- Page 1 Email:info@motionrc.com Http://www.motionrc.com...
- Page 2 SWIFT OPERATING MANUAL...
- Page 3 WARNING! WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and requires some basic mechanical ability.
-
Page 4: Table Of Contents
Table ofcontents Kit contents The spare parts list Kit Inspection Charging the Flight Battery Low Voltage Cutoff Assemble the plane Install the vertical fin Install the nose cone Install the linkage rods Disassembly Install the battery The receiver connection The placement of the receiver Install the canopy and the rear hatch cover Check the C.G. -
Page 5: Kit Contents
step1 Kit contents Kit contents 1. The integrated wing and fuselage assembly ( front gear, rear skid, elevon servos, ESC, motor, propeller, canopy, motor hatch cover, linkage rod) 2. Vertical stabilizer assembly (stabilizer mounted to the plastic base) 3. Nose cowl 4. -
Page 6: The Spare Parts List
The spare parts list ReplacementpartsfortheROCHobby Delta wing are available using the order numbers in the Spare parts list that follows. The fastest, most economical service can be provided by your hobby dealer or mail-order company. Spare parts list content KB 101 Fuselage (With the motor mount installed) KB 102 Vertical fin (With the mounting base installed) KB 103 Rear hatch cover KB 104 Nose cone... -
Page 7: Kit Inspection
Kit inspection Before starting to build, inspect the parts to make sure they are acceptable quality. If any parts are missing or are not in good shape or acceptable quality, or if you need assistance with setup and assembly, please feel free to contact Motion RC. Please write down the name of the parts when you are reporting defective or missing of them. - Page 8 Charging the Flight Battery Electrical Parameters Parameter Type Unit WorkingVoltage InputPower - 2 0 WorkTemperature ℃ - 2 0 StoreTemperature ℃ 4 . 1 9 4 . 2 0 4 . 2 1 ChargingStopVoltage 1 0 0 0 ChargingCurrent 1 5 0 2 0 0 BalancingCurrent 1 2 0...
- Page 9 step1 Charging the Flight Battery Using Steps: 1. Connect the charger to adapter with enough voltage and wattage, then the Power LED will turn on; 2. Connect 2S/3S battery pack to the corresponding balance port (Do not connect two battery packs at the same time), then the Charge LED will flicker (1Hz) and start charging.
-
Page 10: Low Voltage Cutoff
step2 Low voltage cut off (LVC) WhenaLi-Poisdischarged below 3V per cell, it will not hold a charge. The ESC protects the flight battery from over-discharge using Low Voltage Cutoff. Before the battery charge decreases too much, LVC removes power from motor in two ways: (1) Reduces power - ESC reduces motor power (recommended), (2) Hard cutoff - ESC instantly cuts motor power when the pre-set Low Voltage Protection Threshold value is reached. -
Page 11: Install The Nose Cone
step1 Assemble the plane Install the linkage rods Install the nose cone 1.The nose cone is attached to the 1. Put the Z-bend end of the linkage into fuselage by two powerful magnets. the desired servo control horn hole. Note: Do not glue the nose into place, It is a tight fit and should allow the linkage the crash separable nose design will to move just slightly within the hole to... -
Page 12: Disassembly
step2 Assemble the plane Disassembly 1. The tape band attached to the battery hatch 4. Counter-clockwise thread the bullet to cover will help you remove the cover. disassemble the propeller set. Make sure to tightly grip the propeller root with your hand. Do not use tools to grip the propeller as it will damage the propeller. -
Page 13: Install The Battery
step2 Assemble the plane Install the battery 1. Install the battery into the battery compartment 3. Make sure to locate the battery’s power connector in the front of the airplane. toward the front of the battery hatch. There will be enough space for the connector. -
Page 14: The Placement Of The Receiver
step2 Assemble the plane 2. The power system hatch cover is seated The placement of the receiver fully into place. The ESC and receiver will be installed in the same compartment. Place the ESC on its side so that your receiver will fit in the compartment. Make sure that the ESC and receiver have minimal overlap to allow for proper ESC cooling. -
Page 15: Check The C.g. (Center Of Gravity)
step2 Assemble the plane Check the C.G. (Center of Gravity) Center of Gravity When balancing your model, adjust the motor battery as necessary so the model is level or slightly nose down. This the correct balance point for your model. After the first flights, the CG position can be adjusted for your personal preference. -
Page 16: Get Your Model Ready To Fly
step1 Get your model ready to fly Important ESC information 1. The ESC included with the Swift has a safe start. If the motor battery is connected to the ESC and the throttle stick is not in the low throttle or off position, the motor will not start until the throttle stick is moved to the low throttle or off position. -
Page 17: The Transmitter And Model Setup
step1 Get your model ready to fly The transmitter and model setup Before getting started, bind your receiver with your transmitter. Please refer to your Transmitter Manual for proper operation. CAUTION: To prevent personal injury, DO NOT install the propeller assembly onto the motor shaft while testing the control surfaces . -
Page 18: Check The Control Throws
Note: Secure the clevis with the provided piece of tube after the alignment of the surface is complete. Check the control throws The suggested control throw settings for ROC HOBBY Swift are as follows (Dual rate setting): High Rate Low Rate... -
Page 19: Check The Motor Rotating Direction
step1 Get your model ready to fly Check the motor rotation direction 1. The propeller should rotate clockwise 2. The tooth side of the collar for the when viewing the plane from the rear. propeller adaptor will assist in holding the Note: (1.2) Be sure not to discard the propeller firmly into place. -
Page 20: Before The Model Flying
Before the model flying Find a suitable flying site Find a flying site clear of buildings, trees, power lines and other obstructions. Until you know how much area will be required and have mastered flying your plane in confined spaces, a site at least the size of two to three football fields should be adequate– a flying field specifically for R/C planes is best. -
Page 21: Flying Course
Flying course Take off The Swift delta wing can only take off by the hand launch because of the lack of landing gear. To hand launch the Swift, hold the finger grips on the underside of the airplane. Give a firm throw directly into the wind slightly up (5-10 degrees above the horizon) with the throttle all the way down and the propeller not spinning. -
Page 22: Troubleshooting
Troubleshooting Problem Possible Cause Solution Aircraft will not Lower throttle stick and throttle ESC is not armed. respond to the trim to lowest settings. Throttle channel is reversed. throttle but responds Reverse throttle channel on to other controls. transmitter. Extra propeller noise Damaged spinner, propeller, Replace damaged parts. -
Page 23: Ama
If you are not already a member of the AMA, please join, The AMA is the governing body of model aviation and membership provided liability insurance coverage, protects modelers’ rights and interests and is required to fly at most R/C sites. Academy of Model Aeronautics 5151 East Memorial Drive Muncie, IN 47302-9252... - Page 24 Exceptions: ◆ Free Flight fuses or devices that burn producing smoke and are securely attached to the model aircraft during flight. ◆ Officially designated AMA Air Show Teams (AST) are authorized to use devices and practices as defined within the Team AMA Program Document (AMA Document #718). 3.
