WIRED TO PIGTAILS LOCATED BELOW THE CONTROL BOX. FIRST-STAGE COOLING INPUT SECOND-STAGE COOLING INPUT (THIS BOARD IS LOCATED IN THE BLOWER SECTION) • An on-board LED to indicate blower CFM. •...

  • Page 38: Unit Operation With Two-Stage Cooling

    TABLE 8 LED FLASH CODES Interface board DIP switch LED Output settiings • Flashes 12 times 1200 CFM • Illuminate dimly 10 seconds, repeat sequence • Flashes 6 times 600 CFM • Illuminate dimly 10 seconds, repeat sequence • Flashes 9 times, flash once for second 950 CFM •...
  • Page 39 FIGURE 31 COOLING “ON” DELAY PROFILES INTERFACE BOARD SWITCH...
  • Page 40 FIGURE 32 BLOWER “OFF” DELAY PROFILES INTERFACE BOARD SWITCH...

  • Page 41: Heating Airflow Adjustments

    F. HE TING IRFLOW DJUSTMENTS FIGURE 33 HEATING AIRFLOW ADJUSTMENTS HEATING SELECTION SWITCH 5 SWITCH 6 AIRFLOW POSITION POSITION ADJUSTMENT NONE -10% NONE Heating airflow may be adjusted +10% or –10% from nominal airflow using switches 5 & 6. Refer to Figure 33 for switch positions to achieve the desired adjustments in airflow. NOTE: Continuous fan speed is NOT affected by switches 5 &...

  • Page 42: Cooling Mode Dehumidification

    H. COOLING MODE DEHUMIDIFIC TION n Explanation of On Demand Dehumidification Use “On-Demand Dehumidification” (ODD) is an optional feature of the ECM interface board. The ODD allows the user to have automatic dehumidification in the cooling mode that is controlled by the user’s dehumidifying thermostat or humidistat setting.
  • Page 43 Selection B: Factory Setting TABLE 11 This is the factory setting and provides cooling airflows as defined in the COOLING AIR- SWITCH SWITCH FLOWS section (no reduction in airflow). MODEL 9 POSITION 10 POSITION CFM CFM Selection C: On Demand Dehumidification RRRL-C024 This selection allows On Demand Dehumidification when using a dehumidifying thermo- RRRL-C036...

  • Page 44: General Data

    XII. GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B024JK04(E/X) B024JK06(E/X) B024JK08(E/X) B030JK04(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 24,400 [7.15] 24,400 [7.15] 24,400 [7.15] 29,800 [8.73] EER/SEER 11.1/13 11.1/13 11.1/13...
  • Page 45 GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B030JK06(E/X) B030JK08(E/X) B030JK10(E/X) B036CK04 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 29,800 [8.73] 29,800 [8.73] 29,800 [8.73] 37,000 [10.84] EER/SEER 11.1/13 11.1/13 11.1/13 11.3/13...
  • Page 46 GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B036CK06 B036CK08 B036CK10 B036DK06 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 37,000 [10.84] 37,000 [10.84] 37,000 [10.84] 37,000 [10.84] EER/SEER 11.3/13 11.3/13 11.3/13 11.3/13...
  • Page 47 GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B036DK08 B036DK10 B036JK04(E/X) B036JK06(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 37,000 [10.84] 37,000 [10.84] 37,000 [10.84] 37,000 [10.84] EER/SEER 11.3/13 11.3/13 11.3/13 11.3/13...
  • Page 48 GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B036JK08(E/X) B036JK10(E/X) B042CK04 B042CK06 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 37,000 [10.84] 37,000 [10.84] 44,000 [12.89] 44,000 [12.89] EER/SEER 11.3/13 11.3/13 11.2/13 11.2/13...
  • Page 49 GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B042CK08 B042CK10 B042JK04(E/X) B042JK06(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 44,000 [12.89] 44,000 [12.89] 44,000 [12.89] 44,000 [12.89] EER/SEER 11.2/13 11.2/13 11.2/13 11.2/13...
  • Page 50 GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B042JK08(E/X) B042JK10(E/X) B048CK06 B048CK08 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 44,000 [12.89] 44,000 [12.89] 50,000 [14.65] 50,000 [14.65] EER/SEER 11.2/13 11.2/13 11.2/13 11.2/13...
  • Page 51 GENER L D T - RRNL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B048CK10 B048DK10 B048JK06(E/X) B048JK08(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 50,000 [14.65] 50,000 [14.65] 50,000 [14.65] 50,000 [14.65] EER/SEER 11.2/13 11.2/13 11.2/13 11.2/13...
  • Page 52 GENER L D T - RRNL-B MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series B048JK10(E/X) B060CK10 B060JK10(E/X) C060CK10 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 50,000 [14.65] 59,500 [17.43] 59,500 [17.43] 59,500 [17.43] EER/SEER 11.2/13 10.5/13 10.5/13 10.5/13...
  • Page 53 GENER L D T - RRNL-B MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRNL- Series C060DK10 C060JK10(E/X) Cooling Performance Gross Cooling Capacity Btu [kW] 59,500 [17.43] 59,500 [17.43] EER/SEER 10.5/13 10.5/13 Nominal CFM/AHRI Rated CFM [L/s] 2000/1850 [944/873] 2000/1850 [944/873] AHRI Net Cooling Capacity Btu [kW] 57,500 [16.85]...
  • Page 54 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B024JK04(E/X) B024JK06(E/X) B024JK08(E/X) B030JK04(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 24,400 [7.15] 24,400 [7.15] 24,400 [7.15] 29,600 [8.67] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 55 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B030JK06(E/X) B030JK08(E/X) B030JK10(E/X) B036CK04 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 29,600 [8.67] 29,600 [8.67] 29,600 [8.67] 36,800 [10.78] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 56 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B036CK06 B036CK08 B036CK10 B036DK06 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 36,800 [10.78] 36,800 [10.78] 36,800 [10.78] 36,800 [10.78] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 57 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B036DK08 B036DK10 B036JK04(E/X) B036JK06(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 36,800 [10.78] 36,800 [10.78] 36,800 [10.78] 36,800 [10.78] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 58 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B036JK08(E/X) B036JK10(E/X) B042CK04 B042CK06 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 36,800 [10.78] 36,800 [10.78] 44,000 [12.89] 44,000 [12.89] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 59 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B042CK08 B042CK10 B042JK04(E/X) B042JK06(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 44,000 [12.89] 44,000 [12.89] 44,000 [12.89] 44,000 [12.89] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 60 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B042JK08(E/X) B042JK10(E/X) B048CK06 B048CK08 Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 44,000 [12.89] 44,000 [12.89] 50,500 [14.8] 50,500 [14.8] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 61 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B048CK10 B048DK10 B048JK06(E/X) B048JK08(E/X) Cooling Performance Continued -> Gross Cooling Capacity Btu [kW] 50,500 [14.8] 50,500 [14.8] 50,500 [14.8] 50,500 [14.8] EER/SEER 12/14 12/14 12/14 12/14...
  • Page 62 GENER L D T - RRPL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRPL- Series B048JK10(E/X) B060CK10 B060DK10 B060JK10(E/X) Cooling Performance Gross Cooling Capacity Btu [kW] 50,500 [14.8] 59,500 [17.43] 59,500 [17.43] 59,500 [17.43] EER/SEER 12/14 10.8/14 10.8/14 10.8/14 Nominal CFM/AHRI Rated CFM [L/s] 1600/1600 [755/755]...
  • Page 63 GENER L D T - RRRL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] C036CK08 C036CK10 Cooling Performance Con nued -> i l o y t i SEER 13.5/12.4 13.4/12.3 13.4/12.3 13.4/12.3 AHRI Rated CFM (1st / 2nd stage) [L/s] 550/800 [260/378] 800/1200 [378/566] 800/1200 [378/566]...
  • Page 64 GENER L D T - RRRL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Model RRRL- Series C036JK06(E/X) C036JK08(E/X) C036JK10(E/X) C049CK08 Cooling Performance Con nued -> i l o y t i SEER 13.4/12.3 13.4/12.3 13.4/12.3 12.7/11.5 AHRI Rated CFM (1st / 2nd stage) [L/s] 800/1200 [378/566] 800/1200 [378/566] 800/1200 [378/566]...
  • Page 65 GENER L D T - RRRL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Cooling Performance Con nued -> i l o y t i SEER 12.7/11.5 12.7/11.5 12.7/11.5 12/10.7 AHRI Rated CFM (1st / 2nd stage) [L/s] 1050/1600 [495/755] 1050/1600 [495/755] 1050/1600 [495/755] 1250/1850 [590/873]...
  • Page 66 GENER L D T - RRRL- MODELS NOMIN L SIZES 2-5 TONS [7-15.8 kW] Cooling Performance Gross Cooling Capacity (2nd Stage) Btu [kW] 60,500 [17.73] SEER 14.2 12.7/10.7 AHRI Rated CFM (1st / 2nd stage) [L/s] 1250/1850 [590/873] AHRI Net Cooling Capacity (1st / 2nd stage) Btu [kW] 41,800/58,000 [12.25/16.99] Net Sensible Capacity (1st / 2nd stage) Btu [kW] 30,000/42,280 [8.79/12.39]...

  • Page 67: Miscellaneous

    XIII. MISCELL NEOUS ELECTRICAL DATA – RRNL- SERIES B024JK B030JK B036CK B036DK B036JK B042CK B042JK B048CK B048DK Unit Operating 187-253 187-253 187-253 414-506 187-253 187-253 187-253 187-253 414-506 Voltage Range Volts 208/230 208/230 208/230 208/230 208/230 208/230 208/230 Minimum Circuit 19/19 22/22 17/17...
  • Page 68 ELECTRICAL DATA – RRNL- SERIES B048JK B060CK B060JK C060CK C060DK C060JK Unit Operating 187-253 197-253 197-253 197/253 414-506 197-253 Voltage Range Volts 208/230 208/230 208/230 208/230 208/230 Minimum Circuit 34/34 32/32 42/42 32/32 43/43 Ampacity Minimum Overcurrent 35/35 35/35 45/45 40/40 50/50 Protection Device Size...
  • Page 69 ELECTRICAL DATA – RRPL- SERIES B024JK B030JK B036CK B036DK B036JK B042CK B042JK B048CK B048DK Unit Operating 187-253 187-253 187-253 414-506 187-253 187-253 187-253 187-253 414-506 Voltage Range Volts 208/230 208/230 208/230 208/230 208/230 208/230 208/230 Minimum Circuit 21/21 24/24 19/19 27/27 24/24 29/29...
  • Page 70 ELECTRICAL DATA – RRPL- SERIES B048JK B060CK B060DK B060JK Unit Operating 187-253 197-253 414-506 197-253 Voltage Range Volts 208/230 208/230 208/230 Minimum Circuit 36/36 32/32 44/44 Ampacity Minimum Overcurrent 40/40 35/35 45/45 Protection Device Size Maximum Overcurrent 50/50 45/45 60/60 Protection Device Size 208/230 208/230...
  • Page 71 ELECTRICAL DATA – RRRL- SERIES C024JK C036CK C036JK C049CK C049JK C060CK C060JK Unit Operating 197-253 197-253 197-253 197-253 197-253 197-253 197-253 Voltage Range Volts 208/230 208/230 208/230 208/230 208/230 208/230 208/230 Minimum Circuit 18/18 18/18 24/24 22/22 31/31 28/28 40/40 Ampacity Minimum Overcurrent 20/20...

  • Page 72: Airflow Performance Data

    XIV. IRFLOW PERFORM NCE D T INDOOR IRFLOW PERFORM NCE FOR 2-5 TON P CK GE G S ELECTRIC UNITS–RRNL- DIRECT DRIVE...
  • Page 73 INDOOR IRFLOW PERFORM NCE FOR 2-5 TON P CK GE G S ELECTRIC UNITS–RRNL- DIRECT DRIVE...
  • Page 74 INDOOR IRFLOW PERFORM NCE FOR 2-5 TON P CK GE G S ELECTRIC UNITS–RRPL- DIRECT DRIVE...
  • Page 75 INDOOR IRFLOW PERFORM NCE FOR 2-5 TON P CK GE G S ELECTRIC UNITS–RRPL- DIRECT DRIVE...
  • Page 76 INDOOR IRFLOW PERFORM NCE FOR 2-5 TON P CK GE G S ELECTRIC UNITS–RRRL- DIRECT DRIVE...

  • Page 77: Wiring Diagrams

    XV. WIRING DI GR MS FIGURE 35 WIRING DIAGRAM...
  • Page 78 FIGURE 36 WIRING DIAGRAM...
  • Page 79 FIGURE 37 WIRING DIAGRAM...
  • Page 80 FIGURE 38 WIRING DIAGRAM...
  • Page 81 FIGURE 39 WIRING DIAGRAM...
  • Page 82 FIGURE 40 WIRING DIAGRAM...
  • Page 83 FIGURE 41 WIRING DIAGRAM...
  • Page 84 FIGURE 42 WIRING DIAGRAM...
  • Page 85 FIGURE 43 WIRING DIAGRAM...
  • Page 86 FIGURE 44 WIRING DIAGRAM...
  • Page 87 FIGURE 45 WIRING DIAGRAM...

  • Page 88: Charge Charts

    XVI. CH RGE CH RTS FIGURE 46 SYSTEM CHARGE CHARTS (-)RNL/(-)RPL – 2 TON COOLING SYSTEM CHARGE CHART - REFRIGERANT 410A...
  • Page 89 FIGURE 47 SYSTEM CHARGE CHARTS 2 1/2 TON COOLING (-)RNL/(-)RPL – 2 1/2 TON COOLING SYSTEM CHARGE CHART - REFRIGERANT 410A SYSTEM CHARGE CHART - REFRIGERANT 410A Pressure at Suction Service Port (psig) BEFORE FINAL REFRIGERANT CHECK, INDOOR RETURN AIR TEMPERATURE SHOULD BE AT COMFORT CONDITIONS FOR MOST ACCURATE RESULTS.
  • Page 90 FIGURE 48 SYSTEM CHARGE CHARTS (-)RNL/(-)RPL – 3 TON COOLING SYSTEM CHARGE CHART - REFRIGERANT 410A...
  • Page 91 FIGURE 49 SYSTEM CHARGE CHARTS (-)RNL/(-)RPL – 3 1/2 TON COOLING SYSTEM CHARGE CHART - REFRIGERANT 410A...
  • Page 92 FIGURE 50 SYSTEM CHARGE CHARTS (-)RNL/(-)RPL – 4 TON COOLING SYSTEM CHARGE CHART - REFRIGERANT 410A...
  • Page 93 FIGURE 51 SYSTEM CHARGE CHARTS (-)RNL – 5 TON COOLING 5 T O N C O O L I N G S Y S T E M C H A R G E C H A R T R - 4 1 0 A R E F R I G E R A N T P r e s s u r e a t S u c t i o n S e r v i c e P o r t ( p s i g ) INSTRUCTIONS:...
  • Page 94 FIGURE 52 SYSTEM CHARGE CHARTS (-)RPL – 5 TON COOLING 1st (LOW) STAGE CHARGE CHART R-410A REFRIGERANT...
  • Page 95 FIGURE 53 SYSTEM CHARGE CHARTS (-)RPL – 5 TON COOLING 2nd (HIGH) STAGE CHARGE CHART R-410A REFRIGERANT...
  • Page 96 FIGURE 54 SYSTEM CHARGE CHARTS RRRL – 2 TON COOLING 1st (LOW) STAGE CHARGE CHART R-410A REFRIGERANT °...
  • Page 97 FIGURE 55 SYSTEM CHARGE CHARTS RRRL – 2 TON COOLING 2nd (HIGH) STAGE CHARGE CHART R-410A REFRIGERANT °...
  • Page 98 FIGURE 56 SYSTEM CHARGE CHARTS RRRL – 3 TON COOLING 1st (LOW) STAGE CHARGE CHART R-410A REFRIGERANT °...
  • Page 99 FIGURE 57 SYSTEM CHARGE CHARTS RRRL – 3 TON COOLING 2nd (HIGH) STAGE CHARGE CHART R-410A REFRIGERANT °...
  • Page 100 FIGURE 58 SYSTEM CHARGE CHARTS RRRL – 4 TON COOLING 1st (LOW) STAGE CHARGE CHART R-410A REFRIGERANT...
  • Page 101 FIGURE 59 SYSTEM CHARGE CHARTS RRRL – 4 TON COOLING 2nd (HIGH) STAGE CHARGE CHART R-410A REFRIGERANT...
  • Page 102 FIGURE 60 SYSTEM CHARGE CHARTS RRRL – 5 TON COOLING 1st (LOW) STAGE CHARGE CHART R-410A REFRIGERANT...
  • Page 103 FIGURE 61 SYSTEM CHARGE CHARTS RRRL – 5 TON COOLING 2nd (HIGH) STAGE CHARGE CHART R-410A REFRIGERANT...

  • Page 104: Troubleshooting

    XVII. TROUBLESHOOTING XVII. TROUBLESHOOTING COOLING TROUBLE SHOOTING CHART COOLING TROUBLE SHOOTING CHART FIGURE 59 FIGURE 62 WARNING DISCONNECT ALL POWER TO UNIT BEFORE SERVICING. CONTACTOR MAY BREAK ONLY ONE SIDE. FAILURE TO SHUT OFF POWER CAN CAUSE ELECTRICAL SHOCK RESULTING IN PERSONAL INJURY OR DEATH. Unit will not run •...
  • Page 105 FIGURE 63 15 SECOND PREPURGE IS NEGATIVE PRESSURE SYSTEM CLOSED? (BOTH ON 2 STAGE HT) THE SYSTEM WILL ATTEMPT TO LIGHT 3 TIMES (4 TIMES 2 STG HT) WITH A 60 SECOND INTER-PURGE BETWEEN TRIES. IF AFTER THE THIRD TIME THE BURNERS DO NOT LIGHT, THE SYSTEM WILL LOCK OUT.

  • Page 106: Comfort Alert Diagnostic Chart

    XVIII. COMFORT ALERT DIAGNOSTIC CHART XVIII. COMFORT LERT DI GNOSTIC CH RT FIGURE 61 FIGURE 64 SINGLE PHASE UNIT SINGLE PHASE UNIT Status LED Status LED Description Status LED Troubleshooting Information Green “POWER” Module has power Supply voltage is present at module terminals Red “TRIP”...
  • Page 107 FIGURE 65 FIGURE 62 3 PHASE UNIT 3 PHASE UNIT Status LED Status LED Description Status LED Troubleshooting Information Green “POWER” Module has power Supply voltage is present at module terminals Red “TRIP” Thermostat demand signal 1. Compressor internal overload is open Y1 is present, but the 2.
  • Page 108 CM 0314...
